FCC ID: 2AKAIDPF1011 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 802.11b 2.412 5.59 3.62 5±1 6.00 3.98 <5 1.23657 3.00 YES 802.11g 2.412 3.75 2.37 4±1 5.00 3.16 <5 0.98224 3.00 YES 802.11n20 2.462 3.63 2.31 4±1 5.00 3.16 <5 0.99237 3.00 YES Conclusion: For the max result : 1.23657＜3, the SAR testing is not required.

Antenna Test Report 客户名称：志和兴 项目名称: HN-DPF1011 频段：WIFI2.4G 版本：A 制作日期：2024-10-9 专业的4G/3G/GPS/WIFI等天线方案设计及供应商 Manufacturer: Shenzhen ShunDaCheng Technology Co.,Ltd. Contents 1： Antenna Overview & Dimension 2： The test project 2.1 Antenna Matching Network 2.2 VSWR 2.3 Gain & Efficiency 2.4 3D Date 2.5 The Free Space 3D Date/The Free Space 2D Date 3 : Ground processing Series N/A Antenna PA Shunt 01 N/A Shunt 02 N/A LocationDescription Shunt 01 N/A SeriesN/A Shunt 02N/A 天线尺寸图 Gain & Efficiency Frequency (MHz)Efficiency (%)Peak GAIN (dBi) 2400 43.361.43 2450 42.411.36 2500 42.161.32 WIFI OTA Data 2.4G 802.11b，(2.4G)11M ChannelCH1CH6CH11 TRP12.4112.2212.37 TIS -78.28-78.14-78.36 环境处理 天线安装位置图 WIFI天线 Thanks
