2AIMUNEXDOCKXLNexDock XL

NeXDock XL USER MANUAL Summarize 01 The phone book is a portable display device in the form of a notebook (with a keyboard touch panel and a touch screen), which can be connected to a smartphone as a mobile phone terminal, and the keyboard touch panel and touch screen are used as input devices. It can also be connected to the HDMI output of computers, video recorders, TV boxes, etc. TYPE-C (DP) output as display terminal. Smartphones are connected via C to C cable (or wireless) so that our Huawei mobile phones, Samsung and other mobile phones can display desktop mode, allowing users to touch the screen like a tablet computer, and users to write and draw with keyboards and touchpads. In addition, we also provide an HDMI port for easy use like any other monitor. The smartphone is connected to the Phonebook through a C to C cable (or wireless), so that our mobile phone can surf the Internet, play games, edit files and work in a similar use environment as a computer. All the functions above can be used without modification or additional installation of applications. A mouse control can be realized by connecting to a mobile phone or a computer via bluetooth. A TF card slot is available ( when connecting by TYPE-C) as an extra capacity for plug and play. Phonebook can be used for about 5-6 hours under normal brightness without additional charging. When connected to a smartphone, it can also charge the phone so that the phone can maintain enough power during use (the function of charging the phone can be turned on or off in the menu) Monitor Introduction 02 Speakers Wireless charging Power indicator Caps lock indicator Touch pad lock indicator Power on/off Micro SD USB Headphone jack USB-C charge port USB-C data input Mini HDMI input Charging and Bluetooth keyboard indicators OSD panel ++++ Cast Reset HDR 9300 Cool+ 7500 Cool 6500 Warm 5800 Warm+ sRGB USER RGB 12345 6 7 5 6 7 8 9 10 13 14 15 16 17 12 11 13 12 11 123 VolumeBrightnessSharpness 456 BrightnessType C input HDMI input 789 CastWired charging switchWireless charging switch 10 1112 Auto rotatePage upPage down 1314 15 ExitHDR on/off 1617 InformationColor temperature adjustment OSD Reset 03 Hot keys Package List (Fn +F6) Mute (FN+Esc) Touchpad on/off (Fn+F7) Volume- (Fn+ F2) Battery (Fn+F7) Volume+ (Fn+F9) Keyboard Backlight (Fn+F3) Brightness- (Fn+F4) Brightness+ 04 USB-A to USB-CHDMI to Mini HDMI Type-C to Type-C （Full-featured）15.6" Portable Monitor User Manual Type-C to Type-C （For power supply only） Adapter wireless connection Connecting a Bluetooth touchscreen in wireless mode 1. The touchscreen's Bluetooth signal is always active. 2. After opening the Bluetooth menu, connect to Touchs-XXXXXX and select Connect. 3. The Bluetooth touch screen will automatically connect after first connection. Bluetooth Bluetooth OPPO R15 Touchs-a000002 Connected PAIRED DEVICES AVAILABLE DEVICES AVAILABLE DEVICLS Device name HUAWEIMate 30 5G > Received files ? 18:01:F1:5D:49:65 1C:CC:D6:30:3D:4E OPPO R15 AVAILABLE DEVICLS 18:01:F1:5D:49:65 1C:CC:D6:30:3D:4E 1 2 Bluetooth Bluetooth Device name HUAWEIMate 30 5G > Received files ? Bluetooth pairing request Allow access to your contacts and call history CANCELPAIR To pair with: Touchs-a000002 3 Bluetooth Bluetooth Device name HUAWEIMate 30 5G > Received files ? 05 wireless connection Connecting a Bluetooth keyboard in wireless mode 1. The bluetooth keyboard's signal lasts about 2 minutes after power on, after that it will automatically turn off. 2. To reactivate, press Fn+C key, the charging indicator flashes red, indicating that the Bluetooth keyboard signal is activated. 3. Connect to (Fb_keyboard) by the Connect Bluetooth Touch Screen method. 4. The Bluetooth keyboard will automatically connect after first connection. 5. When the Bluetooth keyboard is connected, pressing Fn+C will automatically clear the previous Bluetooth signal connection. 06 wireless connection Wireless projection connection 1. In the menu bar at the top of the screen of Huawei, Samsung and other mobile phones, find the wireless projection or Smart View icon and run it. 2. After the wireless screen projection Flipbook-XXXXXX appears, confirm the unique number of the device and click Run. 3. If the mobile phone in the picture above enters the desktop mode (computer mode) through a wireless connection. Control Panel Not playing yz-yfb Wireless Projection Available devices Flipbook-000002 Recently connected CANCELHELP 2 Touchs-a 000002 FlashlightSound Auto rotate Huawei Share Airplane Mode Mobile data LocationScreen shot Eye Comfort Do Not Disturb Personal hotspot NFC Screen Recorder Wireless projection Flipbook-000011 Wireless Projection Connected to Flipbook-000002 Projection mode Desktop > CANCELDISCONNECT 3 1 Touchpad > 07 1 Wireless mirror connection method Apple/Android mobile phone connection method <Settings WIAN WIAN Password 12345678 NETWORKS i 5033 i AndroidAP_9876 i Flipbook-000002 i gcb i shouhou2.4g <Settings WIAN WIAN NETWORKS i 5033 i AndroidAP_9876 i Tenda_2.4G i √ Flipbook-000002 i gcb i shouhou2.4g 4 Enter the password for“Flipbook-000002" CancelJoinEnter Password Not playing Screen Mirroring Screen Mirroring Flipbook-000002 tv 08 2 3 Wireless mirror connection method How to connect wireless monitor to computer Open Computer Settings > System > Display > Connect to Wireless Display. Wired connection method 1. Mobile phone wired connection: the left Type-C is connected to the TYPE-C (with DP) of the mobile phone or computer, etc, with a C To C cable. 2. HDMI connection: left HDMI connection to computer, VCR, TV box, etc. 1. Search for SSID in WIFI settings (Flipbook-XXXXXX password: 12345678). Once connected, run screen mirroring mode. 2. After running screen mirroring mode, the screen will appear as shown below. 09 FAQ How to access OSD? No image for phonebook No volume can not be charged for your smartphone /devices Questions Answers Access OSD by swiping down with two fingers at the bottom right corner of the scree…

Text truncated - open the document above for the full version.

Nex Computer LLC Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 {June 24, 2024} U.S. Agent Designation Name and company of U.S. agent: Nex Computer LLC {Nex Computer LLC} acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AIMUNEXDOCKXL): Physical U.S. address of agent: 672 Camillo Road Sierra Madre, CA 91024 United States FRN of U.S. agent: 0025625625 Email address of U.S. agent: [email protected] {Nex Computer LLC} with the FRN [0025625625] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission- {Nex Computer LLC} acknowledges their obligation to accept service of process on behalf of {Nex Computer LLC}. related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. Sincerely, Signature Emre Kosmaz Nex Computer LLC Signature Emre Kosmaz President Nex Computer LLC 48_[model] US_Agent_2.911(d)(7)-U, V05

NexComputerLLC ProductSimilarityDeclaration Productname:NexDockXL Modelname:NexDockXL,NDW2415 FCCID:2AIMUNEXDOCKXL We(NexComputerLLC)herebystatethatallthemodelsare electricalidenticalincludingthesamesoftwareparameterand hardwaredesign(i.e.,circuitdesign,PCBLayout,RF module/circuit,antennatype(s)andantennalocation,components onPCB,etc.,),samemechanicalstructureanddesign(including productenclosure,materials,etc.,),theonlydifferenceisthe modelnameandappearancesize. Signature: Name:EmreKosmaz Title:President Shenzhen,June28,2024

FCCID:2AIMUNEXDOCKXL FCCID:2AIMUNEXDOCKXL FCCID:2AIMUNEXDOCKXL FCCID:2AIMUNEXDOCKXL

NexComputerLLC ProductName:NexDockXL ModelName:NexDockXL FCCID:2AIMUNEXDOCKXL LabelLocation

FCCID:2AIMUNEXDOCKXL FCCID:2AIMUNEXDOCKXL FCCID:2AIMUNEXDOCKXL FCCID:2AIMUNEXDOCKXL FCCID:2AIMUNEXDOCKXL 5GWIFIAntenna BTAntenna 2.4GWIFIAntenna FCCID:2AIMUNEXDOCKXL

Page 1 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A Detailed System Check Results 1. System Performance Check System Performance Check 2450 MHz Head System Performance Check 5250 MHz Head System Performance Check 5750 MHz Head Page 2 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/5/27 Test Laboratory: LCS-SAR Lab System Check 2450 MHz DUT: D2450V2; Type: D2450V2; Serial: 808 Communication System: UID 0, CW (0); Frequency: 2450 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2450 MHz; σ = 1.839 S/m; ε r = 39.445; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.42, 7.42, 7.42); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (4x8x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 17.1 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 88.55 V/m; Power Drift = -0.11 dB Peak SAR (extrapolated) = 26.2 W/kg SAR(1 g) = 12.79 W/kg; SAR(10 g) = 5.68 W/kg Maximum value of SAR (measured) = 19.9 W/kg 0 dB = 19.9 W/kg = 12.99 dBW/kg Page 3 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/6/3 Test Laboratory: LCS-SAR Lab System Check 5250 MHz DUT: D5GHzV2; Type: D5GHzV2; Serial: 1046 Communication System: UID 0, CW (0); Frequency: 5250 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5250 MHz; σ = 4.611 S/m; ε r = 35.698; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(5.38, 5.38, 5.38); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (10x10x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 17.8 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x12)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 50.11 V/m; Power Drift = 0.17 dB Peak SAR (extrapolated) = 28.1 W/kg SAR(1 g) = 7.85 W/kg; SAR(10 g) = 2.36 W/kg Maximum value of SAR (measured) = 19.0 W/kg 0 dB = 19.0 W/kg = 12.79 dBW/kg Page 4 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/6/3 Test Laboratory: LCS-SAR Lab System Check 5750 MHz DUT: D5GHzV2; Type: D5GHzV2; Serial: 1046 Communication System: UID 0, CW (0); Frequency: 5750 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5750 MHz; σ = 5.214 S/m; ε r = 34.265; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(4.88, 4.88, 4.88); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (10x10x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 18.5 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x12)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 62.89 V/m; Power Drift = 0.19 dB Peak SAR (extrapolated) = 32.2 W/kg SAR(1 g) = 8.33 W/kg; SAR(10 g) = 2.18 W/kg Maximum value of SAR (measured) = 19.1 W/kg 0 dB = 19.1 W/kg = 12.81 dBW/kg

Page 1 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix B Detailed Test Results 1. WIFI WIFI 2.4GHz for Body WIFI 5.2GHz for Body WIFI 5.8GHz for Body Page 2 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/5/27 Test Laboratory: LCS-SAR Lab WIFI 2.4G 802.11b 1CH Rear side 0mm DUT: NexDock XL; Type: NexDock XL; Serial: A240530006-1 Communication System: UID 0, WIFI 2.4GHz (0); Frequency: 2412 MHz;Duty Cycle: 1:1 Medium parameters used: f = 2412 MHz; σ = 1.765 S/m; ε r = 38.587; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(7.42, 7.42, 7.42); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (11x13x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.945 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.214 V/m; Power Drift = -0.12dB Peak SAR (extrapolated) = 1.41 W/kg SAR(1 g) = 0.621 W/kg; SAR(10 g) = 0.389 W/kg Maximum value of SAR (measured) = 0.966W/kg 0 dB = 0.966W/kg = -0.15 dBW/kg Page 3 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/6/3 Test Laboratory: LCS-SAR Lab WIFI 5.2G 802.11a 48CH Body Rear 0mm DUT: NexDock XL; Type: NexDock XL; Serial: A240530006-1 Communication System: UID 0, WIFI 5GHz (0); Frequency: 5240 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5240 MHz; σ = 4.577 S/m; ε r = 36.224; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(5.38, 5.38, 5.38); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (12x15x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 0.571 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x12)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 0.465 V/m; Power Drift = 0.17 dB Peak SAR (extrapolated) = 1.52 W/kg SAR(1 g) = 0.352 W/kg; SAR(10 g) = 0.181 W/kg Maximum value of SAR (measured) = 0.584W/kg 0 dB = 0.584W/kg = -2.34 dBW/kg Page 4 of 4 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Date: 2024/6/3 Test Laboratory: LCS-SAR Lab WIFI 5.8G 802.11ac40 159CH Body Rear 0mm DUT: NexDock XL; Type: NexDock XL; Serial: A240530006-1 Communication System: UID 0, WIFI 5GHz (0); Frequency: 5795 MHz;Duty Cycle: 1:1 Medium parameters used: f = 5795 MHz; σ = 5.436 S/m; ε r = 36.605; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration:  Probe: EX3DV4 - SN3805; ConvF(4.88, 4.88, 4.88); Calibrated: 2023/11/23;  Sensor-Surface: 2mm (Mechanical Surface Detection)  Electronics: DAE3 Sn373; Calibrated: 2024/1/3  Phantom: ELI v5.0; Type: ELI; Serial: 2010  DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Unnamed procedure/Area Scan (12x15x1): Measurement grid: dx=10mm, dy=10mm Maximum value of SAR (measured) = 0.454 W/kg Configuration/Unnamed procedure/Zoom Scan (7x7x12)/Cube 0: Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 0.318 V/m; Power Drift = 0.10 dB Peak SAR (extrapolated) = 0.941 W/kg SAR(1 g) = 0.269 W/kg; SAR(10 g) = 0.069 W/kg Maximum value of SAR (measured) = 0.487 W/kg 0 dB = 0.487 W/kg = -3.12 dBW/kg

Page 1 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix C Calibration certificate 1. Dipole D2450V2-SN 808(2023-10-23) D5GHzV2-SN 1046(2023-10-23) 2. DAE DAE3-SN 373(2024-01-03) 3. Probe EX3DV4-SN 3805(2023-11-23) Page 2 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 3 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 4 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 5 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 6 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 7 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 8 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 9 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 10 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 11 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 12 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 13 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 14 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 15 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 16 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Page 17 of 27 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Str…

Text truncated - open the document above for the full version.

Page 1 of 5 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix D Photographs 1. SAR measurement System 2. Photographs of Tissue Simulate Liquid 3. Photographs of EUT test position 4. EUT Constructional Details Page 2 of 5 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 1. SAR measurement System Page 3 of 5 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 2. Photographs of Tissue Simulate Liquid Photo 1: Tissue Simulant Liquid for Head 2300-2500 Photo 2: Tissue Simulant Liquid for Head 5000-6000 Page 4 of 5 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 3. Photographs of EUT test position Photo 3: Rear side 0mm N/A Page 5 of 5 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 4. EUT Constructional Details Photo 4: View 1 Photo 5: View 2 Photo 6: View 3 N/A

Page 1 of 45 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT For Nex Computer LLC NexDock XL Test Model: NexDock XL Additional Model No.: Please Refer to Page 8 Prepared for : Nex Computer LLC Address : 672 Camillo Rd, Sierra Madre CA 91024 USA. Prepared by : Shenzhen LCS Compliance Testing Laboratory Ltd. Address : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel : (+86)755-82591330 Fax : (+86)755-82591332 Web : www.LCS-cert.com Mail : [email protected] Date of receipt of test sample : May 27, 2024 Number of tested samples Sample number : : 1 A240530006-1 Serial number : Prototype Date of Test : May 27, 2024 ~ June 03, 2024 Date of Report : June 7, 2024 Page 2 of 45 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR TEST REPORT Report Reference No. ................. : LCSA05304017E Date Of Issue ............................. : June 7, 2024 Testing Laboratory Name ........... : Shenzhen LCS Compliance Testing Laboratory Ltd. Address ......................................... : 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Testing Location/ Procedure ......... : Full application of Harmonised standards ■ Partial application of Harmonised standards □ Other standard testing method □ Applicant’s Name .................... : Nex Computer LLC Address ...................................... : 672 Camillo Rd, Sierra Madre CA 91024 USA. Test Specification: Standard ..................................... : FCC 47CFR §2.1093, ANSI/IEEE C95.1-2019, IEEE 1528-2013 Test Report Form No. ................. : LCSEMC-1.0 TRF Originator ............................ : Shenzhen LCS Compliance Testing Laboratory Ltd. Master TRF ................................ : Dated 2011-03 Shenzhen LCS Compliance Testing Laboratory Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen LCS Compliance Testing Laboratory Ltd. is acknowledged as copyright owner and source of the material. Shenzhen LCS Compliance Testing Laboratory Ltd. takes noresponsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test Item Description. ............. : NexDock XL Trade Mark ................................. : NexDock Model/Type Reference ............... : NexDock XL Ratings ....................................... : Battery: 11.4V, 4300mAh, 49.02Wh Result ...................................... : Positive Compiled by: Supervised by: Approved by: Jay Zhan/ File administrators Cary Luo / Technique principal Gavin Liang/ Manager Page 3 of 45 FCC ID: 2AIMUNEXDOCKXL Report No.: LCSA05304017E Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity SAR -- TEST REPORT Test Result Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of thes…

Text truncated - open the document above for the full version.
