2AKU5ZG66Vision Enhancement Imager

Thank you for purchasing this product. Please read this Guide first and keep it properly for future reference. We hope this product will meet your expectations. Quickstart Guide V1.0.0 Vision Enhancement Imager UMBRA 4.0 SERIES  7DEOHRIFRQWHQWV +4+TMROYN 8;ǟȂȀȀǹǷǸ *+*K[ZYIN ,8,XGT¬GOY /:/ZGROGTU +9+YVG¶UR 06㙾㟅嬷 18뻳� 626URYQO 858US§TÈ 454UXYQ 9+9\KTYQG *1*GTYQ .;3GM_GX ,/9[USGRGOTKT )9ÒKĦZOTG 91YRU\KTYQ 6:6UXZ[M[ ̄Y   +4+TMROYN 1. Product introduction The UMBRA 4.0 series (TU4.0) features an advanced 12μm high-definition infrared detector and a new Hyper Light image algorithm, delivering high- definition viewing images. A 50Hz high frame rate optimizes the visual experience, resulting in smoother, more fluid, and lag - free visuals. A 60mm exit pupil distance enhances wearing compatibility and user comfort. The built-in 1200- meter laser rangefinder, coupled with superior magnification, provides an exceptional shooting experience in both open fields and jungle environments. 2. Packing list Device œ1, Batteries œ2, Battery Charging Block œ1, Data Cable œ1, Adapter Plug œ4, 5V 2A Adapter œ1, Lens Cloth œ1, Carrying Bag œ1, Safety Information Sheet œ1, Quick Start Guide œ1, Warranty Card œ1 3. Appearance SNDevice NameFunction 1Eyepiece Observe the real-time imaging and operation screen of the device 2Diopter Adjustment Rotate the eyepiece to adjust its diopter to suit the human eye and achieve a clear viewing effect 3Ranging Button Live screen: Short press: Activate single distance measurement Long press: Activate continuous distance measurement 4Photo Button Any interface: Short press: Take a photo Long press: Record video 5 Photo Button + Ranging Button Live screen: Long pressCompensation 9 10 12 11 1 2 3 4 6 7 8 13 5  6Power Button Power off status: Long press: Power on Power on, any screen: Long press: Power off when the countdown is complete. Power off countdown: Press and hold any button briefly or rotate to cancel power off Live screen when powered on: Short press: Screen off Menu interface when powered on: Short press: Exit menu 7Zoom Knob Rotate clockwise: Smoothly zoom in Rotate counterclockwise: Smoothly shrink 8Battery Compartment Install battery 9Menu Knob Live screen: Short press: Enter the shortcut menu Long press: Enter the main menu Rotate clockwise : Switch to pseudo-color Rotate counterclockwise: switch pseudo-color in reverse order Menu interface: Short press: Confirm Long press: Save settings, return to the previous page Rotate clockwise : Move the option down. Rotate counterclockwise: Move the option upwards 10Focusing KnobRotate to adjust focus 11Laser ModuleUsed for laser ranging 12 Objective Lens Module Focusing infrared light onto the detector for imaging 13Data InterfaceCharging and data transmission 4. Battery installation a. Press the battery cover button to open the battery compartment. b. Insert one battery according to its positive and negative terminals. c. Close the battery cover and lock the compartment door. +4+TMROYN  5. Data transmission a. Start the device to put it into the power-on state. b. Connect the device to your PC via a USB-Type-C cable. c. Accessing data stored on the device from a PC. d. The USB-Type-C cable connects the device to the power source, supporting both power supply and charging. 6. APP connection a. Start the device to put it into the power-on state. b. Turn on the WiFi hotspot on your device. c. Search for the device's WiFi hotspot name on your mobile phone and connect. d. You can get a live view of the device, control and access the device by launching the TargetIR APP on your mobile phone. +4+TMROYN >>>>>>>>>>^^^^ >>>>>>>>>>^^^^  Scan the code to install the TargetIR app 7. More Operation Scan the QR code for the detailed operation instructions. Avoid pointing the device at intense heat sources (e.g., the sun, lasers, welders) to prevent damage. +4+TMROYN Android iOS  1. Введение в продукцию Серия UMBRA 4.0 (TU4.0) оснащена усовершенствованным инфракрасным детектором высокого разрешения 12 мкм и новым алгоритмом обработки изображений Hyper Light , обеспечивающим изображение высокой четкости. Высокая частота кадров 50 Гц оптимизирует визуальное восприятие, обеспечивая более плавное, непрерывное и без задержек изображение. Расстояние между выходными зрачками 60 мм повышает удобство ношения …

Text truncated - open the document above for the full version.

1 Certification information: · These terms apply only to the products with corresponding markings or features. · The information is intended to ensure that users use this product correctly to avoid danger or property damage. · This product must be used in strict compliance with local electrical safety regulations. EU statement This product and its accessories (where applicable) are marked with "CE" and therefore conform to the European harmonized standards provided in applicable Directive 2014/30/EU (EMCD), Directive 2014/35/EU (LVD), and Directive 2011/65/EU (RoHS). Directive 2012/19/EU (WEEE Directive): Products with this symbol should not be discarded as unsorted municipal waste in the EU. For proper recycling, you're requested to return this product to your local supplier when purchasing the same new equipment, or discard it at a designated recycling collection point. Details are presented on www.recyclethis.info for reference. Directive 2006/66/EC and its revised Directive 2013/56/EU (Battery Directive): This product contains the batteries that must not be disposed of as unsorted municipal waste in the EU. Please see the product manuals for specific information on battery. Batteries marked with this symbol may bear letters representing cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, you're requested to return the battery to the supplier or a designated recycling collection point. Details are presented on www.recyclethis.info for reference. This product and -if applicable- the supplied accessories too are marked with "UKCA" and comply therefore with the following directives: Radio Equipment Regulations 2017, Electromagnetic Compatibility Regulations 2016, Electrical Equipment (Safety) Regulations 2016, the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Regulations 2012. FCC Caution · 15.19 Label requirements (Suit for Verification (VOC) and Certification (ID)) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. · 15.21 Information to user (Suit for Verification (VOC) and Certification (ID) and Declaration of Conformity(DOC)) Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. · 15.105 Information to the user (Suit for Class A and Class B digital device(unintentional radiator or intentional radiator)) Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC RF exposure Statement The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption Rate(SAR). The SAR limit set by the FCC is 1.6 W/kg. The highest SAR level measured for this device is less than SAR limit, so this device meets the FCC Requirement. Laser Hazards Warning a) Before operating the laser device, always make sure the lens hood is fully open to avoid possible damage to lens. EN 2 b) Laser beams with high power, can cause irreversible damage to the eye or skin burns and ignition of other flammable materials. Therefore, make sure that no people or flammable materials are in the path of the laser beam before switching on the laser. c) For safety of you and your family, please keep this device out of the reach of children or minors. Always ensure that equipment is kept in a safe location when not in use. d) You're requested to strictly follow the above safety guidelines and use the laser device with caution to prevent any possible injury or accident. Safety Warning · Power supply: 1) Please use the original adapter (the actual product in the original package may vary) for power supply. 2) Do not connect more than one device to the same power transformer to avoid overheating or fire hazard due to overloading. · Battery: 1) Do not remove the built-in battery. Where necessary, please contact the manufacturer for repair. 2) Do not attempt to disassemble the battery. Once the battery leaks and the liquid gets into the eyes, flush the eyes with clean water immediately and seek medical care. 3) Do not short-circuit the battery (connect its positive and negative terminals). 4) Do not place the battery in humid conditions and water, nor expose them to high ambient temperatures or near hot objects. 5) Do not put the battery near heat sources or combustion sources. Avoid direct sunlight. 6) Keep the battery out of the reach of children. 7) Do not swallow the battery to avoid chemical burns. 8) Please use the battery provided with the product for power supply. Improper use or replacement by an incorrect type can lead to an explosion. 9) Please charge the battery according to the charging instructions and procedures in the operation manual. 10) Please use the original adapter or charger for charging (the actual p…

Text truncated - open the document above for the full version.

Photographs of EUT Setup Fig-4.1 Front of EUT with 0 cm Gap (Body Mode) Fig-4.2 Left Side of EUT with 0 cm Gap (Body Mode) Fig-4.3 Left Side of EUT with 0 cm Gap (Body Mode) Photographs of EUT

Report No. Page 1 of 2 Ver.1.0 TEST SETUP PHOTOGRAPHS 1.1. Photos of Conducted Emission Measurement Report No. Page 2 of 2 Ver.1.0 1.2. 1.2. Photos of Radiation Emission Measurement

Report No. ENS2605140240W00603R Page 63 of 85 Ver.1.0 8.5 RADIATED EMISSION 8.5.1 Applicable Standard According to FCC Part 15.247(d) and 15.209 and KDB 558074 D01 15.247 Meas Guidance v05r02 8.5.2 Conformance Limit According to FCC Part 15.247(d): radiated emissions which fall in the restricted bands, as defined in §15.205(a), must also comply with the radiated emission limits specified in §15.209(a) (see §15.205(c)). According to FCC Part15.205, Restricted bands MHz MHz MHz GHz 0.090-0.110 16.42-16.423 399.9-410 4.5-5.15 10.495-0.505 16.69475-16.69525 608-614 5.35-5.46 2.1735-2.1905 16.80425-16.80475 960-1240 7.25-7.75 4.125-4.128 25.5-25.67 1300-1427 8.025-8.5 4.17725-4.17775 37.5-38.25 1435-1626.5 9.0-9.2 4.20725-4.20775 73-74.6 1645.5-1646.5 9.3-9.5 6.215-6.218 74.8-75.2 1660-1710 10.6-12.7 6.26775-6.26825 123-138 2200-2300 14.47-14.5 8.291-8.294 149.9-150.05 2310-2390 15.35-16.2 8.362-8.366 156.52475-156.52525 2483.5-2500 17.7-21.4 8.37625-8.38675 156.7-156.9 2690-2900 22.01-23.12 8.41425-8.41475 162.0125-167.17 3260-3267 23.6-24.0 12.29-12.293 167.72-173.2 3332-3339 31.2-31.8 12.51975-12.52025 240-285 3345.8-3358 36.43-36.5 12.57675-12.57725 322-335.4 3600-4400 (2) 13.36-13.41 According to FCC Part15.205 the level of any transmitter spurious emission in Restricted bands shall not exceed the level of the emission specified in the following table Restricted Frequency(MHz) Field Strength (μV/m) Field Strength (dBμV/m) Measurement Distance 0.009-0.490 2400/F(KHz) 20 log (uV/m) 300 0.490-1.705 24000/F(KHz) 20 log (uV/m) 30 1.705-30 30 29.5 30 30-88 100 40 3 88-216 150 43.5 3 216-960 200 46 3 Above 960 500 54 3 8.5.3 Test Configuration Test according to clause 6.2 radio frequency test setup 8.5.4 Test Procedure This test is required for any spurious emission that falls in a Restricted Band, as defined in Section 15.205. It must be performed with the highest gain of each type of antenna proposed for use with the EUT. Use the following spectrum analyzer settings: For Above 1GHz: The EUT was placed on a turn table which is 1.5m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 1 MHz VBW  RBW Sweep = auto Detector function = peak Trace = max hold For Below 1GHz: Report No. ENS2605140240W00603R Page 64 of 85 Ver.1.0 The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 100 kHz for VBW  RBW Sweep = auto Detector function = peak Trace = max hold For Below 30MHz: The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 9kHz VBW  RBW Sweep = auto Detector function = peak Trace = max hold For Below 150KHz: The EUT was placed on a turn table which is 0.8m above ground plane. Maximum procedure was performed on the highest emissions to ensure EUT compliance. Span = wide enough to fully capture the emission being measured RBW = 200Hz VBW  RBW Sweep = auto Detector function = peak Trace = max hold Follow the guidelines in ANSI C63.10 with respect to maximizing the emission by rotating the EUT, measuring the emission while the EUT is situated in three orthogonal planes (if appropriate), adjusting the measurement antenna height and polarization, etc. A pre-amp and a high pass filter are required for this test, in order to provide the measuring system with sufficient sensitivity. Allow the trace to stabilize. The peak reading of the emission, after being corrected by the antenna factor, cable loss, pre-amp gain, etc., is the peak field strength, which must comply with the limit. Submit this data. Now set the VBW to 10 Hz, while maintaining all of the other instrument settings. This peak level, once corrected, must comply with the limit. If the dwell time per channel of the hopping signal is less than 100 ms, then the reading obtained with the 10 Hz VBW may be further adjusted by a “duty cycle correction factor”, derived from 20log(dwell time/100 ms), in an effort to demonstrate compliance with the limit. Submit this data. Repeat above procedures until all frequency measured was complete. 8.5.5 Test Results Pass Report No. ENS2605140240W00603R Page 65 of 85 Ver.1.0  Spurious Emission below 30MHz(9KHz to 30MHz) Temperature: 25.7 C Relative Humidity: 55 ATM Pressure: 1011 mbar Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Margin(dB) H/V PK AV PK AV PK AV -- -- -- -- -- -- -- -- Note: the amplitude of spurious emission that is attenuated by more than 20dB below the permissible limit has no need to be reported. Distance extrapolation factor =40log(Specific distance/ test distance)( dB); Limit line=Specific limits(dBuV) + distance extrapolation factor  Spurious Emission Above 1GHz(1GHz to 25GHz) All antenna modes 2.4G 802.11b/g/n have been tested, and the worst result recorded was report as below: Test mode: 802.11 b Frequency: Channel 1: 2412MHz Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Margin(dB) Detector 4980 V 44.22 74.00 29.78 peak 9870 V 58.77 74.00 15.23 peak 17981.25 V 67.00 74.00 7.00 peak 4980 V 30.69 54.00 23.31 AVG 9870 V 40.01 54.00 13.99 AVG 17981.25 V 46.58 54.00 7.42 AVG 4995 H 43.60 74.00 30.40 peak 9883.125 H 58.29 74.00 15.71 peak 17992.5 H 66.23 74.00 7.77 peak 4995 H 30.71 54.00 23.29 AVG 9883.125 H 40.24 54.00 13.76 AVG 17992.5 H 47.00 54.00 7.00 AVG Test mode: 802.11 b Frequency: Channel 6: 2437MHz Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit 3m(dBuV/m) Margin(dB) Detector 4957.5 V 44.19 74.00 29.81 peak 9892.5 V 58.09 74.00 15.91 peak 17615.625 V 66.81 74.00 7.19 peak 4957.5 V 29.97 54.00 24.03 AVG 9892.5 V 40.31 54.00 13.69 AVG 17615.625 V 47.13 54.00 6.87 AVG 4981.875 H 44.04 74.00 29.96 pea…

Text truncated - open the document above for the full version.

Report No. ENS2605140240W00603R Page 48 of 85 Ver.1.0 11G-Ant1-2412-0~Reference-PASS 11G-Ant1-2412-30~1000-PASS 11G-Ant1-2412-1000~26500-PASS Report No. ENS2605140240W00603R Page 49 of 85 Ver.1.0 11G-Ant1-2437-0~Reference-PASS 11G-Ant1-2437-30~1000-PASS 11G-Ant1-2437-1000~26500-PASS Report No. ENS2605140240W00603R Page 50 of 85 Ver.1.0 11G-Ant1-2462-0~Reference-PASS 11G-Ant1-2462-30~1000-PASS 11G-Ant1-2462-1000~26500-PASS Report No. ENS2605140240W00603R Page 51 of 85 Ver.1.0 11N20SISO-Ant1-2412-0~Reference-PASS 11N20SISO-Ant1-2412-30~1000-PASS 11N20SISO-Ant1-2412-1000~26500-PASS Report No. ENS2605140240W00603R Page 52 of 85 Ver.1.0 11N20SISO-Ant1-2437-0~Reference-PASS 11N20SISO-Ant1-2437-30~1000-PASS 11N20SISO-Ant1-2437-1000~26500-PASS Report No. ENS2605140240W00603R Page 53 of 85 Ver.1.0 11N20SISO-Ant1-2462-0~Reference-PASS 11N20SISO-Ant1-2462-30~1000-PASS 11N20SISO-Ant1-2462-1000~26500-PASS Report No. ENS2605140240W00603R Page 54 of 85 Ver.1.0 11N40SISO-Ant1-2422-0~Reference-PASS 11N40SISO-Ant1-2422-30~1000-PASS 11N40SISO-Ant1-2422-1000~26500-PASS Report No. ENS2605140240W00603R Page 55 of 85 Ver.1.0 11N40SISO-Ant1-2437-0~Reference-PASS 11N40SISO-Ant1-2437-30~1000-PASS 11N40SISO-Ant1-2437-1000~26500-PASS Report No. ENS2605140240W00603R Page 56 of 85 Ver.1.0 11N40SISO-Ant1-2452-0~Reference-PASS 11N40SISO-Ant1-2452-30~1000-PASS 11N40SISO-Ant1-2452-1000~26500-PASS Report No. ENS2605140240W00603R Page 57 of 85 Ver.1.0 11AX20SISO-Ant1-2412-0~Reference-PASS 11AX20SISO-Ant1-2412-30~1000-PASS 11AX20SISO-Ant1-2412-1000~26500-PASS Report No. ENS2605140240W00603R Page 58 of 85 Ver.1.0 11AX20SISO-Ant1-2437-0~Reference-PASS 11AX20SISO-Ant1-2437-30~1000-PASS 11AX20SISO-Ant1-2437-1000~26500-PASS Report No. ENS2605140240W00603R Page 59 of 85 Ver.1.0 11AX20SISO-Ant1-2462-0~Reference-PASS 11AX20SISO-Ant1-2462-30~1000-PASS 11AX20SISO-Ant1-2462-1000~26500-PASS Report No. ENS2605140240W00603R Page 60 of 85 Ver.1.0 11AX40SISO-Ant1-2422-0~Reference-PASS 11AX40SISO-Ant1-2422-30~1000-PASS 11AX40SISO-Ant1-2422-1000~26500-PASS Report No. ENS2605140240W00603R Page 61 of 85 Ver.1.0 11AX40SISO-Ant1-2437-0~Reference-PASS 11AX40SISO-Ant1-2437-30~1000-PASS 11AX40SISO-Ant1-2437-1000~26500-PASS Report No. ENS2605140240W00603R Page 62 of 85 Ver.1.0 11AX40SISO-Ant1-2452-0~Reference-PASS 11AX40SISO-Ant1-2452-30~1000-PASS 11AX40SISO-Ant1-2452-1000~26500-PASS

Report No. ENS2605140240W00603R Page 32 of 85 Ver.1.0 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS 11B-Ant1-2462-PASS Report No. ENS2605140240W00603R Page 33 of 85 Ver.1.0 11G-Ant1-2412-PASS 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS Report No. ENS2605140240W00603R Page 34 of 85 Ver.1.0 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS 11N20SISO-Ant1-2462-PASS Report No. ENS2605140240W00603R Page 35 of 85 Ver.1.0 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS Report No. ENS2605140240W00603R Page 36 of 85 Ver.1.0 11AX20SISO-Ant1-2412-PASS 11AX20SISO-Ant1-2437-PASS 11AX20SISO-Ant1-2462-PASS Report No. ENS2605140240W00603R Page 37 of 85 Ver.1.0 11AX40SISO-Ant1-2422-PASS 11AX40SISO-Ant1-2437-PASS 11AX40SISO-Ant1-2452-PASS Report No. ENS2605140240W00603R Page 38 of 85 Ver.1.0 8.4 UNWANTED SPURIOUS EMISSIONS 8.4.1 Applicable Standard According to FCC Part15.247(d) and KDB 558074 D01 15.247 Meas Guidance v05r02 8.4.2 Conformance Limit According to FCC Part 15.247(d): In any 100 kHz bandwidth outside the frequency band in which the spread spectrum or digitally modulated device is operating, the RF power that is produced shall be at least 20 dB below that in the 100 kHz bandwidth within the band that contains the highest level of the desired power, based on either an RF conducted or a radiated measurement, provided that the transmitter demonstrates compliance with the peak conducted power limits. If the transmitter complies with the conducted power limits based on the use of root-mean-square averaging over a time interval, as permitted undersection 5.4(d), the attenuation required shall be 30 dB instead of 20 dB. Attenuation below the general field strength limits specified in RSS-Gen is not required. 8.4.3 Test Configuration Test according to clause 6.1 radio frequency test setup 8.4.4 Test Procedure The transmitter output (antenna port) was connected to the spectrum analyzer  Reference level measurement Establish a reference level by using the following procedure: Set instrument center frequency to DTS channel center frequency. Set the span to ≥ 1.5 times the DTS bandwidth. Set the RBW = 100 kHz. Set the VBW ≥ 3 x RBW. Set Detector = peak. Set Sweep time = auto couple. Set Trace mode = max hold. Allow trace to fully stabilize. Use the peak marker function to determine the maximum PSD level. Note that the channel found to contain the maximum PSD level can be used to establish the reference level.  Emission level measurement Set the center frequency and span to encompass frequency range to be measured. Set the RBW = 100 kHz. Set the VBW =300 kHz. Set Detector = peak Sweep time = auto couple. Trace mode = max hold. Allow trace to fully stabilize. Use the peak marker function to determine the maximum amplitude level. Ensure that the amplitude of all unwanted emissions outside of the authorized frequency band (excluding restricted frequency bands) are attenuated by at least the minimum requirements . Report the three highest emissions relative to the limit. 8.4.5 Test Results All modes 2.4G 802.11b/g/n have been tested, and the worst result recorded was report as below: Report No. ENS2605140240W00603R Page 39 of 85 Ver.1.0 Band edge measurements TestMode Antenna ChName Frequency[MHz] RefLevel[dBm] Result[dBm] Limit[dBm] Verdict 11B Ant1 Low 2412 4.70 -44.79 ≤-25.3 PASS High 2462 4.11 -46.21 ≤-25.89 PASS 11G Ant1 Low 2412 0.72 -37.89 ≤-29.28 PASS High 2462 2.41 -45.25 ≤-27.59 PASS 11N20SISO Ant1 Low 2412 2.91 -36.59 ≤-27.09 PASS High 2462 0.94 -43.24 ≤-29.06 PASS 11N40SISO Ant1 Low 2422 0.02 -39.87 ≤-29.98 PASS High 2452 -2.89 -44.08 ≤-32.89 PASS 11AX20SISO Ant1 Low 2412 0.62 -35.35 ≤-29.38 PASS High 2462 3.55 -42.38 ≤-26.46 PASS 11AX40SISO Ant1 Low 2422 -1.97 -41.78 ≤-31.97 PASS High 2452 -0.99 -42.96 ≤-30.99 PASS Report No. ENS2605140240W00603R Page 40 of 85 Ver.1.0 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS Report No. ENS2605140240W00603R Page 41 of 85 Ver.1.0 11G-Ant1-2462-PASS 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2462-PASS Report No. ENS2605140240W00603R Page 42 of 85 Ver.1.0 11N40SISO-Ant1-2422-PASS 11N40SISO-Ant1-2452-PASS 11AX20SISO-Ant1-2412-PASS Report No. ENS2605140240W00603R Page 43 of 85 Ver.1.0 11AX20SISO-Ant1-2462-PASS 11AX40SISO-Ant1-2422-PASS 11AX40SISO-Ant1-2452-PASS Report No. ENS2605140240W00603R Page 44 of 85 Ver.1.0 Conducted Spurious Emission TestMode Antenna Frequency[MHz] FreqRange [Mhz] RefLevel [dBm] Result [dBm] Limit [dBm] Verdict 11B Ant1 2412 0~Reference 4.60 4.60 --- PASS 11B Ant1 2412 30~1000 4.60 -57.79 ≤-25.4 PASS 11B Ant1 2412 1000~26500 4.60 -29.64 ≤-25.4 PASS 11B Ant1 2437 0~Reference 5.11 5.11 --- PASS 11B Ant1 2437 30~1000 5.11 -57.85 ≤-24.89 PASS 11B Ant1 2437 1000~26500 5.11 -28.73 ≤-24.89 PASS 11B Ant1 2462 0~Reference 3.60 3.60 --- PASS 11B Ant1 2462 30~1000 3.60 -57.63 ≤-26.4 PASS 11B Ant1 2462 1000~26500 3.60 -29.04 ≤-26.4 PASS 11G Ant1 2412 0~Reference 1.57 1.57 --- PASS 11G Ant1 2412 30~1000 1.57 -57.03 ≤-28.43 PASS 11G Ant1 2412 1000~26500 1.57 -29.1 ≤-28.43 PASS 11G Ant1 2437 0~Reference 0.06 0.06 --- PASS 11G Ant1 2437 30~1000 0.06 -56.95 ≤-29.94 PASS 11G Ant1 2437 1000~26500 0.06 -40.18 ≤-29.94 PASS 11G Ant1 2462 0~Reference 0.35 0.35 --- PASS 11G Ant1 2462 30~1000 0.35 -57.1 ≤-29.65 PASS 11G Ant1 2462 1000~26500 0.35 -37.74 ≤-29.65 PASS 11N20SISO Ant1 2412 0~Reference -0.24 -0.24 --- PASS 11N20SISO Ant1 2412 30~1000 -0.24 -56.69 ≤-30.24 PASS 11N20SISO Ant1 2412 1000~26500 -0.24 -41.33 ≤-30.24 PASS 11N20SISO Ant1 2437 0~Reference 3.41 3.41 --- PASS 11N20SISO Ant1 2437 30~1000 3.41 -56.57 ≤-26.59 PASS 11N20SISO Ant1 2437 1000~26500 3.41 -28.91 ≤-26.59 PASS 11N20SISO Ant1 2462 0~Reference 0.60 0.60 --- PASS 11N20SISO Ant1 2462 30~1000 0.60 -56.84 ≤-29.4 PASS 11N20SISO Ant1 2462 1000~26500 0.60 -29.54 ≤-29.4 PASS 11N40SISO Ant1 2422 0~Reference -3.36 -3.36 --- PASS 11N40SISO Ant1 2422 30~1000 -3.36 -57.62 ≤-33.36 PASS 11N40SISO Ant1 2422 1000~26500 -3.36 -40.58 ≤-33.36 PASS 11N40SISO Ant1 2437 0~Reference -2.91 -2.91 …

Text truncated - open the document above for the full version.

Report No. ENS2605140240W00603R Page 1 of 85 Ver.1.0 TEST REPORT Product Name ： Vision Enhancement Imager Model Number ： TU435L4.0, TU635L4.0, TU650L4.0, TU1260L4.0 FCC ID ： 2AKU5ZG66 Prepared for : Wuhan Guide Sensmart Tech Co., Ltd Address : NO.29,Gaoxin 3rd Road,Donghu New-tech Development Zone,Wuhan City,Hubei,P.R.China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ENS2605140240W00603R Date(s) of Tests : May 21, 2026 to August 18, 2026 Date of issue : August 18, 2026 $二维码$ Report No. ENS2605140240W00603R Page 2 of 85 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant : Wuhan Guide Sensmart Tech Co., Ltd Address : NO.29,Gaoxin 3rd Road,Donghu New-tech Development Zone,Wuhan City,Hubei,P.R.China Manufacturer : Wuhan Guide Sensmart Tech Co., Ltd Address : NO.29,Gaoxin 3rd Road,Donghu New-tech Development Zone,Wuhan City,Hubei,P.R.China EUT : Vision Enhancement Imager Model Name : TU435L4.0, TU635L4.0, TU650L4.0, TU1260L4.0 Trademark : Guide Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2 , Subpart J FCC 47 CFR Part 15 , Subpart C PASS The above equipment was tested by EMTEK (SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2020) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report. Date of Test : May 21, 2026 to August 18, 2026 Prepared by : Cai Zefeng /Editor Reviewer : Xia Lilu /Supervisor Approved & Authorized Signer : Wang Li /Manager Report No. ENS2605140240W00603R Page 3 of 85 Ver.1.0 Modified History Version Report No. Revision Date Summary V1.0 ENS2605140240W00603R / Original Report Report No. ENS2605140240W00603R Page 4 of 85 Ver.1.0 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ....................................................................................................... 2 2 EUT TECHNICAL DESCRIPTION ..................................................................................................... 5 3 SUMMARY OF TEST RESULT .......................................................................................................... 6 4 TEST METHODOLOGY ..................................................................................................................... 7 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................................. 7 4.2 MEASUREMENT EQUIPMENT USED ....................................................................................... 7 4.3 DESCRIPTION OF TEST MODES .............................................................................................. 8 5 FACILITIES AND ACCREDITATIONS ............................................................................................... 9 5.1 FACILITIES .................................................................................................................................…

Text truncated - open the document above for the full version.
