2AKLNG35A0Leion Hey AR GLasses

Instruction Guide Leion Hey Augmented Reality Glasses Function illustration of the front of the glasses Product Overview High-performance radio microphone Ambient light sensor Power key Function key LED indicator Array optical waveguide display lens Adjustable nose pads Prescription lenses Type C charging port Adjustment spacer High-strength elastic frame Battery Function illustration of the back of the glasses Installation Instructions Installation of prescription lenses (suitable for vision needs such as myopia/hyperopia/astigmatism) Remove the cover lens Install the fitted prescription lenseAdjust the installation position of the spacer Without any spacers installed Spacer installed 1. Use your fingernails to dig the thin slit of the cover lens, and pull the cover lens out of the card slot. 2. Adjust the prescription lenses with the appropriate prescription and align the side with the snap to the slot position. 3. If you need to remove the prescription lenses, hold the slit in the middle of the prescription lenses with your thumb and hold the AR glasses' body with your other hand to separate the lens from the slot. Installation of Adjustment Spacers (suitable for different face sizes such as narrow/wide faces) 1. The sizes of XS/S/M spacers are available in the accessory box, and the M-size spacer has been installed already. 2. After wearing the glasses for the first time - If you feel loose, replace the spacer with an S or XS spacer. - If you feel tight, you can remove the pre-installed M spacer without installing any spacers. 3. Install appropriate spacers to both sides as shown in the figure. The spacer is not divided into the left and right sides, just insert the side with the snap into the glasses slot. Slow flash............... Long light............... Charging Low battery Charging Fully charged Slow flash............... Fast flash 3 times.... Paired Pairing Paired successfully Power key Function key Power key Function key Combination long press Long press for 6 seconds............Power on Long press for 3 seconds............Shutdown Short press................. Light up/off the screen Long press..................Mode switch Short press.................Enter/exit the application LED indicator Power + function ...... LED indicator Key Function Description *More operations will available after device’s system upgrade. Can be found in glasses’ APP. Fast flash 3 times...No battery to active Call out Restore Factory Setting Product Parameters Model: G35A-00 Name: Leion Hey AR Glasses Color： Sage Gray Processor： Snapdragon Wear 4100 Memory： 1GB RAM+8GB ROM ePOP Wireless： BT 4.2 /WLAN 2.4GHz OS： Android 11 Go Battery： 3.85V, 400mAh Outin spec： 5V/2A Weight： 79g (Bare only, +/-2g) Display module: Binocular array waveguide Image projector： Two LCOS projector Resolution： 640x360 Field of view： 23° (Diagonal) Sound acquisition： Dual MEMS microphone Sound speaker： Support Type-C port headphones Sensors： Accelerator, Gyro, Compass, Light sensor Interaction： Power key, Function key, Mobile APP Indicator: White LED 168mm 162.5mm 51.2mm *Please refer to the specification label sticker on the outer box of the package for product model approval code identification and related certification information identification. 1. Check the following supporting items contained in the package: 2. Before wear glasses, you need to make personalized wearing adjustments according to your head circumference size, nose bridge height and myopia refraction to ensure the best wearing comfort and viewing experience in the use of glasses. 3. Put on the glasses, and then press and hold the power key (the key with a bump) as shown in the picture to turn on the device until it lights up. 4. Download and install the official“Courier” App on your mobile phone, which is available in major mobile application markets or by scanning the QR code on the “Software Download” page. 5. After wearing the glasses, you can perform operations such as pairing, network setup and activation of the glasses based on the prompts in the glasses interface and the prompts in the mobile app. 6. After setting up successfully and ensuring a stable network connection of the glasses, you can start your subtitle glasses experience. 7. Subtitle display settings can be adjusted in a personalized way through the settings of mobile phone applications. It is recommended to use sunglasses lenses to enhance contrast of subtitles in the outdoor or bright environment.。 * If you can’t see the full interface when watching subtitles, try to adjust the nose pad until you can see all the subtitle content clearly. *No power adapter is provided in the product package Please charge with an output power adapter above 5V=2A. Glasses container - Subtitle glasses - Sunglasses lenses - Prescription lenses - Glasses cloth Accessories box - Type-C charging cable - Sizes of spacers XS/S/M *10pcs Instruction set - Instruction guide - Safety instruction - Warranty information - Certificate Usage Process Software Download Contact Us Scan the QR code on the right to download and use the app “Courier” that matches this device, and complete the network matching and pairing of glasses. The app only supports mobile phone versions running Android 10 or higher, and Apple iOS11 or higher for pairing. During pairing, please ensure that the Bluetooth function of the mobile phone is turned on and the distance between the mobile phone and the glasses is kept within 1m. To ensure successful pairing and setup, please ensure that both glasses and the mobile phone have a charge of more than 20% to avoid pairing failure due to insufficient charge. To ensure that factory settings are restored and the firmware online upgrade is successful, please ensure that the glasses have a charge of more than 50% to avoid operation failure due to insufficient charge. Official website customer service: Go to https://www.llvision.com/ Select “Online Customer Service” Customer service hotline: Hotline at 400-0525…
