2AJ7P-XMWXSB01YMXMWXSB01YM

Keyboard Function & Indicator Description Fn Key Combinations Key CombinationFunction Mute Volume - Volume + Open projector modes Play previous track Play/pause Key CombinationFunction Return to desktop Play next track Open task views & desktops Open "This PC" Open Calculator Open mailbox Read this manual carefully before use, and retain it for future reference Battery Compartment Nano Receiver Compartment 2. Install the two AAA batteries into the battery compartments of the keyboard and the mouse respectively. Then turn on the mouse. 3. The keyboard and the mouse are ready for use when your computer system notifies that the installation is successful. Xiaomi Wireless Keyboard and Mouse Combo use the 2.4 GHz wireless technology. Just connect the nano receiver to your computer and then you can start using your mouse and keyboard. Featuring with minimalist style, the wireless mouse and the keyboard are comfortable to use, making your desk a clean and tidy workplace. Product Overview How to Use NumCapsLockScrLkBattery Mouse Indicator Description Battery Indicator Indicator Status Num indicator is on CapsLock indicator is on ScrLk indicator is on Battery indicator is blinking Color White White White Orange Keyboard Status Num lock enabled Caps lock enabled Scroll lock enabled Low battery level Light-on Duration 3 seconds 3 seconds 3 seconds 3 seconds Keyboard Indicator Description Wireless Keyboard and Mouse Combo User Manual ·01 1. Remove the nano receiver from the mouse and plug it into the computer's USB port. Battery Compartment After the battery is installed, the Num indicator, the CapsLock indicator, and the ScrLK indicator will simultaneously remain on for 3 seconds, and the keyboard is ready for use. If you use a flat battery when using the keyboard, or the battery level is running low after the keyboard is awakened from sleep mode, the battery indicator will blink for 3 seconds. Please replace the battery in a timely manner. Package Contents Keyboard×1Mouse×1 Nano Receiver×1 (Inside the Mouse) User Manual×1 In the case of a low battery, the battery indicator will blink orange for 10 seconds when the mouse is turned on or awakened from sleep mode. Note: The mouse adopts the power-saving design, and its battery indicator will automatically turn off and enter into sleep mode during use. The battery service life of the keyboard and the mouse vary depending on their working environment and workload. Generally, the service life can last for over four months. Note: Illustrations of product, accessories, and user interface in the user manual are for reference purposes only. Actual product and functions may vary due to product enhancements. Battery Safety & Warnings Only use the battery approved by the manufacturer. Replacing with an incorrect battery type may invalidate the battery safety protection and cause a fire, or even an explosion. Keep the battery away from extreme heat sources, such as sunlight, fire, microwave, or oven. Failure to do so may lead to leakage of flammable liquid or gas, or even an explosion. Do not disassemble, strike, crush or cut the battery to avoid possible explosions. Do not subject the battery to extremely low air pressure as it might lead to leakage of flammable liquid or gas, or even an explosion. Stop using the battery immediately if there is any swelling. Do not swallow the battery to avoid chemical burns. If you think the battery may have been swallowed or may stay in any part of your or some else's body, seek medical attention immediately. Stop using the mouse and the keyboard and keep them out of reach of children if their battery compartments are not closed securely. Keep new or used batteries out of reach of children. Do not dispose of used batteries with household waste. Dispose of them in a safe manner as per local laws and regulations. Name: Xiaomi Wireless Keyboard and Mouse Combo Model: XMWXSB01YM (Mouse) DXMWXSB01YM (Nano Receiver) WXJS01YM (Keyboard) Connectivity: 2.4 GHz wireless connection Supported Operating System: Windows 10 Rated Input: 1.5 V 50 mA (Keyboard), 1.5 V 50 mA (Mouse) Materials: ABS, metals, and others Number of Keys on Keyboard: 104 Net Weight (Excl. battery): 516 g (Keyboard), 62 g (Mouse) Item Dimensions: 436.5×127.5×27.5 mm (Keyboard), 113×60×36 mm (Mouse) Operating Temperature: 0 °C to 40 °C Specifications RF SpecificationWorking FrequencyMaximum Output Power 2.4 G2408-2474 MHz0 dBm 0102 0304 0506 NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. IC Declaration of Conformity This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. EU Declaration of Conformity Hereby, Beijing Yueme Technology Co., Ltd. declares that the radio equipment type XMWXSB01 YM (Mouse)/DXMWXSB01YM (Nano Receiver…

Text truncated - open the document above for the full version.

1 Safety Human Exposure 1.1 Radio Frequency Exposure Compliance 1.1.1 Electromagnetic Fields RESULT: Pass Test Specification Test standard : CFR47 FCC Part 2: Section 2.1093 CFR47 FCC Part 1: Section 1.1310 FCC KDB Publication 447498 v06, section 7 RSS-102 Issue 5 March 2015, section 2.5.1  FCC requirements EUT RF Exposure Evaluation operations Frequency band(MHz) Maximum Conducted power* Threshold power @5mm (mW) Verdict dBm mW 2408-2474 0.44 1.107 10 Compliant The highest E-field is 92.47dBμV@3m, i.e. -2.76dBm (EIRP). *The max antenna gain is -3.20dBi, and 0.44dBm conducted power based on it.  IC requirements: The EUT shall comply with the requirement of RSS-102 section 2.5.1. a) EUT RF Exposure Evaluation standalone operations Frequency band(MHz) Maximum radiated power* Threshold power @5mm Verdict dBm mW dBm mW 2408-2474 0.44 1.107 6.02 4 Compliant The highest E-field is 92.47dBμV@3m, i.e. -2.76dBm (EIRP), much lower than threshold power level. *The Conducted Power is higher than EIRP and used for evaluation. The antenna gain is -3.20dBi.

Prüfbericht - Produkte Test Report - Products Prüfbericht-Nr.: Test report no.: CN22ZZ0N 001 Auftrags-Nr.: Order no.: 168352501 Seite 1 von 15 Page 1 of 15 Kunden-Referenz-Nr.: Client reference no.: N/A Auftragsdatum: Order date: 2022-01-18 Auftraggeber: Client: Beijing Yueme Technology Co., LTD. Room C608, Building No. B-2, Zhongguancun Dongsheng Science and Technology Park Phase I, No. 66, Xixiaokou Road, Haidian District, Beijing, China Prüfgegenstand: Test item: Wireless Mouse Bezeichnung / Typ-Nr.: Identification / Type no.: XMWXSB01YM (Xiaomi) Auftrags-Inhalt: Order content: Test Report Prüfgrundlage: Test specification: FCC CFR Title 47, Part 15, Subpart C, Section 15.249 RSS-210 Issue 10 April 2020 RSS-Gen Issue 5 February 2021 Wareneingangsdatum: Date of sample receipt: 2022-02-10 Please refer to Photo Document Prüfmuster-Nr.: Test sample no: A003192705-001~003 A003192705-006~008 Prüfzeitraum: Testing period: 2022-02-17 – 2022-03-02 Ort der Prüfung: Place of testing: TÜV Rheinland (Shenzhen) Co., Ltd. Prüflaboratorium: Testing laboratory: TÜV Rheinland (Shenzhen) Co., Ltd. Prüfergebnis*: Test result*: Pass geprüft von: tested by: X Signed by: Bell Hu genehmigt von: authorized by: X Signed by: Lin Lin Datum: Date: 2022-03-31 Ausstellungsdatum: Issue date: 2022-03-31 Stellung / Position: Project Manager Stellung / Position: Reviewer Sonstiges / Other: FCC ID: 2AJ7P-XMWXSB01YM IC: 28281-XMWXSB01YM HVIN: XMWXSB01YM PMN: XMWXSB01YM Zustand des Prüfgegenstandes bei Anlieferung: Condition of the test item at delivery: Prüfmuster vollständig und unbeschädigt Test item complete and undamaged * Legende: 1 = sehr gut 2 = gut 3 = befriedigend 4 = ausreichend 5 = mangelhaft P(ass) = entspricht o.g. Prüfgrundlage(n) F(ail) = entspricht nicht o.g. Prüfgrundlage(n) N/A = nicht anwendbar N/T = nicht getestet * Legend: 1 = very good 2 = good 3 = satisfactory 4 = sufficient 5 = poor P(ass) = passed a.m. test specification(s) F(ail) = failed a.m. test specification(s) N/A = not applicable N/T = not tested Dieser Prüfbericht bezieht sich nur auf das o.g. Prüfmuster und darf ohne Genehmigung der Prüfstelle nicht auszugsweise vervielfältigt werden. Dieser Bericht berechtigt nicht zur Verwendung eines Prüfzeichens. This test report only relates to the a. m. test sample. Without permission of the test center this test report is not permitted to be duplicated in extracts. This test report does not entitle to carry any test mark. TÜV Rheinland (Shenzhen) Co., Ltd. 1601 R&D Room, 1602-1604, 17-18F, Building 7 Site C, Vanke Cloud City Phase I, Xingke First Street, Xili Street, Xili Community, Nanshan District, Shenzhen 518052, P.R. China Mail: [email protected] · Web: www.tuv.com jjj Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22ZZ0N 001 Seite 2 von 15 Page 2 of 15 Test Summary 5.1.1 ANTENNA REQUIREMENT RESULT: Pass 5.1.2 FIELD STRENGTH OF FUNDAMENTAL AND HARMONICS RESULT: Pass 5.1.3 20DB AND 99% BANDWIDTH RESULT: Pass 5.1.4 BAND EDGE RESULT: Pass Prüfbericht - Produkte Test Report - Products Prüfbericht - Nr.: Test Report No.: CN22ZZ0N 001 Seite 3 von 15 Page 3 of 15 Table of Contents 1 GENERAL REMARKS ........................................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS ............................................................................................................ 4 2 TEST SITES ........................................................................................................................................ 5 2.1 TEST FACILITIES ................................................................................................................................. 5 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS................................................................................. 5 2.3 TRACEABILITY .................................................................................................................................... 6 2.4 CALIBRATION ..................................................................................................................................... 6 2.5 MEASUREMENT UNCERTAINTY............................................................................................................. 6 2.6 LOCATION OF ORIGINAL DATA ............................................................................................................. 6 2.7 STATUS OF FACILITY USED FOR TESTING ............................................................................................. 6 3 GENERAL PRODUCT INFORMATION ...................................................................................................... 7 3.1 PRODUCT FUNCTION AND INTENDED USE ............................................................................................. 7 3.2 RATINGS AND SYSTEM DETAILS .......................................................................................................... 7 3.3 INDEPENDENT OPERATION MODES ...................................................................................................... 8 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ......................................................................... 8 3.5 SUBMITTED DOCUMENTS..................................................................................................................... 8 4 TEST SET-UP AND OPERATION MODES ................................................................................................ 9 4.1 PRINCIPLE OF CONFIGURATION SELECTION ......................................................................................... 9 4.2 TEST OPERATION AND TEST SOFTWARE .............................................................................................. 9 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT ............................................................................ 9 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE .............…

Text truncated - open the document above for the full version.

Prüfbericht - Produkte Test Report - Products Appendix A CN22ZZ0N 001 Page 1 of 2 Appendix A: Photographs of the Test Set-Up APPENDIX A: PHOTOGRAPHS OF THE TEST SET-UP ....................................................................................................... 1 PHOTOGRAPH 1: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, BELOW 1GHZ ......................................................................... 2 PHOTOGRAPH 2: SET-UP PHOTO FOR RADIATED SPURIOUS EMISSION, ABOVE 1GHZ ......................................................................... 2 Prüfbericht - Produkte Test Report - Products Appendix A CN22ZZ0N 001 Page 2 of 2 Photograph 1: Set-up photo for Radiated Spurious Emission, Below 1GHz Photograph 2: Set-up photo for Radiated Spurious Emission, Above 1GHz
