IT-60/61 ISOtunes TEAMCOMM User Manual Catologue 1. Product Appearance, Structure & Weight Requirements .......................................... 1 1.1. User Interface ..................................................................................................... 1 1.1.1. Buttons (5 total) .......................................................................................... 1 1.1.2. Reliable Back Clip (replaceable) ................................................................... 1 1.1.3. Replaceable Antenna: .................................................................................. 2 1.1.4. Peripheral Interface ..................................................................................... 3 1.1.5. Display Interface .......................................................................................... 3 1.1.6. Display Information ..................................................................................... 3 1.1.7. Replaceable Battery Pack Design ................................................................. 3 1.2. Product Appearance Rendering .......................................................................... 4 1.2.1. IT-60 Overall Appearance ............................................................................ 4 1.2.2. IT-61 Overall Appearance ............................................................................ 5 1.3. Weight & Dimensions: ........................................................................................ 5 1.3.1. Weight: 153g ............................................................................................... 5 1.3.2. Dimensions: 215*63*41mm ........................................................................ 5 2. Product Function ........................................................................................................ 5 2.1. Full-Duplex Group Communication Function ...................................................... 5 2.2. Bluetooth Function ............................................................................................. 6 2.3. Wired Connection Function ................................................................................ 6 2.4. MIC Operating Mode Switching .......................................................................... 6 2.5. Function Operations ........................................................................................... 6 2.5.1. Starting Up ................................................................................................... 6 2.5.2. Shut Down ................................................................................................... 6 2.5.3. Adjust Volume ............................................................................................. 7 2.5.4. Adjust Channel ............................................................................................ 7 2.5.5. Other Functions ........................................................................................... 7 3. Product Performance and Specification Parameters ................................................. 7 3.1. Battery Power Supply ： ..................................................................................... 7 3.2. Work Environment ： ......................................................................................... 8 3.3. operating Time ：Duration of Continuous Use: 12 hours ................................... 8 3.4. Charging Time: 3.5 hours. ................................................................................... 8 4. Precautions ................................................................................................................ 8 1. Product Appearance, Structure & Weight Requirements 1.1. User Interface 1.1.1. Buttons (5 total) ⚫ Function Button: Power ON/OFF & menu selection ⚫ Back Button: Return to the previous page ⚫ + Button: Volume increase & parameter switching ⚫ - Button: Volume decrease& parameter switching ⚫ Microphone Button (PTT): Voice transmission in PTT mode 1.1.2. Reliable Back Clip (replaceable) 1.1.3. Replaceable Antenna: The model is distinguished by the colour of the ring on the antenna. IT-60 antenna IT-61 antenna 1.1.4. Peripheral Interface ⚫ 3.5mm audio jack ⚫ TYPE-C charging port : located on the device ⚫ Replaceable battery pack: ◼ Connects to the device via contact spring ◼ Support dock charging ◼ Charging protect circuit built-in ⚫ SMA antenna interface 1.1.5. Display Interface ⚫ LED Display ⚫ OLED Display 1.1.6. Display Information ⚫ Current working channel ⚫ Battery level ⚫ External device connection status: Bluetooth / 3.5mm jack ⚫ PTT operating pattern ⚫ PIN CODE input 1.1.7. Replaceable Battery Pack Design The battery pack can be detached from the device and charged independently. 1.2. Product Appearance Rendering 1.2.1. IT-60 Overall Appearance 1.2.2. IT-61 Overall Appearance 1.3. Weight & Dimensions: 1.3.1. Weight: 153g 1.3.2. Dimensions: 215*63*41mm 2. Product Function 2.1. Full-Duplex Group Communication Function The Group Communication handheld terminal supports Bluetooth headsets or wired headsets to enable real-time, full-duplex wireless voice communication. The device supports 16 channels. Each channel allows for at least 8 active speakers, and supports a total of 250 listeners. Each channel on the device supports private group calls (private chats) using a 4-digit access code. 2.2. Bluetooth Function The group communication device features a built-in source Bluetooth function, enabling wireless connection with Bluetooth headsets. (the device cannot connect the smart phone or other source Bluetooth device as a slave Bluetooth) 2.3. Wired Connection Function The device is equipped with an integrated 3.5 mm audio jack. 2.4. MIC Operating Mode Switching The device supports both full-duplex commuincation mode and Push-to-Talk (PTT) mode. In PTT mode, voice transmission occurs only while the microphone button is pressed and held. 2.5. Function …

Text truncated - open the document above for the full version.

Rev 1/26/2023 Haven Technologies, Inc Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-04-16 FCC ID: 2AJRDIT-60 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Haven Technologies, Inc certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Haven Technologies, Inc certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Haven Technologies, Inc certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: Haven Technologies, Inc Address: 873 W Carmel Drive, Carmel, IN, 46032 USA Contact Person: Pete Murphy Tel.: (317)490-7197 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-04-16 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2AJRDIT-60) Haven Technologies, Inc, the undersigned, hereby authorize Haven Technologies, Inc to act as our designated agent for service of process, Haven Technologies, Inc accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Haven Technologies, Inc accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: Haven Technologies, Inc Contact Name: Pete Murphy Address: 873 W Carmel Drive, Carmel, IN, 46032 USA Telephone No: (317)490-7197 Email: [email protected] FRN: 0032593220 Signature: Pete Murphy Agent Information: Company Name: Haven Technologies, Inc Address:873 W Carmel Drive, Carmel, IN, 46032 USA FRN: 0032593220 Contact Name: Pete Murphy Telephone No: (317)490-7197 Email: [email protected] Signature: Pete Murphy

Haven Technologies, Inc Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: May 13, 2026 Subject; Request for Confidentiality FCC ID: 2AJRDIT-60 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Pete Murphy Title: President

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Haven Technologies, Inc Date：2026-04-16 Product Model Number: IT-60 FCC ID：2AJRDIT-60 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Pete Murphy Contact Listed on FCC Wesbite Title: President Email: [email protected] On behalf of: Haven Technologies, Inc

Page 1 of 5 Report No.: LGT25G217 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT25G217 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT25G217 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 5 Report No.: LGT25G217 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT25G217 Appendix - External Photographs of EUT Constructional Details Photo 9 Photo 10

Label

Page 1 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 2.4G ANT Page 4 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 9 Photo 10 BT ANT Page 6 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 11 Photo 12 Page 7 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 13 Photo 14 Page 8 of 8 Report No.: LGT25G217 Appendix - Internal Photographs of EUT Constructional Details Photo 15 Photo 16

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 36 SAR TEST REPORT Product Name: ISOtunes TEAMCOMM Model Name: IT-60 FCC ID: 2AJRDIT-60 Issued For : Haven Technologies, Inc 873 W Carmel Drive, Carmel, IN, 46032 USA Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT25G217HA01 Sample Received Date: July. 17, 2025 Date of Test Aug. 07, 2025 Date of Issue Aug. 22, 2025 Max. SAR (1g) Body: 0.538 W/kg Reprot No.: LGT25G217HA01 Page 2 of 36 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Antenna Location Sketch 15 7.1 SAR test exclusion consider table 16 8. EUT Test Position 18 8.1 Body-worn Position Conditions: 18 8.2 Hotspot mode exposure position condition 18 9. Uncertainty 19 9.1 Measurement Uncertainty 19 9.2 System validation Uncertainty 20 10. Conducted Power Measurement 21 10.1 Test Result 21 11. EUT and Test Setup Photo 22 11.1 EUT Photos 22 11.2 Setup Photos 25 12. SAR Result Summary 29 12.1 Body SAR 29 12.2 Simultaneous Multi-band Transmission Evaluation 30 13. Equipment List 31 Appendix A. System Validation Plots 32 Appendix B. SAR Test Plots 34 Appendix C. Probe Calibration and Dipole Calibration Report 36 Reprot No.: LGT25G217HA01 Page 3 of 36 Revision History Rev. Issue Date Contents 00 Aug. 22, 2025 Initial Issue Reprot No.: LGT25G217HA01 Page 4 of 36 TEST REPORT CERTIFICATION Applicant Haven Technologies, Inc Address 873 W Carmel Drive, Carmel, IN, 46032 USA Manufacture NanJing MeiYin Acoustics Technology Address 9-1 Yinlong Road, Nanjing, Jiangning District Yuepu Technology Nanjing Yunchuang Building 19, Phase 1 Product Name ISOtunes TEAMCOMM Trademark ISOtunes Model Name IT-60 Sample number LGT2507221 APPLICABLE STANDARDS STANDARD TEST RESULTS ANSI/IEEE Std. C95.1-2019 FCC 47 CFR Part 2 (2.1093) IEEE 1528: 2013 PASS Prepared by: Approved by: Deng Deng Engineer Vita Li Manager Reprot No.: LGT25G217HA01 Page 5 of 36 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name ISOtunes TEAMCOMM Trademark ISOtunes Test Model Name IT-60 Series Model N/A Model Difference N/A Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version V1.0 Software Version V1.0 Frequency Range 2.4G: 2420.2 ~ 2450.2 MHz Bluetooth: 2402 ~ 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Test distance: Body:10mm Back Side:0mm Mode Body (W/ kg) 2.4G 0.538 Bluetooth 0.237 Battery Rated Voltage: 3.7V Capacity: 2000mAh Operating Mode: 2.4G: GFSK Bluetooth: GFSK +π/4DQPSK+8DPSK BLE: GFSK Antenna Specification 2.4G: Rubber rod Antenna BT: Ceramic Antenna Operating Mode Maximum continuous output Hotspot Mode Not Support DTM Mode Not Support Reprot No.: LGT25G217HA01 Page 6 of 36 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Temperature (°C) 18-25 Humidity (%RH) 30-70 1.3 Test Factory Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate FCC Registration No.: 746540 A2LA Certificate No.: 6727.01 IC Registration No.: CN0136 Reprot No.: LGT25G217HA01 Page 7 of 36 2. Test Standards and Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-2019 IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial- Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v06 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r04 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D02 v01r02 RF Exposure Reporting 7 FCC KDB 648474 D04 v01r03 SAR Evaluation Considerations for Wireless Handsets (A). Limits for Occupational/Controlled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.4 8.0 20.0 (B). Limits for General Population/Uncontrolled Exposure (W/kg) Whole-Body Partial-Body Hands, Wrists, Feet and Ankles 0.08 1.6 4.0 NOTE: Whole-Body SAR is averaged over the entire body, partial-body SAR is averaged over any 1 gram of tissue defined as a tissue volume in the shape of a cube. SAR for hands, wrists, feet and ankles is averaged over any 10 grams of tissue defined as a tissue volume in the shape of a cube. Population/Uncontrolled Environments: Are defined as locations where there is the exposure of individuals who have no knowledge or control of their exposure. Occupational/Controll…

Text truncated - open the document above for the full version.

Page: 1/11 Ref : ACR.163.3.25.BES.B Cancel and replace the report ACR.163.3.25.BES.A SHENZHEN LGT TEST SERVICE CO., LTD. ROOM 205, BUILDING 13, ZONE B, ZHENXIONG INDUSTRIAL PARK, NO.177, RENMIN WEST ROAD, JINSHA, KENGZI STREET, PINGSHAN DISTRICT, SHENZHEN, GUANGDONG, CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: 2225-EPGO-450 Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise – 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 06/06/2025 Accreditations #2-6789 Scope available on www.cofrac.fr The use of the Cofrac brand and the accreditation references is prohibited from any reproduction. Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed at MVG, using the CALIPROBE test bench, for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units (SI). COMOSAR E-Field Probe Calibration Report Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Pedro Ruiz Technical Manager 6/12/2025 Checked & approved by: Pedro Ruiz Technical Manager 6/12/2025 Authorized by: Kim Rutkowski Quality Manager Customer Name Distribution : SHENZHEN LGT TEST SERVICE CO., LTD. Issue Name Date Modifications A Pedro Ruiz 6/12/2025 Initial release B Pedro Ruiz 6/20/2025 Customer name & address Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E 6/23/2025 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 3/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Sensitivity _______________________________________________________________ 4 3.2 Linearity ________________________________________________________________ 5 3.3 Isotropy _________________________________________________________________ 5 3.4 Boundary Effect __________________________________________________________ 5 3.5 Probe Modulation Response _________________________________________________ 6 4 Measurement Uncertainty .......................................................................................... 6 5 Calibration Results ..................................................................................................... 6 5.1 Calibration in air __________________________________________________________ 6 5.2 Calibration in liquid _______________________________________________________ 7 6 Verification Results ................................................................................................... 8 7 List of Equipment .................................................................................................... 10 Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 4/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number 2225-EPGO-450 Product Condition (new / used) New Frequency Range of Probe 0.15 GHz-7.5GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.226 M Dipole 2: R2=0.224 M Dipole 3: R3=0.229 M 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards. Figure 1 – MVG COMOSAR Dosimetric E field Probe Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEC/IEEE 62209-1528 and FCC KDB865664 D01 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their effect. All calibrations / measurements performed meet the fore-mentioned standards. 3.1 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards for frequency range 600- 7500MHz and using the calorimeter cell method (transfer method) as outlined in the standards for frequency 150-450 MHz. Docusign Envelope ID: D3677F92-510E-48FC-B182-CD820765136E COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.163.3.25.BES.B Page: 5/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Probe vM This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it …

Text truncated - open the document above for the full version.

Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 1 of 4 Inmm L±± W±± T a±± Function Feeding Point NC Need the layout file of the above? Contact us at: www.johansontechnology.com/en/ask-a-technical-question.html Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved Note: It is recommended that the designer leave available slots for a "pi" (or shunt-series- shunt) network. The antenna matching network values here are used when antenna is mounted on Johanson's evaluation board. The matching values and topology on clinet's PCB will be different. Need our help tuning the antenna on your board? Contact our RF Applications Eng Team at: www.johansontechnology.com/component/techquestion Antenna Tuning services: www.johansontechnology.com/ipcantennaservices No. 1 2 0.0200.0120.500.30 Mounting ConsiderationsTerminal Configuration 0.0630.0081.600.20 0.051 +.004/-.008 1.30 +0.1/-0.2 Reel Quanity3,000 Mechanical Dimensions 0.1260.0083.200.20 Input Power2W max. (CW) Impedance50 Ω Operating Temperature-40 to +125°C Peak Gain0.5 dBi typ. (XZ-V) Average Gain-0.5 dBi typ. (XZ-V) Return Loss9.5 dB min. "High Frequency Ceramic Solutions" General Specifications Part Number2450AT18A100 Frequency Range2400 - 2500 Mhz 7/18/2014 1 2 L W a T * 2.6 4.2 1.6 1.9 0.4 2.7nH 1.0pF 3.9nH a) Without Matching Circuits b) With Matching Circuits Mount these devices with mark facing up. Units: mm * Line width should be designed to provide 50 Ω impedance matching characteristics. * Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 2 of 4 Test Board: P/N: 2450AT18A100-EB1SMA (orderable item) Return Loss with matching circuit @ +25 CVSWR with matching circuit @ +25C and +125C Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" Typical Electrical Characteristics (T=25 o C) The antenna matching network values here are used when antenna is monted on Johanson's evaluation board. The matching values on clinet's PCB will be different. Go to: www.johansontechnology.com/ipcantennaservices and see how to obtain the new values. If you need further help, contact our RF Applications Eng Team at: 7/18/2014 GND 13.5mm 6.5mm 39.5mm6.5mm Matching Circuit No Ground 50Feed Line Antenna 19mm This 50ΩFeedline can be as short as needed, this lenth is just for reference to our EVB GND www.johansontechnology.com/component/techquestion Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 3 of 4 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved "High Frequency Ceramic Solutions" Typical Radiation Patterns at 2.45GHz (+25C) 7/18/2014 XY-V/XY-H 180° 270° 0° 90° X Z Y XY-cut scanning direction XY cut @2.45GHz Vertical Horizontal XZ-V/XZ-H YZ-V/YZ-H 180° 270° 0° 90° X Z Y XZ-cut scanning direction 180° 270° 0° 90° X Z Y YZ-cut scanning direction XZ cut @2.45GHz Vertical Horizontal YZ cut @2.45GHz Vertical Horizontal Mini 2.45 GHz AntennaP/N 2450AT18A100 Detail Specification: Page 4 of 4 Would you like Johanson Technology's RF team to help you design and tune our antenna on your board? Click on the link below: Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver 1.3 2014 Johanson Technology, Inc. All Rights Reserved www.johansontechnology.com/technical-notes/msl-rating.html Suffix = S Suffix = E Suffix = S/E/R 2450AT18A100-EB1SMA (Page 2) Orderable item! www.johansontechnology.com/ipcsoldering-profile Antenna layout review, tuning, and characterization services www.johansontechnology.com/ipcantennaservices Packaging information www.johansontechnology.com/technical-notes/rohs-compliance.html Packaging Style Termination style RoHS Compliance MSL Info "High Frequency Ceramic Solutions" 7/18/2014 P/N Suffix Part Number Explanation Eg. 2450AT18A100R (MOQ Applies) Eg. 2450AT18A100(S, E, R) Soldering Information Evaluation Board(s) (1-port SMA antenna test boards) www.johansontechnology.com/ipcpackaging.ht…
