Quick Start Guide VANATOO ® TRANSPARENT ONE ENCORE PLUS ™ POWERED SPEAKERS ™ 1 2 Unpack Your System 1) Active speaker 2) Passive speaker 3) 2 Grills 4) IR remote control 5) Optional isolation feet 6) USB A to USB B cable 7) 3.5 mm to 3.5 mm cable 8) Four conductor speaker wire 9) 3.5 mm to RCA “Y” cable 10) AC power cord 11) Quick Start Guide and a Safety Sheet Connect the Speakers TURN OVER 1 7 9 10 8 2 4 The included speaker interconnect cable with screw-on collar connectors makes this quick and easy. 6 3 Connect Power 1. Make sure the power switch (2) is in the OFF position. 2. Plug the AC power cord into the active speaker. 3. Plug the AC power cord into the power outlet. 4 Connect Your Audio Source Turn the volume controls on the speaker (1) and on the audio source both to minimum. 1. Analog (3) — Connect your source using the included using 3.5mm to 3.5mm cable or 3.5mm to RCA cable as appropriate for your source component. 2. Digital Coax (4) — Connect your source component using a 75 ohm digital coaxial RCA cable. 3. Optical (5) — Connect your source component to the Vanatoo T1E Plus using a Toslink optical cable. 4. USB (6) — Connect your computer to the T1E Plus using the supplied USB A to USB B cable. Select the Vanatoo T1E Plus in your computer’s audio settings. 5. Bluetooth — a. Press and release the “Pair-Prog” button (7) on the rear of the active speaker, or press “Enable” and then “BT Pair” on the remote control. The bluetooth interface will remain in pair mode for 2 minutes. b. Ensure Bluetooth is turned-on on your source device and pair with the Vanatoo T1E Plus. c. Ensure your source device is connected to the Vanatoo T1E Plus over Bluetooth and play music! PAIR-PROG 100-240V-50/60 Hz 148W SERVICE 4 3 7 8 9 5 6 1 2 5 3 7 8 9 Listen to Music! Remote Control Optional Settings Turn the power switch to the ON position (2). The blue LED (8) will light up within 5 seconds to indicate power to the unit. In most applications you can set the T1E Plus volume control to 100% and adjust the volume up/down from your source (Computer, Bluetooth device, etc). The included IR Remote Control is especially handy when your T1E Plus is used with a TV, or for switching sources, adjusting bass and treble, etc. Note that you must hit the “Enable” button to enable the other buttons inside the rectangular box for 15 seconds. The T1E Plus has a lot of setup options, such as enabling the speakers to play mono, disabling sleep mode, varying the LED brightness, connecting a subwoofer and alternate bass profiles for room placement. Go to www.vanatoo.com/ support/downloads to download the user manual for a full description of the T1E Plus and its setup options. CONGRATULATIONS!! That’s it! We hope you enjoy your Vanatoo Transparent One Encore Plus powered speakers. For additional setup up information, connectivity options, and the troubleshooting guide, check out the Transparent One Encore Plus Owner’s Guide or visit us at www.vanatoo.com. Contact Us Email: [email protected] Copyright 2023 Vanatoo LLC, all rights reserved “Vanatoo” is a registered trademark, “Vanatoo Technology Serving Art” logo and “Transparent One Encore Plus” are trademarks of Vanatoo LLC 5 Designate Left-Right speaker Set the Left–Right switch (9) to designate whether the active speaker is located to your right or left (as you face the speakers). This ensures the music is recreated as it was recorded. 6 Install the Grills Grills come in individual plastic bags. Simple magnetic mounting (no or little alignment necessary). Can go either way such that the “Vanatoo” logo is upright on the bottom. 1. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point, within an equilateral triangle, is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel. Place the equipment near a main power supply outlet and make sure that you can easily access the power breaker switch. WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back panel or included power supply of the product. Operation from other voltages other than those indicated may cause irreversible damage to the product and void the product’s warranty. The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into voltages in which the product was not designed to operate. If the product is equipped with a detachable power cord, use only the type provided with your product or by your local distributor and/or retailer. If you are unsure of the correct operational voltage, please contact your local distributor and/or retailer. 2. To prevent risk of fire or electric shock, avoid overloading the wall outlet, extension cords. 3. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as vases, shall not be placed on apparatus. 4. Read these instructions. 5. Keep these instructions. 6. Heed all warnings. 7. Follow all instructions. 8. Do not use this apparatus near water. 9. Clean only with dry cloth. 10. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 11. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 12. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades with one wider than the …
