2AJW5ACCM1Telematic device

WARRANTY The customer shall benefit from the legal warranty against latent defects as specified in sections 1641 to 1649 of the Belgian Civil Code if the latent defect exists at the time of delivery and if the latent defect makes the unit unfit for the use for which it was designed or substantially reduces its use. Latent defects must be notified by registered letter to Continental within one month from the time the customer discovers it or ought reasonably to have discovered it. If the customer is a consumer, Continental shall be liable to the customer for any non-conformity which exists at delivery and appears within two years thereof. Any non-conformity shall be notified by registered letter to Continental within one month from the time the customer discovers it. DISCLAIMER The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty or representation, either expressed or implied, is made with respect of quality, accuracy or fitness for any particular purpose of this document. Without written permission from Continental, any forms of reproduction, spreading, distribution are prohibited. Continental reserves the rights to modify or improve the product without any prior notification. In no event will the supplier be liable for direct, indirect or special, incidental or consequential damages arising out of the user or inability to use this product or documentation, even if advised of the possibility of such damages. This document contains materials protected by copyright. BLUETOOTH The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by Continental is under license. Other trademarks and trade names are those of their respective owners. CE Hereby, Continental declares that this Car & Connected Car Module is compliant with essential requirements and other relevant provisions of directive 2014/53/EU. The ACCM can be operated in at least one Member State without infringing applicable requirements on the use of a radio spectrum FCC (FEDERAL COMMUNICATIONS COMMISSION) WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. The device complies with Part 15 of FCC’s rules. Operation is subject to the following two conditions: (i) this device may not cause harmful interference and (ii) this device must accept any interference received, including interference that may cause undesirable operation. MANUAL REQUIREMENTS ACCORDING 15.19/RSS-GEN This device complies with Part 15 of the FCC Rules [and with Industry Canada licence-exempt RSS standard(s)]. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. MANUAL REQUIREMENTS ACCORDING 15.21 Changes or modifications made to this equipment not expressly approved by Continental Automotive Technologies GmbH may void the FCC authorization to operate this equipment. FCC RF EXPOSURE REQUIREMENTS This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. CORRECT DISPOSAL OF THIS PRODUCT (WASTE ELECTRICAL AND ELECTRONICS EQUIPMENT) This marking shown on the product or its literature indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly. COPYRIGHTS Copyright © 2015 Continental. All rights reserved. No part of this manual may be reproduced or transmitted in any means or for any purpose without the express written content of Continental. All trademarks, product names appearing in this document are registered property of their respective owners. Access and Connected Car Module (ACCM6.1) INSTALLATION GUIDE v1.0 (March 2023) INTRODUCTION Continental is a virtual key enabler. the Car & Connected Car Module - ACCM allow vehicle access, authorization to start and vehicle data for any vehicle fleet management type. Content of the box Specification 1 ACCM Electric Power 12Vcc Consumption in stand-by mode < 8 mA Operating temperature - 25°C ≈ + 55°C Dimensions 131.6 x 61 x 37.6 mm Weight 130g Data transmission BLE - Bluetooth Low Energy and LTE 1 Power cable (OBDII connector) ANTENNA FREQUENCY AND MAX POWER Model Region (ACCM reference) Radio access technology supported bands Frequencies (MHz) Max Power (dBm) BGM123A BLE 2402 ~ 2480 4.08 LARA-R600 Global coverage 4G - LTE 1 2100 23 3 1800 23 7 2600 23 20 800 33 40 2300 30 2 1900 23 4 1700 23 5 850 23 26 850 12 700 13 700 BEFORE YOU BEGIN • We advise our customers to have the ACCM fitted by a professional. • Never remove the cover of the ACCM . • Before you install the individual components, check that the installation area has been selected in such a way that: • The cable length is sufficient to connect later every element: power cable and antenna (if necessary) • for a car equipped with a keyless start system, the location where you plan to install the ACCM must be within the reception area of the keyless system of the car. Use therefore the original key and place it at the chosen installation area and check immediately that the engine can be started. • Do not install any component in the airbag deployment area. • Do not install the ACCM against a large metal surface in the car. • Onc…

Text truncated - open the document above for the full version.

1/1 Continental Automotive Technologies GmbH | Vahrenwalder Straße 9, 30165 Hannover, | Postfach 1 69 | 30001 Hannover Tel. +49 (0)511 938-01 | Fax +49 (0)511 938-81770 | www.continental-automotive.com Sitz der Gesellschaft: Hannover | Handelsregister: Amtsgericht Hannover | HRB 3669 | USt-ID-Nr. DE341447066 Vorsitzende des Aufsichtsrats: Katja Dürrfeld Geschäftsführung: Nicole Werner, Dr. Andreas Listl, Frank Staiger, Harald Stuhlmann Bankverbindung: Deutsche Bank, Frankfurt | BIC/SWIFT: DEUTDEFFXXX | Konto-Nr.: 096887500 | BLZ: 50070010 | IBAN: DE25500700100096887500 Continental Automotive Technologies GmbH Heinrich-Hertz-Strasse 45 78052 Villingen-Schwenningen Germany Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA 2023-08-11 Attestation Statement according to 2.911(d)(5)(i) and 2.911(d)(5)(ii) FCC ID: <2AJW5ACCM1> TO WHOM IT MAY CONCERN: Hereby we certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Further we certify that, as of the date of the filing of the application, <Continental Automotive Technologies GmbH > is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, _______________ (signature & company stamp) Continental Automotive Technologies GmbH, Heinrich-Hertz-Strasse 45, 78052 Villingen- Schwenningen, Germany Dr. Marion Grüner (Manager Homologation) <phone: +49 7721 67 2802 <Email: [email protected] Automotive Automotive

Continental Automotive Technologies Heinrich-Hertz-Strasse 45 78052 Villingen-Schwenningen, Germany Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA June 1 st , 2023 Attestation Statement according to 2.911(d)(7) TO WHOM IT MAY CONCERN: We, Continental Automotive Technologies GmbH designate Continental Automotive Systems to act as U.S. agent for service of process. Continental Automotive Systems hereby acknowledges the obligation of the U.S. agent for service of process. Further Continental Automotive Technologies GmbH accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Sincerely _______________ (signature & company stamp) Applicant company name: Continental Automotive Technologies GmbH FCC Registration Number Gc385546 – FRN: 0025920299 > <Address: Heinrich-Hertz-Strasse 45 78052 Villingen-Schwenningen, Germany> <Name: Dr. Marion Grüner> <phone: +49 7721 67 2802> <Email:Marion.Gruener@continental- corporation.com _______________ (signature & company stamp) Designated Continental USA affiliated company Information: Name: Continental Automotive Systems Contact Person: Mark Kenney Grantee Code M3N FRN: 0022069249 Address: 1 Continental Dr, Auburn Hills, Michigan, USA 48326 Tel.: (248) 393-5300 Email: [email protected] Automotive

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 2023-08-01 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b) (4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AJW5ACCM1 ACCM102-WW4G-00 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Description The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device, which is planned for <DATE: 2023-08-31 (max. up to 180 days after grant date)> If you have any questions, please feel free to contact me at the address shown below. Sincerely, (Signed) Name / Title: Dr. Marion Grüner, Homologation Manager Company: Continental Automotive Technologies GmbH Address: Heinrich-Hertz-Strasse 45, 78052 Villingen-Schwenningen, Germany Phone: + 49 7721/ 67 2802 Fax: + 49 7721/ 67 79 2802 E-Mail: [email protected]

1/1 Continental Automotive Technologies GmbH | Vahrenwalder Straße 9, 30165 Hannover, | Postfach 1 69 | 30001 Hannover Tel. +49 (0)511 938-01 | Fax +49 (0)511 938-81770 | www.continental-automotive.com Sitz der Gesellschaft: Hannover | Handelsregister: Amtsgericht Hannover | HRB 3669 | USt-ID-Nr. DE341447066 Vorsitzende des Aufsichtsrats: Katja Dürrfeld Geschäftsführung: Nicole Werner, Dr. Andreas Listl, Frank Staiger, Harald Stuhlmann Bankverbindung: Deutsche Bank, Frankfurt | BIC/SWIFT: DEUTDEFFXXX | Konto-Nr.: 096887500 | BLZ: 50070010 | IBAN: DE25500700100096887500 Federal Communication Commission Equipment Authorization Devision, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 Certification and Engineering Bureau Innovation, Science and Economic Development Canada 3701 Carling Ave. Bldg. 94 Ottawa, On K2H 8S2 2023-08-11 TO WHOM IT MAY CONCERN FCC ID: 2AJW5ACCM1, IC: 21979-ACCM1, HVIN(s): ACCM6.1 We the undersigned, hereby declare that the conducted measurements of the Test Reports (as attached in this filing) isued for the product (FCC ID: XPYUBX21BE01, IC: 8595A- UBX21BE01, HVIN: LARA-R6001) also apply to our product mentioned above. New radiated measurements have been performed. If you have any questions feel free to contact us at the address shown below. Sincerely, <SIGNATURE> <NAME, TITLE> Dr. Marion Grüner , Manager Homologation <COMPANY NAME> Continental Automotive Technologies GmbH <ADDRESS> Heinrich-Hertz-Strasse.45, 78052 Villingen-Schwenningen, Germany <PHONE NO.> + 49 7721 67 2802

Annex A - Photographs No.1-5003/22-01-01_AnnexA December 14, 2023 DescriptionExternal photographs of EUT This document is electronically signed and valid without handwritten signature. Public keys for verification of the electronic signatures can be requested at the testing laboratory. Authorized Rene Oelmann Lab Manager Radio Labs cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_AnnexA Release 1 - Page 1 of 4 Photo 1 Photo 2 cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_AnnexA Release 1 - Page 2 of 4 Photo 3 Photo 4 cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_AnnexA Release 1 - Page 3 of 4 Photo 5 Photo 6 - END OF DOCUMENT - cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_AnnexA Release 1 - Page 4 of 4

file: Label specification _ ACCMRev.6.1_update 20240214 14.02.2024 Author: G. VALLET Version: V14.1WARNING -Increase the size of the Inner box label (same dimension os the Top label (18mm) -Modification of the design introduction of the symbols for Emark and UKCA certificationsThis document is a visual presentation of the label content and it is not showing the right format Version: V14nor can be used to test the readibility of the labels. -NEW ACCM v6.1 sheets -Change Continental ITS to Continental -Remove all reference to ACCM+. ACCM only - no ACCM+ required - -modification of the design introduction of the symboles for Emark and UKCA certifications 49mm 10 mm 5mm 49mm 10 mm 5mm 5 0mm 18mm Property of Avis Budget Group - Reward for Return: [email protected] For all versions BLE FCC and IC ID 5 0mm 18mm For all versions BLE FCC and IC ID 5 0mm no inscription here 18mm For all versions BLE FCC and IC ID Module Naming convention ACCM102Access and Connected Car ModuleV6.1 Serial Number= A C C My y y y x x x x x x x x x x x x to be read from the ACCM REGION: with yyyyxxxxxxxxxxxx from UUID where UUID = zzzzzzzz-zzzz-zzzz-yyyy-xxxxxxxxxxxx EUEurope US USA Continental P/N= TRC number on for each part version WW Europe + USA LOT=tracking information Technology 4G4G-> TLE CAT 1 for US and EU markets LOT INFO= Ltracking info Key device 00retrofit Key 1 lots is 600 parts BOX INFO= Btracking info n° box in Palette ACCM102-WW4G-00 1 palette has 108 boxes ACCM102-WW4G-01 ACCM102-WW4G-02 Cellular Radio ID= IMEI to be read from the ACCM SIM No= ICCID to be read from the ACCM ACCM102-WW4G-00 --> TRC0306260000 FCC ID= FCC certification number IC ID= IC ACCM102-WW4G-01AVIS --> TRC0306290000 information on RCK FCC ID and IC: -> “Contains FCC ID: M3N-RCKF, IC: 7812A-RCKF” ACCM102-WW4G-02 SF --> TRC0306300000 Part NumberModel Number TRC0306260000 ACCM101-EU4G-00 TRC0306262900 ACCM102-WW4G-01 TRC0306300000 ACCM102-WW4G-02 Modules versions 1810 YearMonthDay Amotech specifiic 03280 ACCM using retrofit Key 4G for specific customer 99 Modules versions vs Continental P/N Description ACCM using retrofit Key WW 4G ACCM using retrofit Key US 4G for the customer AVIS YearMonthDayLot 18032801 118032801000 Definitions / Naming Conventions Module Naming convention Definitions YearMonthDayLotpart ACCM LABELS SPECIFICATION ACCM Box (inner box) ACCM side label Contains FCC ID: QOQBGM12LMA ; IC: 5123A-BGM12LMA GENERIC VERSION AVIS VERSION ACCM Top label ATTENTION ACCM FCC ID's TO BE UPDATED AFTER HOMOLOGATION Contains FCC ID: QOQBGM12LMA ; IC: 5123A-BGM12LMA So Fleet Version ATTENTION ACCM FCC ID's TO BE UPDATED AFTER HOMOLOGATION Contains FCC ID: QOQBGM12LMA ; IC: 5123A-BGM12LMA SerialNo. SIM No. "SIM":SIM No. : ICCID Serial No. "S/N": serial No SerialNo. SIM No. "SIM":SIM No. : ICCID Serial No. "S/N": serial No Serial No. IMEI SerialNo. SIM No. "SIM":SIM No. : ICCID Serial No. "S/N": serial No Author: G. VALLET @OTA keys - confidential # Internal S.1/2 file: Label specification _ ACCMRev.6.1_update 20240214 14.02.2024 100 mm AMOTECH.CO., LTD for CONTINENTAL 3 0 mm 1. Part Name: Access and Connected Car Module 2. Part No: ACCM102-WW4G-00 3. Continental P/N: TRC0306260000 3 0 mm QR CODE FORMAT 4. Box No: B19140301099 5. Lot Info:L190325-01 L190326-02 6: Qty: 30 (ACCM) 1 7 5 mm BOX LABEL (outer box) All parts All parts Serial No. All parts Serial No. Author: G. VALLET @OTA keys - confidential # Internal S.2/2

Annex B - Photographs No.1-5003/22-01-01_B February 06, 2024 DescriptionInternal photographs of EUT This document is electronically signed and valid without handwritten signature. Public keys for verification of the electronic signatures can be requested at the testing laboratory. Authorized Michael Dorongovski Lab Manager Radio Labs cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_B Release 1 - Page 1 of 5 Photo 1 Photo 2 cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_B Release 1 - Page 2 of 5 Photo 3 Photo 4 cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_B Release 1 - Page 3 of 5 Photo 5 Photo 6 cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_B Release 1 - Page 4 of 5 Photo 7 Photo 8 - END OF DOCUMENT - cetecom advanced GmbH Untertürkheimer Str. 6-10, 66117 Saarbrücken Document No. 1-5003/22-01-01_B Release 1 - Page 5 of 5

© cetecom advanced GmbH Page 1 of 3 BNetzA - CAB - 02/21 - 102 RF Exposure Evaluation according to KDB 447498 D01 v06 Report identification number: 1-5003/22-01-13_MPE_FCC Certification numbers and labeling requirements FCC ID 2AJW5ACCM1 This test report is electronically signed and valid without handwritten signature. For verification of the electronic signatures, the public keys can be requested at the testing laboratory. Document authorised: Alexander Hnatovskiy Marco Scigliano Lab Manager Testing Manager Radio Labs Radio Labs Report no.: 1-5003/22-01-13 © cetecom advanced GmbH Page 2 of 3 1. MPE at given distance (KDB 447498 D01 General RF Exposure Guidance v06) Equation from page 18 of OET Bulletin 65, Edition 97-01 S = PG / 4π R 2 where: S = Power density P = Power input to the antenna G = Antenna gain R = Distance to the center of radiation of the antenna PG = Output Power including antenna gain The table below is excerpted from Table 1B of 47 CFR 1.1310 titled “Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure” Frequency Range (MHz) Power Density (mW/cm 2 ) Averaging Time (minutes) 300 -1500 f/1500 30 1500 - 100000 1.0 30 where f = Frequency (MHz) 2. EUT technologies Declared minimum safety distance: 20 cm f Min f Max #P Meas P Max Peak GainP RF Exp S Result S Limit % GSM 850 824849A31.5532.00-6.2922.710.040.556.76% GSM 1900 18501910B28.5530.502.7530.250.211.0021.07% WCDMA Band II 18501910B23.0824.002.7526.750.091.009.41% WCDMA Band V 824849A23.2724.00-6.2917.710.010.552.14% LTE Band 2 18501910C23.4725.002.7527.750.121.0011.85% LTE Band 4 17101755D23.9625.002.3127.310.111.0010.71% LTE Band 5 824849E24.0425.00-6.2918.710.010.552.69% LTE Band 12 699716F24.3925.000.8825.880.080.4716.53% LTE Band 13 777787G24.0725.00-1.9323.070.040.527.79% LTE Band 26 814849H24.1325.00-6.2918.710.010.542.72% Cellular Technology Conducted Frequency [MHz] Reference Output Power [dBm] Power Density [mW/cm²] Share of Limit Correction Notes: - GSM corrected by 10 log (4/8) = - 3 dB (time slots considerations) - Max rated conducted output power taken from customer’s tune up info Report no.: 1-5003/22-01-13 © cetecom advanced GmbH Page 3 of 3 Referenced Documents: # Results from: A Test Report Module PCB - GSM, WCDMA, LTE Part 1: Page 53 B Test Report Module PCB - GSM, WCDMA, LTE Part 2: Page 106 C Test Report Module PCB - GSM, WCDMA, LTE Part 2: Page 108 D Test Report Module PCB - GSM, WCDMA, LTE Part 2: Page 157 E Test Report Module PCB - GSM, WCDMA, LTE Part 1: Page 55 F Test Report Module PCB - GSM, WCDMA, LTE Part 2: Page 158 G Test Report Module PCB - GSM, WCDMA, LTE Part 2: Page 159 H Test Report Module PCB - GSM, WCDMA, LTE Part 1: Page 56 f Min f Max # P ERP P EIRP P RF Exp S Result S Limit % Bluetooth LE 2402 2480 H N/A 3.0 3.0 0.00 1.00 0.04% SRD Technology Frequency [MHz] Reference Power Density [mW/cm²] Share of Limit Output Power [dBm] Referenced Documents: # Results from: H Test Report 1-5003_22-01-12: Page 18 3. Collocation overview: GSM 1900 21.07% Bluetooth LE 0.04% Technology Share of Limit [%] Sum 21.11% 4. Conclusion This prediction demonstrates the following: The power density levels for FCC at a distance of 20 cm are below the maximum levels allowed by regulations. Conclusion: RF exposure evaluation is not required.

Test Laboratory: 7layers GmbH Borsigstrasse 11 40880 Ratingen Germany Note: The following test results relate only to the devices specified in this document. This report shall not be reproduced in parts without the written approval of the test laboratory. 7layers GmbH Geschäftsführer/ Borsigstraße 11 Managing Directors: Registergericht/registered: a Bureau Veritas 40880 Ratingen, Germany Frank Spiller Düsseldorf HRB 75554 Group Company T +49 (0) 2102 749 0 Bernhard Retka USt-Id.-Nr./VAT-No. DE203159652 F +49 (0) 2102 749 350 Alexandre Norré- Oudard Steuer -Nr./TAX -No. 147/5869/0385 www.7layers.com Commerzbank AG Account No. 303 016 000 Bank Code 300 400 00 IBAN DE81 3004 0000 0303 0160 00 Swift Code COBADEFF FCC Measurement/Technical Report on LARA-R6001 / LARA-R6001D 2G / 3G / LTE module FCC ID: XPYUBX21BE01 IC: 8595A-UBX21BE01 Test Report Reference: MDE_UBLOX_2029_FCC_01 TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 2 of 285 Table of Contents 1 Applied Standards and Test Summary 4 1.1 Applied Standards 4 1.2 FCC-IC Correlation Table 6 1.3 Measurement Summary 10 2 Revision History / Signatures 45 3 Administrative Data 46 3.1 Testing Laboratory 46 3.2 Project Data 46 3.3 Applicant Data 46 3.4 Manufacturer Data 46 4 Test object Data 47 4.1 General EUT Description 47 4.2 EUT Main components 47 4.3 Ancillary Equipment 49 4.4 Auxiliary Equipment 49 4.5 EUT Setups 49 4.6 Operating Modes / Test Channels 50 4.7 Product labelling 51 5 Test Results 52 5.1 RF Output power 52 5.2 Frequency stability 61 5.3 Spurious emissions at antenna terminals 67 5.4 Field strength of spurious radiation 74 5.5 Emission and occupied bandwidth 87 5.6 Band edge compliance 95 5.7 Peak-average-ratio 102 5.8 RF Output power 105 5.9 Frequency stability 112 5.10 Spurious emissions at antenna terminal 119 5.11 Field strength of spurious radiation 125 5.12 Emission and occupied bandwidth 137 5.13 Band edge compliance 144 5.14 Peak to Average Ratio 150 5.15 RF Output Power 153 5.16 Frequency stability 166 5.17 Spurious emissions at antenna terminals 174 5.18 Field strength of spurious radiation 183 5.19 Emission and occupied bandwidth 200 5.20 Band edge compliance 209 5.21 Peak to Average Ratio 220 5.22 RF Output Power 227 TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 3 of 285 5.23 Frequency stability 230 5.24 Spurious emissions at antenna terminals 232 5.25 Field strength of spurious radiation 235 5.26 Emission and occupied bandwidth 241 5.27 Band edge compliance 244 5.28 Peak to Average Ratio 247 5.29 RF Output Power 250 5.30 Spurious Emissions at antenna terminals 253 5.31 Field Strength of Spurious Radiation 256 5.32 Emission and Occupied Bandwidth 262 5.33 Band Edge 266 5.34 Peak to Average Ratio 269 6 Test Equipment 271 7 Antenna Factors, Cable Loss and Sample Calculations 275 7.1 LISN R&S ESH3-Z5 (150 kHz – 30 MHz) 275 7.2 Antenna R&S HFH2-Z2 (9 kHz – 30 MHz) 276 7.3 Antenna R&S HL562 (30 MHz – 1 GHz) 277 7.4 Antenna R&S HF907 (1 GHz – 18 GHz) 278 7.5 Antenna EMCO 3160-09 (18 GHz – 26.5 GHz) 279 7.6 Antenna EMCO 3160-10 (26.5 GHz – 40 GHz) 280 8 Measurement Uncertainties 281 9 Photo Report 285 TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 4 of 285 1 APPLIED STANDARDS AND TEST SUMMARY 1.1 APPLIED STANDARDS Type of Authorization Certification for a cellular mobile device. Applicable FCC Rules Prepared in accordance with the requirements of FCC Rules and Regulations as listed in 47 CFR Ch.1 Parts 2 and 22, 24,27 and 90, (10-1-20 Edition). The following subparts are applicable to the results in this test report. Part 2, Subpart J - Equipment Authorization Procedures, Certification Part 22, Subpart H – Cellular Radiotelephone Service § 22.905 – Channels for cellular service § 22.913 – Effective radiated power limits § 22.917 – Emission limitations for cellular equipment Part 24, Subpart E – Broadband PCS § 24.232 – Power and antenna height limits § 24.235 – Frequency stability § 24.238 – Emission limitations for Broadband PCS equipment Part 27; Miscellaneous Wireless Communications Services Subpart C – Technical standards § 27.50 – Power and duty cycle limits § 27.53 – Emission limits § 27.54 – Frequency stability Part 27; Miscellaneous Wireless Communications Services Subpart P – Technical standards § 27.1507 – Power and duty cycle limits § 27.1509 – Emission limits § 27.54 – Frequency stability TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 5 of 285 Part 90; Private Land Mobile Radio Services Subpart S—REGULATIONS GOVERNING LICENSING AND USE OF FREQUENCIES IN THE 806- 824, 851-869, 896-901, AND 935-940 MHZ BANDS Subpart R—REGULATIONS GOVERNING THE LICENSING AND USE OF FREQUENCIES IN THE 763-775 AND 793-805 MHZ BANDS § 90.635 – Limitations on power and antenna height § 90.543 – Emission limitations § 90.539 – Frequency stability The tests were selected and performed with reference to: • FCC Public Notice 971168 applying “Measurement guidance for certification of licensed digital transmitters” 971168 D01 v03r01, 2018-04-09 • ANSI C63.26: 2015 TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 6 of 285 1.2 FCC-IC CORRELATION TABLE Correlation of measurement requirements for Cellular Mobile Devices from FCC and ISED Canada Measurement FCC reference ISED reference RF Output Power § 2.1046 § 22.913 RSS-GEN Issue 5, 6.12 RSS-132 Issue 3, 5.4 Peak-Average-Ratio - RSS 132 Issue 3: 5.4 Emission and Occupied bandwidth § 2.1049 RSS-GEN Issue 5, 6.7 Spurious Emission at Antenna Terminals § 2.1051 § 22.917 RSS-GEN Issue 5, 6.13 RSS-132 Issue 3, 5.5 Band Edge Compliance § 2.1051 § 22.917 RSS-GEN Issue 4, 6.13 RSS-132 Issue 3, 5.5 Frequency stability § 2.1055 § 22.355 RSS-GEN Issue 5, 6.11 RSS-132 Issue 3: 5.3 Field strength of spurious radiation § 2.1053 § 22.917 RSS-GEN Issue 5, 6.13 RSS-132 Issue 3: 5.5 TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 7 of 285 Correlation of measurement requirements for Cellular Mobile Devices from FCC and ISED Canada Measurement FCC reference ISED reference RF Output Power § 2.1046 …

Text truncated - open the document above for the full version.

TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 104 of 285 5.7.4 MEASUREMENT PLOT (EXAMPLE PLOT, SHOWING WORST CASE, IF APPLICABLE) LTE eFDD 5 16QAM, Channel = mid LTE eFDD 26 16QAM, Channel = mid 5.7.5 TEST EQUIPMENT USED - Radio Lab TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 105 of 285 5.8 RF OUTPUT POWER Standard FCC PART 24 Subpart E The test was performed according to: ANSI C63.26: 2015 5.8.1 TEST DESCRIPTION This test case is intended to demonstrate compliance to the applicable RF Output power test case per § 2.1046 and RSS-GEN 6.12. The limit and the requirements come from the applicable rule part and ISED RSS-Standard for the operating band of the cellular device. The EUT was connected to the test setup according to the following diagram: The attenuation of the measuring and stimulus path are known for each measured frequency and are considered. The Spectrum Analyzer settings can be directly found in the measurement diagrams. 5.8.2 TEST REQUIREMENTS / LIMITS FCC Part 24, § 24.232 (c) Mobile and portable stations are limited to 2 watts EIRP and the equipment must employ a means for limiting power to the minimum necessary for successful communications. TEST REPORT REFERENCE: MDE_UBLOX_2029_FCC_01 Page 106 of 285 RSS-133; 6.4 Transmitter Output Power and Equivalent Isotropically Radiated Power The equivalent isotropically radiated power (e.i.r.p.) for transmitters shall not exceed the limits given in SRSP-510. SRSP-510; 5.1.2 Radiated Power and Antenna Height Limits – Mobile Stations Mobile stations and hand-held portables are limited to 2 watts maximum e.i.r.p. The equipment shall employ means to limit the power to the minimum necessary for successful communication. 5.8.3 TEST PROTOCOL Ambient temperature: 20 - 28 °C Relative humidity: 30 - 45 % Radio Technology Channel Re- source Blocks Band- width [MHz] Peak Cond. Power [dBm] Average Cond. Power [dBm] RMS Cond. Power [dBm] FCC EIRP Limit [W] IC EIRP Limit [W] Max Antenna Gain FCC [dBi] Max Antenna Gain IC [dBi] GSM 1900 low - 0.2 29.10 28.42 28.55 2 2 3.90 3.90 GSM 1900 mid - 0.2 28.93 28.28 28.42 2 2 4.07 4.07 GSM 1900 high - 0.2 28.89 28.22 28.36 2 2 4.11 4.11 GSM 1900 EDGE low - 0.2 28.02 24.71 25.20 2 2 4.98 4.98 GSM 1900 EDGE mid - 0.2 28.07 24.95 25.28 2 2 4.93 4.93 GSM 1900 EDGE high - 0.2 28.02 24.64 25.14 2 2 4.98 4.98 FDD II low - 5 28.52 22.95 23.08 2 2 9.92 9.92 FDD II mid - 5 28.12 22.80 23.01 2 2 9.99 9.99 FDD II high - 5 28.12 22.91 23.04 2 2 9.96 9.96 FDD II HSDPA Subtest 1 low - 5 27.62 22.39 22.59 2 2 10.41 10.41 FDD II HSDPA Subtest 1 mid - 5 27.49 21.98 22.48 2 2 10.52 10.52 FDD II HSDPA Subtest 1 high - 5 27.62 22.00 22.36 2 2 10.64 10.64 FDD II HSDPA Subtest 2 low - 5 28.64 22.61 22.37 2 2 10.63 10.63 FDD II HSDPA Subtest 2 mid - 5 28.39 21.74 22.26 2 2 10.74 10.74 FDD II HSDPA Subtest 2 high - 5 28.27 21.67 22.18 2 2 10.82 10.82 FDD II HSDPA Subtest 3 low - 5 28.89 21.82 22.59 2 2 10.41 10.41 FDD II HSDPA Subtest 3 mid - 5 28.52 21.58 22.75 2 2 10.25 10.25 FDD II HSDPA Subtest 3 high - 5 28.12 21.82 22.59 2 2 10.41 10.41 FDD II HSDPA Subtest 4 low - 5 28.64 22.03 22.83 2 2 10.17 10.17 FDD II HSD…
