2AKMBHA-A11TWIRELESS HEADPHONES

Products and batteries with the symbol (crossed-out wheeled bin) cannot be disposed as household waste. This product contains rechargeable battery. Contact JVC authorised dealer for disposal. I prodotti e le batterie recanti questa icona (bidone carrellato della spazzatura con il simbolo della croce) non devono essere eliminati come rifiuti solidi urbani. In queste cuffie è installata una batteria ricaricabile. Per informazioni sulla sua eliminazione si raccomanda di rivolgersi al rivenditore autorizzato JVC. Produkty i baterie opatrzone symbolem (przekreślony pojemnik na kółkach) nie mogą być wyrzucane razem z odpadami domowymi. Ten produkt zawiera akumulator. Informacje o usuwaniu odpadów można uzyskać u autoryzowanego dystrybutora JVC. Продуктите и батериите, обозначени със символа (зачертана с кръст кофа за боклук на колелца), не могат да се изхвърлят като битови отпадъци. Продуктът съдържа презареждаема батерия. Свържете се с оторизиран търговец на JVC за начина на изхвърляне. Produsele și bateriile cu simbolul (pubelă tăiată cu un x) nu pot fi aruncate ca deșeuri menajere. Acest produs conține o baterie reîncărcabilă. Dacă doriți să îl aruncați, luați legătura cu distribuitorul autorizat JVC. Izdelkov in baterij s simbolom (prečrtan smetnjak na kolesih) ni dovoljeno odstraniti kot gospodinjske odpadke. Ta izdelek vsebuje akumulatorsko baterijo. Za odstranitev se obrnite na pooblaščenega zastopnika podjetja JVC. Proizvodi i baterije sa simbolom (precrtana kanta za otpad) ne smiju se odlagati u kućanski otpad. Ovaj proizvod sadrži punjivu bateriju. Za informacije o odlaganju obratite se ovlaštenom prodavaču JVC-ovih proizvoda. Gaminių ir baterijų, ant kurių pateiktas perbrautos šiukšliadėžės simbolis, negalima išmesti kartu su buitinėmis atliekomis. Šiame gaminyje sumontuotas akumuliatorius. Dėl utilizavimo kreipkitės į JVC įgaliotąjį prekybos atstovą. Produkti un baterijas ar simbolu (nosvītrots atkritumu konteiners uz riteņiem) nedrīkst tikt likvidēti kā mājsaimniecības atkritumi. Šis produkts satur atkārtoti uzlādējamu bateriju. Sazinieties ar JVC autorizēto dīleri par likvidēšanu. Prodotti u batteriji bis-simbolu (tantk taż-żibel bir-roti maqtugħ) ma jistgħux jintremew bħala skart domestiku. Dan il-prodott fih batterija rikarikabbli. Ikkuntattja lin-negozjant awtorizzat minn JVC rigward ir-rimi. Προϊόντα και μπαταρίες που φέρουν το σύμβολο (διαγραμμένος τροχήλατος κάδος απορριμμάτων) δεν απορρίπτονται ως κοινά οικιακά απορρίμματα. Το παρόν προϊόν περιέχει επαναφορτιζόμενη μπαταρία. Για την ορθή διάθεσή του επικοινωνήστε με τον εξουσιοδοτημένο αντιπρόσωπο της JVC. Produkter og batterier med symbolet (overstreget skraldespand på hjul) kan ikke bortskaffes som husholdningsaffald. Dette produkt indeholder et genopladeligt batteri. Ret henvendelse til en autoriseret JVC-forhandler angående bortskaffelse. Sümboliga (ratastega prügikonteiner, millel on rist peal) tooteid ja akusid ei tohi kõrvaldada majapidamisjäätmetena. See toode sisaldab laetavat akut. Kõrvaldamiseks võtke ühendust JVC volitatud edasimüüjaga. Laitteita ja paristoja, joissa on seuraava merkintä (ruksattu roskapönttö), ei saa hävittää talousjätteiden mukana. Tässä laitteessa on ladattava paristo. Ota yhteys valtuutettuun JVC-edustajaan ja kysy tietoja hävittämisestä. Výrobky a baterie s tímto symbolem (přeškrtnutá popelnice) nelze vyhazovat s domovním odpadem. Tento výrobek obsahuje dobíjecí baterii. Informace o likvidaci vám podá autorizovaný prodejce JVC. Produkty a batérie označené symbolom (preškrtnutá odpadová nádoba) sa nesmú likvidovať spolu s komunálnym odpadom. Tento produkt obsahuje nabíjateľnú batériu. V prípade likvidácie kontaktujte autorizovaného predajcu JVC. Azokat a termékeket, amelyeken az (áthúzott görgős szeméttároló) jelzés található, nem lehet háztartási szemétként eldobni. A termék újratölthető akkumulátorral rendelkezik. Ártalmatlanítás esetén vegye fel a kapcsolatot a JVC szerződéses kereskedőjével. Producten en batterijen met het (afvalcontainer met x-teken) symbool mogen niet als normaal huisvuill worden weggegooid. Dit product bevat een oplaadbare batterij. Raadpleeg een erkende JVC handelaar voor het weggooien. Os produtos e baterias com o símbolo (caixote de lixo com um X) não podem ser deitados fora junto com o lixo doméstico. Este produto contém uma bateria recarregável. Contate o revendedor JVC autorizado para a sua eliminação. Produkter och batterier med denna symbol (en överkryssad soptunna på hjul) får inte kastas med vanliga hushållssopor. Denna produkt innehåller ett laddningsbart batteri. Kontakta en auktoriserad JVC-handlare angående kassering. Das Symbol (durchgestrichene Mülltonne) auf dem Produkt oder seiner Verpackung weist darauf hin, dass dieses Produkt nicht als normaler Haushaltsabfall behandelt werden darf. Dieses Produkt enthält eine Akkubatterie. Wenden Sie sich an einen JVC-Fachhändler bezüglich der Entsorgung. Les produits et piles électriques sur lesquels le pictogramme (poubelle barrée) est apposé ne peuvent pas être éliminés comme ordures ménagères. Ce produit contient une pile rechargeable. Contactez votre revendeur JVC autorisé pour le mettre au rebut. Los productos y las baterías con el símbolo (contenedor con ruedas tachado) no podrán ser desechados como residuos domésticos. Este producto contiene una batería recargable. Para su eliminación, consulte con el distribuidor autorizado de JVC. • Do not listen at high volume for an extended period. Do not use while driving or cycling. • Pay special attention to traffic around you when using the headphones outside. Failure to do so could result in an accident. • This product with a built-in battery shall not be exposed to excessive heat such as sunshine, fire or the like. • This product contains rechargeable battery, which is not replaceable. Danger of explosion if user replaced battery. Do not replace battery user own self. • Hören Sie nicht lange Zeit mit sehr hoher Lautstärke. Nicht beim Fahren von Motorfahrzeugen…

Text truncated - open the document above for the full version.

FCC ID: 2AKMBHA-A11T IC: 12522A-A11T

JVCKENWOOD Design Corporation【秘】SECRET| C E 宜 甘 ［ 金 XXX - xxxxxx - S/ N | | WIRELESS HEADPHONES WIRELESSSTEREOHEADSETI无线耳机 巨；旦旦 MODEL:HA-A11T 型说HA-A11T INPUr:5V-360mA OUTPUT:5V-60mA•2 CAPAClff3.7V 520mAh 1.924Wh CMIITIDJOOOOOOOOO( 瞪虢(« )0()()()()()()(( L ) FCC ID:2AKMBHA-A11T IC:12522A-A11T URLWWWivcnet (( )0()()()()()()(( R ) 」VCKENWOODCorporation 芯需芦冗国制造 JVC 气器f『$i@ 商品名／PRDDUGT NAME HA-A11T 凳行日／Theday of issue 2021/1/13 Label location

FCC ID: 2AKMBHA-A11T IC: 12522A-A11T BT Antenna

The results reported herein have been performed in accordance with the laboratory’s terms of accreditation. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report apply to the test sample(s) mentioned above at the time of the testing period only and are not to be used to indicate applicability to other similar products. This report does not imply that the product(s) has met the criteria for certification. SAR EVALUATION REPORT FCC 47 CFR § 2.1093 IEEE Std. 1528-2013 RSS-102 Issue 5 IEC 62209-1:2016 For WIRELESS HEADPHONES FCC ID:2AKMBHA-A11T IC: 12522A-A11T Model Name: HA-A11T Report Number: 4789830076-SAR Issue Date: February 07, 2021 Prepared for Kingstate Electronics(DongGuan)Co.,Ltd. Shi Chong Industrial Park, Shi Chong Avenue, Xiang Xi Village, Shi Pai Town, Dong Guan City, Guang Dong Province, China. Prepared by UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch Building 10, Innovation Technology Park, No. 1, Li Bin Road, Song Shan Lake Hi-Tech Development Zone Dongguan, People’s Republic of China Tel: +86 769 22038881 Fax: +86 769 33244054 Website: www.ul.com REPORT No.: 4789830076-SAR Page 2 of 31 Page 2 of 22 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0036 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Revision History Rev. Date Revisions Revised By V1.0 February 07, 2021 Initial Issue \ Note: 1. The Measurement result for the sample received is<Pass> according to < IEEE Std. 1528- 2013> < RSS-102, Issue 5> when <Accuracy Method> decision rule is applied. 2. This report is only published to and used by the applicant, and it is not for evidence purpose in China. REPORT No.: 4789830076-SAR Page 3 of 31 Page 3 of 22 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0036 This report shall not be reproduced except in full, without the written approval of UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch. Table of Contents 1. Attestation of Test Results ......................................................................................................... 4 2. Test Specification, Methods and Procedures............................................................................ 5 3. Facilities and Accreditation ........................................................................................................ 6 4. SAR Measurement System & Test Equipment .......................................................................... 7 4.1. SAR Measurement System ........................................................................................................ 7 4.2. SAR Scan Procedures ............................................................................................................... 8 4.3. Test Equipment ........................................................................................................................ 10 5. Measurement Uncertainty ......................................................................................................... 11 5.1. Uncertainty budget list (30MHz to 3GHz). ................................................................................ 11 6. Device Under Test (DUT) Information ...................................................................................... 12 6.1. DUT Description ...................................................................................................................... 12 6.2. Wireless Technology ................................................................................................................ 12 7. SAR Test Configuration ............................................................................................................ 13 8. Conducted Output Power Measurement and Gain.................................................................. 14 8.1. BT (Average power) ................................................................................................................. 14 8.2. Antenna gain............................................................................................................................ 14 9. Dielectric Property Measurements & System Check .............................................................. 15 9.1. Dielectric Property Measurements ........................................................................................... 15 9.2. System Check .......................................................................................................................... 17 10. Measured and Reported (Scaled) SAR Results ....................................................................... 19 10.1. SAR Test Results of BT........................................................................................................ 20 11. Simultaneous Transmission SAR Analysis ............................................................................. 21 Appendixes .......................................................................................................................................... 22 4789830076-SAR_App A Photo ......................................................................................................... 22 4789830076-SAR_App B System Check Plot .................................................................................... 22 4789830076-SAR_App C Highest Test Plot ....................................................................................... 22 4789830076-SAR_App D Cal. Certificates ......................................................................................... 22 REPORT No.: 4789830076-SAR Page 4 of 31 Page 4 of 22 UL Verification Services (Guangzhou) Co., Ltd, Song Shan Lake Branch FORM NO: 10-SL-F0036 This report shall not be reproduced except in full, without the written approval of UL Verific…

Text truncated - open the document above for the full version.

Report No.: 4789830076-SAR 1 | P a g e Appendix A Photo Test position Left side (0mm)_Left ear Right side (0mm) _Left ear Top side (0mm) _Left ear Bottom side (0mm) _Left ear Report No.: 4789830076-SAR 2 | P a g e Back surface (0mm)_Left ear Cochlea side (0mm) _Left ear Left side (0mm)_Right ear Right side (0mm) _Right ear Top side (0mm) _Right ear Bottom side (0mm) _Right ear Report No.: 4789830076-SAR 3 | P a g e Back surface (0mm)_Right ear Cochlea side (0mm) _Right ear

Date: 2021/2/4 System Performance Check-2450MHz-Head DUT: Dipole 2450 MHz D2450V2; Type: D2450V2; Serial: 977 Communication System: UID 0, CW (0); Communication System Band: D2450 (2450.0 MHz); Frequency: 2450 MHz;Communication System PAR: 0 dB; PMF: 1 Medium parameters used: f = 2450 MHz; σ = 1.81 S/m; ε r = 39.90; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: • Probe: EX3DV4 - SN7383; ConvF(7.75, 7.75, 7.75); Calibrated: 2020/11/30; • Sensor-Surface: 3mm (Mechanical Surface Detection), z = 1.0, 31.0 • Electronics: DAE3 Sn427; Calibrated: 2020/3/31 • Phantom: SAM; Type: QD000P40CD; Serial: 1805 • DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/D2450V2/Area Scan (6x9x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 14.2 W/kg Configuration/D2450V2/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 91.84 V/m; Power Drift = -0.01 dB Peak SAR (extrapolated) = 28.6 W/kg SAR(1 g) = 13.29 W/kg; SAR(10 g) = 6.08 W/kg Maximum value of SAR (measured) = 17.3 W/kg 0 dB = 14.2 W/kg = 11.51 dBW/kg

Date: 2021/2/4 left ear headset BT 3DH5 0CH Left side 0mm Communication System: UID 0, BT(0) (0); Communication System Band: BT; Frequency: 2402 MHz; Medium parameters used: f = 2402 MHz; σ = 1.757 S/m; ε r = 39.761; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: • Probe: EX3DV4 - SN7383; ConvF(7.75, 7.75, 7.75); Calibrated: 2020/11/30; • Sensor-Surface: 3mm (Mechanical Surface Detection), z = 1.0, 31.0 • Electronics: DAE3 Sn427; Calibrated: 2020/3/31 • Phantom: SAM; Type: QD000P40CD; Serial: 1805 • DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Body/Area Scan (6x6x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.181 W/kg Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.755 V/m; Power Drift = 0.1 dB Peak SAR (extrapolated) = 0.283 W/kg SAR(1 g) = 0.158 W/kg; SAR(10 g) = 0.075 W/kg Maximum value of SAR (measured) = 0.163 W/kg 0 dB = 0.181 W/kg = -7.42 dBW/kg Date: 2021/2/5 Right ear headset BT 3DH5 0CH Back surface 0mm Communication System: UID 0, BT(0) (0); Communication System Band: BT; Frequency: 2402 MHz; Medium parameters used: f = 2402 MHz; σ = 1.757 S/m; ε r = 39.761; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY Configuration: • Probe: EX3DV4 - SN7383; ConvF(7.75, 7.75, 7.75); Calibrated: 2020/11/30; • Sensor-Surface: 3mm (Mechanical Surface Detection), z = 1.0, 31.0 • Electronics: DAE3 Sn427; Calibrated: 2020/3/31 • Phantom: SAM; Type: QD000P40CD; Serial: 1805 • DASY52 52.8.8(1222); SEMCAD X 14.6.10(7331) Configuration/Body/Area Scan (6x6x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 0.0887 W/kg Configuration/Body/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.511 V/m; Power Drift = -0.03 dB Peak SAR (extrapolated) = 0.250 W/kg SAR(1 g) = 0.072 W/kg; SAR(10 g) = 0.023 W/kg Maximum value of SAR (measured) = 0.105 W/kg 0 dB = 0.0887 W/kg = -10.52 dBW/kg

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20111821-1E5 Page 1 of 74 FCC AND ISED CERTIFICATION TEST REPORT FOR Issued By: Dongguan Dongdian Testing Service Co., Ltd. Add.: No. 17, Zongbu Road 2, Songshan Lake Sci&Tech, Industry Park, Dongguan City, Guangdong Province, China, 523808 Tel.: +86-0769-38826678, E-mail: [email protected], http://www.dgddt.com Applicant : Kingstate Electronics(DongGuan)Co.,Ltd. Address : Shi Chong Industrial Park, Shi Chong Avenue, Xiang Xi Village, Shi Pai Town, Dong Guan City, Guang Dong Province, China. Equipment under Test : WIRELESS HEADPHONES Model No. : HA-A11T Trade Mark : JVC FCC ID : 2AKMBHA-A11T IC : 12522A-A11T Manufacturer : Kingstate Electronics(DongGuan)Co.,Ltd. Address : Shi Chong Industrial Park, Shi Chong Avenue, Xiang Xi Village, Shi Pai Town, Dong Guan City, Guang Dong Province, China. ■Report No.: DDT-R20111821-1E5 ■Issued Date: Jan. 15, 2021 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20111821-1E5 Page 2 of 74 Table of Contents Test report declares........................................................................................................4 1. Summary of Test Results ............................................................................................... 6 2. General Test Information ............................................................................................... 7 2.1. Description of EUT ......................................................................................................... 7 2.2. Accessories of EUT ........................................................................................................ 7 2.3. Assistant equipment used for test .................................................................................. 8 2.4. Block diagram of EUT configuration for test .................................................................. 8 2.5. Test environment conditions .......................................................................................... 8 2.6. Deviations of test standard ............................................................................................. 8 2.7. Test laboratory................................................................................................................ 9 2.8. Measurement uncertainty ............................................................................................... 9 3. Equipment Used During Test ....................................................................................... 10 4. 6 dB Bandwidth and 99% Bandwidth ........................................................................... 12 4.1. Block diagram of test setup .......................................................................................... 12 4.2. Limits ............................................................................................................................ 12 4.3. Test procedure ............................................................................................................. 12 4.4. Test result ..................................................................................................................... 13 4.5. Original test data .......................................................................................................... 13 5. Maximum Peak Output Power ..................................................................................... 22 5.1. Block diagram of test setup .......................................................................................... 22 5.2. Limits ............................................................................................................................ 22 5.3. Test procedure ............................................................................................................. 22 5.4. Test result ..................................................................................................................... 22 5.5. Original test data .......................................................................................................... 23 6. Power Spectral Density ................................................................................................ 28 6.1. Block diagram of test setup .......................................................................................... 28 6.2. Limits ............................................................................................................................ 28 6.3. Test procedure ............................................................................................................. 28 6.4. Test result ..................................................................................................................... 28 6.5. Original test data .......................................................................................................... 29 7. Band Edge Compliance (Conducted Method) ............................................................. 34 7.1. Block diagram of test setup .......................................................................................... 34 7.2. Limits ............................................................................................................................ 34 7.3. Test procedure ............................................................................................................. 34 7.4. Test result ..................................................................................................................... 35 7.5. Original test data .......................................................................................................... 35 Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20111821-1E5 Page 3 of 74 8. Radiated Emission ....................................................................................................... 39 8.1. Block diagram of test setup ......................................................…

Text truncated - open the document above for the full version.

Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20111821-1E4 Page 103 of 121 15. Test Setup Photograph Dongguan Dongdian Testing Service Co., Ltd. Report No.: DDT-R20111821-1E4 Page 104 of 121
