2AICSS77Bluetooth Connected Shaver

BC Tripleheader shaver S7000 3 1 2 4 5 6 7 89 12 131415 10 11 empty page before TOC English 6 Español 40 English Contents IMPORTANT SAFETY INSTRUCTIONS______________________ 6 General description_________________________________________ 12 Introduction_________________________________________________ 12 What do the icons on my product handle mean?__________ 13 What does the icon on my Quick Clean Pod mean?_______ 15 How do I charge my product?_______________________________ 15 How do I use my product?__________________________________ 17 How do I clean my shaver?_________________________________ 23 How do I use the Quick Clean Pod? (S7783 and S7782 only) _ 27 How do I connect my shaver and smartphone?____________ 30 How do I replace the shaving heads?______________________ 32 Accessories__________________________________________________34 Assistance___________________________________________________ 35 Disposal_____________________________________________________ 35 Full Two-Year Warranty_____________________________________ 35 45-DAY MONEY-BACK GUARANTEE_______________________ 37 Trademarks__________________________________________________38 IMPORTANT SAFETY INSTRUCTIONS When using an electric product, basic precautions should always be followed, including the following: Read all instructions before using this product. DANGER To reduce the risk of electric shock: 6 English - Do not reach for a corded product or charging stand that has fallen into water. Unplug immediately from the power outlet. - Keep the power cord dry. - Do not place or store the product or charging stand where it can fall or be pulled into a tub or sink. Do not place or drop the product or charging stand into water or other liquid. - This product does not work while it is connected to the power outlet. Except when charging, always unplug this product from the power outlet. - Remove power cord from power outlet and product before cleaning. WARNING To reduce the risk of burns, fire, electric shock, or injury to persons: - Close supervision is required when this product is used by, on, or near children, or persons with limited physical, sensory, or mental capabilities or invalids. - Use this product only for its intended household use as described in this manual. Do not use attachments not recommended by Philips North America LLC. - Never operate this product if it has a damaged power cord, if it is not working properly, after it has been dropped or damaged, or after the product or power cord has been dropped into water. For assistance call 1-800-243-3050. - Keep the power cord away from heated surfaces. 7 English - Never drop or insert any object into any opening. - Do not use the power cord in or near a power outlet that contains an electric air freshener to prevent damage to the power cord. - Be careful when handling your smartphone near water and in moist environments. - The shortwave radio frequency signals of a Bluetooth® product may impair the operation of other electronic and medical devices. - Switch off Bluetooth where it is prohibited. - Do not use the product in medical facilities, aircraft, refuelling points, close to automatic doors, automatic fire alarms or other automatically controlled devices. - Keep this product at least 8 inches from pacemakers and other medical devices. Radio waves may impair the operation of pacemakers and other medical devices. - Do not charge or plug in product or charging stand outdoors or operate where aerosol (spray) products are being used or where oxygen is being administered. - Always check shaving heads (caps and cutters) before using the product. Do not use the product if cutters or caps are damaged, as injury may occur. - Always attach power cord to product or charging stand first, then to power outlet. To disconnect, set all controls to 'off' position. Then remove power cord from power outlet. - Plug power cord directly into power outlet. Do not use an extension cord. - Unplug power cord before plugging in or unplugging the product. - Only use the power cord (HQ8505) and other accessories supplied with the product. 8 English - Do not attempt to open the product to remove or replace the built-in rechargeable battery. - The batteries used in this product may present a fire or chemical burn hazard if mistreated. Do not disassemble, heat above 100 °C (212 °F) or incinerate. IMPORTANT: The power plug contains a transformer. Do not cut off the power plug to replace it with another plug as this will cause a hazardous condition. Philips Norelco Quick Clean Pod Cartridge fluid - Do not swallow. - Keep out of reach of children. - In case of eye contact, rinse with plenty of water. Battery safety instructions - Charge, use and store the product at a temperature between 5 °C and 35 °C. - Do not burn products and their batteries and do not expose them to direct sunlight or to high temperatures (e.g. in hot cars or near hot stoves). Batteries may explode if overheated. - If the product becomes abnormally hot, gives off an abnormal smell, changes color or if charging takes much longer than usual, stop using and charging the product and contact your local Philips dealer. - Do not place products and their batteries in microwave ovens or on induction cookers. - When you handle batteries, make sure that your hands, the product and the batteries are dry. - To prevent batteries from heating up or releasing toxic or hazardous substances, do not modify, pierce or damage products and batteries and do not disassemble, short-circuit, overcharge or reverse charge batteries. 9 English - To avoid accidental short-circuiting of batteries after removal, do not let battery terminals come into contact with metal object (e.g. coins, hairpins, rings). Do not wrap batteries in aluminum foil. Tape battery terminals or put batteries in a plastic bag before you discard them. - If batteries are damaged or leaking, avoid contact with the skin or eye. If this occurs, immediately rinse well with water and seek m…

Text truncated - open the document above for the full version.

PHITIPS Date: October 6st, 2020 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de AndalucÍa C/ Severo Ochoa 2 & 6 29590 Campanillas Màlaga, Espafia Ref: Agent letter for FCG lD: 2A|CSS77 We, Philips Consumer Lifestyle 8.V., Tussendiepen 4 9206 AD Drachten, Netherlands hereby authorize DEKRA Testing and CeÉification, S.A.U. Parque Tecnológico de Andalucía Severo Ochoa, 2 & 6 | 29590 | Màlaga, Spain Mr. Alejandro Vega García, e-mail: [email protected], Phone: +34952 6í9 310 to act as our agent in the preparation of this application for equipment certification, including the signing of all documents relating to these matters. The present authorization considers the development of documents on behalf of the client, written under his own letterhead and related to the necessary information to be provided on his behalf to complete the certification process. We also hereby certify that neither we nor any party to this application are subject to a denial of U,S. Federal benefits, which include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by DEKRA Testing and Certification, S.A.U., still resides with us. This agreement expires one year from the current date. Sincerely, & Compliance Engineer : Philips Consumer Lifestyle B.V. : +31 (0) 62142 1691 e-mail: [email protected] FCB01í_02 //DEKM Testing and Certification, S.A.U. // www.dekra-oroduct-safetv.com/wireless

1 External photographs –all models S7731, S7732, S7735, S7782, S7783, S7786, S7787 & S7788. Front viewBack view Right view Left view Top view Bottom view

1100110A4 Page 1 of 1© PHILIPS ELECTRONICS N.V. 2019 Laser inscrip�on CLASS NO. Name: Meenakshi V 4222 021 1418 120-04-22 CHECK SUPERS DATE: 2020-01-14 MV 1 S7783 NOR 18 20 60 5 Scale 200% BATCH_NR /A 15V /5.4W S7783 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS IPX7 PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 BATCH_NR /A 15V /5.4W S7783 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS IPX7 PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 FCC ID: 2AICSS77 FCC ID: 2AICSS77 120-08-20 1100110A4 Page 1 of 1© PHILIPS ELECTRONICS N.V. 2019 CLASS NO. Name: Meenakshi V 4222 021 1419 120-04-22 CHECK SUPERS DATE: 2020-01-14 MV 1 S7782 NOR 18 20 60 5 Scale 200% BATCH_NR /A 15V /5.4W S7782 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 BATCH_NR /A 15V /5.4W S7782 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 IPX7 IPX7 FCC ID: 2AICSS77 FCC ID: 2AICSS77 Laser inscrip�on120-08-20 1100110A4 Page 1 of 1© PHILIPS ELECTRONICS N.V. 2019 CLASS NO. Name: Meenakshi V 4222 021 1420 120-04-22 CHECK SUPERS DATE: 2020-01-14 MV 1 S7786 NOR 18 20 60 5 Scale 200% BATCH_NR /A 15V /5.4W S7786 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 BATCH_NR /A 15V /5.4W S7786 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 IPX7 IPX7 FCC ID: 2AICSS77 FCC ID: 2AICSS77 Laser inscrip�on120-08-20 1100110A4 Page 1 of 1© PHILIPS ELECTRONICS N.V. 2019 CLASS NO. Name: Meenakshi V 4222 021 1421 120-04-22 CHECK SUPERS DATE: 2020-01-14 MV 1 S7788 NOR 18 20 60 5 Scale 200% BATCH_NR /A 15V /5.4W S7788 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 BATCH_NR /A 15V /5.4W S7788 REPLACE WITH SH71 HEADS USE ONLY WITH PHILIPS HQ8505 POWER CORD MADE IN NETHERLANDS PHILIPS NORTH AMERICA LLC FOR QUESTIONS CALL: 1-800-243-3050 IPX7 IPX7 FCC ID: 2AICSS77 FCC ID: 2AICSS77 Laser inscrip�on120-08-20

Internal photographs –all models S7731, S7732, S7735, S7782, S7783, S7786, S7787 & S7788. Top view (w/o rechargeable battery) Bottom view Top view (with rechargeable battery)

Martijn Platzer Quality Assurance Manager Digital InnovationCONFIDENTIAL V 1.5 Aug 2020 Input file Philips new S77xx series Introduction: 2 CL MG shaving Philips shaver, series S79xx with additional App (both iOS and Android) was introduced in March 2019. The complete range comes with Bluetoothand can be connected with the GroomTribe App. The new range of S77xx series is planned as replacement of S79xx series in order to follow market trend and needs of shaving features. The Bluetooth function stays as same as S79xx series. The market introduction timing is scheduled in early 2021. S77xx series model number description The third character (X) is a number from 0 -9 that indicate project code within S77xx series. For this new 7000 range a unique code has been granted for this release: 8. In case of an after launch update (Mid Life Update), this number will increase + 1 to ‘9’. The fourth character (X) is a number from 0 -9 that indicates the body color. S77xx Note: All S77xx models are electrically identical. User Interface specification Note: All S77xx models are electrically identical: only colors or finishing can differ). User Interface specification 5 CL MG shaving S77xx Specifications Shaver handle Outer dimensions (mm) 155.38 49.79 44.10 Photo’s 7 CL MG shaving 8 S77xx series 6-face view (External photo) Front viewBack view Right view Left view Top view Bottom view Internalphoto’s Internalphoto’s(2) 10 CL MG shaving Exploded View 11 Front panel Poseidon Back shell Poseidon 2K Chest Poseidon Back chest Poseidon Trimmer housing Poseidon Trimmer knob Poseidon Design Panels S77xx series 12 CL MG shaving PCB Both sides Top view (w/o rechargeable battery) Bottom view Top view (with rechargeable battery) Specification Adapter SalomSSW-2600US0-2-1M3B2P 15V 5W4 type Specification Battery Product category:Lithium-Ion rechargeable Battery Nominal capacity: 715mAh Supply Voltage:3,6 V (DC) ModelNameSupplier L1450-0.75Lithplus(Suppo) HP14500CYHigh Power Connected Shaver S77xx series Bluetooth Block Diagram Voltage fluctuation: DC3.0 –4.14V Rated voltage: DC3.6V U250: CY8C4248LQI- BL583 Antenna System controller integrated Bluetooth Low Energy (support BLE4.2) Rechargeable battery Operating frequency range: 2402 –2480 MHz B010: L1450-0.75 or HP14500CY SSW-2600 External AC adapter DC15V Specifications Antenna Sunlord-SLDA31-2R400G-S2TF Antenna Antenna Location of RF radio and Antenna & restriction to access products internals. RF radio: (CY8C4248LQI-BL583) Restriction to access products internal: RF (Bluetooth Low Energy) radio is integrated in the system controller which is a surface mount chip and soldered on the PCB, therefore it is unable to access to the RF part. Antenna Radiationpattern Technical specification •Modulation mode：GFSK •Main function：Data Transmission •Adaptive: Non-adaptive equipment •Frequency range：2402-2480 MHz •Occupied band width：1MHz •Number of channels: 40 (channel spacing: 2 MHz) •Bluetooth version: BLE 4.2(Single mode) •Operation mode: One internal antenna •Output Power: Class 2 •Rated voltage：DC15V (output adapter, input shaver) •Rated input power：1.7W •NominalsupplyvoltagetoRFmodule:DC3.0V •TypeofpowersourcetoRFmodule: DCvoltagefrombuilt-inrechargeablebattery •RFoutputpower：≤10dBm(EIRP) •Antennagain：2.5dBi(max)0,5dBi(average) •Cableloss:1.0dBi Bluetooth listing and technical info Current design is qualified Q1 2020 at BT SIG (via Dekra). Bluetooth controllers layers (Low Energy): •RF-PHY •LL •HCI Bluetooth hostlayers: •L2CA (LE) •GAP (LE) •GATT/ATT •SM Bluetooth profilelayers: •BAS •DIS Previous designs in same range are already listed at BT SIG: S79xx Qualified Design ID (QDID): 62887, 63199 Sunlord Specifications for Chip Antenna Page 1 of 8 Preliminary [ New Released, Revised] SPEC No.: SLDA01170000 Shenzhen Sunlord Electronics Co., Ltd. Customer Product Name Chip Antenna Sunlord Part Number SLDA31-2R400G-S2TF Customer Part Number Approved By Checked By Issued By 【For Customer approval Only】 Date: Qualification Status: Full Restricted Rejected Approved By Verified By Re-checked By Checked By Comments: 【This SPEC is total 8 pages including specifications and appendix.】 【ROHS Compliant Parts】 Address: Sunlord Industrial Park, Dafuyuan Industrial Zone, Baoan, Shenzhen, China 518110 Tel: 0086-755-29832660 Fax: 0086-755-82269029 E-Mail: [email protected] SPECIFICATIONS Sunlord Specifications for Chip Antenna Page 2 of 8 【Version change history】 Rev. Effective Date Changed Contents Change reasons Approved By 01 / New Release / Hai Guo Sunlord Specifications for Chip Antenna Page 3 of 8 1. Scope This specification applies to SLDA31-2R400G-S2TF of Multi-layer Chip Antenna. 2. Product Description and Identification (Part Number) 1) Description :Multi-layer Chip Antenna 2) Product Identification (Part Number) SLDA 31 -2R400G -S2 T F ① ② ③ ④ ⑤⑥ 3. Electrical Characteristics Band Width Peak Gain Average Gain VSWR Impedance Power Capacity Part Number MHz In BW Ω W SLDA31-2R400G-S2TF ≥100 2.5 dBi @( XZ-total) 0.5 dBi @( XZ-total) < 2 50 2 W max 1) Operating and storage temperature range (individual chip without packing): -40 ~ +85°C°C. 2) Storage temperature range (packaging conditions): -10 ~ +40 and RH 70% (Max.).°C°C 3) Test equipment: Network Analyzer: E5071C. 4) Measuring diagram. 4. Shape and Dimensions Dimensions and recommended PCB pattern for reflow soldering: A B D C (1) (2) Unit: mm Item A B C D. SLDA31 3.2±0.21.6±0.20.5±0.10.5±0.2 ① Type SLDA Multilayer Chip Antenna ④ Series Code S2 ② External Dimensions (L×W) (mm) 31 3.2×1.6 ③ Center Frequency 2R400G 2400.0MHz ⑤ Packing T Tape Carrier Package ⑥ Hazardous Substance Free Products F Sunlord Specifications for Chip Antenna Page 4 of 8 Demo‐board: To p view Detail view Bottom view 1) Terminal Configuration: 5. Test and Measurement Procedures 5.1 Test Conditions No. Terminal Name No. Terminal Name (1) Feeding Point (2) Soldering terminal (2) (1) 50Ω trace GND via Unit: mm Sunlord Specifications for Chip Antenna Page …

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862RAN.001 2020-08-25 Test report No: NIE: 64862RAN.001 Assessment report RF EXPOSURE REPORT ACCORDING TO FCC 47 CFR Part 2.1093 ISED RSS -102 Issue 5:2015 (*) Identification of item under evaluation Bluetooth Connected Shaver (*) Trademark Philips (*) Model and /or type reference Series 7000 Tested model: S7783 Similar models not tested: S7731, S7732, S7735, S7782, S7786, S7787 & S7788. Other identification of the product HW version: 1.0 SW version: 1270 FCC ID: 2AICSS77 ISED IC: 21912-S77 (*) Features Bluetooth 4.2 Manufacturer PHILIPS Oliemolenstraat 5, 9203 ZN Drachten, the Netherlands. Test method requested, standard FCC 47 CFR Part 2.1093. Radiofrequency radiation exposure evaluation: portable devices. ISED RSS-102 Issue 5 (2015-03) – Radio Frequency Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Summary IN COMPLIANCE Approved by (name / position & signature) Miguel Lacave Antennas Lab Manager Date of issue 2020-08-25 Report template No FAN24_02 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862RAN.001 Page 2 of 12 2020-08-25 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Data provided by the client .......................................................................................................... 3 Identification of the client............................................................................................................. 5 Document history ........................................................................................................................ 5 General description of the device under evaluation ..................................................................... 6 Assessment summary ................................................................................................................. 6 Evaluation Results ...................................................................................................................... 7 Appendix A: FCC RF Exposure information ................................................................................ 8 FCC SAR test exclusion considerations for portable devices ................................................. 9 Appendix B: ISED RF Exposure information ............................................................................. 11 ISED SAR test exclusion considerations .............................................................................. 12 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862RAN.001 Page 3 of 12 2020-08-25 Competences and guarantees In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification, S.A.U. has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification, S.A.U. guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification, S.A.U. at the time of performance of the test. DEKRA Testing and Certification, S.A.U. is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Assessment Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification, S.A.U. General conditions 1. This report is only referred to the item that has undergone the assessment. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification, S.A.U. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification, S.A.U. and the Accreditation Bodies Data provided by the client The following data has been provided by the client: 1. Information relating to the description of the sample ("Identification of the item tested", "Trademark", "Model and/or type reference tested" and “General description of the device under evaluation”). 2. Maximum antenna gain and use distance information. 3. Derived models not tested: S7731, S7732, S7735, S7782, S7786, S7787 & S7788. These models have been declared by the supplier as equivalent, as shown in the following form: DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862RAN.001 Page 4 of 12 2020-08-25 DEKRA Testing and Certification S.A.U. declines any responsibility with respect to the information provided by the client and that may affect the validity of results. DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862RAN.001 Page 5 of 12 202…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862REM.001 2020-06-19 Test report No: NIE: 64862REM.001 Test report FCC Rules and Regulations CFR 47, Part 15, Subpart B (10-1-19 Edition) & ICES-003 Issue 6 (January 2016, Updated April 2019) (*) Identification of item tested Bluetooth Connected Shaver (*) Trademark Philips (*) Model and /or type reference Series 7000 Tested model: S7783 Similar models not tested: S7731, S7732, S7735, S7782, S7786, S7787 & S7788. Other identification of the product HW version: 1.0 SW version: 1270 FCC ID: 2AICSS77 ISED IC: 21912-S77 (*) Features Bluetooth 4.2 Manufacturer PHILIPS Oliemolenstraat 5, 9203 ZN Drachten, the Netherlands. Test method requested, standard FCC CFR 47, Part 15, Subpart B (10-1-19 Edition) & ICES-003 (Updated 04-2019) Summary IN COMPLIANCE Approved by (name / position & signature) Rafael López Martín EMC Consumer & RF Lab. Manager Date of issue 2020-06-19 Report template No FDT08_22 (*) “Data provided by the client” DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862REM.001 Page 2 of 25 2020-06-19 Index Competences and guarantees .................................................................................................... 3 General conditions ...................................................................................................................... 3 Uncertainty ................................................................................................................................. 3 Data provided by the client .......................................................................................................... 4 Usage of samples ....................................................................................................................... 6 Test sample description .............................................................................................................. 6 Identification of the client............................................................................................................. 8 Testing period and place ............................................................................................................. 8 Document history ........................................................................................................................ 8 List of equipment used during the test......................................................................................... 9 Environmental conditions .......................................................................................................... 10 Remarks and comments ........................................................................................................... 11 Testing verdicts ......................................................................................................................... 11 Summary .................................................................................................................................. 11 Appendix A: Test results ........................................................................................................... 12 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862REM.001 Page 3 of 25 2020-06-19 Competences and guarantees DEKRA Testing and Certification is a testing laboratory accredited by the National Accreditation Body (ENAC - Entidad Nacional de Acreditación), to perform the tests indicated in the Certificate No. 51/LE 147. DEKRA Testing and Certification is a FCC recognized accredited testing laboratory with appropriate scope of accreditation that include testing performed in this test report, FCC designation number ES0004. In order to assure the traceability to other national and international laboratories, DEKRA Testing and Certification has a calibration and maintenance program for its measurement equipment. DEKRA Testing and Certification guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at DEKRA Testing and Certification at the time of performance of the test. DEKRA Testing and Certification is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No parts of this report may be reproduced or quoted out of context, in any form or by any means, except in full, without the previous written permission of DEKRA Testing and Certification. General conditions 1. This report is only referred to the item that has undergone the test. 2. This report does not constitute or imply on its own an approval of the product by the Certification Bodies or competent Authorities. 3. This document is only valid if complete; no partial reproduction can be made without previous written permission of DEKRA Testing and Certification. 4. This test report cannot be used partially or in full for publicity and/or promotional purposes without previous written permission of DEKRA Testing and Certification and the Accreditation Bodies. Uncertainty Uncertainty (factor k=2) was calculated according to the DEKRA Testing and Certification internal document PODT000. The total uncertainty of the measurement system for the measured conducted disturbance characteristics of EUT from 150kHz to 30 MHz is I = ± 3,9 dB for quasi-peak measurements, I = ± 3,2 dB for a…

Text truncated - open the document above for the full version.

DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España C.I.F. A29 507 456 Report No: (NIE) 64862RRF.001 2020-08-26 Test report No: NIE: 64862RRF.001 Test Report USA FCC Part 15.247, 15.209 CANADA RSS-247, RSS-Gen Radio Frequency Devices. Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices. General Requirements and Information for the Certification of Radio Apparatus. (*) Identification of item tested Bluetooth Connected Shaver (*) Trademark Philips (*) Model and /or type reference Series 7000 Tested model: S7786 Derived models not tested: S7731, S7732, S7735, S7782, S7783, S7787 & S7788. Other identification of the product HW version: 1.0 SW version: 1270 FCC ID: 2AICSS77 ISED IC: 21912-S77 (*) Features Bluetooth 4.2 Applicant PHILIPS CONSUMER LIFESTYLE BV Oliemolenstraat 5, 9203 ZN Drachten, the Netherlands Test method requested, standard USA FCC Part 15.247 (10-1-19 Edition): Operation within the bands 902 - 928 MHz, 2400 -2483.5 MHz, and 5725 - 5850 MHz. USA FCC Part 15.209 (10-1-19 Edition): Radiated emission limits; general requirements. CANADA RSS-247 Issue 2 (February 2017). CANADA RSS-Gen Issue 5 Amendment 1(March 2019). Guidance for Performing Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid Systems Devices Operating Under Section 15.247 of the FCC Rules. 558074 D01 Meas Guida…

Text truncated - open the document above for the full version.
