2AKAIHNDC03Digital Calendar

FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

Rev 1/26/2023 SHENZHEN HARMONY INDUSTRIAL CO., LTD Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-09-14 FCC ID: 2AKAIHNDC03 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing SHENZHEN HARMONY INDUSTRIAL CO., LTD certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. SHENZHEN HARMONY INDUSTRIAL CO., LTD certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing SHENZHEN HARMONY INDUSTRIAL CO., LTD certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: SHENZHEN HARMONY INDUSTRIAL CO., LTD Address: BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Contact Person: Xiaojun Zhou Tel.: +8613714192468 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-09-14 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2AKAIHNDC03) SHENZHEN HARMONY INDUSTRIAL CO., LTD, the undersigned, hereby authorize HOPEK CORPORATION INC to act as our designated agent for service of process, SHENZHEN HARMONY INDUSTRIAL CO., LTD accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. HOPEK CORPORATION INC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: SHENZHEN HARMONY INDUSTRIAL CO., LTD Contact Name: Xiaojun Zhou Address: BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Telephone No: +8613714192468 Email: [email protected] FRN: 0026011122 Signature: Xiaojun Zhou Agent Information: Company Name: HOPEK CORPORATION INC Address:16755 Coyote Bush Dr Unit 84, San Diego, CA 92127 United States FRN: 0034562900 Contact Name: Yangyang Xu Telephone No: 561-875-9826 Email: [email protected] Signature: Yangyang Xu

SHENZHEN HARMONY INDUSTRIAL CO., LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 14, 2026 Subject; Request for Confidentiality FCC ID: 2AKAIHNDC03 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Xiaojun Zhou Title: CEO

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 SHENZHEN HARMONY INDUSTRIAL CO., LTD Date：2026-09-14 Product Model Number: DC03, HN-DC2159, HN-DC2173, HN-DC2156 FCC ID：2AKAIHNDC03 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Xiaojun Zhou Contact Listed on FCC Wesbite Title: CEO Email: [email protected] On behalf of: SHENZHEN HARMONY INDUSTRIAL CO., LTD

SHENZHEN HARMONY INDUSTRIAL CO., LTD Declaration Letter of Model Difference Date: 2026-09-14 FCC ID: 2AKAIHNDC03 Tested Model Number: DC03 Adding Model Number(s): HN-DC2159, HN-DC2173, HN-DC2156 All Adding Model Number(s) is/are same electrically identical as Tested Model Number. Only the model and appearance color are different, everything else is the same. Yours Sincerely, Applicant: SHENZHEN HARMONY INDUSTRIAL CO., LTD Address: BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Contact Person: Xiaojun Zhou Tel.: +8613714192468 Email: [email protected] Sincerely, Signature:

Page 1 of 5 Report No.: LGT26H257 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT26H257 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT26H257 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 5 Report No.: LGT26H257 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT26H257 Appendix - External Photographs of EUT Constructional Details Photo 9 Photo 10

Label Size: 48*102mm FCC ID: 2AKAIHNDC03 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Page 1 of 6 Report No.: LGT26H257 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 ANT Page 2 of 6 Report No.: LGT26H257 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 6 Report No.: LGT26H257 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 6 Report No.: LGT26H257 Appendix - Internal Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 6 Report No.: LGT26H257 Appendix - Internal Photographs of EUT Constructional Details Photo 9 Photo 10 Page 6 of 6 Report No.: LGT26H257 Appendix - Internal Photographs of EUT Constructional Details Photo 11

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: Digital Calendar Model Number: DC03, HN-DC2159, HN-DC2173, HN-DC2156 FCC ID: 2AKAIHNDC03 Issued For : SHENZHEN HARMONY INDUSTRIAL CO., LTD BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26H257HA01 Sample Received Date: Aug. 27, 2026 Date of Test: Aug. 27, 2026 ~ Sep. 10, 2026 Date of Issue: Sep. 10, 2026 Report No.: LGT26H257HA01 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: SHENZHEN HARMONY INDUSTRIAL CO., LTD Address: BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Manufacturer: SHENZHEN HARMONY INDUSTRIAL CO., LTD Address: BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Product Name: Digital Calendar Trademark: N/A Model Number: DC03, HN-DC2159, HN-DC2173, HN-DC2156 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1091 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Chris Chen Engineer Technical Director Report No.: LGT26H257HA01 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Report No.: LGT26H257HA01 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Sep. 10, 2026 Initial Issue Report No.: LGT26H257HA01 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Digital Calendar Test Model Number: DC03 Series Number: HN-DC2159, HN-DC2173, HN-DC2156 Model Difference: Only the model and appearance color are different, everything else is the same Frequency Bands: 2.4G WLAN IEEE 802.11b/g/n(20MHz): 2412~2462MHz Adapter: Input: DC 12V/3A Hardware Version: Q320_V05_20260729 Software Version: Andorra 10.1 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26H257HA01 Page 6 of 8 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 0.3-3.0 614 1.63 *(100) 3.0-30 1842/f 4.89/f *(900/f 2 ) 30-300 61.4 0.163 1.0 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 1.34-30 824/f 2.19/f *(180/f 2 ) 30-300 27.5 0.073 0.2 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz * = Plane-wave equivalent power density. Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Report No.: LGT26H257HA01 Page 7 of 8 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Report No.: LGT26H257HA01 Page 8 of 8 2.5 TEST RESULT The MPE result of worst mode: RF Function Max Turn up Power (dBm) Max Turn up Power (mW) ANT Gain (dBi) ANT Gain (gain of antenna in linear scale) Power Density (mW/cm²) Limit (mW/cm²) Ratio Result 2.4G WIFI 16.00 39.81 1.37 1.37 0.011 1 0.011 Pass Note: 1. The Power Density is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 63 RF TEST REPORT Product Name: Digital Calendar Model Number: DC03, HN-DC2159, HN-DC2173, HN-DC2156 FCC ID: 2AKAIHNDC03 Issued For : SHENZHEN HARMONY INDUSTRIAL CO., LTD BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26H257RF01 Sample Received Date: Aug. 27, 2026 Date of Test: Aug. 27, 2026 ~ Sep. 10, 2026 Date of Issue: Sep. 10, 2026 Report No.: LGT26H257RF01 Page 2 of 63 TEST REPORT CERTIFICATION Applicant: SHENZHEN HARMONY INDUSTRIAL CO., LTD Address: BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Manufacturer: SHENZHEN HARMONY INDUSTRIAL CO., LTD Address: BLOCK 2,JIAYUAN INDUSTRIAL ZONE,HEPING COMMUNITY HIGH-TECH PARK,NO 2 FUYUANROAD,FUYONG,BAO’AN, SHENZHEN,China Product Name: Digital Calendar Trademark: N/A Model Number: DC03, HN-DC2159, HN-DC2173, HN-DC2156 Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26H257RF01 Page 3 of 63 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 29 4.1 LIMIT 29 4.2 TEST PROCEDURE 29 4.3 DEVIATION FROM STANDARD 29 4.4 TEST SETUP 29 4.5 EUT OPERATION CONDITIONS 29 4.6 TEST RESULTS 29 5. POWER SPECTRAL DENSITY TEST 30 5.1 LIMIT 30 5.2 TEST PROCEDURE 30 5.3 DEVIATION FROM STANDARD 30 5.4 TEST SETUP 30 5.5 EUT OPERATION CONDITIONS 30 5.6 TEST RESULTS 30 6. BANDWIDTH TEST 31 6.1 LIMIT 31 6.2 TEST PROCEDURE 31 6.3 DEVIATION FROM STANDARD 31 6.4 TEST SETUP 31 6.5 EUT OPERATION CONDITIONS 31 6.6 TEST RESULTS 31 Report No.: LGT26H257RF01 Page 4 of 63 7. PEAK OUTPUT POWER TEST 32 7.1 LIMIT 32 7.2 TEST PROCEDURE 32 7.3 DEVIATION FROM STANDARD 32 7.4 TEST SETUP 32 7.5 EUT OPERATION CONDITIONS 32 7.6 TEST RESULTS 32 8. ANTENNA REQUIREMENT 33 8.1 STANDARD REQUIREMENT 33 8.2 EUT ANTENNA 33 APPENDIX I - TEST RESULTS 34 DUTY CYCLE 34 MAXIMUM PEAK CONDUCTED OUTPUT POWER 38 -6DB BANDWIDTH 39 OCCUPIED CHANNEL BANDWIDTH 43 MAXIMUM POWER SPECTRAL DENSITY LEVEL 47 BAND EDGE 51 CONDUCTED RF SPURIOUS EMISSION 56 APPENDIX II - MEASUREMENT PHOTOS 63 Report No.: LGT26H257RF01 Page 5 of 63 Revision History Rev. Issue Date Revisions 00 Sep. 10, 2026 Initial Issue Report No.: LGT26H257RF01 Page 6 of 63 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024. Report No.: LGT26H257RF01 Page 7 of 63 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 All Emissions, Radiated (18GHz-40GHz) ±4.31dB 10 Temperature ±0.5°C 11 Humidity ±2% 12 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26H257RF01 Page 8 of 63 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Digital Calendar Test Model Number: DC03 Series Number: HN-DC2159, HN-DC2173, HN-DC2156 Model Difference: Only the model and appearance color are different, everything else is the same Product Description: Operation Frequency: 802.11b/g/n(20MHz): 2412~2462MHz Modulation Type: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM Number of Channel: 802.11b/g/n(20MHz): 11CH Antenna Designation: PIFA antenna Antenna Gain(dBi): 1.37 Channel List: Please re…

Text truncated - open the document above for the full version.

SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 SPECIFICATIONFORAPPROVAL ApprovalCustomerApproval PreparedByCheckedByApprovalByCheckedByApprovalBy Signature LiYaonaYangYonghuiFuXuerong Date2026.08.112026.08.112026.08.11 ChangeLog VersionChangeDescriptionPersonin Charge ApprovalByDate CustomerNameZhihexing CustomerProject Name HN-DC2173 SDCProject Name HN-DC2173 CustomerP/NSDCP/N WF714B-1131L-250 Band WIFI2.4G/5.8G/BTLogo:SDCF543AWF Version A0 DesignerInformation RFEngineerYangYonghuiR&DDiretorFuXuerong MEEngineerLiYaona SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 Catalogue No.ItemPageNo. 1DrawingorProductImage3 2DimensionsTestReport4 3RFPerformanceTestReport5-8 4ReliabilityTestReport19 5PackageDocument10 6RoHSControllistforSample11 7InstallWizardorOther11 SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 DrawingorProductImage L i Y a o N a W F 7 1 4 B - 1 1 3 1 L - 2 5 0 H N - D C 2 1 7 3 X . X ± 0 . 5 X . X X ± 0 . 2 X X X . ± 1 0 . 0 X X . ± 5 . 0 X . ± 2 . 0 1 2 5 0 1 N o t e : F o r w i r e s w i t h i n 6 0 m m , i f n o t r e q u i r e d b y t h e c u s t o m e r , t h e t e r m i n a l s f a c e d o w n b y d e f a u l t C u s t o m e r m o d e F i n i s h e d m a t e r i a l n u m b e r p r o p o r t i o n E d i t i o n U n i t V i e w C h a n g e c o n t e n t P a g e n u m b e r  S D C F 5 4 3 A W F H a n d a   SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 SampleDimensionsTestReport TestDate2026.08.11SampleQty.3Inspector XuYanfang DimensionNo.StandardSample1Sample2Sample3Pass/NG ①length48.68±0.2mm48.748.848.8 Pass ②width7.9±0.2mm7.98.08.0 Pass ③thickness0.1±0.03mm0.10.10.1 Pass ④wire length 250±2mm250251250 Pass ConclusionPASS Inspector&Date XuYanfang2026.08.11 Approval&Date SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 RFPerformanceTestReport AntennaTestEquipmentIntroduction TestofantennainputcharacteristicsusingAgilentE5071CandAgilent5062Avectornetwork analyzer;Theradiationpatternoftheantennaaretestedusingtheguangping3DnearfieldAnechoic Chamber,andtheinstrumentisusedtoagilent8960E5515andAgilentE4438C.Thetestcoordinatesofthe darkroomareasfollows: 1.S11Parameter-VSWR MeasuringMethodisa50Ωcoaxialcableisconnectedtotheantenna.Thenthiscableisconnectedtoanetworkanalyzerto measuretheS11parameter,Keepingthisfixtureawayfrommetalatleast20cm. SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 S11Parameter-VSWR 2.AntennaMatchingNetwork SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 3.Electricalparameter ： Electricalparameter （Frequencyrange）2400-2500MHz5150-5850MHz PolarizationmodeHorizontalandverticalpolarization Antennagain1.37dbi standing-waveratio＜2.0 Measurementprogram / Testequipment Agilent(5071B）/ROHDE&SCHWARZ (CMW500) TestSettings Preparethetestedobjectwithafixtureand placeitonthetestingturntablefor preparation.Openthetestingsoftwareand selectthecorrespondingfrequencybandto conductthetest TestinglocationOTAmicrowaveanechoicchamber AntennamanufacturerShenzhenShundachengTechnologyCo.,Ltd DebuggingmodePIFA AntennamaterialFPC+coaxialline 2400-2500MHz @ SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 4.Gain&Efficiency SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 5.WiFiOTAData SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 ReliabilityTestReport TestDate2026.08.11SampleQty.3Inspector XuYanfang TestItemRequirement testing equipment Sample1Sample2Sample3PASS/NG High temperatur estorage Thetestwascarried outafter24H exposureat+85°C and2Hrecovery Constant temperatureand humiditybox OKOKOKPass Low temperatur estorage Thetestwascarried outafter24H exposureat-40°C and2Hrecovery Constant temperatureand humiditybox OKOKOKPass High temperatur ework At+60°Cfor24H Constant temperatureand humiditybox OKOKOKPass Workin low temperatur e At-20°Cunderthe conditionofpower workfor24H Constant temperatureand humiditybox OKOKOKPass Saltspray test ThepHvaluewas 6.5~7.2,andthe temperatureofthe experimental chamberwas(35± 2)°C □24H☑48H Saltspraytesting machine OKOKOKPass Connector riveting and drawing force 1.13Wirediameter≥ 10N 0.81Wirediameter≥ 8N RG174≥60N RG178≥50N Pushpullmeter ≥10N≥10N≥10NPass Conclusion Pass Inspector& Date XuYanfang2026.08.11 Approval&D ate SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 SHUNDACHENGTECHNOLOGYCO.,LTD CompanyAddress:4thFloor,BuildingB5,XinfuIndustrialPark,ChongqingRoad,FuyongTown,BaoanDistrict, ShenzhenTelephone:0755-27211658Fax:0755-29485750 InstallWizardorOther Installationprocess: Take1PCSofproductsandtearoffthereleasepaperonthebackoftheFP…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: LGT26H257 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT26H257 Set-up for Conducted Emission
