CoFrame Sent RESET USB MicroSD DC K Smart Cloud Photo Frame User Manual Package list Power adapter Holder Notes 1. Please use the included power adapter, otherwise it may cause malfunction . 1.2. According to the design, the product is only recommended for indoor use . 2.3. The product must not be exposed to rain or water splashes . 3.5. Avoid using under conditions of vibration, dust, direct sunlight, and high temp.5.6. Please do not let this product fall, otherwise it may cause damage . 6.7. Do not use alcohol, chemicals, etc. to clean the screen and the product . 7.4. During thunderstorm weather, please shut down and unplug the power adapter to avoid lightning strikes. 4.8. It is not allowed to disassemble the product . 8. The product is manufactured using recyclablehigh-performance materials and components . Do not dispose of th product together with other e . household waste Screen Decorative Get to know Hanging H older Anti-theft P ower SD Card USB R eset Speaker DC Input 1. Installing the holder and connecting to the power supply,turn on the device . 1.2. Scan the QR code,download and install the CoFrame application. 2. 3. Open the CoFrame app , log in or choose to create a free account. 3. 4. Logging in follow the prompts to , connect to the network . 4.5. Add successful and bind photo frame.5. 6. Select a picture or video and send it to the frame. 6. 7. More rich features are subject to the prompts on the app interface . 7. How to use How to use How to use How to use FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.

Rev 1/26/2023 SHENZHEN COSHIP ELECTRONICS CO., LTD. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-09-04 FCC ID: 2AL2O-CF-S101RTCW Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing SHENZHEN COSHIP ELECTRONICS CO., LTD. certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. SHENZHEN COSHIP ELECTRONICS CO., LTD. certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing SHENZHEN COSHIP ELECTRONICS CO., LTD. certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: SHENZHEN COSHIP ELECTRONICS CO., LTD. Address: C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Contact Person: Fang Na Tel.: 18566259709 Email: [email protected] Sincerely, Signature:

Attestation Statements Date: 2026-09-04 TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(FCC ID: 2AL2O-CF-S101RTCW) SHENZHEN COSHIP ELECTRONICS CO., LTD., the undersigned, hereby authorize HOPEK CORPORATION INC to act as our designated agent for service of process, SHENZHEN COSHIP ELECTRONICS CO., LTD. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. HOPEK CORPORATION INC accepts the responsibility to act as designated agent for service of process. Applicant Information： Company name: SHENZHEN COSHIP ELECTRONICS CO., LTD. Contact Name: Fang Na Address: C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Telephone No: 18566259709 Email: [email protected] FRN: 0026503755 Signature: Fang Na Agent Information: Company Name: HOPEK CORPORATION INC Address:16755 Coyote Bush Dr Unit 84, San Diego, CA 92127 United States FRN: 0034562900 Contact Name: Yangyang Xu Telephone No: 561-875-9826 Email: [email protected] Signature: Yangyang Xu

SHENZHEN COSHIP ELECTRONICS CO., LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 4, 2026 Subject; Request for Confidentiality FCC ID: 2AL2O-CF-S101RTCW To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Fang Na Title: engineer

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 SHENZHEN COSHIP ELECTRONICS CO., LTD. Date：2026-09-04 Product Model Number: CF-S101RTCW, CF-S101LTCW, CF-S101ATCW, CF-S101RTW, CF-S101LTW, CF- S101ATW, CF-S156RTCW, CF-S156LTCW, CF-S156ATCW, CF-S156RTW, CF-S156LTW, CF-S156ATW, WF133, WF1561, SKY-168-1, SKY-168, SKY-2216, BT-168, BT-188, SP-101, SP-156, SP-116, WD-106, WD-108, WD-156, WD-101, CF-S07RNCIRW, CF-S07RTCIRW, CF-S07RNCW, CF-S07RTCW, CF-S07R, CF-S07LNCIRW, CF- S07LTCIRW, CF-S07LNCW, CF-S07LTCW, CF-D07LR, CF-S07ANCIRW, CF-S07ATCIRW, CF-S07ANCW, CF- S07ATCW, CF-D07AR, CF-D07R, CF-D07L, CF-D07A, CF-D101R, CF-D101L, CF-D101A, CF-D156R, CF-D156L, CF- D156A FCC ID：2AL2O-CF-S101RTCW To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Fang Na Contact Listed on FCC Wesbite Title: engineer Email: [email protected] On behalf of: SHENZHEN COSHIP ELECTRONICS CO., LTD.

SHENZHEN COSHIP ELECTRONICS CO., LTD. Declaration Letter of Model Difference Date: 2026-08-28 FCC ID: 2AL2O-CF-S101RTCW Tested Model Number: CF-S101RTCW Adding Model Number(s): CF-S101LTCW, CF-S101ATCW, CF-S101RTW, CF-S101LTW, CF-S101ATW, CF-S156RTCW, CF-S156LTCW, CF-S156ATCW, CF-S156RTW, CF-S156LTW, CF-S156ATW, WF133, WF1561, SKY-168-1, SKY-168, SKY-2216, BT-168, BT-188, SP-101, SP- 156, SP-116, WD-106, WD-108, WD-156, WD-101, CF-S07RNCIRW, CF-S07RTCIRW, CF- S07RNCW, CF-S07RTCW, CF-S07R, CF-S07LNCIRW, CF-S07LTCIRW, CF-S07LNCW, CF- S07LTCW, CF-D07LR, CF-S07ANCIRW, CF-S07ATCIRW, CF-S07ANCW, CF-S07ATCW, CF- D07AR, CF-D07R, CF-D07L, CF-D07A, CF-D101R, CF-D101L, CF-D101A, CF-D156R, CF-D156L, CF-D156A All Adding Model Number(s) is/are same electrically identical as Tested Model Number. The differences in model. Yours Sincerely, Applicant: SHENZHEN COSHIP ELECTRONICS CO., LTD. Address: C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Contact Person: Fang Na Tel.: 18566259709 Email: [email protected] Sincerely, Signature:

Page 1 of 5 Report No.: LGT26H071 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT26H071 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT26H071 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 5 Report No.: LGT26H071 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT26H071 Appendix - External Photographs of EUT Constructional Details Photo 9

Label Size:30*50 mm

Page 1 of 3 Report No.: LGT26H071 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 ANT Page 2 of 3 Report No.: LGT26H071 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 3 Report No.: LGT26H071 Appendix - Internal Photographs of EUT Constructional Details Photo 5 Photo 6

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 EMF TEST REPORT Product Name: CoFrame Model Number: CF-S101RTCW (Series Model Number refer to page 6) FCC ID: 2AL2O-CF-S101RTCW Issued For : SHENZHEN COSHIP ELECTRONICS CO., LTD. C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26H071HA03 Sample Received Date: Aug. 07, 2026 Date of Test: Aug. 07, 2026 ~ Aug. 21, 2026 Date of Issue: Aug. 21, 2026 Report No.: LGT26H071HA03 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: SHENZHEN COSHIP ELECTRONICS CO., LTD. Address: C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Manufacturer: SHENZHEN COSHIP ELECTRONICS CO., LTD. Address: C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Product Name: CoFrame Trademark: Model Number: Model Number: CF-S101RTCW (Series Model Number refer to page 6) Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1091 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Chris Chen Engineer Technical Director Report No.: LGT26H071HA03 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Report No.: LGT26H071HA03 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Aug. 21, 2026 Initial Issue Report No.: LGT26H071HA03 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: CoFrame Test Model Number: CF-S101RTCW Series Number: CF-S101LTCW, CF-S101ATCW, CF-S101RTW, CF-S101LTW, CF-S101ATW, CF-S156RTCW, CF-S156LTCW, CF- S156ATCW, CF-S156RTW, CF-S156LTW, CF-S156ATW, WF133, WF1561, SKY-168-1, SKY-168, SKY-2216, BT-168, BT-188, SP-101, SP-156, SP-116, WD-106, WD-108, WD-156, WD-101, CF-S07RNCIRW, CF-S07RTCIRW, CF-S07RNCW, CF-S07RTCW, CF-S07R, CF-S07LNCIRW, CF-S07LTCIRW, CF-S07LNCW, CF-S07LTCW, CF-D07LR, CF-S07ANCIRW, CF-S07ATCIRW, CF-S07ANCW, CF-S07ATCW, CF-D07AR, CF-D07R, CF-D07L, CF-D07A, CF-D101R, CF-D101L, CF- D101A, CF-D156R, CF-D156L, CF-D156A Model Difference: The differences in model. Frequency Bands: 2.4G WLAN IEEE 802.11b/g/n(20MHz): 2412~2462MHz Adapter: Input: 100-240V ~ 50/60Hz 0.6A Battery: N/A Hardware Version: YMB.C015.A Software Version: 1.0.1 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT26H071HA03 Page 6 of 8 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio-frequency (RF) radiation as specified in 1.1307 (b) Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm²) Limits for Occupational / controlled Exposures 0.3-3.0 614 1.63 *(100) 3.0-30 1842/f 4.89/f *(900/f 2 ) 30-300 61.4 0.163 1.0 300 - 1500 -- -- F/300 1500 – 100000 -- -- 5.0 Limits for General population / Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 1.34-30 824/f 2.19/f *(180/f 2 ) 30-300 27.5 0.073 0.2 300 - 1500 -- -- F/1500 1500 – 100000 -- -- 1.0 F= Frequency in MHz * = Plane-wave equivalent power density. Friss Formula Friss Transmission Formula: Pd = (Pout * G) / (4*pi*r²) Where Pd = power density in mW/cm² Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = Distance between observation point and the center of radiator in cm If we know the maximum gain of the antenna and the total output power to the antenna, through calculation, we will know MPE value at distance 20cm. Report No.: LGT26H071HA03 Page 7 of 8 2.3 EUT OPERATION CONDITION EUT was enabled to transmit and receive at lowest, middle and highest channels. 2.4 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance from the antenna should be included in the User manual. So, this device is classified as Mobile device. Report No.: LGT26H071HA03 Page 8 of 8 2.5 TEST RESULT Tu…

Text truncated - open the document above for the full version.

深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 2026-8-618:09:37 1 承认书 SPECIFICATIONFORAPPROVAL 客户名称 CUSTOMERNAME: 产品名称 PRODUCTNAME:C100-WIFI120MM 通诚料号： TCTZC3100fpc120 客户料号 CUSTOMERP/N:430100298 MANUFACTURER SIGNATURE CUSTOMER SIGNATURE CHECKEDBY: APPROVEDBY: DATE:2026.08.06 地址:深圳市宝安区28区大宝路金富来大厦A座401-406 :0755-27728733 :0755-27805416 Address: 401-406, Block A, Jinfulai Building, Dabao Road, District 28, Bao 'an District, Shenzhen Tel Fax 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 2026-8-618:09:37 3 1. 2、 ABC NF0NF Testing instruments and environment: CTIA 743 darkroom, 8960/5515C, with the mobile phone facing away from the standard horn antenna 4 m turntable Matching circuit No matching circuit is added. matching circuit Numerical ohms 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 2026-8-618:09:37 4 3. 4. S11，ReturnLoss，Smith： Machine and antenna position picture 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 2026-8-618:09:37 5 5. ： The whole machine antenna S11 contrast The average value of S11 of our whole antenna is 1.7 The average S11 of the whole antenna of other companies is 4. 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 2026-8-618:09:37 6 6. Antenna efficiency gain: Our company's antenna Samples of antennas from other companies 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 2026-8-618:09:37 7 7： Antenna Apple Figure 深圳通诚无限科技有限公司 ShenzhenTopolinkTechnologyCO.,Ltd 2026-8-618:09:37 8 8. Unit Attached drawings

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 62 RF TEST REPORT Product Name: CoFrame Model Number: CF-S101RTCW (Series Model Number refer to page 8) FCC ID: 2AL2O-CF-S101RTCW Issued For : SHENZHEN COSHIP ELECTRONICS CO., LTD. C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT26H071RF02 Sample Received Date: Aug. 07, 2026 Date of Test: Aug. 07, 2026 ~ Aug. 21, 2026 Date of Issue: Aug. 21, 2026 Report No.: LGT26H071RF02 Page 2 of 62 TEST REPORT CERTIFICATION Applicant: SHENZHEN COSHIP ELECTRONICS CO., LTD. Address: C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Manufacturer: SHENZHEN COSHIP ELECTRONICS CO., LTD. Address: C588, Industrial Building, Science Park, No. 6, Keyuan Road, Science Park Community, Yuehai Street, Nanshan District, ShenzhenCity, Guangdong Province, China Product Name: CoFrame Trademark: Model Number: Model Number: CF-S101RTCW (Series Model Number refer to page 8) Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.247, Subpart C ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024 PASS Prepared by: Approved by: Chris Chen Vita Li Engineer Technical Director Report No.: LGT26H071RF02 Page 3 of 62 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST LABORATORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 10 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3. EMC EMISSION TEST 14 3.1 CONDUCTED EMISSION MEASUREMENT 14 3.2 RADIATED EMISSION MEASUREMENT 18 4. CONDUCTED SPURIOUS & BAND EDGE EMISSION 28 4.1 LIMIT 28 4.2 TEST PROCEDURE 28 4.3 DEVIATION FROM STANDARD 28 4.4 TEST SETUP 28 4.5 EUT OPERATION CONDITIONS 28 4.6 TEST RESULTS 28 5. POWER SPECTRAL DENSITY TEST 29 5.1 LIMIT 29 5.2 TEST PROCEDURE 29 5.3 DEVIATION FROM STANDARD 29 5.4 TEST SETUP 29 5.5 EUT OPERATION CONDITIONS 29 5.6 TEST RESULTS 29 6. BANDWIDTH TEST 30 6.1 LIMIT 30 6.2 TEST PROCEDURE 30 6.3 DEVIATION FROM STANDARD 30 6.4 TEST SETUP 30 6.5 EUT OPERATION CONDITIONS 30 6.6 TEST RESULTS 30 Report No.: LGT26H071RF02 Page 4 of 62 7. PEAK OUTPUT POWER TEST 31 7.1 LIMIT 31 7.2 TEST PROCEDURE 31 7.3 DEVIATION FROM STANDARD 31 7.4 TEST SETUP 31 7.5 EUT OPERATION CONDITIONS 31 7.6 TEST RESULTS 31 8. ANTENNA REQUIREMENT 32 8.1 STANDARD REQUIREMENT 32 8.2 EUT ANTENNA 32 APPENDIX I - TEST RESULTS 33 DUTY CYCLE 33 MAXIMUM PEAK CONDUCTED OUTPUT POWER 37 -6DB BANDWIDTH 38 OCCUPIED CHANNEL BANDWIDTH 42 MAXIMUM POWER SPECTRAL DENSITY LEVEL 46 BAND EDGE 50 CONDUCTED RF SPURIOUS EMISSION 55 APPENDIX II - MEASUREMENT PHOTOS 62 Report No.: LGT26H071RF02 Page 5 of 62 Revision History Rev. Issue Date Revisions 00 Aug. 21, 2026 Initial Issue Report No.: LGT26H071RF02 Page 6 of 62 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted Band Edge Emission PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020 + Cor. 1-2023+C63.10a-2024 + Errata to C63.10a-2024. Report No.: LGT26H071RF02 Page 7 of 62 1.1 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 Occupied Channel Bandwidth ±0.46% 2 RF Output Power, Conducted ±0.71dB 3 Power Spectral Density, Conducted ±1.57dB 4 Unwanted Emission, Conducted ±0.63dB 5 Conducted emission ±2.80dB 6 All Emissions, Radiated (0.009-30MHz) ±2.16dB 7 All Emissions, Radiated (30MHz-1GHz) ±4.61dB 8 All Emissions, Radiated (1GHz-18GHz) ±5.49dB 9 All Emissions, Radiated (18GHz-40GHz) ±4.31dB 10 Temperature ±0.5°C 11 Humidity ±2% 12 Duty Cycle ±2.3% Note: The measurement uncertainty is not included in the test result. Report No.: LGT26H071RF02 Page 8 of 62 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: CoFrame Test Model Number: CF-S101RTCW Series Number: CF-S101LTCW, CF-S101ATCW, CF-S101RTW, CF-S101LTW, CF-S101ATW, CF-S156RTCW, CF-S156LTCW, CF-S156ATCW, CF-S156RTW, CF-S156LTW, CF-S156ATW, WF133, WF1561, SKY-168-1, SKY-168, SKY-2216, BT-168, BT-188, SP-101, SP-156, SP-116, WD-106, WD-108, WD-156, WD-101, CF-S07RNCIRW, CF-S07RTCIRW, CF-…

Text truncated - open the document above for the full version.

Page 1 of 2 Report No.: LGT26H071 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz Page 2 of 2 Report No.: LGT26H071 Set-up for Conducted Emission
