2AJQZ-TSCAN-750Face Recognition Scanner

Amphenol Thermometrics, Inc.

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Sep 24, 2020
Application Purpose: Original Equipment
Date of Application: Sep 22, 2020
Equipment Note: Face Recognition Scanner
Frequency Range: 2402.00000000 - 2480.00000000
Company: Amphenol Thermometrics, Inc.
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Face Recognition Scanner User's manual Please read this manual before switching the unit on. Important safety information inside. V200721 1 Face Recognition Scanner user's manual Contents Page 1. Product Appearance ...................................................................3 2. Interface Instruction ...................................................................4 3. Wiring Instruction .......................................................................5 4. Technical Specifications .............................................................6 5. Access Control & Attendance for Company............................7 6. Access Control & Attendance for School .................................8 7. Quick Screening ...........................................................................8 8. Scan QR code to get guidance ..................................................8 9. Install Instruction ........................................................................9 32 Face Recognition Scanner user's manualFace Recognition Scanner user's manual Biometric products cannot be 100% suitable for any anti-counterfeiting environment. High security level places, please use combination authentication. Do not touch the temperature probe with your fingers or blow the probe. Please make sure no hair, sweat, or hat cover your forehead before measuring temperature. If the forehead is cold, wait for the forehead to become warm before taking the temperature measurement. Such as: after washing the face, after applying ice, after entering the room from the outside in winter. 1. Product Appearance Color Camera Temperature Probe White Fill Light Infrared Fill Light Infrared Camera LCD Screen The Face Recognition Scanner supports 3 usage modes, and is equipped with different platform software for more powerful functions. 1. Access Control & Attendance for Company | Equipped with Attendance & Access Control Management Platform Software for Company. 2. Access Control & Attendance for School | Equipped with Attendance & Access Control Management Platform for School. 3. Quick Screening | Used for quick temperature screening. Notice: To ensure the normal operation of the temperature measurement module, the device needs to be warmed up for more than 2 hours after it is powered on. During installation and use, all electrical safety regulations of the country and the region of use must be strictly observed. When wiring, disassembling and other operations, please be sure to disconnect the power supply, do not operate with electricity. If the device emits smoke, produces unusual odors, or makes noises, immediately turn off the power and unplug it, and contact the dealer or service center in time. If the equipment is not working properly, please contact customer service, do not disassemble or modify the equipment in any way. (The company does not assume any responsibility for problems caused by unauthorized modification or maintenance) Do not drop objects on the device or vibrate the device vigorously to keep the device away from magnetic interference. Avoid installing the device where the surface vibrates or is vulnerable to shock. Avoid installing the device at the air outlet of the air conditioner or in a place with large airflow fluctuations. Try to ensure that the equipment is installed vertically. Please do not use the device in high temperature, low temperature or high humidity environment. Please do not aim the lens of the device at strong light objects such as the sun, incandescent lamp, etc., otherwise it will cause lens damage. Avoid placing the device in direct sunlight, poorly ventilated locations, or heat source accessories such as heaters or heaters. 54 Face Recognition Scanner user's manualFace Recognition Scanner user's manual 3. 7PIN 12V Power Supply, Relay Interface 1234567 COMNONCGNDGND12V12V 4. Ethernet port 5. 2PIN 485 Interface 6. Tamper key 7. Micro USB Port 8. USB-A Port 9. 12V Power Adapter Socket 12 485A485B 3. Wiring Instruction Microphone Screw holes for hanging board Reset Button 1 2 3 4 5 6 7 8 9 Speaker 2. Interface Instruction 1. 6PIN Door Button, Door Sensor, Alarm Interface 2. 11PIN Reserved I O 123456 5VGNDNCDoor ButtonDoor SensorAlarm 1234567891011 PWRONIO7GND3.3VIO6IO5IO4IO3IO2IO1 76 Face Recognition Scanner user's manualFace Recognition Scanner user's manual Smart functions Face recognition capacity50000 Offline record100000 Recongition accuracy99.83% Face liveness detectionSupport binocular near infrared live detection Face detection 1080P @ 25fps, support face detection tracking, optimization Face recognition speedAbout 200ms Face liveness detection speed About 400ms Occlusion adaptation Supports wearing glasses, wigs, makeup, etc., wearing masks Basic parameters Screen size7 inch Product size268*135*45 (length*width*height) Operation humidity10%~90% Operation temperature10~40 o C/ 50~140 o F 5. Access Control & Attendance for Company At this mode, User need to login to the Attendance & Access Control Management Platform Software for Company to add the device ID, import employees’ information and their face photos and configure this device as an attendance device for employees. After the configuration is complete, the user can use the device to synchronize data. After synchronization is complete, face recognition/temperature measurement/access control/attendance can be started. For detailed instructions, please refer to the guidance of the Face Recognition Temperature Monitor and the instructions of the Attendance & Access Control Management Platform Software for Company. Temperature measurement module parameters Measuring range32 o C~45 o C/ 89.6 o F~113 o F Measurement accuracy±0.5 o C/ ±0.9 o F (at 25±2 o C/ 77±3.6 o F ambient temperature) Measuring diatance20~50cm Measure time0.5s System hardware parameters Processor4-core A7 Operating systemAndroid 8.1 Memory size1GB LPDDR3 Storage size16G EMMC Camera Parameters ResolutionColor 200W (1920*1080) Infrared 130W (1280*…

Text truncated - open the document above for the full version.

External Photos

Internal Photos

RF Exposure Info

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 7 Report Version 1 Test Report No.: FM2008WDG0192 RF EXPOSURE REPORT Applicant Amphenol Thermometrics,Inc. Address 967 WINDFALL ROAD ST. MARYS PA 15857 USA Manufacturer or Supplier Shenzhen Everbest Machinery Industry Co., Ltd Address 19th Building, 5th Region, Baiwangxin Industrial Park, SongBai Rd.,Baimang, Xili, Nanshan, Shenzhen China Product Face Recognition Scanner Brand Name ADVANCE IR» Model TSCAN-750 Additional Models & Model Difference N/A Date of tests May. 21, 2020 ~ Jun. 22, 2020 FCC Part 2 (Section 2.1091) KDB 447498 D01 IEEE C95.1 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Breeze Jiang Senior Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Sep. 14, 2020 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 7 Report Version 1 Test Report No.: FM2008WDG0192 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................ 3 1. CERTIFICATION .............................................................................................. 4 2. RF EXPOSURE LIMIT ..................................................................................... 5 3. MPE CALCULATION FORMULA ..................................................................... 5 4. CLASSIFICATION ........................................................................................... 5 5. ANTENNA GAIN .............................................................................................. 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ................... 6 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 3 of 7 Report Version 1 Test Report No.: FM2008WDG0192 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED FM200521N025 Original release Jun. 24, 2020 FM2008WDG0192 Based on the original report FM200521N025 changed the information of applicant, FCC ID number, model No. and brand name. Sep. 14, 2020 After the verification of worst case of AC Power Conducted Emission and Transmitter Radiated Emissions, all test data can be referred to the original report and showed in this report. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 4 of 7 Report Version 1 Test Report No.: FM2008WDG0192 1. CERTIFICATION FCC ID: 2AJQZ-TSCAN-750 PRODUCT: Face Recognition Scanner BRAND NAME: ADVANCE IR » MODEL NO.: TSCAN-750 ADDITIONAL NO.: N/A TEST SAMPLE: Engineering Sample APPLICANT: Amphenol Thermometrics,Inc. STANDARDS: FCC Part 2 (Section 2.1091) KDB 447498 D01 IEEE C95.1 Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 5 of 7 Report Version 1 Test Report No.: FM2008WDG0192 1. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 3. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Devic…

Text truncated - open the document above for the full version.

Test Report

Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 1 of 57 Report Version 1 Test Report No.: RF2008WDG0192-1 TEST REPORT Applicant Amphenol Thermometrics,Inc. Address 967 WINDFALL ROAD ST. MARYS PA 15857 USA Manufacturer or Supplier Shenzhen Everbest Machinery Industry Co., Ltd Address 19th Building, 5th Region, Baiwangxin Industrial Park, SongBai Rd.,Baimang, Xili, Nanshan, Shenzhen China Product Face Recognition Scanner Brand Name ADVANCE IR» Model TSCAN-750 Additional Models & Model Difference N/A Date of tests May. 21, 2020 ~ Jun. 22, 2020 the tests have been carried out according to the requirements of the following standards: FCC Part 15, Subpart C, Section 15.247 CONCLUSION: The submitted sample was found to COMPLY with the test requirement Tested by Breeze Jiang Senior Project Engineer / EMC Department Approved by Glyn He Assistant Manager / EMC Department Date: Sep. 14, 2020 This report is governed by, and incorporates by reference, CPS Conditions of Service as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute you unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch No. 96, Guantai Road (Houjie Section), Houjie Town, Dongguan City, Guangdong Province. 523942. People’s Republic of China. Tel: +86 769 8998 2098 Fax: +86 769 8593 1080 Email: [email protected] Page 2 of 57 Report Version 1 Test Report No.: RF2008WDG0192-1 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................................... 5 1 SUMMARY OF TEST RESULTS ............................................................................................. 6 2 MEASUREMENT UNCERTAINTY .......................................................................................... 6 3 GENERAL INFORMATION ..................................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT .................................................................................... 7 3.2 DESCRIPTION OF TEST MODES ...................................................................................... 8 3.2.1. CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 9 3.2.2. TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................... 11 3.4 DESCRIPTION OF SUPPORT UNITS ............................................................................... 11 4 TEST TYPES AND RESULTS ............................................................................................... 12 4.1. CONDUCTED EMISSION MEASUREMENT ............................................................... 12 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................ 12 4.1.2 TEST INSTRUMENTS .............................................................................................. 12 4.1.3 TEST PROCEDURES .............................................................................................. 13 4.1.4 DEVIATION FROM TEST STANDARD .................................................................... 13 4.1.5 TEST SETUP ............................................................................................................ 14 4.1.6 EUT OPERATING CONDITIONS ............................................................................. 14 4.1.7 TEST RESULTS........................................................................................................ 15 4.2. RADIATED EMISSION AND BANDEDGE MEASUREMENT ....................................... 17 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................ 17 4.2.2 TEST INSTRUMENTS .............................................................................................. 18 4.2.3 TEST PROCEDURES .............................................................................................. 19 4.2.4 DEVIATION FROM TEST STANDARD .................................................................... 20 4.2.5 TEST SETUP ............................................................................................................ 20 4.2.6 EUT OPERATING CONDITIONS ............................................................................. 21 4.2.7 TEST RESULTS........................................................................................................ 22 4.3 NUMBER OF HOPPING FREQUENCY U…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Matthew Schwabenbauer(TRS Technical Leader)

[email protected]814-834-5521Fax: 814-834-5529

Test Firm

Bureau Veritas Shenzhen Co., Ltd. Dongguan BranchEdwin Ye

[email protected]86-20-8714 8549

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	1.71 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance.
