1/1 US Agent for Service of Process LETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: PADMATE INTERNATIONAL LLC FRN: 0033462839 Contact Name: LIANHUA MAO Address: 160 W Santa Clara St Ste 600 SAN JOSE, CA 95113 Telephone No: 0086-13606901248 Email: [email protected] Applicant: Company name: Xiamen Padmate Technology Co., LTD Product Description: Sport headphones Grantee code: 2AJEO FCC ID: 2AJEO-S36 Contact Name: Xiaoming Wu Address: RM 201, Huli Park No.37, Industrial Zone, Tong'an District Xiamen China Telephone No: +86 592 5919800 Email: [email protected] [Xiamen Padmate Technology Co., LTD] certifies that, as of the date of this filing of the application with the TCB, [PADMATE INTERNATIONAL LLC] is our designated US agent for service of process for the above referenced FCC ID. [Xiamen Padmate Technology Co., LTD] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [PADMATE INTERNATIONAL LLC] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 8.19.2023 Applicant’s Name: Xiaoming Wu US Agent’s Name: LIANHUA MAO Title: Manager Title: President Signature Signature

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Xiamen Padmate Technology Co., LTD Grantee code: 2AJEO FCC ID: 2AJEO-S36 Contact Name: Xiaoming Wu Address: RM 201, Huli Park No.37, Industrial Zone, Tong'an District Xiamen China Telephone No: +86 592 5919800 Fax No: +86 592 5915300 Email: [email protected] i. [Xiamen Padmate Technology Co., LTD] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [ Xiamen Padmate Technology Co., LTD] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Xiamen Padmate Technology Co., LTD. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Date: 8.19.2023 Applicant’s Name: Xiaoming Wu Title: Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Xiamen Padmate Technology Co., LTD Address: RM 201, Huli Park No.37, Industrial Zone, Tong'an District Xiamen China Product Name: Sport headphones Model Number: S36 FCC Identifier: 2AJEO-S36 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Xiaoming Wu Date: 8/19/2023 Title: Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 Xiamen Padmate Technology Co., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 8/19/2023 Subject: Request for Confidentiality FCC ID: 2AJEO-S36 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Xiaoming Wu Date: 8/19/2023 Title: Manager

Page 1 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Photographs of the EUT Model: S36 External Page 2 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 5 of 5 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected]

Page 1 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Photographs of the EUT Model: S36 Internal Page 2 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 4 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ANT

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi230621042-06E2 Date of issue: 2023-08-15 Applicant: Xiamen Padmate Technology Co., LTD Product: Sport headphones Model(s): S36 FCC ID: 2AJEO-S36 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 6- Report No.: MTi230621042-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 6- Report No.: MTi230621042-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Applicant: Xiamen Padmate Technology Co., LTD Address: RM 201, Huli Park No.37, Industrial Zone, Tong'an District Xiamen China Manufacturer: Xiamen Padmate Technology Co., LTD Address: RM 201, Huli Park No.37, Industrial Zone, Tong'an District Xiamen China Product description Product name: Sport headphones Trademark: Padmate Model name: S36 Serial Model: N/A Standards: N/A Test method: KDB 447498 D01 v06 Date of Test Date of test: 2023-07-19 to 2023-08-15 Test result: Pass Test Engineer : (David Lee) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) - Page 4 of 6- Report No.: MTi230621042-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of Contents 1. STANDALONE SAR TEST EXCLUSION CONSIDERATIONS ............................................................................................ 5 2. SAR TEST EXCLUCSION THRESHOLDS ........................................................................................................................ 6 - Page 5 of 6- Report No.: MTi230621042-06E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1. Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition(s), listed below, is (are) satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance defined in 4.1 f) is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified, typically in the SAR measurement or SAR analysis report, by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting are required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions. a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f (GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison  The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following (also illustrated in Appendix B): 1) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·(f(MHz)/150)]} mW, for 100 MHz to 1500 MHz 2) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz c) For frequencies below 100 MHz, the fo…

Text truncated - open the document above for the full version.

_______________________________________________________________________________________________________ Application: WLAN, 802.11b/g, Bluetooth, etc... Features SMD, high reliability, ultra Impact, Omni-directional... Part number AAN 2012 P (1) (2) (3) (4) 2G45 (5) (1)Product Type Chip Antenna (2)Size Code 2.0x1.2mm (3)Type Code (4)Packing Paper &Reel (5)Frequency 2.45GHz (6)Internal code Electrical Specification Working Frequency Range Peak Gain Impedance 50 Ohm Return loss 10 dB ( Min) Polarization Linear Azimuth Beamwidth Omni-directional Operation Temperature(°C) -40 ~85°C The specification is defined on EVB. Dimension and Terminal Configuration 2.4GHz 2012 Chip Antenna: AAN2012F0P2G45 F0 F0 1.32 dBi (Typ.) 2400 ~2483MHz _______________________________________________________________________________________________________ Evaluation Board Reference PCB Dimension Antenna Layout Reference Unit :mm Unit :mm Electrical Characteristics Return Loss & Radiation Return Loss Frequency (MHz) S11 (dB) 2400 -10.78 2442 -24.81 2484 -10.24 Radiation M 3 M 2 M 1 dB-10.243 GHz2.484000M 3 dB-24.812 GHz2.442000M 2 dB-10.776 GHz2.400000M 1 S11 Cal int Offs Invisible Ref 0 dB Ref 0 dB 10 dB / 10 dB / dB Mag dB Mag S11 S22 Trc3 Trc2 3 GHzStop2 GHzStartCh10 dBm Pwr 1 0 41 31 21 11 1 -9 -19 -29 -39 2.4GHz 2012 Chip Antenna: AAN2012F0P2G45 _______________________________________________________________________________________________________ Taping Specifications Reel and Taping Specification Reel Specification TYPE SIZE A ψB ψC ψD W ψM 2012 7” 5K/Reel 2.0±0.5 13.5±1.0 21±1.0 60±1.0 11.5±2.0 178±2.0 Tapping Specification Packaging Type A B W E F G H T ψD P Paper Type 20121.90±0.20 3.50±0.20 8.0±0.20 1.75±0.10 3.5±0.05 4.0±0.10 2.0±0.05 0.75±0.10 +0.10 1.50 -0 4.0±0.1 2.4GHz 2012 Chip Antenna: AAN2012F0P2G45 _______________________________________________________________________________________________________ Reliability Table Method 106 MIL-STD-202 specification. Fulfill the electrical No Visible Damage. 3. Measurement at 24 ± 2hrs after test condition. 2. Time: 500 ± 24 hours. 1. Humidity: 85% R.H., Temperature: 85 ± 2 °C. Bias Humidity Method 213 MIL-STD-202No Visible Damage. Waveform: Half-sine Velocity change: 15.4 ft/s Duration: 0.5ms Peak value: 1,500g’s mutually perpendicular axes of the test specimen (18 shocks) Three shocks in each direction shall be applied along the three Shock Mechanical Method 204 MIL-STD-202No Visible Damage. Hz. mounted within 2" from any secure point. Test from 10-2000 side and 2 secure points at corners of opposite sides. Parts Note: Use 8"X5" PCB .031" thick 7 secure points on, one long 5g's for 20 min., 12 cycles each of 3 orientationsVibration 4.10 IEC 60384-21/22No Visible Damage. Dipping time: 5 ± 0.5s Solder temperature: 260 ± 5°C. Preheating time: 1~2 min. Preheating temperature: 150 ± 10°C. (RSH) Resistance Soldering Heat 4.10 IEC 60384-21/22 area of bottom side. over 95% of the critical The solder should cover b. Dipping time: 3 ± 0.5s a. Temperature: 235 ± 5°C Dipping method: (SMD Bottom Side) Solderability 108 MIL-STD-202 specification. Fulfill the electrical No Visible Damage. 3. Measurement at 24 ± 2 hours after test. .°C2. Unpowered: 500hours @ T= -30 1. Initial measure: Spec: refer Initial spec. Storage Low Temperature 108 MIL-STD-202 specification. Fulfill the electrical No Visible Damage. 3. Measurement at 24 ± 2 hours after test. .°C2. Unpowered; 500hours @ T=+85 1. Initial measure: Spec: refer Initial spec. Exposure High Temperature JA104 JESD22 specification. Fulfill the electrical No Visible Damage. 3. Measurement at 24 ± 2Hours after test condition. ), Soak Mode=1 (2 Cycle/hours).°C to +85°C2. 100 Cycles (-30 1. Initial measure: Spec: refer Initial spec. Cycling Temperature 107 MIL-STD-202 specification. Fulfill the electrical No Visible Damage. 15 minutes at Upper category temperature. 15 minutes at Lower category temperature; ; 100 cycles;°C to +85°C-30 3. Rapid change of temperature test: 2. Initial measure: Spec: refer Initial spec. / 1 hr , then keep for 24 ± 1 hrs at room temp.°C50 ± 10 1. Preconditioning: Shock Thermal User Spec. specification Fulfill the electrical Characterization Electrical (Reference) Remark Ceramic Type Requirements ProcedureTest Item 2.4GHz 2012 Chip Antenna: AAN2012F0P2G45 _______________________________________________________________________________________________________ Revision History Revision Date Content 1 2015/8/20 New issue 2 2017/4/20 Update detail dimension on antenna layout 3 2018/3/1 Part number and coding rule updated JB100 JESD22 specification. In accordance with dimensions. equipment, capable of determining the actual specimen calipers, gauges, contour projectors, or other measuring Any applicable method using x10 magnification, micrometers, Dimension Physical 006 AEC-Q200 body/terminal junction. device body terminals and mechanical integrity of the for inspection of the greater may be employed Magnification of 20X or No Visible DamageForce of 1.8Kg for 60 seconds.Adhesion 005 No Visible Damage.AEC-Q200 2 mm. 2. Apply the load in direction of the arrow until bending reaches IR-Reflow. PCB Size (L:100 × W:40 × T:1.6mm) 1. Mounting method: (SMD) Flex Board 2.4GHz 2012 Chip Antenna: AAN2012F0P2G45

The test report is only used for customer scientific research, teaching, internal quality control and other purposes, and is for internal reference only. Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230621042-06E1 Date of issue: 2023-08-15 Applicant: Xiamen Padmate Technology Co., LTD Product: Sport headphones Model(s): S36 FCC ID: 2AJEO-S36 Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 57 Report No.: MTi230621042-06E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 57 Report No.: MTi230621042-06E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1 General Description ......................................................................................................................... 5 1.1 Description of the EUT ............................................................................................................................... 5 1.2 Description of test modes .......................................................................................................................... 5 1.3 Environmental Conditions .......................................................................................................................... 7 1.4 Description of support units ....................................................................................................................... 7 1.5 Measurement uncertainty .......................................................................................................................... 7 2 Summary of Test Result .................................................................................................................. 8 3 Test Facilities and accreditations ................................................................................................... 9 3.1 Test laboratory ........................................................................................................................................... 9 4 List of test equipment .................................................................................................................... 10 5 Evaluation Results (Evaluation) .................................................................................................... 11 5.1 Antenna requirement ............................................................................................................................... 11 6 Radio Spectrum Matter Test Results (RF) .................................................................................... 11 6.1 Occupied Bandwidth ................................................................................................................................ 11 6.2 Maximum Conducted Output Power ........................................................................................................ 13 6.3 Channel Separation ................................................................................................................................. 14 6.4 Number of Hopping Frequencies ............................................................................................................. 15 6.5 Dwell Time ............................................................................................................................................... 16 6.6 Unwanted emission ................................................................................................................................. 18 6.7 Band edge emissions (Radiated) ............................................................................................................ 19 6.8 Radiated emissions (below 1GHz) ......................................................................................................... 22 6.9 Radiated emissions (above 1GHz) .......................................................................................................... 26 Photographs of the test setup ............................................................................................................. 30 Photographs of the EUT....................................................................................................................... 31 Appendix A: 20dB Emission Bandwidth ............................................................................................. 33 Appendix B: Maximum conducted output power ............................................................................... 36 Appendix C: Carrier frequency separation ......................................................................................... 39 Appendix D: Time of occupancy ......................................................................................................... 41 Appendix E: Number of hopping channels......................................................................................... 46 Appendix F: Band edge measurements .................................…

Text truncated - open the document above for the full version.

Page 1 of 1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel : (8 6-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Photographs of the test setup Model: S36 Radiated emissions (below 1GHz) Radiated emissions (above 1GHz)
