2AJA3EDSP-5000Triad Grip Portable Bluetooth LED Party Speaker

Bluetooth 5.2 version Transmission distance: >10 meters Output power: 40Wx2 Frequency response: 55Hz~20KHz Speaker: 4"x2+1"x2 Input power: 5V 3A Maximum power consumption: 96W Built-in battery: 18650 lithium battery 11.1V 3600mAh Audio input interface: Standard ɸ3.5mm jack Bluetooth/USB/TF/AUX 80W DSP high-fidelity amplifier, low distortion and low noise. 2 channel high-fidelity speaker, sound more natural and delicate. Bluetooth 5.2 version Bluetooth TWS function Colorful LED light 1.M Press to switch BT,USB,TF and AUX mode cyclic.(Please insert USB,TF card and AUX cable). Long press M key, TWS Turn ON / OFF. 2. TWS Press to turn on or off TWS connection. 3. Repeat Press to replay the current music, press again to replay all music. 4. - Press to decrease volume / previous song. 5. Press and hold 3 seconds to turn ON /OFF speaker. 6. + Press to increase volume / next song. 7. short press to play / pause,long press to disconnect. 8. EQ Press to select EQ preset from Normal/ROCK/CLASSIC and normal cyclic. 9. LED light Press to switch lighting mode,press and hold to turn on/off light. 10. AUX Connect external audio device. 11. TF Inset TF card that had install MP3/WAV/WMA/APE/FLAC. 12. USB Inset USB that had install MP3/WAV/WMA/APE/FLAC. 13. Charge LED Charge LED Red led turn on when charging battery,it will turn green after fully charged. 14. TYPE-C Plug type C charging cable to charge your speaker. Please turn off speaker while charging. Technical specification: Feature: Tone Prompt There is a tone prompt when turning on or off speaker. There is a tone prompt when volume increase to maximum. There is a tone prompt when battery low power, speaker will shut down after 3 times tone prompt battery low power. USB and TF card 1.Insert USB or TF card that had MP3/WMA/WAV/APE/FLAC music file installed. 2.Speaker playback music automatically. 3.Press “+” or “-” to increase or decrease volume. 4.Press and hold “-” or “+” to previous or next music program. 5.Press “PLAY/PAUSE” to pause or resume music program. AUX 1.Insert audio cable into AUX port. Connect another cable plug to your external audio device. 2.Press “- “ or “+” to decrease or increase volume. 3.Press “PLAY/PAUSE” to mute or resume AUX program. Problem Can not turn on speaker No Sound Sound is distorted from AUX input 1.Volume is too low. 2.AUX/BT source volume is too low. AUX source volume is too high. Reduce the output volume of the AUX source. 1.Increase the volume. 2.Increase the output volume. of the AUX/BT source. Reasons Battery power low.Please charge unit used 5V/3A adapter via Type C USB port. Solution Trouble shooting Bluetooth TWS connection You need two party speaker, turn on the power of both speaker. 1.Press “TWS” to turn on TWS function of both speaker. It will connect automatically. 2.Enable Bluetooth on your audio device (For example a smartphone)and search for available Bluetooth connections. select the " EDSP-5000 " from the list. 3. Once paired an audible sound is heard through the speakers. 4. You can now begin playback from the audio device and the output will playback through the two speaker as a stereo audio speaker. Bluetooth 1.Press “POWER” to turn on speaker and it is already in Bluetooth mode. 2.Enable Bluetooth on your audio device (For example a smartphone)and search for available Bluetooth connections. select the " EDSP-5000 " from the list. 3. Once paired an audible sound is heard through the speakers. 4. You can now begin playback from the audio device and the output will playback through the speaker. 5. When using a mobile phone as an audio source and you receive a phone call the audio playback stops 6.Press “+” or “-” to increase or decrease volume. 7.Press “PLAY/PAUSE” to pause or resume music program. Button:Quick use: EDSP-5000 size : 70*122mm. Accordion fold 128g coated paper , 2 sides black print 正面 反面
    1.2.3.4.5.6.7.8.9. 10.11.12.13.14. FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. RF warning statement: The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

(GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP.) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2024-07-15 FCC ID: (2AJA3EDSP-5000) Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing (“GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP.”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing (“GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP.”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates)as an entity producing “covered” equipment. Applicant: GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Address: 2025, Block D, South Phase, Longguang Jiudiamond Business Center, Hongshan Community, Minzhi Street, Longhua District, Shenzhen, Guangdong Province, China Contact Person: Victoria Visnenko Tel.: Sales Manager Email: [email protected] Sincerely, Signature:

GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Address: 2025, Block D, South Phase, Longguang Jiudiamond Business Center, Hongshan Community, Minzhi Street, Longhua District, Shenzhen, Guangdong Province, China Date: 2024-07-15 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(7) Filing SUBJECT: FCC Application for FCC ID: 2AJA3EDSP-5000 FRN: 0025777293 (“GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP.”) certifies that, as of the date of the filing of the application, Naxa Electronics. Inc. is our designated U.S. agent for service of process for the above referenced FCC ID. (“GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP.”) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Naxa Electronics. Inc accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Naxa Electronics. Inc Address: 2320 E. 49'" St., Vernon CA 90058 FRN: 0025676834 Contact Person: Danielle Phillips Email: [email protected] Sincerely, Signed on behalf of GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Signed on behalf of Naxa Electronics. Inc Name: Victoria Visnenko Name: Danielle Phillips Title: Sales Manager Title: Manager Date: 2024-07-15 Date: 2024-07-15

Product specification Quick Reference Date Antenna module on the system board Frequenc Range 2400 ~ 2500MHz Ant. Port Input Pwr. (dBm) 0 (Typ. BT class 2 output power) Tot. Rad. Pwr. (dBm) -1.2 (Input pwr – loss pwr) Peak EIRP(d Bm) 1.2 Directivity (dBi) 1 (all direction antenna) Efficiency (dB) 6 0.2 % Gain (dBi) 1.68(Avg Gain XY-plane) Maximum Power (dBm) 1.7 (XY-plane) Minimum Power (dBm) -4 (XY-plane) Avg. Power (dBm) -0.5(XY-plane) Input Impendence(ohm) 50 Polarization Type V ertical & Horizontal V . S .W . R < 1.4 All the technical data and information contained herein are subject to ch ange without prior notice Antenna Layout & modu le on the system board Antenna Gain Gain Table Unit in dBi @2.44GHz XY-plane XZ-plane YZ-plane Efficiency Peak Avg. Peak Avg. Peak Avg. Module Board 1.35-0.481.68-3.831.11-2.996 0.2 % Manufacturer: GUA NGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Address: BBK Road of Wusha, Changan town, Dongguan city, Guangdong province, China Antenna Type PCB Antenna Retum Loss The Environment of Antenna Radiation Pattem 3D radiation pattern diagram XY-plane XZ-plane YZ-plane

GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Date:2024-07-15 Product Model Number: EDSP-5000, EDSP-5001, EDSP-5002, EDSP-5003, EDSP-5000-XX FCC ID: 2AJA3EDSP-5000 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Sales Manager Email: [email protected] Telephone: +(86)-769-8542 5655 On behalf of: GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP.

GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 15, 2024 Subject; Request for Confidentiality FCC ID: 2AJA3EDSP-5000 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Victoria Visnenko Title: Sales Manager

GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Declaration on Model Differences We, GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. BBK Road of Wusha, Changan town, Dongguan city, Guangdong province, China Declare that the following product(s): Product Name: Triad Grip Portable Bluetooth LED Party Speaker Model No.: EDSP-5000, EDSP-5001, EDSP-5002, EDSP-5003, EDSP-5000-XX FCC ID: 2AJA3EDSP-5000 Utilize the identical circuit design, PCB layout, shielding and interface with (EDSP-5000), only differ in model name. Therefore this application can be regarded as identical in performance to the submitted test sample. The manufacturer would take all the responsibilities for the above product(s). For and on behalf of Dongguan city, Guangdong province, China Authorized person Location Name: Victoria Visnenko Position: Manager Date of issue: 2024-0 7-15 *I hereby declare that I am entitled to sign on behalf of the applicant and that the information supplied is correct and complete.

Page 1 of 5 Report No.: 8228EU010213W-AB ANNEX B EXTERNAL PHOTOS PHOTO 1 PHOTO 2 Page 2 of 5 Report No.: 8228EU010213W-AB PHOTO 3 PHOTO 4 Page 3 of 5 Report No.: 8228EU010213W-AB PHOTO 5 PHOTO 6 Page 4 of 5 Report No.: 8228EU010213W-AB PHOTO 7 PHOTO 8 Page 5 of 5 Report No.: 8228EU010213W-AB PHOTO 9 --- End ---

Label Location On EUT Label Sizes: 56*29*R2mm

Page 1 of 4 Report No.: 8228EU010213W-AC ANNEX C INTERNAL PHOTOS PHOTO 1 PHOTO 2 Page 2 of 4 Report No.: 8228EU010213W-AC PHOTO 3 PHOTO 4 Page 3 of 4 Report No.: 8228EU010213W-AC PHOTO 5 PHOTO 6 PCB Antenna Page 4 of 4 Report No.: 8228EU010213W-AC PHOTO 7 PHOTO 8 --- End ---

RF EXPOSURE EVALUATION FCC ID: 2AJA3EDSP-5000 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b): Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. B T: Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (dBm) Distance (mm) Calculation results Limit Operating Mode 2402 0.61 0.61±1 1.61 5 0.449 3 BDR&EDR 2441 0.84 0.84±1 1.84 5 0.477 3 2480 0.33 0.33±1 1.33 5 0.428 3 2402 2.80 2.80±1 3.80 5 0.744 3 2441 3.11 3.11±1 4.11 5 0.805 3 2480 2.54 2.54±1 3.54 5 0.712 3 2402 3.25 3.25±1 4.25 5 0.825 3 2441 3.54 3.54±1 4.54 5 0.889 3 2480 2.86 2.86±1 3.86 5 0.766 3 Test Results: PASS.

TEST REPORT Report No.: 8228EU010213W Applicant: GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Address: BBK Road of Wusha, Changan town, Dongguan city, Guangdong province, China Product Name: Triad Grip Portable Bluetooth LED Party Speaker Model No.: EDSP-5000 (refer to clause 2.4) Trademark: Emerson FCC ID: 2AJA3EDSP-5000 Test Standard(s): 47 CFR Part 15 Subpart C Date of Receipt: Apr. 11, 2024 Test Date: Apr. 11, 2024 – May 25, 2024 Date of Issue: Jul. 12, 2024 ISSUED BY: SHENZHEN EU TESTING LABORATORY LIMITED Prepared by: Reviewed and Approved by: ____________________ _____________________ Mikey Zhu/ Engineer Sally Zhang/ Manager Page 2 of 40 Report No.: 8228EU010213W TRF No.: FCC Part 15.247 (A01) Revision Record Report Version Issued Date Description Status V0 Jul. 12, 2024 Original Valid Page 3 of 40 Report No.: 8228EU010213W TRF No.: FCC Part 15.247 (A01) Table of Contents 1 COVER PAGE .................................................................................................................................. 1 2 GENERAL INFORMATION ...................................................................................................................... 5 2.1 APPLICANT INFORMATION .................................................................................................................. 5 2.2 MANUFACTURER INFORMATION .......................................................................................................... 5 2.3 FACTORY INFORMATION ..................................................................................................................... 5 2.4 GENERAL DESCRIPTION OF E.U.T. ..................................................................................................... 5 2.5 TECHNICAL INFORMATION OF E.U.T. .................................................................................................. 6 3 TEST SUMMARY ...................................................................................................................................... 7 3.1 TEST STANDARD ............................................................................................................................... 7 3.2 TEST VERDICT ................................................................................................................................... 7 3.3 TEST LABORATORY ........................................................................................................................... 7 4 TEST CONFIGURATION .......................................................................................................................... 8 4.1 TEST ENVIRONMENT .......................................................................................................................... 8 4.2 TEST EQUIPMENT .............................................................................................................................. 8 4.3 DESCRIPTION OF SUPPORT UNIT ........................................................................................................ 9 4.4 TEST MODE ...................................................................................................................................... 9 4.5 MEASUREMENT UNCERTAINTY ........................................................................................................... 9 4.6 DEVIATION FROM STANDARDS ........................................................................................................... 9 4.7 ABNORMALITIES FROM STANDARD CONDITION ................................................................................... 9 5 TEST ITEMS ........................................................................................................................................... 10 5.1 ANTENNA REQUIREMENT .................................................................................................................. 10 5.1.1 Test Requirement .............................................................................................................. 10 5.1.2 Antenna Anti-Replacement Construction .......................................................................... 10 5.1.3 Antenna Gain .................................................................................................................... 10 5.2 CONDUCTED EMISSION AT AC POWER LINE ..................................................................................... 11 5.2.1 Test Requirement .............................................................................................................. 11 5.2.2 Test Setup Diagram .......................................................................................................... 11 5.2.3 Test Procedure .................................................................................................................. 11 5.2.4 Test Data ........................................................................................................................... 11 5.3 OCCUPIED BANDWIDTH ................................................................................................................... 14 5.3.1 Test Requirement .............................................................................................................. 14 5.3.2 Test Setup Diagram .......................................................................................................... 14 5.3.3 Test Procedure .................................................................................................................. 15 5.3.4 Test Data ........................................................................................................................... 15 5.4 MAXIMUM CONDUCTED OUTPUT POWER .......................................................................................... 16 5.4.1 Test Requirement .............................................................................................................. 16 5.4.2 Test Setup Diagram ...................…

Text truncated - open the document above for the full version.

Page 1 of 54 Report No.: 8228EU010213W-AD ANNEX D TEST DATA For Project No.: 8228EU010213W Client: GUANGDONG LEIYON INTELLIGENCE TECHNOLOGY CORP. Product Description: Triad Grip Portable Bluetooth LED Party Speaker Model No.: EDSP-5000 FCC ID: 2AJA3EDSP-5000 Technology: Bluetooth BDR&EDR Test Engineer: Test Date: 2024-05-25 Page 2 of 54 Report No.: 8228EU010213W-AD Test Summary Item Result Bandwidth Pass Maximum Conducted Output Power Pass Carrier Frequency Separation Pass Number of Hopping Frequencies Pass Time of Occupancy (Dwell Time) Pass Unwanted Emissions In Non-restricted Frequency Bands Pass Page 3 of 54 Report No.: 8228EU010213W-AD 1. Bandwidth 1.1 OBW 1.1.1 Test Result Mode TX Type Frequency (MHz) Packet Type ANT 99% Occupied Bandwidth (MHz) Verdict Result Limit GFSK SISO 2402 DH5 1 0.825 / Pass 2441 DH5 1 0.827 / Pass 2480 DH5 1 0.825 / Pass π/4DQPSK SISO 2402 2DH5 1 1.173 / Pass 2441 2DH5 1 1.175 / Pass 2480 2DH5 1 1.174 / Pass 8DPSK SISO 2402 3DH5 1 1.178 / Pass 2441 3DH5 1 1.178 / Pass 2480 3DH5 1 1.179 / Pass Page 4 of 54 Report No.: 8228EU010213W-AD 1.1.2 Test Graph GFSK_DH5_LCH_2402MHz_Ant1_NTNV GFSK_DH5_MCH_2441MHz_Ant1_NTNV Page 5 of 54 Report No.: 8228EU010213W-AD GFSK_DH5_HCH_2480MHz_Ant1_NTNV π/4DQPSK_2DH5_LCH_2402MHz_Ant1_NTNV Page 6 of 54 Report No.: 8228EU010213W-AD π/4DQPSK_2DH5_MCH_2441MHz_Ant1_NTNV π/4DQPSK_2DH5_HCH_2480MHz_Ant1_NTNV Page 7 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_LCH_2402MHz_Ant1_NTNV 8DPSK_3DH5_MCH_2441MHz_Ant1_NTNV Page 8 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_HCH_2480MHz_Ant1_NTNV Page 9 of 54 Report No.: 8228EU010213W-AD 1.2 20dB BW 1.2.1 Test Result Mode TX Type Frequency (MHz) Packet Type ANT 20dB Bandwidth (MHz) Verdict Result Limit GFSK SISO 2402 DH5 1 0.939 / Pass 2441 DH5 1 0.935 / Pass 2480 DH5 1 0.935 / Pass π/4DQPSK SISO 2402 2DH5 1 1.295 / Pass 2441 2DH5 1 1.292 / Pass 2480 2DH5 1 1.293 / Pass 8DPSK SISO 2402 3DH5 1 1.310 / Pass 2441 3DH5 1 1.308 / Pass 2480 3DH5 1 1.308 / Pass Page 10 of 54 Report No.: 8228EU010213W-AD 1.2.2 Test Graph GFSK_DH5_LCH_2402MHz_Ant1_NTNV GFSK_DH5_MCH_2441MHz_Ant1_NTNV Page 11 of 54 Report No.: 8228EU010213W-AD GFSK_DH5_HCH_2480MHz_Ant1_NTNV π/4DQPSK_2DH5_LCH_2402MHz_Ant1_NTNV Page 12 of 54 Report No.: 8228EU010213W-AD π/4DQPSK_2DH5_MCH_2441MHz_Ant1_NTNV π/4DQPSK_2DH5_HCH_2480MHz_Ant1_NTNV Page 13 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_LCH_2402MHz_Ant1_NTNV 8DPSK_3DH5_MCH_2441MHz_Ant1_NTNV Page 14 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_HCH_2480MHz_Ant1_NTNV Page 15 of 54 Report No.: 8228EU010213W-AD 2. Maximum Conducted Output Power 2.1 Power 2.1.1 Test Result Mode TX Type Frequency (MHz) Packet Type Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit GFSK SISO 2402 DH5 0.61 <=30 Pass 2441 DH5 0.84 <=30 Pass 2480 DH5 0.33 <=30 Pass π/4DQPSK SISO 2402 2DH5 2.80 <=20.97 Pass 2441 2DH5 3.11 <=20.97 Pass 2480 2DH5 2.54 <=20.97 Pass 8DPSK SISO 2402 3DH5 3.25 <=20.97 Pass 2441 3DH5 3.54 <=20.97 Pass 2480 3DH5 2.86 <=20.97 Pass Page 16 of 54 Report No.: 8228EU010213W-AD 2.1.2 Test Graph GFSK_DH5_LCH_2402MHz_Ant1_NTNV GFSK_DH5_MCH_2441MHz_Ant1_NTNV Page 17 of 54 Report No.: 8228EU010213W-AD GFSK_DH5_HCH_2480MHz_Ant1_NTNV π/4DQPSK_2DH5_LCH_2402MHz_Ant1_NTNV Page 18 of 54 Report No.: 8228EU010213W-AD π/4DQPSK_2DH5_MCH_2441MHz_Ant1_NTNV π/4DQPSK_2DH5_HCH_2480MHz_Ant1_NTNV Page 19 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_LCH_2402MHz_Ant1_NTNV 8DPSK_3DH5_MCH_2441MHz_Ant1_NTNV Page 20 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_HCH_2480MHz_Ant1_NTNV Page 21 of 54 Report No.: 8228EU010213W-AD 3. Carrier Frequency Separation 3.1 Ant1 3.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) Packet Type Channel Separation (MHz) 20dB Bandwidth (MHz) Limit (MHz) Verdict GFSK SISO HOPP DH5 1.000 0.939 >=0.939 Pass π/4DQPSK SISO HOPP 2DH5 1.001 1.295 >=0.863 Pass 8DPSK SISO HOPP 3DH5 1.001 1.310 >=0.873 Pass Page 22 of 54 Report No.: 8228EU010213W-AD 3.1.2 Test Graph GFSK_DH5_HOPP_Ant1_NTNV π/4DQPSK_2DH5_HOPP_Ant1_NTNV Page 23 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_HOPP_Ant1_NTNV Page 24 of 54 Report No.: 8228EU010213W-AD 4. Number of Hopping Frequencies 4.1 HoppNum 4.1.1 Test Result Mode TX Type Frequency (MHz) Packet Type Num of Hopping Frequencies Verdict ANT1 Limit GFSK SISO HOPP DH5 79 >=15 Pass π/4DQPSK SISO HOPP 2DH5 79 >=15 Pass 8DPSK SISO HOPP 3DH5 79 >=15 Pass Page 25 of 54 Report No.: 8228EU010213W-AD 4.1.2 Test Graph GFSK_DH5_HOPP_Ant1_NTNV π/4DQPSK_2DH5_HOPP_Ant1_NTNV Page 26 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH5_HOPP_Ant1_NTNV Page 27 of 54 Report No.: 8228EU010213W-AD 5. Time of Occupancy (Dwell Time) 5.1 Ant1 5.1.1 Test Result Ant1 Mode TX Type Frequency (MHz) Packet Type Duration of Single Pulse (ms) Observation Period (s) Num of Pulse in Observation Period Dwell Time (ms) Limit (ms) Verdict GFSK SISO HOPP DH1 0.382 31.600 320 122.240 <=400 Pass DH3 1.640 31.600 165 270.600 <=400 Pass DH5 2.888 31.600 115 332.120 <=400 Pass π/4DQPSK SISO HOPP 2DH1 0.398 31.600 320 127.360 <=400 Pass 2DH3 1.646 31.600 161 265.006 <=400 Pass 2DH5 2.898 31.600 97 281.106 <=400 Pass 8DPSK SISO HOPP 3DH1 0.396 31.600 320 126.720 <=400 Pass 3DH3 1.644 31.600 154 253.176 <=400 Pass 3DH5 2.900 31.600 108 313.200 <=400 Pass Page 28 of 54 Report No.: 8228EU010213W-AD 5.1.2 Test Graph GFSK_DH1_HOPP_Ant1_NTNV GFSK_DH1_HOPP_Ant1_NTNV Page 29 of 54 Report No.: 8228EU010213W-AD GFSK_DH3_HOPP_Ant1_NTNV GFSK_DH3_HOPP_Ant1_NTNV Page 30 of 54 Report No.: 8228EU010213W-AD GFSK_DH5_HOPP_Ant1_NTNV GFSK_DH5_HOPP_Ant1_NTNV Page 31 of 54 Report No.: 8228EU010213W-AD π/4DQPSK_2DH1_HOPP_Ant1_NTNV π/4DQPSK_2DH1_HOPP_Ant1_NTNV Page 32 of 54 Report No.: 8228EU010213W-AD π/4DQPSK_2DH3_HOPP_Ant1_NTNV π/4DQPSK_2DH3_HOPP_Ant1_NTNV Page 33 of 54 Report No.: 8228EU010213W-AD π/4DQPSK_2DH5_HOPP_Ant1_NTNV π/4DQPSK_2DH5_HOPP_Ant1_NTNV Page 34 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH1_HOPP_Ant1_NTNV 8DPSK_3DH1_HOPP_Ant1_NTNV Page 35 of 54 Report No.: 8228EU010213W-AD 8DPSK_3DH3_HOPP_Ant1_NTNV 8DPSK_3DH3_HO…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: 8228EU010213W-AA ANNEX A TEST SETUP PHOTOS PHOTO 1 Photo of Power Line Conducted Emission Test PHOTO 2 Photo of Radiated Emission Test (below 1GHz) Page 2 of 2 Report No.: 8228EU010213W-AA PHOTO 3 Photo of Radiated Emission Test (above 1GHz) --- End ---
