2AIZY-QS100Power Bank

IDEA ELECTRONICS INC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2019/12/16 Subject; Request for Confidentiality FCC ID: 2AIZY-QS100 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name:Qidong gao Title: Manager

IDEA ELECTRONICS INC Letter of Authorization Company: IDEA ELECTRONICS INC Address: 13620 Benson Ave. Suite B, Chino, California 91710, United States Product Name: Power Bank Model Number(s): QS100 Product Description: Power Bank We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 19/06/2020 Name:Qidong gao Title:Manager Company: IDEA ELECTRONICS INC

Model Number: QS100

Label Location:

Product Name: Power Bank Model No.: QS100 FCC ID: 2AIZY-QS100 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Model Number: QS100 ANT

Report No.: 18220WC00066602FCC ID: 2AIZY-QS100Page 1 of 14 Code:AB-RF-05-a FCC TEST REPORT Client Name: IDEA ELECTRONICS INC Address: 13620 Benson Ave. Suite B, Chino, California 91710, United States Product Name: Power Bank Date: Jun. 18, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00066602FCC ID: 2AIZY-QS100Page 2 of 14 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Test Equipment List .................................................................................................................................... 5 1.5. Measurement Uncertainty ......................................................................................................................... 5 1.6. Description of Test Facility ........................................................................................................................ 6 2. Measurement and Result ..................................................................................................................................... 7 2.1. Requirements .............................................................................................................................................. 7 2.2. Test Setup .................................................................................................................................................... 8 2.3. Test Procedure ............................................................................................................................................ 8 2.4. Test Result ................................................................................................................................................... 8 2.4.1. Equipment Approval Considerations item 5.b of KDB 680106 D01 v03. ...................................... 8 2.4.2. Environmental evaluation and exposure limit according to FCC CFR 47 part 1, 1.1307(b), 1.1310 ................................................................................................................................................................ 10 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 12 Report No.: 18220WC00066602FCC ID: 2AIZY-QS100Page 3 of 14 Code:AB-RF-05-a TEST REPORT Applicant: IDEA ELECTRONICS INC Manufacturer: Shenzhen Wanchuangbo Industry Development Co., Ltd. Product Name: Power Bank Model No.: QS100 Trade Mark: iDeaPLAY Rating(s): Input: DC 5V, 3A (with DC 3.7V, 10000mAh battery inside) USB 1 Output: DC 5V, 2.1 USB 2 Output: DC 5V, 2.1 Wireless Output: 5W, 7.5W, 10W Output1+Output2+Wireless Output(TOTAL): USB1/2: DC 5V,1A/ Wireless Output: 10W Test Standard(s) : FCC Part 1.1310, 1.1307(b) Test Method(s): KDB680106 D01 RF Exposure Wireless Charging Apps v03 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 1.1307 & KDB680106 D01 requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptJun. 03, 2020 Date of TestJun. 03~17, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00066602FCC ID: 2AIZY-QS100Page 4 of 14 Code:AB-RF-05-a 1. General Information 1.1. Client Information 1.2. Description of Device (EUT) Product Name : Power Bank Model No.: QS100 Trade Mark: iDeaPLAY Test Power Supply: AC 120V, 60Hz for adapter / AC 240V, 60Hz for adapter Test Sample No.: 1-2-1(Normal Sample), 1-2-1(Engineering Sample) Product Description : Operation Frequency:110.1-205KHz Modulation Type:QI Antenna Type:Inductive loop coil Antenna Antenna Gain(Peak):0 dBi Remark:1) For a more detailed features description, please refer to the manufacturer’s specifications or the User’s Manual. Applicant: IDEA ELECTRONICS INC Address: 13620 Benson Ave. Suite B, Chino, California 91710, United States Manufacturer: Shenzhen Wanchuangbo Industry Development Co., Ltd. Address : 2407,24 th floor,building A,Xinghe yabao phase 1,meiban avenue,bantian street,Longgang District,Shenzhen,Guangdong,China Factory: Shenzhen Wanchuangbo Industry Development Co., Ltd. Address : 2407,24 th floor,building A,Xinghe yabao phase 1,meiban avenue,bantian street,Longgang District,Shenzhen,Guangdong,China Report No.: 18220WC00066602FCC ID: 2AIZY-QS100Page 5 of 14 Code:AB-RF-05-a 1.3. Auxiliary Equipment Used During Test Adapter: Manufacturer: Anker Innovations Limited M/N: A2013 Input: 100-240V~50-60Hz Output: 3.6-6.5V 3A/ 6.5-9V2A/ 9-12V1.5A 1.4. Test Equipment List ItemEquipmentManufacturerModel No.Serial No.Last Cal.Cal. Interval 1 Magnetic field meter NARDAELT-400423623 Dec. 24, 2018 3 Year 2E-Field ProbeNardaEF0391Q15221 Nov.17, 2017 3 Year 3H-Field ProbeNardaHF3061Q15835 Nov.17, 2017 3 Year 1.5. Measurement Uncertainty Radiation Uncertainty: Ur = 3.9 dB (Hori…

Text truncated - open the document above for the full version.

Report No.: 18220WC00066601FCC ID: 2AIZY-QS100Page 1 of 30 Code:AB-RF-05-a FCC TEST REPORT Client Name: IDEA ELECTRONICS INC Address: 13620 Benson Ave. Suite B, Chino, California 91710, United States Product Name: Power Bank Date: Jun. 18, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00066601FCC ID: 2AIZY-QS100Page 2 of 30 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 5 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. Description Of Test Setup ......................................................................................................................... 6 1.6. Test Equipment List .................................................................................................................................... 7 1.7. Measurement Uncertainty ......................................................................................................................... 8 1.8. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 15 4.1. Test Standard and Limit .......................................................................................................................... 15 4.2. Test Setup .................................................................................................................................................. 15 4.3. Test Procedure .......................................................................................................................................... 16 4.4. Test Data .................................................................................................................................................... 17 5. Antenna Requirement ......................................................................................................................................... 21 5.1. Test Standard and Requirement ............................................................................................................ 21 5.2. Antenna Connected Construction .......................................................................................................... 21 APPENDIX I -- TEST SETUP PHOTOGRAPH ................................................................................................... 22 APPENDIX II -- EXTERNAL PHOTOGRAPH ..................................................................................................... 24 APPENDIX III -- INTERNAL PHOTOGRAPH ..................................................................................................... 27 Report No.: 18220WC00066601FCC ID: 2AIZY-QS100Page 3 of 30 Code:AB-RF-05-a TEST REPORT Applicant: IDEA ELECTRONICS INC Manufacturer: Shenzhen Wanchuangbo Industry Development Co., Ltd. Product Name: Power Bank Model No.: QS100 Trade Mark: iDeaPLAY Rating(s): Input: DC 5V, 3A (with DC 3.7V, 10000mAh battery inside) USB 1 Output: DC 5V, 2.1 USB 2 Output: DC 5V, 2.1 Wireless Output: 5W, 7.5W, 10W Output1+Output2+Wireless Output(TOTAL): USB1/2: DC 5V,1A/ Wireless Output: 10W Test Standard(s) : FCC Part15 Subpart C 2019, Paragraph 15.209 Test Method(s): ANSI C63.10: 2013 The device described above is tested by Shenzhen Anbotek Compliance Laboratory Limited to determine the maximum emission levels emanating from the device and the severe levels of the device can endure and its performance criterion. The measurement results are contained in this test report and Shenzhen Anbotek Compliance Laboratory Limited is assumed full of responsibility for the accuracy and completeness of these measurements. Also,this report shows that the EUT (Equipment Under Test) is technically compliant with the FCC Part 15 Subpart C requirements. This report applies to above tested sample only and shall not be reproduced in part without written approval of Shenzhen Anbotek Compliance Laboratory Limited. Date of ReceiptJun. 03, 2020 Date of TestJun. 03~17, 2020 Prepared By (Engineer / Dolly Mo) Reviewer (Supervisor / Bibo Zhang) Approved & Authorized Signer (Manager / Tom Chen) Report No.: 18220WC00066601FCC ID: 2AIZY-QS100Page 4 of 30 Code:AB-RF-05-a 1. General Information 1…

Text truncated - open the document above for the full version.

PHOTOSOFTESTSETUP Model Number: QS100 Photo of Conducted Emission Measurement Photo of Radiation Emission Test Photo of MPE Measurement
