2AKJB-AMP8200-1Smart POS Terminal

2AKJB-AMP8200-1) FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Note: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help RF Exposure Statement The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types Smart POS Terminal (FCC ID: has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification when properly worn on the body is 1.022W/kg. This device was tested for typical body- worn operations with the back of the handset kept 0cm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0cm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.

Advanced Mobile Payment Inc. Agent Authorization Company: Advanced Mobile Payment Inc. Address: Units 401-403, 15 Wertheim Court. Richmond Hill Ontario L4B 3H7 Canada Product Name: Smart POS Terminal Model Number(s): AMP 8200 Product Description: Smart POS Terminal supports 2G/3G/4G and Bluetooth, WIFI, NFC functions We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-01-16 Name: Homayoon Saghari Title: Manager Company: Advanced Mobile Payment Inc.

Date:Jan.14,2020 To:FederalCommunicationsCommission, Authorization&EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD21046 ToWhomItMayConcern: TheAdvancedMobilePaymentInc.,theundersigned,herebyauthorizesMr.WuXuewenfrom ShenzhenBALUNTechnologyCo.,Ltd.,toactonthebehalfoftheAdvancedMobilePaymentInc. solelyinmattersrelatingtotheapplicationforanFCCequipmentauthorizationforFCCID: 2AKJB-AMP8200-1includingthesigningofdocumentsinconnectionwiththisApplication. NecessaryactscarriedoutbyShenzhenBALUNTechnologyCo.,Ltd.inconnectionwiththe ApplicationshallhavethesameeffectasactsoftheAdvancedMobilePaymentInc.. TheAdvancedMobilePaymentInc..alsoherebycertifythatnopartytothisapplicationissubject toadenialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.Section862. YoursSincerely, HomayoonSaghari Manager AdvancedMobilePaymentInc.

Date: Jan. 14, 2020 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 RE: Advanced Mobile Payment Inc. FCC ID: 2AKJB-AMP8200-1 FCC Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Advanced Mobile Payment Inc. requests that the following documents regarding this submission for FCC ID: 2AKJB-AMP8200-1 be kept confidential: Exhibit TypeFile Name Block Diagram Schematics Block Diagram Schematics Those documents contain detailed system and equipment description and related information about the product which Advanced Mobile Payment Inc.. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve,Advanced Mobile Payment Inc.. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Thank you for your attention to this matter. Y ours Sincerely, Homayoon Saghari Manager Advanced Mobile Payment Inc. Operational Description Operational Description Part List BOM Tune-up procedure tune-up software security information software security information

Annex No.: BL-SZ19A0583-AW 1 / 5 EUT EXTERNAL PHOTOS FRONT VIEW OF EUT REAR VIEW OF EUT Annex No.: BL-SZ19A0583-AW 2 / 5 LEFT SIDE VIEW OF EUT RIGHT SIDE OF EUT Annex No.: BL-SZ19A0583-AW 3 / 5 TOP VIEW OF EUT BOTTOM VIEW OF EUT Annex No.: BL-SZ19A0583-AW 4 / 5 Accessory-Power Adapter CLOSE-UP Annex No.: BL-SZ19A0583-AW 5 / 5 Accessory-Printing Paper

Label Label location -1

Annex No.: BL-SZ19A0583-AI 1 / 8 EUT INTERNAL PHOTOS EUT UNCOVER VIEW EUT UNCOVER VIEW Annex No.: BL-SZ19A0583-AI 2 / 8 EUT UNCOVER VIEW EUT UNCOVER VIEW 2/3/4G Antenna BT/WIFI Antenna 2/3/4G Antenna Annex No.: BL-SZ19A0583-AI 3 / 8 NFC Antenna EUT UNCOVER VIEW NFC Antenna Annex No.: BL-SZ19A0583-AI 4 / 8 EUT UNCOVER VIEW EUT UNCOVER VIEW Annex No.: BL-SZ19A0583-AI 5 / 8 MAIN BOARD TOP VIEW (WITH SHIELDING) MAIN BOARD TOP VIEW (WITHOUT SHIELDING) RF Chip Annex No.: BL-SZ19A0583-AI 6 / 8 MAIN BOARD REAR VIEW MAIN BOARD TOP VIEW Annex No.: BL-SZ19A0583-AI 7 / 8 MAIN BOARD REAR VIEW Battery Photo (FRONT) Annex No.: BL-SZ19A0583-AI 8 / 8 Battery Photo (REAR)

Report No.: BL-SZ19A0583-701 2 / 90 Revision History Version Issue Date Revisions Content Rev. 01 Jan. 15, 2020 Initial Issue Rev. 02 Jan. 20, 2020 Updated the battery information in section 2.5 Ancillary Equipment TABLE OF CONTENTS 1 ADMINSTRATIVE DATA (GENERAL INFORMATION) .............................................................................. 5 1.1 Identification of the Testing Laboratory ................................................................................................. 5 1.2 Identification of the Responsible Testing Location ................................................................................ 5 1.3 Test Environment Condition .................................................................................................................. 5 1.4 Announce .............................................................................................................................................. 5 2 PRODUCT INFORMATION ......................................................................................................................... 6 2.1 Applicant Information ............................................................................................................................. 6 2.2 Manufacturer Information ...................................................................................................................... 6 2.3 Factory Information ............................................................................................................................... 6 2.4 General Description for Equipment under Test (EUT) .......................................................................... 6 2.5 Ancillary Equipment ............................................................................................................................... 6 2.6 Technical Information ............................................................................................................................ 7 3 SUMMARY OF TEST RESULTS ................................................................................................................. 8 3.1 Test Standards ...................................................................................................................................... 8 3.2 Device Category and SAR Limit ............................................................................................................ 8 3.3 Test Result Summary .......................................................................................................................... 10 3.4 Test Uncertainty .................................................................................................................................. 11 4 SAR MEASUREMENT SYSTEM ............................................................................................................... 13 4.1 Definition of Specific Absorption Rate (SAR) ...................................................................................... 13 4.2 SATIMO SAR System ......................................................................................................................... 13 5 SYSTEM VERIFICATION .......................................................................................................................... 22 5.1 Antenna Port Test Requirement .......................................................................................................... 22 5.2 Purpose of System Check ................................................................................................................... 22 5.3 System Check Setup ........................................................................................................................... 22 6 EUT TEST POSITION CONFIGURATUONS ............................................................................................ 23 Report No.: BL-SZ19A0583-701 3 / 90 6.1 Head Exposure Conditions .................................................................................................................. 23 6.2 Body-worn Position Conditions ........................................................................................................... 24 6.3 Hotspot Mode Exposure Position Conditions ...................................................................................... 25 7 SAR MEASUREMENT PROCEDURES .................................................................................................... 26 7.1 SAR Measurement Process Diagram ................................................................................................. 26 7.2 SAR Scan General Requirements ....................................................................................................... 27 7.3 SAR Measurement Procedure ............................................................................................................ 28 7.4 Area & Zoom Scan Procedures ........................................................................................................... 28 8 CONDUCTED RF OUPUT POWER .......................................................................................................... 29 8.1 GSM .................................................................................................................................................... 29 8.2 WCDMA .............................................................................................................................................. 30 8.3 LTE ...................................................................................................................................................... 31 8.4 WIFI ..................................................................................................................................................... 38 8.5 Bluetooth ............................................................................................................................................. 39 9 EUT ANTENNA LOCATIO…

Text truncated - open the document above for the full version.

2 / 76 1 GENERAL INFORMATION 1.1 Introduction This document contains a summary of the requirements set forth by the IEEE 1528, FCC KDB 865664 D01 for reference dipoles used for SAR measurement system validations. Instead of the typical annual calibration recommended by measurement standards, the reference dipoles were demonstrated that the SAR target, impedance and return loss have remain stable, so the longer calibration interval is acceptable. 1.2 General Description for Equipment under Test (EUT) Model Frequency Serial Number Product Condition(New/ Used) Last Cal. Date Last Meas. Date Dipole DIP 0G750 750 MHz SN 11/17 DIP 0G750-446 Used 2017/03/17 2019/03/21 DIP 0G835 835 MHz SN 11/17 DIP 0G835-447 Used 2017/03/17 2019/03/21 DIP 0G900 900 MHz SN 11/17 DIP 0G900-448 Used 2017/03/17 2019/03/21 DIP 1G800 1800 MHz SN 11/17 DIP 1G900-449 Used 2017/03/17 2019/03/19 DIP 1G900 1900 MHz SN 11/17 DIP 1G900-450 Used 2017/03/17 2019/03/19 DIP 2G000 2000 MHz SN 11/17 DIP 2G000-451 Used 2017/03/17 2019/03/19 DIP 2G450 2450 MHz SN 11/17 DIP 2G450-452 Used 2017/03/17 2019/03/19 DIP 2G600 2600 MHz SN 11/17 DIP 2G600-453 Used 2017/03/17 2019/03/19 Waveguide SWG5500 5GHz-6GHz SN 49/16 WGA42 Used 2017/03/17 2019/03/20 3 / 76 1.3 Test Equipment List Description Manufacturer Model Serial No. Cal. Date Cal. Due PC Dell N/A N/A N/A N/A E-Field Probe MVG SSE2 SN 34/15 SSE2 EPGO265 2019/03/19 2019/03/18 Phantom1 SATIMO SAM SN 30/13 SAM103 N/A N/A Phantom2 SATIMO SAM SN 30/13 SAM104 N/A N/A MultiMeter Keithley MultiMeter 2000 4024022 2018/06/15 2019/06/14 Signal Generator R&S SMBV100A 260592 2018/06/15 2019/06/14 Power Meter Agilent E4419B GB40201833 2018/11/02 2019/11/01 Power Sensor Agilent E9300A MY41498012 2018/11/02 2019/11/01 Power Sensor Agilent E9300A MY41499891 2018/11/02 2019/11/01 Network Analyzer R&S ZVL-6 101380 2018/06/15 2019/06/14 Thermometer Elitech RC-4HC N/A 2018/11/13 2019/11/12 Power Amplifier SATIMO 6552B 22374 N/A N/A Dielectric Probe Kit SATIMO SCLMP SN 25/13 OCPG56 N/A N/A Attenuator COM-MW ZA-S1-31 1305003187 N/A N/A Directional coupler AA-MCS AAMCS-UDC 000272 N/A N/A 4 / 76 1.4 EUT Photos DIP 0G750-446 DIP 0G835-447 5 / 76 DIP 0G900-448 DIP 1G800-449 DIP 1G900-450 DIP 2G000-451 6 / 76 DIP 2G450-452 DIP 2G600-453 Waveguide SWG5500 7 / 76 2 DIPOLE IMPEDANCE AND RETURN LOSS The dipoles are designed to have low return loss when presented against a flat phantom at the specified distance. A Vector Network Analyzer was used to perform a return loss measurement on the specific dipole when in the measurement location against the phantom and the distance was specified by the manufacturer with a special, low loss and low relative permittivity spacer. The impedance was measured at the SMA-connector with the network analyzer. The measurement of verification with return loss should not deviate by more than 20% and minimum of 20 dB of the return loss, and the impedance (real or imaginary parts) should not deviate by more than 5 Ohms from the previous measurement using network analyzer. Note: The “Previous Meas.” in the following table refer to dipoles or other equivalent RF sources calibration reports. 8 / 76 2.1 DIP 0G750 RETURN LOSS AND IMPEDANCE IN HEAD LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -26.12 -26.40 1.1 % Impedance 53.2 Ω +2.7 jΩ 53.7 Ω +1.9 jΩ 0.8 Ω (Imaginary part) Return Loss Impedance 9 / 76 RETURN LOSS AND IMPEDANCE IN BODY LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -26.69 -27.73 3.8 % Impedance 50.1 Ω + 5.4 jΩ 51.1 Ω + 5.9 jΩ 1.0 Ω (Real part) Return Loss Impedance 10 / 76 2.2 DIP 0G835 RETURN LOSS AND IMPEDANCE IN HEAD LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -31.42 -30.45 3.1% Impedance 55.6 Ω -3.4 jΩ 53.5 Ω -1.1 jΩ 2.3 Ω (Imaginary part) Return Loss Impedance 11 / 76 RETURN LOSS AND IMPEDANCE IN BODY LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -24.02 -23.10 4.0% Impedance 47.3Ω+5.0 jΩ 48.2Ω+5.2 jΩ 0.9 Ω (Real part) Return Loss Impedance 12 / 76 2.3 DIP 0G900 RETURN LOSS AND IMPEDANCE IN HEAD LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -30.91 -31.55 2.0% Impedance 50.39 Ω - 2.4 jΩ 51.8 Ω - 2.1 jΩ 1.4 Ω (Real part) Return Loss Impedance 13 / 76 RETURN LOSS AND IMPEDANCE IN BODY LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -28.58 -27.62 3.5% Impedance 54.4 Ω +2.1 jΩ 54.7 Ω +2.2 jΩ 0.3 Ω (Real part) Return Loss Impedance 14 / 76 2.4 DIP 1G800 RETURN LOSS AND IMPEDANCE IN HEAD LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -23.52 -24.28 3.1% Impedance 41.6Ω + 3.3 jΩ 44.8Ω + 3.9 jΩ 3.2 Ω (Real part) Return Loss Impedance 15 / 76 RETURN LOSS AND IMPEDANCE IN BODY LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -26.39 -27.41 3.7% Impedance 46.0Ω +3.4 jΩ 47.8Ω +3.4 jΩ 1.8 Ω (Real part) Return Loss Impedance 16 / 76 2.5 DIP 1G900 RETURN LOSS AND IMPEDANCE IN HEAD LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -27.40 -23.59 16.2 % Impedance 52.4Ω+6.6 jΩ 52.7Ω+8.0 jΩ 1.4 Ω (Imaginary part) Return Loss Impedance 17 / 76 RETURN LOSS AND IMPEDANCE IN BODY LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -25.02 -22.29 12.2 % Impedance 50.4 Ω +6.6 jΩ 47.6 Ω +4.5 jΩ 2.8 Ω (Real part) Return Loss Impedance 18 / 76 2.6 DIP 2G000 RETURN LOSS AND IMPEDANCE IN HEAD LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -24.19 -25.10 3.6% Impedance 53.8Ω – 1.0 jΩ 55.7Ω – 1.2 jΩ 1.9 Ω (Real part) Return Loss Impedance 19 / 76 RETURN LOSS AND IMPEDANCE IN BODY LIQUID Meas. Results Current Meas. Previous Meas. Max. Deviation Return Loss(dB) -24.48 -25.32 3.3 % Impedance 55.9Ω-0.3 jΩ 54.8Ω-0.4 jΩ 1.1 Ω (Real part) Return Loss Impedance 20 / 76 2.7 DIP 2G450 RETURN LOSS AND IMPEDANCE IN HEAD LIQUID Meas. Results Current Meas. Pr…

Text truncated - open the document above for the full version.

Report No.: BL-SZ19A0582-701 CALIBRATION REPORT F.1 E-Field Probe Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 F.2 750 MHz Dipole Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 F.2 835 MHz Dipole Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 F.3 1800 MHz Dipole Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 F.4 1900 MHz Dipole Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701 Report No.: BL-SZ19A0582-701

Report No.: BL-SZ19A0583-501 2/ 53 Revision History Version Issue Date Revisions Content Rev. 01 Jan. 15, 2020 Initial Issue Rev. 02 Jan. 20, 2020 Corrected the Antenna Type TABLE OF CONTENTS 1 ADMINISTRATIVE DATA (GENERAL INFORMATION) ......................................................................... 4 1.1 Identification of the Testing Laboratory ............................................................................................. 4 1.2 Identification of the Responsible Testing Location ............................................................................ 4 1.3 Laboratory Condition ......................................................................................................................... 4 1.4 Announce .......................................................................................................................................... 5 2 PRODUCT INFORMATION ..................................................................................................................... 6 2.1 Applicant Information ........................................................................................................................ 6 2.2 Manufacturer Information .................................................................................................................. 6 2.3 Factory Information ........................................................................................................................... 6 2.4 General Description for Equipment under Test (EUT) ...................................................................... 6 2.5 Technical Information ........................................................................................................................ 7 3 SUMMARY OF TEST RESULTS ............................................................................................................. 9 3.1 Test Standards .................................................................................................................................. 9 3.2 Test Verdict ..................................................................................................................................... 10 4 GENERAL TEST CONFIGURATIONS .................................................................................................. 11 4.1 Test Environments .......................................................................................................................... 11 4.2 Test Equipment List ........................................................................................................................ 11 4.3 Test Configurations ......................................................................................................................... 13 4.4 Test Setup ....................................................................................................................................... 17 5 TEST ITEMS .......................................................................................................................................... 19 5.1 Transmitter Radiated Power (EIRP/ERP) ....................................................................................... 19 5.2 Peak to Average Ratio .................................................................................................................... 22 5.3 Occupied Bandwidth ....................................................................................................................... 24 5.4 Frequency Stability .......................................................................................................................... 26 5.5 Spurious Emission at Antenna Terminals ....................................................................................... 28 5.6 Band Edge ...................................................................................................................................... 31 Report No.: BL-SZ19A0583-501 3/ 53 5.7 Field Strength of Spurious Radiation .............................................................................................. 34 ANNEX A TEST RESULTS ....................................................................................................................... 38 A.1 Transmitter Radiated Power (EIRP/ERP) ....................................................................................... 38 A.2 Peak to Average Ratio .................................................................................................................... 50 A.3 Occupied Bandwidth ....................................................................................................................... 50 A.4 Frequency Stability .......................................................................................................................... 50 A.5 Spurious Emission at Antenna Terminals ....................................................................................... 50 A.6 Band Edge ...................................................................................................................................... 50 A.7 Field Strength of Spurious Radiation .............................................................................................. 51 ANNEX B TEST SETUP PHOTOS ........................................................................................................... 53 ANNEX C EUT EXTERNAL PHOTOS ...................................................................................................... 53 ANNEX D EUT INTERNAL PHOTOS ....................................................................................................... 53 Report No.: BL-SZ19A0583-501 4/ 53 1 ADMINISTRATIVE DATA (GENERAL INFORMATION) 1.1 Identification of the Testing Laboratory Company Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1st FL, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China. Phone Number +86 755 …

Text truncated - open the document above for the full version.

Annex A.7. Field Strength of Spurious Radiation GPRS 1 GPRS 850 1.1 GPRS 850 Low Channel RSE-H&V GPRS 850 CH128 Frequency (MHz) Result (dBm) Factor (dB) PK Limit (dBm) Over Limit (dB) Table (o) ANT EUT Verdict 221.818 -70.58 -14.88 -13.0 -57.58 137.00 Horizontal Vertical Pass 824.284 -47.26 -1.52 -13.0 -34.26 329.00 Horizontal Vertical N/A 869.244 -54.43 -1.22 -13.0 -41.43 77.00 Horizontal Vertical N/A 1648.200 -34.94 -3.95 -13.0 -21.94 321.00 Horizontal Vertical Pass 2472.300 -43.25 0.93 -13.0 -30.25 0.00 Horizontal Vertical Pass 4121.000 -47.73 5.74 -13.0 -34.73 319.00 Horizontal Vertical Pass RSE-V&V GPRS 850 CH128 Frequency (MHz) Result (dBm) Factor (dB) PK Limit (dBm) Over Limit (dB) Table (o) ANT EUT Verdict 35.238 -61.84 -18.87 -13.0 -48.84 184.00 Vertical Vertical Pass 824.236 -40.94 -1.52 -13.0 -27.94 127.00 Vertical Vertical N/A 869.147 -56.82 -1.22 -13.0 -43.82 82.00 Vertical Vertical N/A 1648.500 -36.12 -3.93 -13.0 -23.12 54.00 Vertical Vertical Pass 2472.600 -38.44 0.94 -13.0 -25.44 167.00 Vertical Vertical Pass 9259.150 -33.63 36.12 -13.0 -20.63 195.00 Vertical Vertical Pass 1.2 GPRS 850 Middle Channel RSE-H&V GPRS 850 CH190 Frequency (MHz) Result (dBm) Factor (dB) PK Limit (dBm) Over Limit (dB) Table (o) ANT EUT Verdict 223.030 -70.37 -15.05 -13.0 -57.37 131.00 Horizontal Vertical Pass 836.555 -66.03 -1.33 -13.0 -53.03 131.00 Horizontal Vertical N/A 881.660 -52.15 -1.27 -13.0 -39.15 89.00 Horizontal Vertical N/A 1673.000 -38.13 -3.65 -13.0 -25.13 317.00 Horizontal Vertical Pass 2509.500 -47.25 1.24 -13.0 -34.25 33.00 Horizontal Vertical Pass 9097.300 -34.09 35.26 -13.0 -21.09 194.00 Horizontal Vertical Pass RSE-V&V GPRS 850 CH190 Frequency (MHz) Result (dBm) Factor (dB) PK Limit (dBm) Over Limit (dB) Table (o) ANT EUT Verdict 34.316 -61.30 -18.96 -13.0 -48.30 217.00 Vertical Vertical Pass 836.555 -60.13 -1.33 -13.0 -47.13 124.00 Vertical Vertical N/A 881.612 -55.48 -1.28 -13.0 -42.48 206.00 Vertical Vertical N/A 1673.100 -39.73 -3.65 -13.0 -26.73 94.00 Vertical Vertical Pass 2509.500 -42.53 1.24 -13.0 -29.53 117.00 Vertical Vertical Pass 9252.700 -33.03 35.76 -13.0 -20.03 266.00 Vertical Vertical Pass 1.3 GPRS 850 High Channel RSE-H&V GPRS 850 CH251 Frequency (MHz) Result (dBm) Factor (dB) PK Limit (dBm) Over Limit (dB) Table (o) ANT EUT Verdict 216.774 -69.85 -15.18 -13.0 -56.85 117.00 Horizontal Vertical Pass 848.729 -54.56 -0.94 -13.0 -41.56 314.00 Horizontal Vertical N/A 893.737 -52.87 -1.31 -13.0 -39.87 91.00 Horizontal Vertical N/A 1697.600 -40.83 -3.32 -13.0 -27.83 221.00 Horizontal Vertical Pass 2546.200 -49.86 0.37 -13.0 -36.86 221.00 Horizontal Vertical Pass 3395.200 -50.01 3.25 -13.0 -37.01 166.00 Horizontal Vertical Pass RSE-V&V GPRS 850 CH251 Frequency (MHz) Result (dBm) Factor (dB) PK Limit (dBm) Over Limit (dB) Table (o) ANT EUT Verdict 34.753 -62.36 -18.92 -13.0 -49.36 193.00 Vertical Vertical Pass 848.729 -52.46 -0.94 -13.0 -39.46 64.00 Vertical Vertical N/A 893.737 -57.76 -1.31 -13.0 -44.76 82.00 Vertical Vertical N/A 1697.500 -39.12 -3.33 -13.0 -26.12 328.00 Vertical Vertical Pass 2546.400 -50.98 0.35 -13.0 -37.98 60.00 Vertical Vertical Pass 9269.200 -34.11 36.14 -13.0 -21.11 29.00 Vertical Vertical Pass 2 GPRS 1900 2.1 GPRS 1900 Low Channel RSE-H&V GPRS 1900 CH512 Frequency (MHz) Result (dBm) Factor (dB) PK Limit (dBm) Over Limit (dB) Table (o) ANT EUT Verdict 227.492 -70.63 -15.20 -13.0 -57.63 150.00 Horizontal Vertical Pass 1850.500 -56.88 -1.29 -13.0 -43.88 40.00 Horizontal Vertical N/A 1930.100 -47.48 -1.83 -13.0 -34.48 138.00 Horizontal Vertical N/A 3700.400 -41.62 4.38 -13.0 -28.62 264.00 Horizontal Vertical Pass 9259.175 -33.54 36.12 -13.0 -20.54 358.00 Horizontal Vertical Pass 19077.075 -20.98 44.77 -13.0 -7.98 78.00 Horizontal Vertical Pass RSE-V&V GPRS 1900 CH512 Frequency (MHz) Result (dBm)…

Text truncated - open the document above for the full version.
