2AI28-AEPJS3ABluetooth Speaker with Magnet and Hook

Klein Tools AEPJS3A is a powered speaker designed to provide high- quality sound for smart phones, tablets, computers, or other audio devices. The AEPJS3A will also charge common mobile devices like cell phones, tablets, headphones, and other smaller USB devices. CONTENTS •AEPJS3A Bluetooth ® Speaker • 39.4" (1000mm) USB-A to USB-C Cable • 23.6" (600mm) 1/8" (3.5 mm) Auxiliary Cable • Instruction Sheet GENERAL SPECIFICATIONS •Dimensions: 5.46" × 5.39" × 2.34" (139 × 137 × 59 mm) •Weight: 1.4 lb. (635g) •Bluetooth ® Version: 4.2 •Bluetooth ® Connection Range: 100 ft. (30 m) in open space •Support Profiles: AD2P, AVRCP, HFP, SPP •Battery Type: Internal, Li-Ion, 3.63V / 5200mAh (18.88Wh) •Battery Life: 20+ hours at 70% volume •Daisy-Chain Range: 30' (9 m) in open space •Operating/Charging Temperature: 32° to 104°F (0° to 40°C) •Storage Temperature: -22° to 140°F (-30° to 60°C) •Relative Humidity: <85% non-condensing •Drop Protection: 6.6' (2 m) •Ingress Protection (IP) Rating: IP54 •Certifications: CE, UKCA, FCC, IC, DOE/CEC, NRCAN, NOM Specifications subject to change. WARNINGS Read, understand, and follow these instructions to ensure safe operation. Failure to observe these warnings can result in risk of fire or electric shock. Keep these instructions for future reference. •DO NOT use the product if it is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or injury. •Risk of fire and burns. DO NOT open, crush, heat above specified maximum temperature or incinerate. Prolonged exposure to direct sunlight can result in elevated temperatures. •DO NOT immerse in water or other liquids. Properly seal the charging port cover to achieve specified water & foreign object ingress protection. Keep seal free of dirt, oil, sand, or other material that interferes with proper sealing. Failure to do so can result in risk of fire or electric shock. •DO NOT open the charging port cover if wet or in a wet environment. Thoroughly dry the unit and the seal around water-resistant cover completely before opening water resistant cover. •DO NOT subject to impacts or drops greater than 6.6' (2 m). Drops larger than this may not show signs of damage, but internal components may have been compromised. It is advisable to replace the unit if any such severe events occur. •DO NOT attempt to repair the product or charging cable. There are no user-serviceable parts. SYMBOLS ON PRODUCT Warning or Caution Strong Magnetic Field Risk of Electrical Shock Read Manual Conforms with particular Code of Federal regulations Energy Efficiency Verified This product has been independently tested by Intertek and meets applicable published standards NOM-NYCE – IFETEL Conformité Européenne: Conforms with European Economic Area directives UKCA - United Kingdom Conformity Assessment Do not place equipment and its accessories in the trash FEATURE DETAILS (FIG.A) 1 Power Button 10 Battery Status Indicator 2 Skip Backward Button 11 Broadcast LED Indicator 3 Play/Pause/Talk Button 12 Nail Hook 4 Skip Forward Button 13 Magnets (×2) 5 Broadcast Button 14 Auxiliary “Aux In” Jack 6 “-“ Volume Down Button 15 USB-A Charge Out Port 7 “+” Volume Up Button 16 USB-C Charge In/Out Port 8 Voice Control Button 17 Water/Dust-Resistant Cover 9 Bluetooth ® LED Indicator OPERATING INSTRUCTIONS CHARGING BATTERY NOTE: Fully charge speaker before use. First-time charge should be at least 4 hours. Connect the USB Type C cable connection to USB-Charging port 16 ; plug the other end of cable to computer or USB-AC adapter or other USB power supply (not included). Charge times will vary: 5V-2.4A Charger - Approx. 3 Hours, 5V-1.0A Charger: Approx. 5 Hours. The battery level indicator will illuminate to indicate charging status (see table below). CHARGING STATUS LED INDICATORS Cascading Not IlluminatedSolid YellowSolid GreenSolid RedBlinking LED Status% Charged Cascading Green Cascading Green Cascading Yellow Cascading Red 0% to 24% charged Cascading Green Cascading Green Cascading Yellow Solid Red 25% to 49% charged Cascading Green Cascading Green Solid Yellow Solid Red 50% to 74% charged Blinking Green Solid Green Solid Yellow Solid Red 75% to 99% charged Solid Green Solid Green Solid Yellow Solid red 100% charged ON/OFF: Press & hold power button 1 for 3 seconds, a tone will sound. Unit will automatically power off after 20 minutes of inactivity. NOTE: Turn unit off when not in use to prolong battery life. PAIRING: Wireless connection activates automatically and is ready to pair when unit is turned on. On your Bluetooth ® wireless compatible device, enable Bluetooth ® and search/scan for devices that can be paired. Select “AEPJS3A” when it appears (refer to the user manual of your device). If necessary, enter “0000” as pairing passcode. A tone sounds after a successful pairing. NOTE: Unit automatically attempts to connect the last paired wireless device but is ready to pair with any compatible device if the last paired device is not detected within 5 seconds of powering on. DISCONNECT CURRENT PAIRING: 1. Turn unit off, -OR- 2. Single-press Power Button 1 . Bluetooth ® LED Indicator 9 will blink, -OR- 3. Plug a cable into AUX jack 14 , -OR- 4. Turn off Bluetooth ® wireless connection in paired device. PAIRING DIFFERENT DEVICES: 1. Single-press Power Button 1 (tone sounds twice) to re-enter pairing mode. 2. Follow instructions in PAIRING section to pair with a different device. RESET WIRELESS CONNECTION: 1. Double-press Power Button 1 (tone sounds once) to to clear the Bluetooth pairing list. 2. Follow instructions in PAIRING section to pair with new devices (a new pairing list will be created). AEPJS3A Bluetooth ® Speaker with Magnet and Hook – Instructions Altavoz Bluetooth ® con imán y gancho – Instrucciones Haut-parleur Bluetooth ® avec aimants et crochet – Instructions ESPAÑOL FRANÇAISENGLISH 1390371 Rev 08/22 F FIG. A TOP / VISTA SUPERIOR / DESSUS BOTTOM / VISTA INFERIOR / DESSOUS 14925 61078 113 BACK…

Text truncated - open the document above for the full version.

Klein Tools Inc. 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Klein Tools Inc. Address: 450 Bond Street Lincolnshire, IL 60069, USA Product Name: Bluetooth Speaker with Magnet and Hook FCC ID: 2AI28-AEPJS3A Model(s): AEPJS3A 2.911(d)(5)(i) EquipmentType We, [Klein Tools Inc.] (“the applicant”) certify that the equipment for which authorization is sought through certification is not: Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules. Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Russ Goldmann II Date: 5/5/2023 Title and Company name: Director, Product Design and Development / Klein Tools Inc. NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Klein Tools Inc. 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Klein Tools Inc. Address: 450 Bond Street Lincolnshire, IL 60069, USA Product Name: Bluetooth Speaker with Magnet and Hook FCC ID: 2AI28-AEPJS3A Model(s): AEPJS3A 2.911(d)(5)(ii) Applicant filing We, [Klein Tools Inc.] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 ,established pursuant to §1.50002 of this chapter,as an entity producing coveredcommunications equipment. Yours sincerely, Name: Russ Goldmann II Date: 5/9/2023 Title and Company name: Director, Product Design and Development / Klein Tools Inc. NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

4 5 0 B o n d S t r e e t • L i n c o l n s h i r e , I L 6 0 0 6 9 • p. 8 4 7 . 8 2 1 . 5 5 0 0 • w w w . K l e i n t o o l s. c o m Section 2.911(d)(7) USA Agent for Service of Process To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Company name: Klein Tools, Inc. Address: 450 Bond St. Lincolnshire, IL 60069 FRN: 0025719949 Product Name: Bluetooth Jobsite Earbuds FCC IDs: 2AI28-AEPJS3A Model(s): AEPJS3A 2.911(d)(7) USA Designated Agent for Service of Process We, [Klein Tools, Inc.] (“the applicant”) designate [ourselves] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent & Applicant Company name: Klein Tools, Inc. Address: 450 Bond St. Lincolnshire, IL 60069, USA Contact Name: Russell Goldmann II Telephone No: 847-821-3305 Email: [email protected] Signature:___________________________ Title: Product Safety Engineering Director Date: NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-communications-supply-chain-through-the May 26, 2023

Letter of Authorization Company: Klein Tools Inc. Address: 450 Bond Street Lincolnshire, IL 60069, USA Product Name: Bluetooth Speaker with Magnet and Hook Model Number: AEPJS3A FCC Identifier: 2AI28-AEPJS3A We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Russell Goldmann II Date: Feb.2, 2023 Title: Director, Product Safety and Compliance Signature of applicant: DocuSign Envelope ID: AFD25686-E9BD-46DF-AE15-0101F727F7AD

Klein Tools Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2023/02/02 Subject; Request for Confidentiality FCC ID:2AI28-AEPJS3A To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Russell Goldmann II Title: Director, Product Safety and Compliance Email: [email protected] DocuSign Envelope ID: AFD25686-E9BD-46DF-AE15-0101F727F7AD

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

k3 L 如 eoaM 川 － tqd um d 川 川 WJ8 刷 m m 刊 阴阳』 EI 萨 ．． 咱－ b 仙酌－ T m b ” 5 机 扭曲． ” IC: 21655-AEPJS3A F C C I D : 2 A 1 2 8 · A E P J S 3 A M o d e l : A E P J S 3 A IFETEL: F@ &&OJ& α巨吕而同情 剧uetoo由1句eakerwith Magnet and”。ok 罚 ； � y � ： � � ： ：旦 旦 ； 8W h ) )r' cs 30851 rn 醉”罩”k ’”睛， 、，·“－

ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 BT ANT Photo 7 Photo 8

FCC ID: 2AI28-AEPJS3A Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BT: Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.402-2.035 0.63-2±1-10.79<50.246223.00YES 2.441 -2.473 0.57-2±1-10.79<50.248213.00YES 2.480 -1.155 0.77-2±1-10.79<50.250183.00YES 2.402-3.598 0.44-4±1-30.50<50.155353.00YES 2.441 -4.484 0.36-4±1-30.50<50.156613.00YES 2.480 -2.718 0.53-2±1-10.79<50.250183.00YES 2.402 -3.086 0.49-3±1-20.63<50.195583.00YES 2.441 -3.991 0.40-3±1-20.63<50.197163.00YES 2.480 -2.14 0.61-3±1-20.63<50.198733.00YES GFSK π/4- DQPSK 8-DQPSK Conclusion: For the max result : 0.25018 ≤ 3.0 for 1g SAR, SAR is not required. Signature: Date: 2023-07-11 NAME AND TITLE (Please print or type): Alex li /Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.

1 Antenna Assessment Report For Bluetooth Project Type: Bluetooth Antenna Product Description 2402.00-2480.00MHz Report Date: 2022.6.12 Report Version: 1.0 Prepared by: SQW Approved by: 2 u目录: Catalogue 1. 研发设备图 R&D equipment diagram 2. 天线外观图 Antenna appearing diagram 3. 天线性能 Antenna performance 3.1.天线SWR Antenna SWR 3.2.天线效率及增益 Antenna efficiency and gain 3.3.天线场型图 Antenna pattern diagram 3 1.研发设备图 R&D equipment diagram 32.0mm 14.2mm 17.8mm | 丁 5.0mm 32.0mm 14.2mm 17.8mm 尸.Omm 2.天线外观图Antenna appearing diagram 5 3. 天线性能 Antenna performance 3.1 天线SWR Antenna SWR 6 3.2 天线效率及增益 Antenna efficiency and gain 7 3.3 天线场型图 Antenna pattern diagram 3D 2D

Report No.: S22092100502001 Version.1.3 Page 1 of 83 RADIO TEST REPORT FCC ID: 2AI28-AEPJS3A Product: Bluetooth Speaker with Magnet and Hook Trade Mark: Klein Tools Model No.: AEPJS3A Family Model: N/A Report No.: S22092100502001 Issue Date: Dec 23. 2022 Prepared for Klein Tools Inc. 450 Bond Street Lincolnshire, IL 60069, USA Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen 518126 P.R. China Tel. 400-800-6106, 0755-2320 0050, 0755-2320 0090 Website: http://www.ntek.org.cn Report No.: S22092100502001 Version.1.3 Page 2 of 83 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ............................................................................................................. 3 2 SUMMARY OF TEST RESULTS .............................................................................................................. 4 3 FACILITIES AND ACCREDITATIONS ..................................................................................................... 5 3.1 FACILITIES ....................................................................................................................................... 5 3.2 LABORATORY ACCREDITATIONS AND LISTINGS ........................................................................ 5 3.3 MEASUREMENT UNCERTAINTY .................................................................................................... 5 4 GENERAL DESCRIPTION OF EUT ........................................................................................................ 6 5 DESCRIPTION OF TEST MODES ........................................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ................................................................................................. 9 6.1 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM .............................................................. 9 6.2 SUPPORT EQUIPMENT ................................................................................................................. 10 6.3 EQUIPMENTS LIST FOR ALL TEST ITEMS ................................................................................... 11 7 TEST REQUIREMENTS ......................................................................................................................... 13 7.1 CONDUCTED EMISSIONS TEST .................................................................................................. 13 7.2 RADIATED SPURIOUS EMISSION ................................................................................................ 16 7.3 NUMBER OF HOPPING CHANNEL ............................................................................................... 25 7.4 HOPPING CHANNEL SEPARATION MEASUREMENT ................................................................. 26 7.5 AVERAGE TIME OF OCCUPANCY (DWELL TIME) ....................................................................... 27 7.6 20DB BANDWIDTH TEST ............................................................................................................... 29 7.7 PEAK OUTPUT POWER ................................................................................................................. 30 7.8 CONDUCTED BAND EDGE MEASUREMENT .............................................................................. 31 7.9 SPURIOUS RF CONDUCTED EMISSION ..................................................................................... 32 7.10 ANTENNA APPLICATION ............................................................................................................... 33 7.11 FREQUENCY HOPPING SYSTEM (FHSS) EQUIPMENT REQUIREMENTS ............................... 34 8 TEST RESULTS ..................................................................................................................................... 35 8.1 DWELL TIME ...................................................................................................................................... 35 8.2 MAXIMUM CONDUCTED OUTPUT POWER ............................................................................................ 40 8.3 OCCUPIED CHANNEL BANDWIDTH ....................................................................................................... 45 8.4 CARRIER FREQUENCIES SEPARATION ................................................................................................. 55 8.5 NUMBER OF HOPPING CHANNEL ......................................................................................................... 60 8.6 BAND EDGE ...................................................................................................................................... 61 8.7 CONDUCTED RF SPURIOUS EMISSION ................................................................................................ 74 Report No.: S22092100502001 Version.1.3 Page 3 of 83 1 TEST RESULT CERTIFICATION Applicant’s name ........................ : Klein Tools Inc. Address ....................................... : 450 Bond Street Lincolnshire, IL 60069, USA Manufacturer's Name ................. : Xingtel Xiamen Group Co., Ltd. Address ....................................... : Xingtel Building,Chuangxin Road, Torch Hi-Tech Industrial District,Xiamen 361006, PR China Product description Product name ............................. : Bluetooth Speaker with Magnet and Hook Model and/or type reference ..... : AEPJS3A Family Model .............................. : N/A Sample number S220921005002 Measurement Procedure Used: APPLICABLE STANDARDS STANDARD/ TEST PROCEDURE TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C ANSI C63.10-2013 Complied This device described above has been tested by Shenzhen NTEK Testing Technology Co., Ltd., and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample ide…

Text truncated - open the document above for the full version.

Radiated Measurement Photos Conducted Measurement Photos
