MABU2 (M0208) Product User Manual 1 Device Safety Information To reduce the risk of injury or damage, refer to the following guidelines when operating Mabu: General Guidelines ● Read all safety and operating instructions before operating Mabu. ● Retain the safety and operating instructions for future reference. ● Heed all warnings provided by this user manual. ● Follow all operating and use instructions. ● Keep Mabu in a room temperature environment. Safety Warnings ● Do not expose Mabu to extreme temperatures. ● The product should be situated away from heat sources such as radiators, stoves, or other products that produce heat. ● Do not submerge Mabu in water or leave her in extreme humidity. ● Keep Mabu away from exposed flames. ● Please avoid poking Mabu in the eyes and neck; these are pinch points and may cause you injury. ● Do not attempt to disassemble Mabu, or expose her electronics, as opening or removing parts may expose you to parts that could result in fire or electric shock. ● Do not attempt to remove Mabu’s touch screen module. ● Use only the provided charger to charge Mabu. ● Mabu is not a toy. Please supervise young children around Mabu when she is operational. ● Keep Mabu away from pets, as they may knock her over and cause damage or malfunction. ● Damage requiring service: unplug this device from the wall outlet and refer servicing to the Mabu help desk under the following conditions: 2 ○ When the power supply or plug is damaged. ○ If liquid has been spilled, or objects have fallen into the product. ○ If the product does not operate normally by following operating instructions. ○ If the product has been damaged. ● Mabu has a cellular component that may interfere with certain medical devices like hearing aids and pacemakers. Please keep them more than 8 inches away when Mabu is powered on. How to Operate Mabu First Time Setup: ● Take Mabu out of her box. ● Set her in a place where you can easily talk with Mabu every day, with an accessible power outlet. ● Plug the power adapter into the outlet, and connect the power plug to the connector on her back. It’s important to keep Mabu plugged in at all times. ● The “Mabu” logo screen should appear once the power plug is connected. It may take a few seconds; after all, she’s been asleep for a while! ● Once she wakes up, you’re ready to go! ● After you’ve set her up, if you need to move her, be sure to unplug her first. Note: Mabu will power off automatically after 30 seconds once unplugged or loses power. She will resume normal operation if power is reconnected within this time. Otherwise, she will power down, and once power is reconnected, the “Mabu” logo screen will appear. Wake Up, Restart, and Power Off: ● If she falls asleep, just double-tap her screen to wake her. 3 ● If she needs to be restarted for any reason, unplug Mabu and allow her to power off. Mabu will automatically power off after 30 seconds. To restart, reconnect her power plug after she has powered off. The “Mabu” logo will reappear. ● If you need to turn her off for any reason, unplug Mabu and allow her to power off. Mabu will automatically power off after 30 seconds. Interacting with Mabu: ● Mabu will move her head and eyes around when interacting with you, displaying various animations like blinking. If for some reason her head or eyes are not moving, please try to restart her. If that does not work, please call the technical service line at 1- 855-8MY-MABU (1-855-869-6228). ● Try to position Mabu so that she is not facing any bright lights; she will not be able to look at you if she is blinded! ● Mabu will explain to you how to interact with her in the first time setup. ● Mabu will ask questions verbally in conversation; to respond, you can use two methods: ○ Voice: Respond vocally to her question; just be sure to say what is on the button responses. (She is still learning how to talk to humans!) ○ Touch buttons: Press the appropriate response on her screen. ● Some responses require text input. When appropriate, a keyboard will appear to input text. Use the keyboard and press the appropriate button when finished. ● Some responses require selecting a date or time. Cycle through the options using the arrow buttons that appear and press the appropriate button when finished. Volume Control: ● To adjust the volume of Mabu’s voice, say “Speak Louder” or “Speak Softer” at any point in her conversation (after she 4 finishes speaking, of course). She will confirm with you if her volume is loud or soft enough on the next screen. Repeat the appropriate command until Mabu is at the desired volume. ● You can confirm Mabu’s volume setting by pressing the button on the confirm screen or saying what’s on the button. Wifi Networking: ● Out of the box, Mabu tries to connect directly through her own cellular network connection, and there is nothing you have to set up. If you live in an area with poor cellular service, or if she has trouble establishing a connection, then she may ask you to connect to your WiFi network. If she does ask you to connect, she'll want to know which WiFi network is yours. She'll show you a list of all networks nearby for you to choose from. Please be sure to use only secure wireless networks. After you've chosen a network, she will ask you for the password only if you have set one up previously. Important Security and Privacy Note: You should always use Mabu with a WiFi secure wireless network (i.e. one that requires a password to use) instead of an open network. Your personal health information is sent through the connection with your Wifi network. An unsecure network may allow this information to be captured or otherwise monitored. Please call the technical service line at 1-855-8MY-MABU (1-855-869-6228) if you have any questions. Storing Mabu: ● If Mabu needs to be stored away for any reason, please be sure to disconnect the power plug from the connector on Mabu’s back. ● Store Mabu in a cool, dry place, preferably in her original packaging. ● If …

Text truncated - open the document above for the full version.

Catalia Health Inc. Agent Authorization Date: 15th Apr, 2020 Company: Catalia Health Inc. Address: 118 2nd street, 2nd Floor, San Francisco, CA, USA, 94105 Product Description: Mabu FCC ID: 2AK8Y-M0208 Tested Model Number: M0208 We authorize Eurofins Product Service GmbH, Storkower Strasse 38c, D-15526 Reichenwalde, Germany, to act on our behalf on all matters concerning the certification of above mentioned equipment. We declare that Eurofins Product Service GmbH is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We, Catalia Health Inc., the undersigned, hereby authorize Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.), Shenzhen Microwave Certification Services Co., Ltd. (Gilbert Lui, Marketing Manager) and Ka.Ma.S UG (Karin Schmidt, CEO) on our behalf, to apply to the Federal Communications Commission on our equipment. We, the undersigned, hereby authorize Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.) to act on our behalf in matters relating to the application for a FCC equipment authorization for mentioned FCC ID Number including the signing of Form 731, necessary forms and documents in connection with this application. Any and all acts carried out by Shenzhen Toby Technology Co., Ltd. (Ivan Su, Supervisor of EMC Dep.) on our behalf shall have the same effect as acts of our own. This authorization expires on 31th December, 2020. Yours Sincerely, Catalia Health Inc. <Signature of Mechanical Engineering Lead > ----------------------------------------------------------------------------------- Kristopher Dos Santos / (Mechanical Engineering Lead) Address:118 2nd street, 2nd Floor, San Francisco, CA, USA, 94105 Phone: 415-660-9264 Fax: 415-660-9264 Email: [email protected]

CONFIDENTIALITY REQUEST for Certification under the FCC Rules Date: 15th Apr, 2020 Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the following product: FCC ID Number: 2AK8Y-M0208 Tested Model Number: M0208 For the product stated above, we request that the following information be held confidential: Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days Block Diagram Schematic Diagram/ Circuit Diagram Circuit Description/ Operational Description Parts List Tune Up Information User’s Manual 180days External Photos 180days Internal Photos 180days Test Setup Photos 180days The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. Please do not hesitate to contact me if you have any queries. Yours Sincerely, Catalia Health Inc. <Signature of Mechanical Engineering Lead > ----------------------------------------------------------------------------------- Kristopher Dos Santos / (Mechanical Engineering Lead) 118 2nd street, 2nd Floor, San Francisco, CA, USA, 94105 Phone: 415-660-9264 Fax: 415-660-9264 Email: [email protected]

Report No.: TB-FCC171159 Page: 3 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Report No.: TB-FCC171159 Page: 4 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT Report No.: TB-FCC171159 Page: 5 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT Report No.: TB-FCC171159 Page: 6 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Photo 7 Appearance of EUT Photo 8 Appearance of EUT

Report No.: TB-FCC171159 Page: 1 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Appendix IFCC ID Label Wide & length:20mm *30mm FCC ID: 2AK8Y-M0208 Catalia Health Inc. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Model: M0208 Report No.: TB-FCC171159 Page: 2 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Appendix II ID Label Location ID LOCATION

Report No.: TB-FCC171159 Page: 7 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Appendix IV EUT Internal Photographs Photo 11 Internal of EUT Photo 12 Internal of EUT BT/2.4WIFI Ant. Diversity LTE Ant. Main LTE Ant. Report No.: TB-FCC171159 Page: 8 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Photo 13 Internal of EUT Photo 14 Appearance of PCB Report No.: TB-FCC171159 Page: 9 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Photo 15 Appearance of PCB Photo 16 Appearance of PCB Report No.: TB-FCC171159 Page: 10 of 13 FCC ID:2AK8Y-M0208 TB-RF-074-1.0 Photo 17 Battery parameter

Ref : ACR.233.1.17.SATU.A WALTEK TESTING GROUP (SHENZHEN) CO., LTD. 1/F, BUILDING A, HONGWEI INDUSTRIAL PARK, LIUXIAN 2ND ROAD BAO'AN DISTRICT SHENZHEN (518101), CHINA MVG COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 45/15 EPGO280 Calibrated at MVG US 2105 Barrett Park Dr. - Kennesaw, GA 30144 Calibration Date: 07/08/2019 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in MVG USA using the CALISAR / CALIBAIR test bench, for use with a COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 2/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 7/8/2019 Checked by : Jérôme LUC Product Manager 7/8/2019 Approved by : Kim RUTKOWSKI Quality Manager 7/8/2019 Customer Name Distribution : Waltek Testing Group (Shenzhen) Co., Ltd. Issue Date Modifications A 7/8/2019 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 3/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment .................................................................................................... 10 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 4/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer MVG Model SSE2 Serial Number SN 45/15 EPGO280 Product Condition (new / used) New Frequency Range of Probe 0.7 GHz-6GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.193 M Dipole 2: R2=0.188 M Dipole 3: R3=0.198 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION MVG’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – MVG COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 2 mm Maximum external diameter 8 mm Probe Tip External Diameter 2.5 mm Distance between dipoles / probe extremity 1 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.233.1.17.SATU.A Page: 5/10 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid, with the plasti…

Text truncated - open the document above for the full version.

Model: M0208 Report No.: WTX20X05026059W Page 1 of 90 SAR Report FCC SAR Measurement and Test Report For Catalia Health Inc. 118 2nd Street, 2nd Floor, San Francisco, CA, USA, 94105 FCC ID: 2AK8Y-M0208 Test Standards: FCC Part 2.1093 ANSI / IEEE C95.1 :2005+A1:2010 ANSI / IEEE C95.3 : 2002(R2008) IEEE 1528 :2013 Product Description: Mabu Tested Model: M0208 Report No.: WTX20X05026059W Sample Received Date: 2020-05-11 Tested Date: 2020-05-18 to 2020-05-25 Issued Date: 2019-05-26 Tested By: Jack Sun / Engineer Reviewed By: Lion Cai / RF Manager Approved & Authorized By: Silin Chen / Manager Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Waltek Testing Group (Shenzhen) Co., Ltd. Model: M0208 Report No.: WTX20X05026059W Page 2 of 90 SAR Report TABLE OF CONTENTS 1. General Information ................................................................................................................................................... 3 1.1 Product Description for Equipment Under Test (EUT) ......................................................................................... 3 1.2 Test Standards .................................................................................................................................................... 5 1.3 Test Methodology ................................................................................................................................................ 5 1.4 Test Facility ......................................................................................................................................................... 5 2. Summary of Test Results .......................................................................................................................................... 6 3. Specific Absorption Rate (SAR) ................................................................................................................................ 7 3.1 Introduction .......................................................................................................................................................... 7 3.2 SAR Definition ..................................................................................................................................................... 7 4. SAR Measurement System ........................................................................................................................................ 8 4.1 The Measurement System .................................................................................................................................. 8 4.2 Probe ................................................................................................................................................................... 8 4.3 Probe Calibration Process ................................................................................................................................. 10 4.4 Phantom ............................................................................................................................................................ 11 4.5 Device Holder .................................................................................................................................................... 11 4.6 Test Equipment List ........................................................................................................................................... 12 5. Tissue Simulating Liquids ....................................................................................................................................... 13 5.1 Composition of Tissue Simulating Liquid ........................................................................................................... 13 5.2 Tissue Dielectric Parameters for Head and Body Phantoms ............................................................................. 14 5.3 Tissue Calibration Result ................................................................................................................................... 15 6. SAR Measurement Evaluation ................................................................................................................................ 16 6.1 Purpose of System Performance Check ............................................................................................................ 16 6.2 System Setup .................................................................................................................................................... 16 6.3 Validation Results .............................................................................................................................................. 17 7. EUT Testing Position ............................................................................................................................................... 19 7.1 Define Two Imaginary Lines on The Handset .................................................................................................... 19 7.2 Cheek Position .................................................................................................................................................. 20 7.3 Tilted Position .................................................................................................................................................... 20 7.4 Body Position .................................................................................................................................................... 21 7.5 EUT Antenna Position ...............................................................…

Text truncated - open the document above for the full version.

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC171161 Page: 1 of 119 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2AK8Y-M0208 Original Grant Report No. : TB-FCC171161 Applicant : Catalia Health Inc. Equipment Under Test (EUT) EUT Name : Mabu Model No. : M0208 Series Model No. : N/A Brand Name : MABU2 Receipt Date : 2020-01-02 Test Date : 2020-01-03 to 2020-04-14 Issue Date : 2020-04-14 Standards : 47 CFR Part 2, 22(H), 24(E), 27 Test Method : ANSI C63.26 2015 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, Test/Witness Engineer : Jack Deng Engineer Supervisor : Ivan Su Engineer Manager : Ray Lai This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC171161 Page: 2 of 119 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT.............................................................................. 5 1.1 Client Information ................................................................................................................. 5 1.2 General Description of EUT (Equipment Under Test) ................................................... 5 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 9 1.4 Description of Support Units .............................................................................................. 9 1.5 Description of Test Mode .................................................................................................. 10 1.6 Measurement Uncertainty ................................................................................................ 11 1.7 Test Facility ......................................................................................................................... 11 2. TEST SUMMARY ..................................................................................................................... 12 3. TEST EQUIPMENT .................................................................................................................. 13 4. CONDUCTED RF OUTPUT POWER ................................................................................... 13 4.1 Test Standard and Limit .................................................................................................... 14 4.2 Test Setup ........................................................................................................................... 14 4.3 Test Procedure ................................................................................................................... 14 4.4 EUT Operating Condition ................................................................................................. 14 4.5 Deviation From Test Standard ......................................................................................... 14 4.6 Test Data ............................................................................................................................. 14 5. PEAK-AVERAGE RATIO ....................................................................................................... 15 5.1 Test Standard and Limit .................................................................................................... 15 5.2 Test Setup ........................................................................................................................... 15 5.3 Test Procedure ................................................................................................................... 15 5.4 EUT Operating Condition ................................................................................................. 15 5.5 Deviation From Test Standard ......................................................................................... 15 5.6 Test Data ............................................................................................................................. 15 6. OCCUPIED BANDWIDTH ...................................................................................................... 16 6.1 Test Standard and Limit .................................................................................................... 16 6.2 Test Setup ........................................................................................................................... 16 6.3 Test Procedure ................................................................................................................... 16 6.4 EUT Operating Condition ................................................................................................. 17 6.5 Deviation From Test Standard ......................................................................................... 17 6.6 Test Data ............................................................................................................................. 17 7. OUT OF BAND EMISSION AT ANTENNA TERMINALS ................................................. 18 7.1 Test Standard and Limit .................................................................................................... 18 7.2 Test Setup ........................................................................................................................... 18 7.3 Test Procedure ................................................................................................................... 19 7.4 EUT Operating Condition ..................................................…

Text truncated - open the document above for the full version.

Report No.: TB-FCC171161 Page: 79 of 119 TB-RF-074-1.0 Low Channel High Channel LTE BAND 2 (20MHz RB Size 100& RB Offset 0 QPSK) Report No.: TB-FCC171161 Page: 80 of 119 TB-RF-074-1.0 Low Channel High Channel LTE BAND 4 (1.4MHz RB Size 6& RB Offset 0 QPSK) LTE BAND 4 (1.4MHz RB Size 6& RB Offset 0 16QAM) Report No.: TB-FCC171161 Page: 81 of 119 TB-RF-074-1.0 Low Channel High Channel LTE BAND 4 (3MHz RB Size 15& RB Offset 0 QPSK) LTE BAND 4 (3MHz RB Size 15& RB Offset 0 16QAM) Report No.: TB-FCC171161 Page: 82 of 119 TB-RF-074-1.0 Low Channel High Channel LTE BAND 4 (3MHz RB Size 1& RB Offset 0 16QAM) LTE BAND 4 (3MHz RB Size 15& RB Offset 0 16QAM) Report No.: TB-FCC171161 Page: 83 of 119 TB-RF-074-1.0 Low Channel High C…
