2AJD6-722RBaby Monitor

SHENZHEN LOFTYNN INTELLIGENCE CO., LTD.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Mar 09, 2021
Application Purpose: Original Equipment
Date of Application: Mar 09, 2021
Equipment Note: Baby Monitor
Frequency Range: 2410.87500000 - 2471.62500000
Company: SHENZHEN LOFTYNN INTELLIGENCE CO., LTD.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Get to know us at: www.axvue.com Please read the following instructions and warnings carefully Keep this instruction manual for future. For technical support see FAQ page. For adult use only. Adapters: INSTRUCTION MANUAL Model- E722 Revised at 12/2020 AXVUE E722 Video Baby Monitor with 2.8'' LCD Screen and Two Cameras The SCAN, SELECT, ADD, DELETE, VIEW CAMERA options are only available when multiple cameras connected with the monitor. Order extra cameras by visiting us at www.axvue.com or search “Axvue Baby monitor” on Amazon. 1. LED* 2. Microphone 3. Power/Video 4. Talk Back/Zoom 5. Volume Up/Up 6. Menu/OK 7. Right 8. Volume Down/Down 9. Left 10. Speaker 11. Battery Compartment 12. DC Jack 13. Kickstand × 3× 1× 2 Power & Low BatterySound Lights *LED Keep the distance between sensor and body at least 0.6 inch for accurate temperature result. 1. Night-Vision LED 2. Lens 3. Microphone 4. Speaker 5. Power/Code 6. Temperature Sensor 7. DC Jack 8. Wall Mounting Hole 0.6 in Monitor: TO USE PORTABLE/BATTERY MODE Step 1: Charge the battery for at least 8 hours before using portable/battery mode. Step 2: Make sure the adapter is plugged into camera. Step 3: The battery life can be up to 10 hours if it is fully charged. Battery life will be shortened if recharging it continuously. Unplug the power adapter when you are not using it for a long time. Please charge the battery for 6 ~ 8 hours before using the product. TO USE PLUGGED-IN MODE Step 1: Place the monitor display in living room, bedroom or any place you want to watch your baby. Use adapter to connect camera with electrical outlet. Step 2: Turn on monitor by pressing Power/Video“ ” button for 6 seconds until axvue logo or video shows up on the screen. Step 3: Press Power/Video“ ” button to turn off the video if you only need to hear the voice. Step 4: Turn off the monitor completely by pressing and holding Power/Video“ ” button for 5 seconds. The monitor and camera are paired before shipment. If it is unpaired for some reason, please refer to the following steps: TO PAIR MONITOR AND CAMERA (ADD CAMERA) Step 1: Make sure the camera and monitor are in the same place. Step 2: Step 3: Make sure the power adapter is plugged into camera and turn on the camera by pressing Power/Code“ ” button for 6 seconds. Turn on monitor by pressing and holding Power/Video “ ” button for 6 seconds. Step 5: Step 4: Red LED flashs vox TEMP C F 1324 1324 4 2 3 1 65 Press Press SETUP & USE 3 feet Figure 1 3 feet Figure 2 Please charge the battery for at least 8 hours before using the product. Step 1: Test reception first, put the camera in a suitable place that will provide you the best view of your baby in the crib (Note: Do not hang up the camera firmly until the initial installation test is completed). Plug the adapter into the wall outlet and turn on the camera. Step 2: Turn on the monitor by pressing and holding the Power/ Video “ ” button for 6 seconds until “axvue” shows up, then the video will show up on the screen immediately. If the video does not show up, please refer to “TO PAIR MONITOR AND CAMERA (ADD CAMERA)” on the next page. If the video shows up, the initial installation test is completed, then you can set up the camera according to the instruction below. Set Up Camera: Place the camera on a flat surface, such as a wardrobe or shelf (Figure 1). Or hang it on the wall (Figure 2). No matter wherever to place the camera, please make sure to keep it away from the crib for at least 3 feet and all power cords should be placed behind the camera properly. Then adjust the angle of the camera lens until the entire crib shows up on the display, or adjust it to the best angle that you think to watch your baby. -Store this product out of the reach of babies (at least 3 feets (0.9 m) away from the crib). A strap wound around the baby’s neck may result in asphyxiation. Use a safety clip to clamp the power cord and keep it out of baby’s reach. Do not use other extension cords. Only use the power adapter provided. -Do not touch the exposed part if the adapter is connected with power. -Test regularly before initial use or when change the position of camera. -Avoid placing the product in humid place or contacting with liquid. (such as bathtub, sink, etc.) -Do not apply heat to the product.(such as stoves, radiators, etc.) -Using the product in ventilated place. Avoid placing it on sofas, cushions, beds or other places which may block ventilation. -The product only can be operated by adult. Do not allow baby to play with it. Tiny accessories are contained, please be careful when unpack and install it. THIS PRODUCT CAN NOT SUBSTITUE PARENT’S SUPERVISION ON YOUR CHILD. WARNING -Only use the recommended rechargeable battery. Please contact us if you need to change it. For the contact list, please refer to the last page of the instruction. -Please clean the battery compartment before using it. -Avoid short circuits the power supply terminal. -Remove the battery when you are not using it or when running out of power. -Keep the battery away from children. -Dispose of the empty battery properly. BATTERY WARNING FEATURES & COMPONENTS Camera: 12 6 SETUP & USE (continued) Favorite Features Press and hold the Talk Back/Zoom“ ” button on the monitor to activate two-way communication DIGITAL ZOOM IN & OUT x 1x 1Zoom x 2 TWO-WAY COMMUNICATION BRIGHTNESS ADJUSTMENT VOLUME CONTROL TEMPERATURE DISPLAY cam 1 85°Fcam 1 85°Fcam 1 85°F vox TEMP C F 51 2 43 cam 1 29°C cam 1 85°F 1 Press & hold cam 1 85°F TO DELETE A CAMERA 3 1 2 vox TEMP C F 5 4 CAM SIGNAL WILL BE LOST! CANCELYES 8 7 TO SELECT A CAMERA 12 cam 1 85°F 3 1 2 5 * Press the AUTO-SCAN“ ” button again to stop scanning. TO SCAN ALL CAMERAS (AUTO-SCAN) cam 1 85°F 31 2 TO SET UP VOX - VIDEO ON CRYING cam 1 85°F vox TEMP C F 3 1 2 TO ADJUST SCREEN COLOR TEMPERATURE 2 vox TEMP C F 5 436 71 6 cam 1VOX 1 85°F OFF123 8 FCC INFORMATION This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1)…
