QUICK START GUIDE https://minidv.com/m3/guide Minidv APPManual Tutorials Scan the QR code to view tutorials and download the app 01 Download the APP for instructions and tutorials Getting to know the parts Lens Touchscreen Charging indicator / Status indicator Lanyard hole 1 Microphone 1 Speaker Power button Wi-Fi button TF USB Lanyard hole 2 Microphone 2 TF Card slot Reset button USB Type-C port 1/4 Nut interface 02 Shutter Button Please use a 5V2A power adapter to charge the camera Charging the camera 03 Insert TF card 04 Please insert the TF card with the gold finger toward the lens side. Power Button Power on / Power off. 05 Tap to turn on Press and hold for 3 seconds to turn off Wi-Fi ON/OFF 06 Wi-Fi Button In standby, tap the Wi-Fi button to turnon Wi-Fi, Tap the Wi-Fi button again to turn off Wi-Fi. Shutter Button Shutter Button 07 Playback Pause OK Back This button is a multi-function button and also has the following button functions Wi-Fi can also be turned on and off in the settings menu Once the Wi-Fi is on, scan the QR code with the minidv App to connect to the camera. You can also manually Þnd the camera Wi-Fi hotspot with SSID minidv_****, The password is 12345678 to connect to the camera manually. WiFi status Microphone state State of charge Memory card status Parameter settings Date Time Remaining shootable time Playback Mode Resolution/frame rate Touchscreen operation 08 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10 Swipe left or right to select the appropriate shooting mode, then tap to enter and slide down to back to standby. VIDEOTIME-LAPSESLOW-MOPHOTO In standby, swipe down from the top of the screen to access mode switching for VIDEO, TIME-LAPSE, SLOW-MO, and PHOTO. Video TIME-LAPSE 2 VIDEO In video standby, swipe from the right to the left of the screen to enter the video parameter settings. 1 In TIME-LAPSE standby, swipe from the right to the left of the screen to enter the TIME-LAPSE parameter settings. Swipe left or right to select a parameter, slide down from top to bottom to exit the parameter setting PHOTO 4 SLO-MO In SLO-MO standby, swipe from the right to the left of the screen to enter the SLO-MO parameter settings. 3 In PHOTO standby, swipe from the right to the left of the screen to enter the PHOTO parameter settings. Swipe left or right to select a parameter, slide down from top to bottom to exit the parameter setting Playback In camera standby, swipe from the left to the right of the screen to enter the playback screen. 5 Enter playbackSelecting Playback FilesClick to play/pause File Delete/Lock 6 In playback mode, select the Þle you want to delete or lock, press and hold the screen for 3 seconds, the "Delete and Lock" window will pop up, if you want to exit. If you want to exit, just swipe down or press the button at the bottom of the screen. Setup In camera standby, swipe up from the bottom of the screen to enter the camera settings screen. 7 Enter setup Switch to next page Switch to previous page Exit setup Click to Format Click to turn the microphone off or on Click to turn WiFi on or off Click to go to more settings Click to go to volume control Click to go to presets Click to go to Image Reversal Click to enter parameter settings Connecting the APP 09 1 Turn on the M3 camera. Turn on your phone's Wi-Fi. Turn on the M3 camera's Wi-Fi 2 3 Open minidv App and click "Device", scan the QR code or manually Þnd the SSID of the camera to connect the camera. 3 Click “Device” Click “Scan” Click “Connecting Device” Click “Set Wi-Fi” Connect to a computer 10 1 U-Disk Mode. Charging. PC CAM. 2 3 FCCWarningStatement:Changesormodificationstothisunitnotexpressly approvedbythepartyresponsibleforcompliancecouldvoidtheuser’s authoritytooperatetheequipment.Thisequipmenthasbeentestedandfound tocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15ofthe FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates, usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedin accordancewiththeinstructions,maycauseharmfulinterferencetoradio communications. However,thereisnoguaranteethatinterferencewillnotoccurinaparticular installation.Ifthisequipmentdoescauseharmfulinterferencetoradioor televisionreception,whichcanbedeterminedbyturningtheequipmentoffand on,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreof thefollowingmeasures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. - Connecttheequipmentintoanoutletonacircuitdifferentfromthatto whichthereceiverisconnected. - Consultthedealeroranexperiencedradio/TVtechnicianforhelp. ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothe followingtwoconditions:(1)thisdevicemaynotcauseharmfulinterference, and(2)thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation. FCCRadiationExposureStatement ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.The devicecanbeusedinportableexposureconditionwithoutrestriction.

ShenzhenBAKERElectronicsCo.LTD 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:ShenzhenBAKERElectronicsCo.LTD Address:6/F.A.Building,ThefirstindustrialareaofFenghuang,Fuyong Bao'an,Shenzhen,China ProductName:smartscreen FCCID:2AIGT-GM3 Model(s):GM3 2.911(d)(5)(i)EquipmentType We,ShenzhenBAKERElectronicsCo.LTD(“theapplicant”)certifythattheequipmentforwhich authorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:TonyHuDate:2024.7.24 TitleandCompanyname:Manager/ShenzhenBAKERElectronicsCo.LTD NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

ShenzhenBAKERElectronicsCo.LTD 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:ShenzhenBAKERElectronicsCo.LTD Address:6/F.A.Building,ThefirstindustrialareaofFenghuang,Fuyong Bao'an,Shenzhen,China ProductName:smartscreen FCCID:2AIGT-GM3 Model(s):GM3 2.911(d)(5)(ii)Applicantfiling We,ShenzhenBAKERElectronicsCo.LTD(“theapplicant”)certifythat,asofthedateofthefilingof theapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,established pursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:TonyHuDate:2024.7.24 TitleandCompanyname:Manager/ShenzhenBAKERElectronicsCo.LTD NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Shenzhen BAKER Electronics Co.LTD 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name:Shenzhen BAKER Electronics Co.LTD Address:6/F.A.Building,The first industrial area of Fenghuang,Fuyong Bao'an,Shenzhen,China Product Name:smart screen FCCID: 2AIGT-GM3 Model(s):GM3 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen BAKER Electronics Co.LTD] (“the applicant”) designate [Stone Trading Limited] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Stone Trading Limited USA Address: 6547 N Academy Blvd #2266, Colorado Springs, CO 80918, United States FRN Number: 0033401936 Contact Name: Dongmei Fang Telephone No: +12134573118 Email: [email protected] Applicant Company name:Shenzhen BAKER Electronics Co.LTD Address:6/F.A.Building,The first industrial area of Fenghuang,Fuyong Bao'an,Shenzhen,China Grantee FRN Number：0025594805 FCC Grantee Code:2AIGT Contact Name:Tony Hu Telephone No:+86-0755-27330082 Email:[email protected] Signature: Title: Manager Signature: Title: Manager Date: 2024.7.24 Date: 2024.7.24 Shenzhen BAKER Electronics Co.LTD 2.911 (d)(7)USA Agent v1.5 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

ShenzhenBAKERElectronicsCo.LTD AgentAuthorization Company:ShenzhenBAKERElectronicsCo.LTD Address:6/F.A.Building,ThefirstindustrialareaofFenghuang,Fuyong Bao'an,Shenzhen,China ProductName:smartscreen ModelNumber(s):GM3 ProductDescription:smartscreen WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2024.7.24 Name:TonyHu Title:Manager Company:ShenzhenBAKERElectronicsCo.LTD

ShenzhenBAKERElectronicsCo.LTD OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA Date:2024.7.24 Subject;RequestforConfidentiality FCCID:2AIGT-GM3 ToWhomItMayConcern, PursuanttotheprovisionsoftheCommission’srulesTitle47Sections§0.457and§0.459,we arerequestingtheCommissiontowithholdthefollowingattachment(s)asconfidential documentsfrompublicdisclosureindefinitely. Thesedocumentscontaindetailedsystemandequipmentdescriptionsandareconsideredas proprietaryinformationinoperationoftheequipment.Thepublicdisclosureofthesedocuments mightbeharmfultoourcompanyandwouldgivecompetitorsanunfairadvantageinthemarket. SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure Inadditionaltoabovementioneddocuments,inordertocomplywiththemarketingregulations inTitle47CFR§2.803andtheimportationrulesinTitle47CFR§2.1204,whileensuringthat businesssensitiveinformationremainsconfidentialuntiltheactualmarketingofnewly authorizeddevices,werequestShortTermConfidentialityofthefollowingattachment(s); ExternalPhotos TestSetupPhotos InternalPhotos UserManual For45days,pursuanttoPublicNoticeDA04-1705. OR For180dayspursuanttoKDB726920D01. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondenceduringthecertificationreviewprocesscannotbegrantedasconfidential documentsandthisinformationwillbeavailableforpublicreviewoncethegrantofequipment authorizationisissued. Sincerely, Signature: Name:TonyHu Title:Manager

EUTPHOTO(ExternalPhotos) Productname:smartscreen Model:GM3 EUTPhoto1 EUTPhoto2 EUTPhoto3 EUTPhoto4 EUTPhoto5 EUTPhoto6

Labelandlabellocation 3.0cm smartscreen FCCID:2AIGT-GM3 2.0cm

EUTPHOTO(InternalPhotos) Productname:smartscreen Model:GM3 EUTPhoto1 EUTPhoto2 EUTPhoto3 EUTPhoto4 EUTPhoto5 EUTPhoto6 EUTPhoto7 ANT

FCCID:2AIGT-GM3 RFExposureEvaluation AccordingtoKDB447498D01GeneralRFExposureGuidancev06andpart2.1093， UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone 1-gheadorbodyand10-gextremitySARevaluationforgeneralpopulationexposure conditions,bymeasurementornumericalsimulation,isnotrequiredwhenthe correspondingSARTestExclusionThresholdcondition(s),listedbelow,is(are)satisfied. For100MHzto6GHzandtestseparationdistances≤50mm,the1-gand10-gSARtest exclusionthresholdsaredeterminedbythefollowing: [(max.powerofchannel,includingtune-uptolerance,mW)/(min.testseparationdistance, mm)]·[√f (GHz) ]≤3.0for1-gSAR,and≤7.5for10-gextremitySAR,where f (GHz) istheRFchanneltransmitfrequencyinGHz PoweranddistanceareroundedtothenearestmWandmmbeforecalculation Theresultisroundedtoonedecimalplaceforcomparison Here, 2.4GWiFi ModeMax Power(dBm) Max Power(mW) Frequency(MHz)Min. distance(mm) Calc. thresholds limit 802.11b6.0123.99246251.253.0 802.11g9.5909.10243752.843.0 802.11n209.1678.25241252.563.0 802.11n409.7169.37243752.923.0 SoaSARtestisnotrequired

深圳市千目通讯科技有限公司 ShenzhenQianmuCommunicationTechnologyCo.,Ltd. 天线承认书 适用型号 GM3 客户 深圳市贝克影音数码科技有限公司 规格描述 产品内容规格客户物料编码 规 格 描 述 WIFI天线 FPC/黑色/字符QM-GM3-V1.0+ 三代端子0.81*111mm 更改履历 序号日期版本更改内容简述 12024-01-17V1.0 新项目 2 3 供应商样品确认 研发 结构 审核判定 PASS FAIL 客户样品确认 电子 结构 项目 采购品质审核 拒收原因或其它注意事项： 联系人：王志强联系方式：13760153961电话：0755-21633653传真：0755-21633541 深圳市宝安区航城街道三围社区航空路华丰智谷-航城高科技产业园A座4层425、443号 第1页 第 2 页 1、匹配电路-WIFI天线 贵司原始匹配未做任何修改 2、WiFi天线效率与增益 3、WiFi天线方向图 第 3 页 4、天线装配示意图 APP测试直线距离无障碍情况下10米无卡顿 第 4 页 5、结构图纸
