2AIDL-SS-FTWI600Wireless charger

Model: FTW600 User Manual Product introduction: Function and Description: 1. How to connect: a. For the first time using, take out the earphones and they will turn on automatically. Open the Bluetooth function of smart phone, search the Bluetooth name of “FISHER‐FTW600” to pair and connect. Then you can listen to music or calling. b. For the second time using, the earphones will connect to each other and your phone automatically. If the earphone doesn’t connect with any device in 5 minutes, it will power off automatically. Note:If you want to use single earphone, any one earphone will work separately. 2. How to Disconnect: Put earphones into charging case, they will be disconnected automatically and start charging. Or you can press charging case button to start charging. 3. How to use: On Music: a. Press right earphone three times to play next song. b.Press left earphone three times to play previous song. c. One press on left or right earphone to play or pause the song. d. Press right earphone about1.5S to increase volume, Press left earphone about 1.5S to decrease volume. (Not support for some of phone software versions) . On Call: a. One press to answer the call and then one click to hang‐up the call. b. Long press to reject the incoming call. Google & Siri : Doublepress left or right earphone to activate Google or Siri then one press to quit. 4. How to charge: Charging for earphone: Put the earphone into charging case, they will be charged automatically. When the charging case battery is low, connect the type C cable to charge, the led light will be red and flash quickly. When the case is fully charged, the red LED light will stop flash. When the charging cable is unplugged, the red light will change to blue. Charging for charging case via cable: 1) Use included cable to charge earphone. 2) Recommend to charge with 1A – 2A charger. Charging for charging case via wireless charger: 3) Use included cable to power wireless charger. 4) Recommend to charge with 1A – 2A charger. 5) Put the charging case onto the wireless charger to charge. When charging, the indicator light will flash red; when the case is fully charged, the indicator light will stop flashing and keep red. 5. Package Includes: a) True wireless earphones b) Wireless charger c) Case cover d) Pair of Silicone wings e) Neck strap f) Carabiner g) 1 USB cable h) User manual i) Warranty card Product specification 1. Earphone specification: Earphone battery capacity 40mAh Bluetooth version: 5.0 Transmission distance 33ft Frequency 20‐20KHZ Earbuds working time: Up to 6hours of playtime with case Charging time About 40min‐1.5 hours 2. Charging box parameter Battery of Charging box 230mAh Charging time About 40min‐1.5 hours DC charging voltage DC 5V (Note: Battery life & charging time may vary based on usage & types of devices used.) 3. Wireless charger specification Output power 5W Input DC 5V,2A Output DC 5V,1A FCC‐ID: TRUE WIRELESS EARPHONES FCC ID :2AIDL‐SS‐FTW600 Charging compartment FCC ID :2AIDL‐SS‐FTW600C Wireless charger FCC ID :2AIDL‐SS‐FTWI600 FCC WARNING: This device complies with Part 15of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15& part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipmentgeneratesuses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help NOTE: This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. RF exposure （TRUE WIRELESS EARPHONES）: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. RF exposure （Charging compartment&Wireless charger）: This equipment must be installed and operated with a minimum distance of 15 cm between the radiator and user body. Matters needing attention 1. Please confirm if your device supports wireless charging function, otherwise it will not be charged. 2. Please do not place magnetic objects such as metal/magnetic discs/credit cards on the wireless charger, as this may result in inability to charge. 3. Do not use this product in high temperature and humid environments to avoid malfunctions, damage, or leakage. 4. Do not splash water or other liquids onto the wireless charger. If cleaning is required, please make sure to disconnect the power supply. Migear International Group LLC, 21 W 38th Street, 14th Floor, NY, NY 10018 USA TEL: 929‐390‐4504

Migear International Group LLC 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – EquipmentType Company name: Migear International Group LLC Address: 21 West 38th Street, 14th Floor. New York, 10018, United States Product Name: Wireless charger FCCID: 2AIDL-SS-FTWI600 Model(s): FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 2.911(d)(5)(i) EquipmentType We, [Migear International Group LLC] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: David Betesh Date: May 25, 2023 Title: Manager Company name: Migear International Group LLC Signature: NOTE 1 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Migear International Group LLC 2.911 (d)(5)(ii) Applicant Attestation v1.3 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: Migear International Group LLC Address: 21 West 38th Street, 14th Floor. New York, 10018, United States Product Name: Wireless charger FCCID: 2AIDL-SS-FTWI600 Model(s): FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 2.911(d)(5)(ii) Applicant filing We, [Migear International Group LLC] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2 , established pursuant to §1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Name: David Betesh Date: May 25, 2023 Title: Manager Company name: Migear International Group LLC Signature: NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List ”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Migear International Group LLC 2.911 (d)(7)USA Agentv1.3 Section 2.911(d)(7) USA Agent for Service of Process Company name: Migear International Group LLC Address: 21 West 38th Street, 14th Floor. New York, 10018, United States Product Name: Wireless charger FCCID: 2AIDL-SS-FTWI600 Model(s): FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 2.911(d)(7) USA Designated Agent for Service of Process We, [Migear International Group LLC] (“the applicant”) designate [Migear International Group LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email addressfor no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Migear International Group LLC Address: 21 West 38th Street, 14th Floor. New York, 10018, United States FCC Registration Number (FRN): 0025568379 Contact Name: David Betesh Telephone No: 646-680-6786 Email: [email protected] Applicant Company name: Migear International Group LLC Address: 21 West 38th Street, 14th Floor. New York, 10018, United States FCC Grantee Code: 2AIDL Contact Name: David Betesh Telephone No: 646-680-6786 Email: [email protected] Migear International Group LLC 2.911 (d)(7)USA Agentv1.3 Signature: Title: Manager Signature: Title: Manager Date: May 25, 2023 Date: May 25, 2023 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference;Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Migear International Group LLC Agent Authorization Company: Migear International Group LLC Address: 21 West 38th Street, 14th Floor.New York, New York, 10018, United States Product Name: Wireless charger Model Number(s): FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 Product Description: Wireless charger We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: May 25, 2023 Name: David Betesh Title: Manager Company: Migear International Group LLC

Migear International Group LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 25, 2023 Subject; Request for Confidentiality FCC ID: 2AIDL-SS-FTWI600 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: David Betesh Title: Manager

Migear International Group LLC Model Difference Declaration To Whom It May Concern, We, Migear International Group LLC (Wireless charger) ; Model Number: FTWI600, FTW600, SS- WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206; All model’s the function, software and electric circuit are the same, only with product model named different. Test sample model: FTWI600. Please contact me if you have any question. Signature: Date: May 25, 2023 Name: David Betesh Title: Manager

Annex A External Photos Report No.: HK2304251635-1E/2E Page 1 of 4 Report No.:HK2304251635-1E/2E Page 2 of 4 Report No.:HK2304251635-1E/2E Page 3 of 4 Report No.:HK2304251635-1E/2E Page 4 of 4

FCC ID LABEL: Ca. 30mm x 30mm label location FCC ID: 2AIDL-SS-FTWI600

Annex B Internal Photos Report No.:HK2304251635-1E/2E Page 1 of 2 Antenna Report No.:HK2304251635-1E/2E Page 2 of 2

Page 1 of 11 Report No.: HK2304251635-2E FCC Test Report Test Report On Behalf of Migear International Group LLC For Wireless charger Model No.: FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 FCC ID: 2AIDL-SS-FTWI600 Prepared For: Migear International Group LLC 21 West 38th Street, 14th Floor. New York, 10018, United States Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Apr. 25, 2023 ~ May 05, 2023 Date of Report: May 05, 2023 Report Number: HK2304251635-2E Page 2 of 11 Report No.: HK2304251635-2E Test Result Certification Applicant’s Name ................. : Migear International Group LLC Address.................................. : 21 West 38th Street, 14th Floor. New York, 10018, United States Manufacture's Name ............ : SKY SINCERITY INTERNANTIONAL CO.,LTD Address.................................. : Flat C, 9/F Winning House, No.72-74 Wing Lok Street, Hong Kong Production plant Name ....... : YICHUN SANYANG ELECTRONICS CO., LTD Address.................................. : Sanyang Town, Yuanzhou District, Yichun City, Jiangxi, China Product Description Trade Mark ................................ : 2BOOM, FISHER Product Name ........................... : Wireless charger Model and/or Type Reference: FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 Standards ............................. : FCC CFR 47 PART 18, KDB 680106 D01 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of Performance of Tests ............ : Apr. 25, 2023 ~ May 05, 2023 Date of Issue ........................................... : May 05, 2023 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 11 Report No.: HK2304251635-2E Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications or the User's Manual. 2. Channel List Channel Frequency (KHz) Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 01 120 The EUT antenna is Coil Antenna. No antenna other than that furnished by the responsible party shall be used with the device. 2. Summary of Test Results 2.1. Test procedures according to the technical standards: FCC KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 FCC CFR 47 Standard Section Test Item Judgment Remark FCC CFR 47 part1, 1.1310 KDB 680106 D01v03r01 (3)(3) Electric Field Strength (E) (V/m) PASS Magnetic Field Strength (H) (A/m) PASS 2.2. Measurement Uncertainty The reported uncertainty of measurement y ±U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 All Emissions, Radiated(<30M)(9KHz-30MHz) ±3.90dB 2 Temperature ±0.5°C 3 Humidity ±2% Page 4 of 11 Report No.: HK2304251635-2E 2.3. Test Instruments Description Brand Model No.S/N Calibrated Date Calibrated Until Exposure Level Te s t e r narda ELT-400 N-0231 Feb. 17, 2023 Feb. 16, 2024 Magnetic field probe 100cm 2 narda NBM-520B-0324 Feb. 17, 2023 Feb. 16, 2024 NOTE: 1. The calibration interval of the above test instruments is 12 months. Page 5 of 11 Report No.: HK2304251635-2E 3. Maximum Permissible Exposure Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180 / f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1 30 Note 1: f = frequency in MHz; *Plane-wave equivalent power density. Note 2: For the applicable limit, see FCC 1.1310, 680106 D01 RF Exposure Wireless Charging Apps v03. Note 3: Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. Page 6 of 11 Report No.: HK2304251635-2E 4. Test Procedure a. For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of (H-field & E- field strengths for all sides is 15cm, H-field strengths of top side is 20cm). E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. 4.1 Test Setup 4.2 Result of Maximum Permissible Exposure Page 7 of 11 Report No.: HK2304251635-2E All test modes are tested, and the report shows only the worst mode: ANT：5W For Full load: H-Field Strength at 15 cm (E top side: 20cm) from the edges surrounding the EUT (A/m) Field strength Test Position A Test Position B Test Position C Test Position D Test Position E Limits (A/m) uT 0.193 0.226 0.254 0.243 0.238 / A/m 0.154 0.181 0.203 0.194 0.1…

Text truncated - open the document above for the full version.

Page 1 of 21 Report No.: HK2304251635-1E FCC Test Report Test Report On Behalf of Migear International Group LLC For Wireless charger Model No.: FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 FCC ID: 2AIDL-SS-FTWI600 Prepared For: Migear International Group LLC 21 West 38th Street, 14th Floor. New York, 10018, United States Prepared By: Shenzhen HUAK Testing Technology Co., Ltd. 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Date of Test: Apr. 25, 2023 ~ May 05, 2023 Date of Report: May 05, 2023 Report Number: HK2304251635-1E Page 2 of 21 Report No.: HK2304251635-1E Test Result Certification Applicant’s Name ................. : Migear International Group LLC Address.................................. : 21 West 38th Street, 14th Floor. New York, 10018, United States Manufacture's Name ............ : SKY SINCERITY INTERNANTIONAL CO.,LTD Address.................................. : Flat C, 9/F Winning House, No.72-74 Wing Lok Street, Hong Kong Product Description Trade Mark ................................ : 2BOOM, FISHER Product Name ........................... : Wireless charger Model and/or Type Reference: FTWI600, FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 Standards ............................. : FCC CFR 47 PART 18 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen HUAK Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen HUAK Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Date of Test ............................................ : Date (s) of Performance of Tests ............ : Apr. 25, 2023 ~ May 05, 2023 Date of Issue ........................................... : May 05, 2023 Test Result ............................................... : Pass Testing Engineer : (Gary Qian) Technical Manager : (Eden Hu) Authorized Signatory : (Jason Zhou) Page 3 of 21 Report No.: HK2304251635-1E Table of Contents Page 1 . Test Summary 5 1.1 . Test Procedures and Results 5 1.2 . Information of the Test Laboratory 5 1.3 . Measurement Uncertainty 5 2. General Information 6 2.1. General Description of EUT 6 2.2. Carrier Frequency of Channels 7 2.3. Operation of EUT during Testing 7 2.4. Description of Test Setup 8 2.5. Measurement Instruments List 9 3. Conducted Emission Test 10 3.1. Block Diagram of Test Setup 10 3.2. Conducted Power Line Emission Limit 10 3.3. Test Procedure 10 3.4. Test Result 11 4. Radiated Emissions 13 4.1. Block Diagram of Test Setup 13 4.2. Rules and Specifications 14 4.3. Test Procedure 14 4.4. Test Result 14 5. Antenna Requirement 18 6. Photograph of Test 19 7. Photos of the EUT 21 Page 4 of 21 Report No.: HK2304251635-1E ** Modified History ** Revision Description Issued Data Remark Revision 1.0 Initial Test Report Release May 05, 2023 Jason Zhou Page 5 of 21 Report No.: HK2304251635-1E 1. Test Summary 1.1. Test Procedures and Results Description of Test Section Number Result Conducted Emissions Test 18.307 COMPLIANT Radiated Emission Test 18.305 COMPLIANT Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. 1.2. Information of the Test Laboratory Shenzhen HUAK Testing Technology Co., Ltd. Add.: 1-2/F., Building B2, Junfeng Zhongcheng Zhizao Innovation Park, Heping, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Testing Laboratory Authorization： A2LA Accreditation Code is 4781.01. FCC Designation Number is CN1229. Canada IC CAB identifier is CN0045. CNAS Registration Number is L9589. 1.3. Measurement Uncertainty Measurement Uncertainty Conducted Emission Expanded Uncertainty =2.71dB, k=2 Radiated emission expanded uncertainty(9kHz-30MHz) = 3.90dB, k=2 Radiated emission expanded uncertainty(30MHz-1000MHz)= 3.90dB, k=2 Radiated emission expanded uncertainty(Above 1GHz) = 4.28dB, k=2 Page 6 of 21 Report No.: HK2304251635-1E 2. General Information 2.1. General Description of EUT Production plant Name: YICHUN SANYANG ELECTRONICS CO., LTD Address: Sanyang Town, Yuanzhou District, Yichun City, Jiangxi, China Equipment: Wireless charger Model Name: FTWI600 Series Models: FTW600, SS-WC001, SS-WC002, SS-WC003, SS-WC004, SS-WC006, FWI206 Model Difference: All model's the function, software and electric circuit are the same, only with product model named different. Test sample model: FTWI600. Trade Mark: 2BOOM, FISHER FCC ID: 2AIDL-SS-FTWI600 Antenna Type: Coil Antenna Antenna Gain: 0dBi Operation Frequency: 112KHz~205KHz Test Frequency: 120KHz Number of Channels: 1 Modulation Type: ASK Power Source: Input: 5V, 2A Output: 5V, 1A Output Power: 5W Power Rating: Input: 5V, 2A Output: 5V, 1A Output Power: 5W Page 7 of 21 Report No.: HK2304251635-1E 2.2. Carrier Frequency of Channels Operation Frequency each of channel Channel Frequency 1 120KHz 2.3. Operation of EUT during Testing Operating Mode The mode is used: Transmitting mode Page 8 of 21 Report No.: HK2304251635-1E 2.4. Description of Test Setup Operation of EUT during Testing: AC Plug Adapter information Model: HW-100225C00 Input: AC100-240V, 50/60Hz, 0.75A Output: DC5V/2A, 9V/2A, 10V/2.25A MAX The sample was placed (0.8m (30MHz~1GHz), 0.8m (9KHz~30MHz)) above the ground plane of 3m chamber. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigated all operating modes, rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in bot…

Text truncated - open the document above for the full version.

Report No.: HK2304251635-1E/2E Radiated Emissions Report No.: HK2304251635-1E/2E Conducted Emission
