2AIQW-DA2110ACTIVE SPEAKER

SimmonsDrums.net OWNER’S MANUAL ADVANCED ELECTRONIC DRUM AMPLIFIERS DA2100 SERIES WILL USE KEYSHOT IMAGES HERE 4 Position your DA2100 Series amplifier in the desired location, and ensure the amp is stable. INITIAL SETUP FloorPole (speaker stand not included) Free-standing POWER • Make sure the 1 power switch is set to the OFF (0) position. • Connect the included detachable IEC power cable from a power outlet to the 2 power cable input. • The 3 red voltage switch comes factory-set to the position appropriate for the market where the amplifier is sold. For the USA, this is 100-120V. 1 3 2 DA2100 SERIES ADVANCED ELECTRONIC DRUM AMPLIFIERS 5 • Each model in the DA2100 series ships with a removable mobile device holder as an accessory inside the retail packaging. • When using your amp in floor wedge position, you can attach the holder to the front-panel as shown below. • Slide the angled bottom end of the device holder into the 1 front panel slot, until it 2 clicks into place. • Now you can keep your 3 tablet or smart-phone held in a convenient position during performance or rehearsal. • Please remove the cradle before transporting the amplifier, or when using the amplifier on a speaker pole or standing upright. DEVICE HOLDER BLUETOOTH ® CONNECTING BLUETOOTH ® TROUBLESHOOTING • Press the 1 front panel On/Pair button so that the 2 Bluetooth LED flashes, indicating that Bluetooth audio is enabled and ready for pairing • From your Bluetooth source device, select your drum amplifier’s model number (DA2108, DA2110 or DA2112) to pair • Play audio from your source device, making sure your device’s volume is turned up, as well as the amplifier’s volume These steps should resolve any Bluetooth trouble you may encounter: Power off the DA2100 Series amplifier and leave it off, then follow directions for Apple and Android devices below: Then power on your DA2100 Series amplifier, press the Bluetooth On/Pair button, and follow the Bluetooth Connecting steps above • On your Apple iOS device 1. Open Settings app, select Bluetooth 2. If your amplifier is listed under MY DEVICES, touch info button, tap to Forget This Device 3. Turn off Bluetooth, wait 10 seconds, turn on Bluetooth • On your Android device 1. Open Settings, select Bluetooth 2. If DA2012B is listed under Paired Devices, touch gear icon, and tap to unpair 3. Turn off Bluetooth, wait 10 seconds, turn on Bluetooth 1 2 123 6 INPUTS • Connect your electronic drum sound module’s audio outputs to the 1 INPUT 1 jacks on the amplifier rear panel • Stereo Input: use 2 cables to connect to both the INPUT 1 LEFT(MONO) and RIGHT jacks • Mono Input: use 1 cable to connect to the INPUT 1 LEFT(MONO) input jack only • If you’d like to amplify additional sources, connect them to the remaining rear panel inputs, or the front panel aux input ROUTING SWITCH • If you are using a single DA2100 series amplifier, set the 2 rear panel switch to Mono • For dual-amp stereo configuration, see Smart Stereo on the next page DA2108 REAR PANEL DA2110 REAR PANEL DA2112 REAR PANEL QUICK START: INPUT 1 2 2 2 1 1 DA2100 SERIES ADVANCED ELECTRONIC DRUM AMPLIFIERS 7 VOLUME CONTROLS • Turn all 3 input level control knobs to the minimum position • DA2112 only: also turn the Master 4 knob to minimum VOICING SWITCH • Set the 5 Voicing switch to Floor when using the amplifier lying horizontally on the floor, or free-standing vertically • Set the switch to Pole when using the amplifier on a speaker pole POWER ON • Power on the drum sound module and set its output volume to max • Then power on the amplifier, via the rear panel switch • DA2112 only: turn the Master 4 knob to noon position • Turn up the INPUT 1 knob 3 while playing your drum sound module, until you reach a comfortable listening level EQ • Turn the EQ knobs 6 to adjust your tone as desired QUICK START: CONTROLS DA2108 FRONT PANEL DA2110 FRONT PANEL DA2112 FRONT PANEL 3 46 6 6 3 3 5 5 5 8 A pair of DA2100 Series amplifiers can operate together as a Smart Stereo system, giving you control of the sound and volume of both amplifiers from the first master amplifier, and optimally distributing all audio inputs to both for rich stereo sound. • Use two like amplifiers: two DA2108s, two DA2110s, or two DA2112 amplifiers • Set the switch on the first amplifier to Stereo Master • Set the switch on the second amplifier to Link In • Connect a standard microphone cable (female XLR to male XLR cable) from the first unit’s LINK OUT jack to the second unit’s LINK IN jack CONNECT ALL INPUTS TO FIRST AMPLIFIER ONLY • Connect all inputs and make all sound settings on the first (left) unit only, this will be the master amplifier • All inputs and controls on the second amplifier will be disabled • For headphones, use the headphone jack on the first amplifier SMART STEREO WITH PAIR OF AMPLIFIERS FIRST/MASTER/LEFT UNITSECOND/LINKED/RIGHT UNIT DA2100 SERIES ADVANCED ELECTRONIC DRUM AMPLIFIERS 9 SMART STEREO WITH SUBWOOFER OR DIRECT OUT To connect a subwoofer, or a direct out, the setup is the same as on the opposite page, but you can add a connection from the first unit’s DIRECT OUT jack to a subwoofer or other audio receiving device, as shown below. • The DIRECT OUT provides a full-range, mono signal • The DIRECT OUT level is not effected by the MASTER knob of the DA2112. TO SUBWOOFER OR OTHER UNIT FIRST/MASTER/LEFT UNITSECOND/LINKED/RIGHT UNIT 10 1 1 1 2 2 2 3 3 3 4 4 4 5 5 5 6 6 7 7 78 12 12 12 1314 11 11 11 9 9 9 18 1516 16 16 17 17 17 10 10 10 CONNECTIONS AND CONTROLS DA2108 REAR PANELDA2108 FRONT PANEL DA2110 REAR PANELDA2110 FRONT PANEL DA2112 REAR PANELDA2112 FRONT PANEL REAR PANEL POWER 68 8 DA2100 SERIES ADVANCED ELECTRONIC DRUM AMPLIFIERS 11 1 REAR PANEL BALANCED LINE INPUTS Balanced or unbalanced line level sources can be connected here. - Mono sources: connect to Left/Mono jack only - Stereo sources: connect separate cables to Left/Mono and Right 2 FRONT PANEL AUX INPUT Use this input to connect the audio cable from a computer, smartphon…

Text truncated - open the document above for the full version.

Ningbo Tonwel Audio Co., LTD Agent Authorization Company: Ningbo Tonwel Audio Co., LTD Address: No. 28 Xiyi Road, Jiangshan Town, Yinzhou, Ningbo, China. Product Name: ACTIVE SPEAKER Model Number(s): DA2110, DA2108 Product Description: BLUETOOTH ACTIVE SPEAKER We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/11/18 Name: Zhihong Fu Title: Manager Company: Ningbo Tonwel Audio Co., LTD

Ningbo Tonwel Audio Co., LTD Authorization Letter We, (the approval holder) Company name Ningbo Tonwel Audio Co., LTD Addresss No. 28 Xiyi Road, Jiangshan Town, Yinzhou, Ningbo, China. declare that the following representative (agent): Name (person) Bovey Yang Company name Shenzhen STS Test Services Co., Ltd. Addresss 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Micom Labs for product certification below Product Description ACTIVE SPEAKER Type or Model(s) DA2110, DA2108 Tradename or Brand(s) Attestation: City: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Ningbo 2020/11/18 Zhihong Fu Manager

Differences Description We Ningbo Tonwel Audio Co., LTD state: Product： ACTIVE SPEAKER Model Name： DA2110, DA2108 Brand Name： FCC ID： 2AIQW-DA2110 Both of models have the same circuit schematic, construction, PCB Lavout and critical components. The difference is horn size and lead to different power, function and confiquration are different therefore model name is different. Sincerely, Company: Ningbo Tonwel Audio Co., LTD Title: Manager E-mail: [email protected] Name: Zhihong Fu Signature

Ningbo Tonwel Audio Co., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/11/18 Subject; Request for Confidentiality FCC ID: 2AIQW-DA2110 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Zhihong Fu Title: Manager

Page 1 of 4 Report No.: STS2010120 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: DA2110 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2010120 Photo 3 Photo 4 Page 3 of 4 Report No.: STS2010120 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2010120 Photo 7 Photo 8

Label Size:20*30mm The label is printed on the shell ACTIVE SPEAKER Model name: DA2110 FCC ID: 2AIQW-DA2110 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 10 Report No.: STS2010120 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: DA2110 Photo 1 Photo 2 Page 2 of 10 Report No.: STS2010120 Photo 3 Photo 4 Page 3 of 10 Report No.: STS2010120 Photo 5 Photo 6 Page 4 of 10 Report No.: STS2010120 Photo 7 Photo 8 Page 5 of 10 Report No.: STS2010120 Photo 9 Photo 10 Page 6 of 10 Report No.: STS2010120 Photo 11 Photo 12 Page 7 of 10 Report No.: STS2010120 Photo 13 Photo 14 Page 8 of 10 Report No.: STS2010120 Photo 15 Photo 16 Page 9 of 10 Report No.: STS2010120 Photo 17 Photo 18 Page 10 of 10 Report No.: STS2010120 Photo 19 Photo 20

RF Exposure Report FCC ID: 2AIQW-DA2110 RF Exposure Measurement The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) F= Frequency in MHz Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. EUT Operation condition EUT was enabled to transmit and receive at lowest, middle and highest channels. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. BT5.0+EDR Mode 2402-2480MHz Detector PEAK GFSK 0±1dBm π/4-DQPSK 2.5±1dBm 8DPSK 3.1±1dBm ANT Gain (G) Antenna gain : 0dBi (gain of antenna in linear scale=1) GFSK12402 11.25890.00025 1 π/4-DQPSK12402 3.52.23870.00045 1 8DPSK12402 4.12.57040.00051 1 Power Density (mW/cm²) Limit (mW/cm²) ANT Gain(gain of antenna in linear scale) Protocol Channel Frequenc y (MHz) Output Power to Antenna (dBm) Output Power to Antenna (mW) According to the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know max MPE value 0.00051 t distance 20cm. This is less than the limit 1. Compliance the RF exposure requirement.
