2AJ9T-20801Smart Access Control Terminal

Rev 11/20/07 ZKTECO CO., LTD. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AJ9T-20801 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Zhonglie Ge ZKTECO CO., LTD.

Declaration on model difference We the undersigned hereby confirm that any of our production units bearing the following model numbers are identical in circuitry and electrical, mechanical and physical construction; the only differences are the model name and the color of appearance for trading purpose. FCC ID: 2AJ9T -20801 Production name Trade name Model no. Smart Access Control Terminal N/A SpeedFace-V4L, MiniAC, SpeedFace-V4LM1 Confirmed by ZKTECO CO.,LTD. Zhonglie Ge ZKTECO CO., LTD. Date: 2021-3-5

ZKTECO CO., LTD. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2021-3-5 SUBJECT: FCC Application for FCC ID: 2AJ9T-20801 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. ZhonglieGey/ Engineer ZKTECO CO., LTD.

EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 EUT View 3 EUT View 4 EUT View 5 EUT View 6 EUT View 7 EUT View 8 EUT View 8 ----------------The end----------------

Label and label location

TRF NO. FCC Page 1 of 7 Report No.: ES200731064W Ver.1.0 EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1 Solder Board-Component View 1 NFC Antenna TRF NO. FCC Page 2 of 7 Report No.: ES200731064W Ver.1.0 Solder Board-Component View 2 Solder Board-Component View 3 TRF NO. FCC Page 3 of 7 Report No.: ES200731064W Ver.1.0 Solder Board-Component View 4 IC Chip View1 TRF NO. FCC Page 4 of 7 Report No.: ES200731064W Ver.1.0 IC Chip View2 Solder Board-Component View 5 TRF NO. FCC Page 5 of 7 Report No.: ES200731064W Ver.1.0 Solder Board-Component View6 Solder Board-Component View7 TRF NO. FCCPage 6 of 7 Report No.: ES200731064W Ver.1.0 Solder Board-Component Vi ew8 Solder Board-Component Vi ew9 TRF NO. FCC Page 7 of 7 Report No.: ES200731064W Ver.1.0 Antenna ---------------The end---------------- WIFI Antenna

Report No. ES200731064W02-1 Page 1 of 33 Ver.1.0 TEST REPORT Product Name ： Smart Access Control Terminal Model Number ： SpeedFace-V4L, MiniAC, SpeedFace-V4LM1 FCC ID ： 2AJ9T-20801 Prepared for : ZKTECO CO.,LTD. Address : No.32,Pingshan Industrial Avenue,Tangxia Town,Dongguan City,Guangdong Province,China 523728 Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES200731064W02-1 Date(s) of Tests : Aug. 6, 2020 to Sep. 13, 2020 Date of issue : Feb. 25, 2021 Report No. ES200731064W02-1 Page 2 of 33 Ver.1.0 Table of Contents 1 EUT TECHNICAL DESCRIPTION ........................................................................................................... 4 2 SUMMARY OF TEST RESULT ................................................................................................................ 5 3 TEST METHODOLOGY ........................................................................................................................... 6 3.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................................ 6 3.2 MEASUREMENT EQUIPMENT USED .......................................................................................... 6 3.3 DESCRIPTION OF TEST MODES ................................................................................................. 7 4 FACILITIES AND ACCREDITATIONS ..................................................................................................... 8 4.1 FACILITIES .................................................................................................................................... 8 4.2 LABORATORY ACCREDITATIONS AND LISTINGS ..................................................................... 8 5 TEST SYSTEM UNCERTAINTY .............................................................................................................. 9 6 SETUP OF EQUIPMENT UNDER TEST ............................................................................................... 10 6.1 RADIO FREQUENCY TEST SETUP 1 ......................................................................................... 10 6.2 RADIO FREQUENCY TEST SETUP 2 ......................................................................................... 10 6.3 CONDUCTED EMISSION TEST SETUP ..................................................................................... 11 6.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ......................................................... 12 6.5 SUPPORT EQUIPMENT .............................................................................................................. 12 7 TEST REQUIREMENTS......................................................................................................................... 13 7.1 OCCUPIED BANDWIDTH............................................................................................................ 13 7.2 FREQUENCY STABILITY ............................................................................................................ 15 7.3 RADIATED SPURIOUS EMISSION ............................................................................................. 17 7.4 CONDUCTED EMISSION TEST .................................................................................................. 30 8 ANTENNA APPLICATION ..................................................................................................................... 33 8.2 RESULT .......................................................................................................................................... 33 Report No. ES200731064W02-1 Page 3 of 33 Ver.1.0 TEST RESULT CERTIFICATION Applicant : ZKTECO CO.,LTD. Address： No.32,Pingshan Industrial Avenue,Tangxia Town,Dongguan City,Guangdong Province,China 523728 Manufacturer : ZKTECO CO.,LTD. Address： No.32,Pingshan Industrial Avenue,Tangxia Town,Dongguan City,Guangdong Province,China 523728 EUT : Smart Access Control Terminal Model Name : SpeedFace-V4L, MiniAC, SpeedFace-V4LM1 Trademark : N/A Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.225. The test results of this report relate only to the tested sample identified in this report. Date of Test : Aug. 6, 2020 to Sep. 13, 2020 Prepared by : Qiang Wang /Editor Reviewer : Sewen Guo /Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No. ES200731064W02-1 Page 4 of 33 Ver.1.0 1 EUT TECHNICAL DESCRIPTION Characteristics Description Device Type: RFID Modulation: ASK modulation Test sample 1# Operating Frequency Range(s): 13.553-13.567MHz Channel Frequency: 13.56MHz Number of Channels: 1 channel Antenna Type : Induction coil antenna Power Supply DC12V from adapter Test Voltage AC 230V/50Hz Adapter Model :ADS-40SI-12-3 Input:AC100-240V,50/60Hz,1.0A Max Output:DC12V,3.0A Temperature Range 0°C ~ +45°C Note: for more details, please refer to the User’s manual of the EUT. Report No. ES200731064W02-1 Page 5 of 33 Ver.1.0 2 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 2.1049 Occupied Bandwidth PASS 15.225(e) Frequency stability PASS 15.225(d) 15.209 Radiated Spurious Emissions PASS 15.207 Conducted Emission PASS NOTE1: N/A (Not Applicable) RELATED SUBMITTAL(S) / GRANT(S): This submittal(s) (test report) is intended for FCC ID: 2AJ9T-20801 filing to comply with Section 15.225 of the FCC Part 15, Subpart C Rules. Report No. ES200731064W02-1 Page 6 of 33 Ver.1.0 3 TEST MET…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS 1.1. Photos of Radiation Emission Measurement Spurious Emission Test Setup (Below 30MHz) Spurious Emission Test Setup (30MHz-1GHz) Spurious Emission Test Setup (Above 1GHz) 1.2. Conducted Emission Test ----------------The end----------------
