2AKU5ZG38Vision Enhancement Imager

1 Thank you for purchasing this product. Please read this Guide first and keep it properly for future reference. We hope this product will meet your expectations. Quickstart Guide Vision Enhancement Imager V1.0.0 EN/RU/DE/FR/IT/ES/JP/KR/PL/RO/NO/SE/DK/HU/FI/CS/SK Table of contents EN English ............................................................................2 RU Русский ...........................................................................4 DE Deutsch ...........................................................................6 FR Français ...........................................................................9 IT Italiano ...........................................................................12 ES Español..........................................................................15 JP 日本語 .............................................................................17 KR 한국인 ............................................................................19 PL Polski .............................................................................21 RO Română ........................................................................23 NO Norsk ............................................................................25 SE Svenska .........................................................................27 DK Dansk ............................................................................29 HU Magyar .........................................................................31 FI Suomalainen ..................................................................33 CS čeština ...........................................................................35 SK slovenský .......................................................................38 2 1. Appearance (P1~P2) S/NComponentsFunctions 1 Objective lens module Focus on infrared light to the detector for imaging 2Ranging module It is used to transmit and receive lasers for ranging 3 Battery compartment Space for installing batteries 4Power button Short press: compensation/exit menu/wake up Long press: turn on power/turn off power/turn off screen/wake up 5Menu knob Rotate clockwise: switch pseudo color/movement Rotate counterclockwise: Switch pseudo color/movement in reverse order Short press: enter the shortcut menu/confirm to enter the current option Long press: enter the main menu/ return to the superior menu without saving 6Ranging button Short press: turn on ranging Long press: Turn off ranging 7Shutter button Short press: take a photo Long press: video recording 8 Left and right focusing knobs Rotate to adjust the focal length 9Type-C portConnect a PC via a type-C cable EN English 3 S/NComponentsFunctions 10Eyepiece Observe the real-time imaging and operation screen of equipment 11 Sight distance adjustment Turn and regulate the eyepiece diopter to meet the clear observation effect of human eyes 12Zoom-in knob Rotate clockwise: smooth zoom-out Rotate counterclockwise: smooth zoom-in 13MICSound-recording port 2.Detailed operation Scan QR code for more instructions. Laser product for TS632L,TS432L complies with 21 CFR 1040.10 and 1040.11 Pulse width: 17ns Important This Guide is a general guide for a series of products, which means that the product you receive may differ from the description in the Guide. The actual product you receive shall prevail. This Guide is prepared to introduce our products to the users. We will try our best to ensure the accuracy of the Guide, but the completeness of the Guide still cannot be guaranteed, because our products have been continuously upgraded. We reserve the right to modify at any time without prior notice. FCC WARNING This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. iOS Android NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, • Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. • The rating information is located at the bottom of the unit. there is no guarantee that interference will not occur in a particular installation.if this equipment does cause harmful interference to radio or television reception,which can be determined by turning the equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures: IIIustrations 5 6 7 9 8 P1 P2 1 13 12 11 10 2 4 3 A B C 5G5G WiFiWiFi 5G 2.4G XXXXXXXX-XX-xxxx XXXXXXXX-XX-xxxx 4 1. Внешний вид (P1~P2) No Наименование элемента Функции 1 Модуль объектива Сфокусировать инфракрасный свет на детекторе для получения изображений 2 Модуль дальнометрии Используется для излучения и приема лазеров для дальнометрии 3 Отсек аккумулятора Установить аккумулятор сюда 4Кнопка питания Короткое нажатие: компенсация/…

Text truncated - open the document above for the full version.

Rev 31/3/2024 Wuhan Guide Sensmart Tech Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 20-08-2024 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AKU5ZG38 [Wuhan Guide Sensmart Tech Co., Ltd] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) Yong Bao Rev 31/3/2024 Wuhan Guide Sensmart Tech Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 20-08-2024 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AKU5ZG38 [Wuhan Guide Sensmart Tech Co., Ltd] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Yong Bao

Wuhan Guide Sensmart Tech Co., Ltd Date: 2024-08-22 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AKU5ZG38 To Whom It May Concern: This letter is to ascertain that Wuhan Guide Sensmart Tech Co., Ltd EUT：Vision Enhancement Imager MODEL No.: TS632L，TS432L Has been the units used for conducting FCC compliance testing, the SDoC part will be tested by EMTEK (SHENZHEN) CO., LTD. If you have any question or concerns, pls. contact us. Sincerely, Client’s signature ： Client’s name / title ： Yong Bao Contact information / address: Wuhan Guide Sensmart Tech Co., Ltd /NO.29,Gaoxin 3rd Road,Donghu New-tech Development Zone,Wuhan City,Hubei,P.R.China

[Wuhan G [NO.29, G P.R.Chin Date: [20 Federal C Authoriza 7435 Oa Columbi a FCC ID: Applican US [Wuhan G US Agen [Wuhan G United St marketing Commiss later. FCC US the desi g Sensmar Designat Company FRN: 003 Address: Contact P Phone: 7 Email: Su Sincerely Company Ltd] Compan y Signature Guide Sensm Gaoxin 3rd R na] 024-8-27] Communicat ation and Ev kland Mills R a, MD 21046 [2AKU5ZG3 t FRN: [0026 S Agen Guide Sensm nt, LLC to acc Guide Sensm tates for no l g and import sion-related a Agent, LLC, gnated agent rt Tech Co., ted Agent In y Name: FCC 33402884 3722 Illinoi s Person: Tim 708-571-3148 upport@FCC y, y: [Wuhan G y Represent e: mart Tech C Road, Dong tions Comm valuation Div Road 6 38] 6156638] t – Atte mart Tech C cept service mart Tech C less than one tation of the administrativ accepts as t for the purp Ltd] for FCC nformation: C US Agent, s Avenue, Sa Payne 8 CUSAgent.co Guide Sensm ative: [Yong Co., Ltd] hu New-tec h mission vision station Co., Ltd] cert of process o Co., Ltd], acc e year after applicable e ve or judicial of the date o pose of acce C ID: [2AKU5 : , LLC aint Charles, om mart Tech Co Bao] h Developm Statem ifies, that as on our behal cepts to main either the gr equipment wi proceeding of the filing o pting service 5ZG38]. , IL, 60174, U o., Designat Designat ] Signatur e ent Zone, W ment / Pa of [2024-8-2 f for FCC ID ntain an agen rantee has pe ithin the U.S involving the of this applica e of process USA ted Agent: F ted Agent Re e: Wuhan City, H art 2.91 27], we have D: [2AKU5ZG nt of service ermanently t S., or the con e equipment ation, the ob on behalf o f CC US Agen epresentativ Hubei, 1(d)(7) e designated G38]. of process i terminated a clusion of an t, whichever ligation of b e f [Wuhan Gu nt, LLC e: Tim Payn FCC n the all ny is eing uide e

Rev 11/20/07 Wuhan Guide Sensmart Tech Co., Ltd Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2AKU5ZG38 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagram, Schematics, Operational Description, Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Yong Bao Wuhan Guide Sensmart Tech Co., Ltd

Declaration on model difference We the undersigned hereby confirm that any of our production units bearing the following model numbers are identical in circuitry and electrical, mechanical and physical construction; the only differences are the model name and the color of appearance for trading purpose. FCC ID: 2AKU5ZG38 Production name Trade name Model no. Vision Enhancement Imager Guide TS632L，TS432L Confirmed by Wuhan Guide Sensmart Tech Co., Ltd Yong Bao Wuhan Guide Sensmart Tech Co., Ltd Date: 2024-08-22

Wuhan Guide Sensmart Tech Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 2024-08-22 SUBJECT: FCC Application for FCC ID: 2AKU5ZG38 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, Yong Bao Wuhan Guide Sensmart Tech Co., Ltd

EUT EXTERNAL PHOTOGRAPHS . ----------------The end----------------

 (87,17(51$/3+272*5$3+6

ANTENNA ----------------The end----------------

. Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/22 System Check_H2450 DUT: Dipole 2450 MHz; Type:D2450V2; SN:927 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2450 MHz;σ=1.77S/m;ε r =40.13;ρ=1000kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=250mW/Area Scan (41x51x1):Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 25.1 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 114.9 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 31.5 W/kg SAR(1 g) = 13.09 W/kg; SAR(10 g) = 6.11 W/kg Maximum value of SAR (measured) = 23.1 W/kg . Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/23 System Check_H5250 DUT: Dipole 5GHzV2;Type:D5GHzV2; SN:1169 Communication System: CW; Frequency: 5250 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5250 MHz;σ=4.74S/m;ε r = 36.82;ρ= 1000 kg/m 3 AmbientTemperature：22.2°C; LiquidTemperature：22.0°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=100mW/Area Scan (91x91x1):Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 22.3 W/kg Pin=100mW/Zoom Scan (4x4x2mm) (7x7x12)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 58.441 V/m; Power Drift = 0.12 dB Peak SAR (extrapolated) = 36.7 W/kg SAR(1 g) =7.91 W/kg; SAR(10 g) = 2.15 W/kg Maximum value of SAR (measured) = 23.4 W/kg

Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/22 2.4GWIFI DUT: TQ630L Communication System: 802.11b ; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2437 MHz;σ=1.75S/m;ε r =40.10;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Front/Area Scan (8x11x1):Measurement grid: dx=20mm, dy=20mm Maximum value of SAR (measured) = 0.441 W/kg Front/Zoom Scan (7x7x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.088 V/m; Power Drift = 0.11 dB Peak SAR (extrapolated) = 0.749 W/kg SAR(1 g) = 0.345 W/kg; SAR(10 g) = 0.145 W/kg Maximum value of SAR (measured) = 0.536 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2024/7/23 5.2GWIFI DUT: TQ630L Communication System: 802.11a; Frequency: 5200 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5200 MHz;σ=4.72S/m;ε r = 36.80;ρ= 1000 kg/m 3 AmbientTemperature：22.2°C; LiquidTemperature：22.0°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2024/6/25; - Electronics: DAE4 Sn1418; Calibrated: 2024/5/17 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Front/Area Scan (8x11x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.758 W/kg Front/Zoom Scan (7x7x7)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 4.149 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 2.81 W/kg SAR(1 g) = 0.581 W/kg; SAR(10 g) = 0.168 W/kg Maximum value of SAR (measured) = 1.15 W/kg

Photographs of EUT Setup Fig-4.1 Front of EUT with 0 cm Gap (Body Mode) Photographs of EUT

Report No. ENS2407090237W00504R Page 1 of 43 Ver.1.0 TEST REPORT Product Name ： Vision Enhancement Imager Model Number ： TS632L，TS432L FCC ID ： 2AKU5ZG38 Prepared for : Wuhan Guide Sensmart Tech Co., Ltd Address : NO.29,Gaoxin 3rd Road,Donghu New-tech Development Zone,Wuhan City,Hubei,P.R.China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2407090237W00504R Date(s) of Tests : July 22, 2024 to July 23, 2024 Date of Issue : July 24, 2024 $二维码$ Report No. ENS2407090237W00504R Page 2 of 43 Ver.1.0 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION ............................................................................................................................ 4 2. Description of Equipment Under Test .................................................................................................................. 6 3. SAR Measurement System .................................................................................................................................... 7 3.1 Definition of SpecificAbsorptionRate (SAR) ..................................................................................................... 7 3.2 SPEAG DASY System ..................................................................................................................................... 7 3.2.1 Robot .................................................................................................................................................. 8 3.2.2 Probes ................................................................................................................................................ 9 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................... 9 3.2.4 Phantoms ......................................................................................................................................... 10 3.2.5 Device Holder ................................................................................................................................... 11 3.2.6 System Validation Dipoles ................................................................................................................ 11 3.2.7 Tissue Simulating Liquids ................................................................................................................. 12 3.3 SAR System Verification ................................................................................................................................ 14 3.4 SAR Measurement Procedure ....................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure.......................................................................................................... 15 3.4.2 VolumeScan Procedure .................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................... 16 3.4.5 SAR Averaged Methods ................................................................................................................... 16 4. SARMeasurement Evaluation .............................................................................................................................. 17 4.1 Applicable Standards ..................................................................................................................................... 17 4.2 EUT Configuration and Setting ...................................................................................................................... 17 4.3 EUT Testing Position ...................................................................................................................................... 19 4.3.1 Front-of-face device ......................................................................................................................... 19 4.3.2 SAR Test Exclusion Evaluations ...................................................................................................... 21 4.4 Tissue Verification .......................................................................................................................................... 23 4.5 System Validation ........................................................................................................................................... 23 4.6 System Verification ......................................................................................................................................... 24 4.7 Maximum Output Power ................................................................................................................................. 25 4.7.1 Maximum Conducted Power ............................................................................................................ 25 4.7.2 Measured Conducted Power Result ................................................................................................ 26 4.8 SAR Testing Results ....................................................................................................................................... 29 4.8.1 SAR Test Reduction Considerations ................................................................................................ 29 4.8.2 SAR Results for Body Exposure Condition ...................................................................................... 30 4.8.3 2.4GHz 802.11g/n OFDM SAR Test Exclusion Consideration: ........................................................ 30 4.8.4 SAR…

Text truncated - open the document above for the full version.

Report No. ENS2407090237W00503R Page 1 of 61 Ver.1.0 $印章$ TEST REPORT Product Name ： Vision Enhancement Imager Model Number ： TS632L，TS432L FCC ID ： 2AKU5ZG38 Prepared for : Wuhan Guide Sensmart Tech Co., Ltd Address : NO.29, Gaoxin 3rd Road, Donghu New-tech Development Zone, Wuhan City, Hubei, P.R.China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2407090237W00503R Date(s) of Tests : July 14, 2024 to August 6, 2024 Date of issue : August 8, 2024 $二维码$ Report No. ENS2407090237W00503R Page 2 of 61 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Wuhan Guide Sensmart Tech Co., Ltd Address : NO.29, Gaoxin 3rd Road, Donghu New-tech Development Zone, Wuhan City, Hubei, P.R.China Manufacturer : Wuhan Guide Sensmart Tech Co., Ltd Address : NO.29, Gaoxin 3rd Road, Donghu New-tech Development Zone, Wuhan City, Hubei, P.R.China EUT : Vision Enhancement Imager Model Name : TS632L，TS432L Trademark : Guide Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15, Subpart E PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Part 15.407 The test results of this report relate only to the tested sample identified in this report. Date of Test : July 14, 2024 to August 6, 2024 Prepared by : Una Yu /Editor Reviewer : Joe Xia /Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No. ENS2407090237W00503R Page 3 of 61 Ver.1.0 Modified History Version Report No. Revision Date Summary V1.0 ENS2407090237W00503R / Original Report Report No. ENS2407090237W00503R Page 4 of 61 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ..................................................................................................................... 2 2 EUT TECHNICAL DESCRIPTION ................................................................................................................... 5 3 SUMMARY OF TEST RESULT ......................................................................................................................... 6 4 TEST METHODOLOGY .................................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ........................................................................................................ 7 4.3 DESCRIPTION OF TEST MODES ................................................................................................................. 8 5 FACILITIES AND ACCREDITATIONS ........................................................................................................... 9 5.1 FACILITIES .................................................................................................................................................... 9 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ................................................................................. 9 6 TEST SYSTEM UNCERTAINTY ......................................................................................................................10 7 SETUP OF EQUIPMENT UNDER TEST ......................................................................................................... 11 7.1 RADIO FREQUENCY TEST SETUP ............................................................................................................ 11 7.2 RADIO FREQUENCY TEST SETUP ............................................................................................................ 11 7.3 CONDUCTED EMISSION TEST SETUP .....................................................................................................13 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ....................................................................14 7.5 SUPPORT EQUIPMENT ...............................................................................................................................14 8 TEST REQUIREMENTS ...................................................................................................................................15 8.1 BANDWIDTH MEASUREMENT .................................................................................................................15 8.2 MAXIMUM CONDUCTED OUTPUT POWER ...........................................................................................23 8.3 MAXIMUM PEAK POWER DENSITY ........................................................................................................35 8.4 UNDESIRABLE RADIATED SPURIOUS EMISSION ................................................................................43 8.5 POWER LINE CONDUCTED EMISSIONS .................................................................................................57 8.6 ANTENNA APPLICATION ...........................................................................................................................60 Report No. ENS2407090237W00503R Page 5 of 61 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Characteristics Description Product Vision Enhancement Imager Model Number TS632L，TS432L Sample number 2# Wifi Type UNII-1: 5150MHz-5250MHz Band WLAN Supported 802.11a 802.11n(20MHz channel bandwidth) 802.11n(40MHz channel bandwidth) 802.11ac(20MHz channel bandwidth) 802.11ac(40MHz channel bandwidth) 802.11ac(80MHz channel bandwidth) Data Rate 802.11a:54/48/36/24/18/12/9/6Mbps 802.11n:up to 300 Mbps Modulation OFDM with BPSK/QPSK/16QAM/64QAM for 802.11a/n; Frequency Range UNII-1: 5150MHz-5250MHz Band 5180-5240MHz for…

Text truncated - open the document above for the full version.

Dongguan YiJia Electronics Communication Technology Co.,Ltd. SPECIFICATION FOR APPROVAL Da te 2023/11/10 File No 23111001 Revision 1.0 CUSTOMER: Guide Sensmart CUSTOMER NO: ZG31A WIFI Antenna L 105mm MHF PART NAM E: WIFI Antenna L=105mm MHF SUPPLIER NO: YJT01.220.023.301A Date: Q“TY: CUS TOMER APPROVED BY APPROVALCHIEFSUPERVISOR SUPPLIER S IGNATURE APPROVALCHECKDESIGN add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax :0769-82586086 APPROVALCHECKDESIGN ChenGuoqiangXieLiChenXingyi YJ-RD-F04-A Ad mission book item table NO . （Contents） （Number of Page） （Page Code） 11 1 （Sppec Cover）） 2 （S pec Item ） 12 3 （Drawing） 13 4 （A ntenna Specification） 14 5 （S Parameter ） 15 6 （P assive Test ） 36 ~ 8 7 （Radiation P attern ） 29 ~ 10 8 （Antenna Profile） 211 ~ 12 9 NANANA 10 NA NANA 11N/AN/AN/A add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 12--- 13--- Antenna Specification Electrical Properties Frequency 2.4-2.5GHz 5.15-5.85GHz Impedance50 Ohm Nominal V.S.W.R 2.0 [email protected] 5.0 [email protected] Gain 2.2 [email protected] Gain 5.4 [email protected] RadiationOmni-directional PolarizationLinear Physical Properties Connector Generation 1 IPEX Cable TypeO.D.1.13mm Cable Length105mm Cable ColorBlack add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Operating Temp.-40 ~ +85 ̊C Storage Temp / Humidity 25±5 ̊C / <70% Antenna Performance Test Agilent Antenna Performance Te s t Agilent E5071B SS Parameter Test // WiFi Antenna add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 AntennaPassive TestAntenna Passive Te s t Z Y X X Z Y add：Yuanfu Industrial Zone, 59 Muyu Road, Shatou Community, Changan Town, Dongguan City Tel:0769-82586086 Fax:0769-82586086 Passive Test For WiFi Antenna(2.4G) FreqEffiEffiGain (MHz)(%)(dB)(dBi) 2400 40.7 -3.9 2.2 2410 40.2 -4.0 2.2 2420 44.2 -3.5 2.0 2430 41.8 -3.8 2.0 2440 41.6 -3.8 1.7 2450 40.1 -4.0 2.0 2460 37.2 -4.3 1.4 2470 42.9 -3.7 1.6 2480 43.1 -3.7 1.2 add：Yuanfu Industrial Zone, 59 Muy…

Text truncated - open the document above for the full version.
