FCC ID: 2AJ9T-21004 RF Exposure Evaluation LIMIT The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 - - f/300 6 1500–100,000 - - 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 - - f/1500 30 1500–100,000 - - 1.0 30 Note: f = frequency in MHz EVALUATION METHOD Transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW, G = gain of antenna in linear scale; Pi = 3.1416, R = distance between observation point and center of the radiator in cm TEST RESULT Passed Not Applicable Radio Type Frequency range (MHz) Conducted Average Power (dBm) Maximum Tune-up (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result WIFI 2412-2472 17.44 17.50 0.0177 1.0000 Pass Note: 1) The maximum antenna gain is 2.05dBi 2) The exposure evaluation safety distance is 20cm.

DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 1.ElectricalSpecification: 2.TestItemsandEquipment CharacteristicsSpecificationsUnit OutlineDimensions17.5x18.3,L125 mm Frequency 2400-2500 MHz Impedance50Ω VSWR<2.0 PolarizationLinearPolarization Gain2.05 dBi Efficiency>40 % ConnectorTypeMHF-1-Plug Operatingtemperature -20 °C ~+85 °C StorageTemp -20 °C ~+50 °C TestitemsTestequipment SParameter 1.ReturnLoss 2.VSWR Networkanalyzer (AgilentE5071B) Thewholemachineof Passiveparameters 1.Frequency 2.Gain 3.RadiationPattern 1.3Dmicrowavedarkroom (5m*5m*5m) 2.Networkanalyzer (AgilentE5071B) Thewholemachineof Activeparameters 1.TRP 2.TIS 1.3Dmicrowavedarkroom (5m*5m*5m) 2.Comprehensivetestinstrument (CMW500) WIFI Antenna Model:UB01C Company Name:Dongguan Youbi Electronics Co.,LTD Company Address:Room 101,Building 2,No.9,Xinfa Road,Lin Village,Tangxia Town, Dongguan City,Guangdong Province,China DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 3.SParameter *VoltageStandingWaveRatio(VSWR) ReturnLoss(RL) RL=20*log10[(VSWR+1)/(VSWR-1) 4.EfficiencyandGain Frequency (MHz) 240024502500 Efficiency (%) 46.0346.4547.32 Gain (dBi) 1.631.442.05 Frequency (MHz) Return Loss(dB) VSWR 2400-19.161.24 2450-23.611.14 2500-17.501.30 DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 6 /11 5.RadiationPattern 5-1Antenna3DRadiationPattern 2400MHz 2450MHz 2500MHz DongguanYoubiElectronicsCo.,LTDHangzhouYoubigeElectronicsCo.,LTDShenzhenYoubiElectronicsCo.,LTD Room101,Building2,No.9,Room106,Building3,LetongSciencePark,Room106,BuildingA,XinzhengIndustrialPark, XinfaRoad,LinVillage,TangxiaTownNo.500QiuyiRoad,BinjiangDistrict57LiuxianRoad,Bao'anDistrict,Shenzhen Tel:+86-769-81777126Website：www.ubuant.com 5-2Antenna2DRadiationPattern Phi02D Phi902D Theta902D Vertical Plane Horizontal Plane

Page: 1 of 42 TEST REPORT For WiFi-2.4GHz Band Report No. ...................................... : CHTEW22120106 Report Verification: Project No.................................： SHT2210104805EW FCC ID ............................................. : 2AJ9T-21004 Applicant’s name ........................... : ZKTECO CO., LTD. Address ............................................. : No.32,Pingshan Industrial Avenue,Tangxia Town,Dongguan City,Guangdong Province,China 523728 Product Name ................................ : Smart Access Control Terminal Trade Mark ....................................... : - Model No. ......................................... : FA2000 Listed Model(s) ................................. : - Standard ......................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 Date of receipt of test sample..........: Dec.05, 2022 Date of testing.............................: Dec.05, 2022- Dec.21, 2022 Date of issue...............................: Dec.22, 2022 Result .................. ........................: PASS Compiled by ( Position+Printed name+Signature): File administrator Fanghui Zhu Supervised by (Position+Printed name+Signature): Project Engineer Caspar Chen Approved by (Position+Printed name+Signature): RF Manager Hans Hu Testing Laboratory Name ............. : Shenzhen Huatongwei International Inspection Co., Ltd. Address ............................................. : 1/F, Bldg 3, Hongfa Hi-tech Industrial Park, Genyu Road, Tianliao, Gongming, Shenzhen, China Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report merely correspond to the test sample. Report No.: CHTEW22120106 Page: 2 of 42 Date of issue: 2022-12-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) ` Contents 1. TEST S T AN D AR D S A N D R E P O R T VERS I O N 3 1.1. Test Standards 3 1.2. Report version 3 2. TEST DESCRIPTION 4 3. SUMMARY 5 3.1. Client Information 5 3.2. Product Description 5 3.3. Radio Specification Description 5 3.4. Testing Laboratory Information 6 4. TEST CONFIGURATION 7 4.1. Test frequency list 7 4.2. Descriptions of Test mode 7 4.3. Test mode 7 4.4. Test sample information 8 4.5. Support unit used in test configuration and system 8 4.6. Testing environmental condition 8 4.7. Statement of the measurement uncertainty 9 4.8. Equipment Used during the Test 10 5. TEST CONDITIONS AND RESULTS 12 5.1. Antenna Requirement 12 5.2. AC Conducted Emission 13 5.3. Peak Output Power 15 5.4. Power Spectral Density 16 5.5. 6dB bandwidth 17 5.6. 99% Occupied Bandwidth 18 5.7. Duty Cycle 19 5.8. Conducted Band edge and Spurious Emission 20 5.9. Radiated Band edge Emission 22 5.10. Radiated Spurious Emission 27 6. TEST SETUP PHOTOS 35 7. EXTERNAL AND INTERNAL PHOTOS 37 8. APPENDIX REPORT 42 Report No.: CHTEW22120106 Page: 3 of 42 Date of issue: 2022-12-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) ` 1. TEST STAND ARDS AND REPORT VERSION 1.1. Test Standards The tests were performed according to following standards: ‒ FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz ‒ ANSI C63.10:2013: American National Standard for Testing Unlicensed Wireless Devices ‒ KDB 558074 D01 15.247 Meas Guidance v05r02: Guidance for Compliance Measurements on Digital Transmission System, Frequency Hopping Spread Spectrum System, and Hybrid System Devices Operating under Section 15.247 of The FCC Rules 1.2. Report version Revision No. Date of issue Description N/A 2022-12-22 Original Report No.: CHTEW22120106 Page: 4 of 42 Date of issue: 2022-12-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) ` 2. TEST DESCRIPTION Report clause Test Items Standard Requirement Result Test Engineer 5.1 Antenna Requirement 15.203/15.247(c) PASS Xiaoxiao Li 5.2 AC Conducted Emission 15.207 PASS Junman Wang 5.3 Peak Output Power 15.247(b)(3) PASS Xiaoxiao Li 5.4 Power Spectral Density 15.247(e) PASS Xiaoxiao Li 5.5 6dB Bandwidth 15.247(a)(2) PASS Xiaoxiao Li 5.6 99% Occupied Bandwidth - PASS *1 Xiaoxiao Li 5.7 Duty cycle - PASS *1 Xiaoxiao Li 5.8 Conducted Band Edge and Spurious Emission 15.247(d)/15.205 PASS Xiaoxiao Li 5.9 Radiated Band Edge Emission 15.205/15.209 PASS Yifan Wang 5.10 Radiated Spurious Emission 15.247(d)/15.205/15.209 PASS Dongyang Wu Note: ‒ The measurement uncertainty is not included in the test result. ‒ *1: No requirement on standard, only report these test data. Report No.: CHTEW22120106 Page: 5 of 42 Date of issue: 2022-12-22 Shenzhen Huatongwei International Inspection Co., Ltd. Report Template Version: V04 (2022-01) ` 3. SUMMARY 3.1. Client Information Applicant: ZKTECO CO., LTD. Address: No.32,Pingshan Industrial Avenue,Tangxia Town,Dongguan City,Guangdong Province,China 523728 Manufacturer: ZKTECO CO., LTD. Address: No.32,Pingshan Industrial Avenue,Tangxia Town,Dongguan City,Guangdong Province,China 523728 3.2. Product Description Main unit information: Product Name: Smart Access Control Terminal Trade Mark: - Model No.: FA2000 Listed Model(s): - Power supply: DC 12V from Adapter Hardware version: V1.2 Software version: V1.2.1 Accessory unit information: Adapter information: Model: UES18LU-120150SPA Input: 100-240Va.c., 50/60Hz, 0.5A Output: 12.0Vd.c., 1.5A 18.0W 3.3. Radio Specification Description Support type *2 : 802.11b 802.11g 802.11n Support ba…

Text truncated - open the document above for the full version.

Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 1 of 35 APPENDIX REPORT Project No. SHT2210104805EW Radio Specification WIFI 2.4G Test sample No. YPHT22101048001 Model No. FA2000(13.56MHz) Start test date 2022-11-25 Finish date 2023-01-12 Temperature 25.6°C Humidity 39% Test Engineer Xiaoxiao Li Auditor Appendix clause Test item Result A Conducted Peak Output Power PASS B Power Spectral Density PASS C 6 dB Bandwidth PASS D 99% Occupied Bandwidth PASS E Duty Cycle PASS F Band edge and Spurious Emissions (conducted) PASS Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 2 of 35 Appendix A：Conducted Peak Output Power Type Channel Peak Output power (dBm) Average Output power (dBm) Limit (dBm) Result 802.11b 01 19.31 16.30 ≤ 30.00 Pass 06 19.02 16.54 11 18.77 16.25 802.11g 01 20.15 17.08 ≤ 30.00 Pass 06 20.56 17.44 11 20.36 17.27 802.11n (HT20) 01 19.34 16.22 ≤ 30.00 Pass 06 19.67 16.55 11 19.52 16.37 802.11n(HT40) 03 19.64 16.54 ≤ 30.00 Pass 06 19.59 16.71 09 19.49 16.62 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 3 of 35 Appendix B：Power Spectral Density Type Channel Power Spectral Density (dBm/30KHz) Limit (dBm/3KHz) Result 802.11b 01 0.62 ≤8.00 Pass 06 0.71 11 0.21 802.11g 01 -5.24 ≤8.00 Pass 06 -4.72 11 -5.25 802.11n(HT20) 01 -5.46 ≤8.00 Pass 06 -5.78 11 -5.62 802.11n(HT40) 03 -9.74 ≤8.00 Pass 06 -8.98 09 -9.43 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 4 of 35 Type: 802.11 b CH01 Date: 25.NOV.2022 08:18:58 CH06 Date: 25.NOV.2022 08:23:24 CH11 Date: 25.NOV.2022 08:25:12 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 5 of 35 Type: 802.11 g CH01 Date: 25.NOV.2022 08:27:10 CH06 Date: 25.NOV.2022 08:29:20 CH11 Date: 25.NOV.2022 08:31:08 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 6 of 35 Type: 802.11n(HT20) CH01 Date: 25.NOV.2022 08:33:31 CH06 Date: 25.NOV.2022 08:48:45 CH11 Date: 25.NOV.2022 08:39:11 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 7 of 35 Type: 802.11n(HT40) CH03 Date: 25.NOV.2022 09:35:56 CH06 Date: 25.NOV.2022 09:41:49 CH09 Date: 25.NOV.2022 09:44:29 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 8 of 35 Appendix C：6dB bandwidth Type Channel 6dB Bandwidth (MHz) Limit (MHz) Result 802.11b 01 9.96 ≥0.5 Pass 06 10.08 11 10.11 802.11g 01 16.59 ≥0.5 Pass 06 16.62 11 16.59 802.11n(HT20) 01 17.70 ≥0.5 Pass 06 17.70 11 17.76 802.11n(HT40) 03 36.48 ≥0.5 Pass 06 36.48 09 36.48 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 9 of 35 Type: 802.11 b CH01 Date: 25.NOV.2022 08:13:09 CH06 Date: 25.NOV.2022 08:22:45 CH11 Date: 25.NOV.2022 08:24:29 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 10 of 35 Type: 802.11 g CH01 Date: 25.NOV.2022 08:26:28 CH06 Date: 25.NOV.2022 08:28:37 CH11 Date: 25.NOV.2022 08:30:26 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 11 of 35 Type: 802.11n(HT20) CH01 Date: 25.NOV.2022 08:32:50 CH06 Date: 25.NOV.2022 08:47:58 CH11 Date: 25.NOV.2022 08:38:31 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 12 of 35 Type: 802.11n(HT40) CH03 Date: 25.NOV.2022 09:35:16 CH06 Date: 25.NOV.2022 09:41:28 CH09 Date: 25.NOV.2022 09:43:47 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 13 of 35 Appendix D：99% Occupied Bandwidth Type Channel 99% Bandwidth (MHz) Limit (kHz) Result 802.11b 01 14.99 - Pass 06 14.93 11 14.93 802.11g 01 16.87 - Pass 06 16.87 11 16.87 802.11n(HT20) 01 17.89 - Pass 06 17.89 11 17.89 802.11n(HT40) 03 35.84 - Pass 06 35.84 09 35.84 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 14 of 35 Type: 802.11 b CH01 Date: 25.NOV.2022 08:13:23 CH06 Date: 25.NOV.2022 08:22:53 CH11 Date: 25.NOV.2022 08:24:38 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 15 of 35 Type: 802.11 g CH01 Date: 25.NOV.2022 08:26:37 CH06 Date: 25.NOV.2022 08:28:45 CH11 Date: 25.NOV.2022 08:30:35 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 16 of 35 Type: 802.11n(HT20) CH01 Date: 25.NOV.2022 08:32:58 CH06 Date: 25.NOV.2022 08:48:07 CH11 Date: 25.NOV.2022 08:38:39 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 17 of 35 Type: 802.11n(HT40) CH03 Date: 25.NOV.2022 09:35:25 CH06 Date: 25.NOV.2022 09:41:36 CH09 Date: 25.NOV.2022 09:43:56 Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 18 of 35 Appendix E：Duty Cycle Modulation Type Test Frequency （MHz） T on time for single burst (ms) T period (ms) Duty cycle 1/T on time (kHz) 11b 2437 1.00 1.00 100% 1 11g 2437 1.00 1.00 100% 1 11n20 2437 1.00 1.00 100% 1 11n40 2437 1.00 1.00 100% 1 11b 11g Project No.: SHT2210104805EW Radio Specification: WIFI 2.4G Shenzhen…
