2AJ9T-FR1500SIRS485 Fingerprint Reader

Installation Guide FR1500S Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual. Installation 1 Dimensions(mm) Remove both the screws STEP 1 Procedure to be followed before installation Note: Not all the devices have the fingerprint cover. The real product prevails. 77.3 121.3 7.1 38.0 Installation 2 Take out the front panel as shown below STEP 2 Method 1: Mounting on the standard Single gang junction box Lay the cables from the desired hole in Single gang junction box and fix the machine part to the box part. The Single gang junction box's size recommendations: Location column: 83.3mm Inside of the box Depth: Minimum 36mm Outside the box size: maximum length 120mm , maximum width 76mm 8 3 . 3 m m 3 6 m m 1 2 0 m m 7 6 m m 3 Method 2: Mounting inside the wall STEP 1 Place the mounting sticker to the place where device needs to be installed STEP 2 Drill fixing holes and dig mounting groove deep of 36mm 10 11 Instruction for the Mounting Paper Before the device is fastened, please stick the paper to the place where you want to install it, then make holes and lay cables according to the mounting paper. Fixing Hole Fixing Hole Mounting Paper (only for your reference) The depth of the installation groove is 36mm wall 3 6 m m STEP 3STEP 4 If cables need to be laid from behind then it must be done before installing Install the device with the screws After installing the back plate attach the machine part in the same reverse manner as shown in previous page STEP 5

Wiring Terminals This reader is an innovative Silk ID reader. It needs to be connected to a host machine so that fingerprint information can be transferred through Rs485. Reader wires nomenclature and Dip Switch Dip Switch RED 12V BLACK GND YELLOW 485+ PURPLE 485- BLACK GND +12V GND 485- 485+ E X T - + DC12V 1 2 8 Connected as inBIO Pro Reader(with External 485), maximum 8 readers can be connected. The reader requires a separate power supply. 4 1. Connection with a Control Panel. STATE PWR EXTRS485 PCRS485 SWITCH so on...... DC12V - + - + > Dip Switch setting with control panel Terminal Resistance 8 4 2 1 12 3 4 5 6 Switch SettingSwitch Setting Address Address 1 2 3 4 5 6 7 8 12 3 4 5 6 12 3 4 5 6 12 3 4 5 6 12 3 4 5 6 12 3 4 5 6 12 3 4 5 6 12 3 4 5 6 1 2 3 4 5 6 5 Working Principle Number 1, 2, 3, 4 of the dip switch are used to set the address of RS485, 5 is the restart switch, and 6 is the Terminal Resistance. Number 5 is the restart switch: dial up and dial down. The machine will restart. The right side figure shows the address number setting. Number 6 switch is used to set the terminal resistance in RS485. Communication: If the 485 communication wire is longer, than 100 meters, it is needed to set the number 6 dip switch of the last reader to ON state, that is parallel a terminal resistance of 120 ohm between 485+ and 485-. +12V GND GND 485+ 485- 2. Connection with a Standalone Access Controller 6 + 1 2 V G N D 4 8 5 A G N D 4 8 5 B 1 4 +12V GND 1 5 GND 485A 485B When using the reader with Standalone access controller device, please move the dial code “1” to the ON position as shown above. Verification Proccess 7 Safety Precautions 1. Power cable should be connected at last, after all the wiring. If the device is working abnormally, immediately shutdown the device. 2. Please read the terminals description and wiring by rule strictly. Any damage caused by improper operations will be out of the range of our guarantee. 3. Please connect the ‘GND’ before all the other wiring especially under the serious electrostatic environment. 4. Keep the exposed part of wire less than 5mm to avoid unexpected connection, and result in machinery damage. 5. If the distance between power supply and device is little long, please do not use the Internet cable or other types of cable instead. When choosing the power supply cable, you should consider that the transmission distance may cause voltage attenuation. Connection with the controller: Unsuccessful:LED flashes blue light twice every one second. Successfully:LED flashes blue light once every one second. When verifying the fingerprint or punching the card: Successful Verification: Authentication error: Data Error: Timeout: Authentication failed: Red LED, two short BEEP No rights:Red LED, three short BEEP Verify unfinished: Red LED flashes three times Green LED lights, short BEEP Red LED lights, two short and a long BEEP Red LED lights, one short and a long BEEP Red LED lights, four short BEEP

Copyright © 2020 ZKTECO CO., LTD. All Rights Reserved. Tangxia Town, Dongguan, China. No. 26, 188 Industrial Road, Phone : +86 769 - 82109991 Fax : +86 755 - 89602394 www.zkteco.com FCC warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help.
