2AKSAMOBULAA-TABTablet PC

Tablet PC Tab-1 English Installing the SIM and Memory Card Installing or replacing the SIM or Memory card when you need.  About SIM Card Hold the SIM card with the cut corner oriented as shown and slip it into the card holder.  About Memory Card Insert the memory card into the card slot with the metal contacts facing down until it inserts to the right position. Important Notes: Please take out the memory card after safe uninstalling or power off to prevent possible system faults. Screen unlocking and Locking After power on, press the Power key to light up the screen and click the unlocking icon. Sliding touch screen into menu. Press the Power key in any interface to enter Standby mode. Intall Helper User can open the Install Helper in the Menu interface to install or lifted applications. Desktop Setting After unlocking and entering the desktop, users can click an icon to open corresponding program, and drag an icon, press and hold it until “Delete” pops up on the screen, drag it on the location of “Delete” and release it. Inthis way, the shortcut icon will be removed but not uninstalled. Contacts Managing Please select the mode to add contacts in first use. Supports multiple modes to add contacts. Users can import contacts from SIM card and SD card, set a sync account, or directly add new contacts. SMS Sending Before sending a SMS, users can add one or several receivers at a time. The smart phone supports sending texts, photos, expressions, contact information, audio or video. Quick Uninstalling To quick uninstall a program, users can open the Menu interface, press the icon until pops up, and then uninstall and view application information. Flashlight After pressing the Power key to light up the screen, users turns on the flashlight via the drop-down status bar. Calls Making T9 keyboard can be used to make calls or search contacts. Contacts can be searched by the letter, partial spelling, full spelling of their names and contact numbers. The search results will be displayed in the order of degree of match and frequency of contact. Missed calls will be highlighted in red in Call Logs. Swipe to the right to switch to Recent Calls Swipe to the right again to switch to Contacts. Photos or Videos Open the Camera to take photos. Support quick adjust focus, continuous capture, special effect and other more professional photo modes. Switch to Video Mode in the menu. Click “Photo key” while making a video to take photos. Support sync multi-task operation. Photo Browsing Enter the Gallery program, double click or pinch to zoom out a single photo, swipe to the left or right to switch to the previous or next photo. Click the photo to pop up or conceal the Menu. Select MMS, Bluetooth, Youtube, E-mail or other applications to share the photos. Song Listening The Music Program supports local music playing and song playing according to song name, singer, album and playlist. E-mails After setting the e-mail account, users cansend e-mails through the smart phone. New e-mail reminders for will be promptly given. Internet Surfing Users can double click or pinch the webpage to zoom out, and rapidly visit frequently-visited websites through Website Navigation. The browser supports multi-tag and tag-based webpage switchover. The area to be browsed is best adapted to the smart full screen. Notification Panel Users can open the Notification Panel to view message, calendar or event notifications, and easily set Wi-Fi and Bluetooth. To open the Notification Panel, press the Status Bar, swipe down and click Status Switch, and then make the settings as shown above. Multi-task Switchover Supports multi-task operation at the same time. Users can press and hold the Home key, swipe the task to the left or right to end it. Click to switch to the program. Desktop Widgets Adding Users can click "Window Widgets" in the Application Menu, swipe to the left and right to browse the widgets to be added. To add a desktop widget, press and hold the widget in the Widgets Menu and drag it to the blank desktop space. FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. SAR Information Statement Your Tablet PC is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by inde…

Text truncated - open the document above for the full version.

ShenzhenYLWDTechnologyCo.,Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020.10.19 Subject; Request for Long Term Confidentiality FCC ID: 2AKSAMOBULAA-TAB To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: XIE PENG FEI Title: Manager

Shenzhen YLWD Technology Co., Ltd RM1002.A.Haisong BLD.RD Tairan.FuTian District, Shenzhen, China Statement Product: Tablet PC Model: Tab-1 Additional Model: Tab-2, Tab-3, Tab-4, Tab-5, Tab-6, Tab-7, Tab-8, Tab-9, Tab-10, Tab-11, Tab-12, Tab-13, Tab-14, Tab-15, Tab-16, Tab-17, Tab-18, Tab-19, Tab-20, Tab-21, Tab-22, Tab-23, Tab-24, Tab-25, Tab-26, Tab-27, Tab-28, Tab-29, Tab-30 Trademark: MOBULAA We hereby state that All models above are identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Date: 2020/10/19 Name: XIE PENG FEI Company Name : Shenzhen YLWD Technology Co., Ltd Address: RM1002.A.Haisong BLD.RD Tairan.FuTian District, Shenzhen, China Tel / Fax: 13922896118/0755-83272327 E-Mail: [email protected]

Shenzhen YLWD Technology Co., Ltd Agent Authorization Company: Shenzhen YLWD Technology Co., Ltd Address: RM1002.A.Haisong BLD.RD Tairan.FuTian District, Shenzhen, China Product Name: Tablet PC Model Number(s): Tab-1, Tab-2, Tab-3, Tab-4, Tab-5, Tab-6, Tab-7, Tab-8, Tab-9, Tab-10, Tab-11, Tab-12, Tab-13, Tab-14, Tab-15, Tab-16, Tab-17, Tab-18, Tab-19, Tab-20, Tab-21, Tab-22, Tab-23, Tab-24, Tab-25, Tab-26, Tab-27, Tab-28, Tab-29, Tab-30 Product Description: Tablet PC We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-10-19 Name:XIE PENG FEI Title:Manager Company: Shenzhen YLWD Technology Co., Ltd

Shenzhen YLWD Technology Co., Ltd 2020-10-19 To: Federal Communications Commission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia, MD FCC ID: 2AKSAMOBULAA-TAB To Whom It May Concern: This letter is to ascertain thatShenzhen YLWD Technology Co., LtdProductMobile phonehas been the units used for conducting FCC compliance testing, the sDoC part will be tested by FCC accredited testlab. The result shows that the EUT has complied to unintentional Radiators requirements (15.101). Test lab information: FCC-Registration No.: 645098 Shenzhen Tongce Testing Lab. Adress: 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China If you have any question or concerns, pls. contact us. Sincerely, (signed) Name / Title: XIE PENG FEI / Manager Company: Shenzhen YLWD Technology Co., Ltd Address: RM1002.A.Haisong BLD.RD Tairan.FuTian District, Shenzhen, China Phone: 13922896118 Fax: 0755-83272327 Email: [email protected]

Page 1 of 4 Appendix B: Photographs of EUT Product: Tablet PC Model: Tab-1 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: Tab-1 Label: Size: L*W=70*35mm Location

Page 1 of 7 Appendix B: Photographs of EUT Product: Tablet PC Model: Tab-1 Internal Photos BT/WIFI ANT GSM/WCDMA/LTE Main ANT GSM/WCDMA/LTE Assist ANT Page 2 of 7 Page 3 of 7 Page 4 of 7 Page 5 of 7 Page 6 of 7 Page 7 of 7

RF exposure evaluation FCC ID: 2AKSAMOBULAA-TAB §2.1093 Radiofrequency radiation exposure evaluation: Portable Devices. According to§15.247(i) and§1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The 1-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  When the minimum test separation distance is < 5 mm, a distance of 5 mm according is applied to determine SAR test exclusion.  The result is rounded to one decimal place for comparison  For EDR+BDR: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 00 2.402 7.92 7±1 8 6.31 5 1.96 3.0  For BLE: Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 19 2.440 -7.84 -8.5±1 -7.5 0.18 5 0.06 3.0 Result: Base on the calculation value, No SAR measurement is required.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AKSAMOBULAA-TAB Product: Tablet PC Model No.: Tab-1 Additional Model No.: Tab-2, Tab-3, Tab-4, Tab-5, Tab-6, Tab-7, Tab-8, Tab-9, Tab-10, Tab-11, Tab-12, Tab-13, Tab-14, Tab-15, Tab-16, Tab-17, Tab-18, Tab-19, Tab-20, Tab-21, Tab-22, Tab-23, Tab-24, Tab-25, Tab-26, Tab-27, Tab-28, Tab-29, Tab-30 Trade Mark: MOBULAA Report No.: TCT200907E045 Issued Date: Oct. 10, 2020 Issued for: Shenzhen YLWD Technology Co., Ltd RM1002.A.Haisong BLD.RD Tairan.FuTian District, Shenzhen, China Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT200907E045 Page 2 of 70 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 7 4.1. Test environment and mode ................................................................................. 7 4.2. Description of Support Units ................................................................................ 7 5. Facilities and Accreditations .................................................................. 8 5.1. Facilities ................................................................................................................. 8 5.2. Location ................................................................................................................. 8 5.3. Measurement Uncertainty ..................................................................................... 8 6. Test Results and Measurement Data ..................................................... 9 6.1. Antenna requirement ............................................................................................ 9 6.2. Conducted Emission ........................................................................................... 10 6.3. Conducted Output Power ................................................................................... 14 6.4. 20dB Occupy Bandwidth .................................................................................... 19 6.5. Carrier Frequencies Separation ......................................................................... 24 6.6. Hopping Channel Number .................................................................................. 29 6.7. Dwell Time ............................................................................................................ 32 6.8. Pseudorandom Frequency Hopping Sequence ................................................ 37 6.9. Conducted Band Edge Measurement ................................................................ 38 6.10. Conducted Spurious Emission Measurement ................................................. 42 6.11. Radiated Spurious Emission Measurement .................................................... 46 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT200907E045 Page 3 of 70 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Tablet PC Model No.: Tab-1 Additional Model No.: Tab-2, Tab-3, Tab-4, Tab-5, Tab-6, Tab-7, Tab-8, Tab-9, Tab-10, Tab-11, Tab-12, Tab-13, Tab-14, Tab-15, Tab-16, Tab-17, Tab-18, Tab-19, Tab-20, Tab-21, Tab-22, Tab-23, Tab-24, Tab-25, Tab-26, Tab-27, Tab-28, Tab-29, Tab-30 Trade Mark: MOBULAA Applicant: Shenzhen YLWD Technology Co., Ltd Address: RM1002.A.Haisong BLD.RD Tairan.FuTian District, Shenzhen, China Manufacturer: Shenzhen YLWD Technology Co., Ltd Address: RM1002.A.Haisong BLD.RD Tairan.FuTian District, Shenzhen, China Date of Test: Sep. 08, 2020 – Oct. 09, 2020 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Oct. 09, 2020 Kevin Huang Reviewed By: Date: Oct. 10, 2020 Beryl Zhao Approved By: Date: Oct. 10, 2020 Tomsin Report No.: TCT200907E045 Page 4 of 70 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(1) PASS 20dB Occupied Bandwidth §15.247 (a)(1) PASS Carrier Frequencies Separation §15.247 (a)(1) PASS Hopping Channel Number §15.247 (a)(1) PASS Dwell Time §15.247 (a)(1) PASS Radiated Emission §15.205/§15.209 PASS Band Edge §15.247(d) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT200907E045 Page 5 of 70 Hotline: 400-6611-140 …

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Tablet PC Model: Tab-1 Radiated Emission Page 2 of 2 Conducted Emission
