eInstruction Diagram eBasic Camera Operation Charging: Type-C only supports DC 5V power supply, please use conventional phone charger or power bank. Green light will turn on during charging, while it will tun off when it is fully charged.It takes about 2 hours to get fully charged. Low Battey Reminder: When the battery is lower than 8%, the camera vibrates 4 times continuously, 30s each vibration. Capacity up to 128GB; High Speed SD card (Class 10/UHS-I/UHS-II/UHS-III )is highly recommended MicroSD Card Push button down, LED1 and LED2(Red Light) turn off simultaneously Long pressing WIFI button 3s, LED1 (Blue light) off, the camera turns off simultaneously Forced shutdown Long pressing WIFI button 8s No SD card or SD card abnormality, LED1, LED2 have a quick flash simultaneously Note: The camera only supports FAT32 or exFAT format, SD cards over 64GB must be formatted via the App. Operation1: Long Pressing WIFI button 3s in recording status Waiting for a connection: LED1( Blue light flashes slowly at 1s interval), Connected: LED1(Blue Light is on) Operation2: Long Pressing WIFI button 3s in shutdown status Waiting for a connection: LED1( Blue light flashes slowly at 1s interval) Connected: LED1(Blue Light is on) Push button up, LED1, LED2(Red Light) have a slow flash at 1s interval simultaneously Scope cam 2 User Manual Stop Recording Open WIFI Close WIFI Abnormal Status Start Recording eConnection to the Computer 5ZQF$ eParameter e"QQ 1. Long press WiFi button 3s, LED1(blue light) flashes, WiFi is started and waiting for connection. 3. Default SSID: RCSC02_*****PW:1234567890 2. Find the SSID connection of the Scope Cam 2 in the wireless network of the mobile phone and enter the password, after successful connection, firmware update/WIFI indicatorblue light) is constantly on U Disk Mode: Connecting to PC via TYPE-C to USB, the camera will enter into U disk mode automatically, recording indicator(red light is on WEBCAM/PCCAM/UVC Mode Short pressing WIFI button to switch to WEBCAM/PCCAM/UVC mode in U disk mode, then Short pressing WIFI button can switch back and forth to U Disk or WEBCAM mode. NOTICE: If the camera cannot be recognized after connecting to the computer, please confirm whether there is microSD card in Scope cam 2. If the information in the SD card cannot be read normally, please replace the USB cable or retry the computer USB port. eFirmware Upgrade Firmware Upgrade Status (Blue light blinks)Ensure that the Scope Cam battery is more than 50% before the upgrade. Manually copy the firmware file (FWSCLITE.bin) onto the microSD card. Follow the instruction on https://runcam.com/download/scopecam2. To get the latest features and best performance from your Scope Cam, make sure you are using the most current camera software. You can update your firmware with the RunCam App or at https://runcam.com/download/scopecam2. Android and iOS APP: Search 'RunCam App' on Google Play/App Store, or download on our website: https://runcam.com/download/scopecam2. Image Sensor Lens ISO Shutter Resolution Video format Memory Card File system Battery Battery life Charging time Wi-Fi USB Interface Work Current Work Temp Housing Material Vibration motor Waterproof Mount Net Weight Dimensions 1/2.9”CMOS 2MP 40mm@FOV 8.2 25mm@FOV 12° 3.6mm@FOV 126 100 / 200 / 400 / 800 / 1600 1~1/500s 1080P@60fps / 1080P@50fps / 720P@90fps MP4(H.264) Micro SD(Max 128g) Fat32/exFat 1400mAh About 240 minutes (1080P@60fps) About 120 minutes 2.4g Type-C 1.25W (wi-fi off) -10°C ~ 45°C Aluminum alloy & PA Built-in IP64 Picatinny 40mm@135g 25mm@130g 3.6mm@118g 112mm*32mm*36mm 93mm*32mm*36mm 79mm*32mm*36mm eTechnical Support Please visit: https://support.runcam.com/hc/en-us     WiFi Button Powering on /off Switch  LED1 Red LightRecording Status/ Blue Light(WiFi Status)  LED2 Red Light( Recording Status)/ Green Light (Charging Status)  Type-C   Micro-SD Card Slot MICROPHONE      FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cables when connecting to computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Radiation Exposure Statement: The equipment complies with FCC Radiation exposure limits set forth for uncontrolled enviroment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. .

RunCam Technology (Shenzhen) Co., Ltd. Add: No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Date: 2021-5-7 FCC ID: 2AK4W-SCOPECAM Dear Sir/Madam, We, RunCam Technology (Shenzhen) Co., Ltd. Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: RunCam Scope Cam 2 Model no.: ScopeCam, ScopeCam4K 、ScopeCamLite、Scope Cam、ScopeCam*、Scope Cam*、 ScopeCamLite* (* represents 18-digit characters, and each character can be anything ranging from 0 to 9, A to Z, and symbols like “- “or “space” and different product models. And * is targeted at different sales territories, sales regions, sales methods, varied client groups, different market positioning and different product colors, and won’t affect the product safety and electromagnetic compatibility) Sincerely, Name/Title： Sunny Mao/Engineer Company: RunCam Technology (Shenzhen) Co., Ltd. Address: No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Phone: 13312990069 Fax: 0755-83692330 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021-5-7> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AK4W-SCOPECAM ScopeCam For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： Sunny Mao/Engineer Company: RunCam Technology (Shenzhen) Co., Ltd. Address: No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Phone: 13312990069 Fax: 0755-83692330 E-Mail: [email protected]

RunCam Technology (Shenzhen) Co., Ltd. No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Date: 2021-5-7 FCC ID: 2AK4W-SCOPECAM Model Number: ScopeCam To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, RunCam Technology (Shenzhen) Co., Ltd., declare that this EUT (FCC ID: 2AK4W-SCOPECAM) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, Name/Title： Sunny Mao/Engineer Company: RunCam Technology (Shenzhen) Co., Ltd Address: No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Phone: 13312990069 Fax: 0755-83692330 E-Mail: [email protected]

RunCam Technology (Shenzhen) Co., Ltd. No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-5-7 To whom it may concern: We, RunCam Technology (Shenzhen) Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AK4W-SCOPECAM including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： Sunny Mao/Engineer Company: RunCam Technology (Shenzhen) Co., Ltd. Address: No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Phone: 13312990069 Fax: 0755-83692330 E-Mail: [email protected]

Page: 3 of 9 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Page: 4 of 9 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Photo 3 Appearance of EUT

Page: 1 of 9 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Appendix IFCC ID Label Size for the label: 10mm X10mm Model: ScopeCam FCCID: 2AK4W-SCOPECAM Page: 2 of 9 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

Page: 5 of 10 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 4 Internal of EUT Photo 5 Internal of EUT 9 Page: 6 of 10 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Photo 6 Internal of PCB Photo 7 Appearance of PCB Page: 7 of 10 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Photo 8 Appearance of PCB Photo 9 Appearance of PCB Antenna Page: 8 of 10 FCC ID:2AK4W-SCOPECAM TB-RF-074-1.0 Photo 10 Appearance of PCB

Report No.: TB-MPE178981 Page: 1 of 3 TB-RF-075-1.0 Maximum Permissible Exposure Evaluation FCC ID: 2AK4W-SCOPECAM 1. Client Information Applicant : RunCam Technology (Shenzhen) Co., Ltd. Address : No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China Manufacturer : RunCam Technology (Shenzhen) Co., Ltd. Address : No. 310, 1 Jinxing Road, Xinmu Community, Pinghu Street, Longgang District, Shenzhen, China 2. General Description of EUT EUT Name : RunCam Scope Cam 2 Models No. : ScopeCam、ScopeCam4K、ScopeCamLite、Scope Cam、 ScopeCam*、Scope Cam*、ScopeCamLite* (* represents 18-digit characters, and each character can be anything ranging from 0 to 9, A to Z, and symbols like “- “or “space” and different product models. And * is targeted at different sales territories, sales regions, sales methods, varied client groups, different market positioning and different product colors, and won’t affect the product safety and electromagnetic compatibility) Model Different : All these models are the same on the same PCB, layout and circuit, the only difference is the appearance and model. Brand Name : RunCam Product Description : Operation Frequency: 802.11b/g/n(HT20): 2412MHz~2462MHz 802.11n (HT40):2422MHz~2452MHz Number of Channel: 802.11b/g/n(HT20):11 Channels 802.11n (HT40):7 Channels RF Output Power: 802.11b: 16.629dBm 802.11g: 16.306dBm 802.11n(HT20): 14.840dBm 802.11n(HT40): 12.562dBm Antenna Gain: 2 dBi PIFA Antenna Power Rating : USB Input: DC 5V2A, DC 3.7V by 1400mAh Li-ion battery Software Version : V1.0 Hardware Version : N/A Connecting I/O Port(S) : : Please refer to the User's Manual Remark : the MPE report used the EUT(20210126-06-2#). Report No.: TB-MPE178981 Page: 2 of 3 TB-RF-075-1.0 MPE Calculations for WIFI 1. Antenna Gain: Dipole Antenna:2dBi. 2. EUT Operation Condition: Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 3. Exposure Evaluation: Equation from page 18 of OET Bulletin 65, Edition 97-01 S=(PG)/4πR 2 Where S: power density P: power input to the antenna G: power gain of the antenna in the direction of interest relative to an isotropic radiator. R: distance to the center of radiation of the antenna 4. Test Result: 2.4G WiFi Mode Conducted Power(max) (dBm) Turn-up Power (dB) Max tune up power (dBm) [P] ANT Gain (dBi) [G] Distance (cm) [R] Power Density (mW/ cm 2 ) [S] Limit of Power Density (mW/ cm 2 ) (S) 802.11B 16.629 16±1 17 2 20 0.01580 1 802.11G 16.306 16±1 17 2 20 0.01580 1 802.11N(HT20) 14.840 14±1 15 2 20 0.00997 1 802.11N(HT40) 12.562 12±1 13 2 20 0.00629 1 Report No.: TB-MPE178981 Page: 3 of 3 TB-RF-075-1.0 5. Conclusion: As specified in Table 1B of 47 CFR 1.1310- Limits for Maximum Permissible Exposure (MPE), Limits for General Population/ Uncontrolled Exposure Frequency Range (MHz) Power density (mW/ cm 2 ) 300-1,500 F/1500 1,500-100,000 1.0 For 2.4WIFI:2412~2462 MHz MPE limit S: 1mW/ cm 2 The MPE is calculated as 0.01580 mW / cm 2 < limit 1mW / cm 2 . So, RF exposure limit warning or SAR test are not required. The EUT will only be used with a separation of 20cm or greater between the antenna and nearby persons and can therefore be considered a mobile transmitter per 47 CFR2.1091 (b). The RF Exposure Information page from the manual is included here for reference. Note For a more detailed features description, please refer to the RF Test Report. 6. Conclusion: The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. -----END OF REPORT-----
