2AL7FFCD-W100portable bluetooth CD player

WARNING 1.NeverplayacrackedCDoraCDisNOTclean,thatwoulddamagethelaser. 2.PleaseremovetheprotectionpaperCDfromtheCDPlayerbeforepowering on,otherwise,thelasercouldbedamaged. 3.Nevertouchthelaserofthedevice. 4.Ifthedeviceisunabletoscandiscsproperly,useastandardcommerciallyavailablecleaner tocleanthelaseroptics.Othercleaningmethodsmaydamagethelaseroptics. Accessories: 1.CDplayerx1 2.5V-2AUSBadaptorx1 3.Remotecontrol×1 4.Wall-mountkit×1 5.Usermanualx1 6.Deskstand×1 7.TypeCcablex1 Specifications: 1.CDformatsupportCD.CD-R.CD-RW.MP3,WMA,WAV 2.FMRadioRange87.5MHz-108.0MHz 3.Speaker:50mm×2 4.Ratedimpedance:4Ω 5.Speakeroutput:3Wx2 6.Powersupply:AC110-220V.50Hz/60Hz 7.TypeCcablelength:2.5m B.Dimensionofmainunit/package: 9.Netweight/Grossweight: 10.Color:White MainFeatures: 1.LEDscreendisplay 2.USBflashreading/playing 3.MicrosSDcardreading/playing 4.Full-bandFMradio 5.BluetoothIN/OUTV5.1 6.Standard3.5mmaudioinput/outputport 7.LoopPlaybackmodes:RepeatOne,RepeatAll,Shuffle.Normal 8.SupportA-Brepeat 9.Supporttimeandalarmclock 10.CopyCDsongsintoUSB/SDCard BasicOperation 2.RemovetheprotectionpaperCDfromtheCDPlayerbeforepoweringon,otherwise,thelaser couldbedamaged. 3.PutaCDintotheCDPlayer. 1.PlugintheTypeCcabletotheUSBadaptor. 4.Keeppress“PowerON/OFF”button(onthedevice)about3stopoweriton,andthenitwill playtheCDin5-12s. 5.Pressthe“MODE”button(onthedevice)toswitchamong5modes:“CD”,“USB”,“SD”, “FM”,and“Bluetooth”. PowerOn/OffInstructions 1.PowerOn Keeppress“PowerON/OFF”buttonabout3stopowerontheCDPlayer,theCDPlayerwillplay theCDautomatically(theCompactDiskmustbeinsertedtotheCDPlayerbeforeturnon). 2.Poweroff Keeppress“PowerON/OFF”buttonagainabout3stoPowerofftheCDPlayer.Pleasedonot touchtheCompactDiskbeforeturnoffthedevice. CDModeInstructions PresstheCDbuttonontheremotetoswitchtoCDmodeorswitchthe“Mode”key(onthedevice) toCDmode,thentheCompactDiskwillrunautomatically CDCopy/TranscriptionModeInstructions 1.PresstheCopy/Transcriptionbuttonontheremote,itwillcopyCDmusicsintotheUSB/SD cardfromthecurrentmusictime,thebluelightwillflash. 2.PresstheCopy/Transcriptionbuttonagainontheremote,itwillendthecopy,theblue lightwillstayon. BluetoothModeInstructions 1.BT1mode 1).PressBluetoothbuttonontheremotetoswitchtoBT1modeorswitchthe“Mode"key(onthe device)totheBT1mode,andtheBluetoothiconwillappearonthescreen,thebluelightwill flash. 2).ActivatetheBluetoothinyourmobilephone. 3).Choosethenamed“CD”deviceinyourmobilephoneBluetoothdevicelisttopair. 4).Yourmobilephonewillbepaired/connectedtotheCDPlayerinafewseconds,andtheblue lightwillstayon. 5).PlayingmusiconyourmobilephoneandtheaudiowillbetransmittedtotheCDPlayer speakerthroughBluetooth. 2.BT2mode 1).WhenstayonBT1mode,pressBluetoothbuttonagainontheremotetoswitchtoBT2modeor keeppressthe“Play/Pause”key(onthedevice)about3stotheBT2mode,thentheCDPlayer willbereadytopairotherBluetoothdevicessuchasbluetoothspeaker,bluetoothearphone etc.,thebluelightwillflash. 2).ActivatetheBluetoothdevicessuchasbluetoothspeaker,bluetoothearphoneetc.,andit will automaticallysearchnearbyBluetoothdevicestopair. 3).TheCDplayerwillbeconnectedtothebluetoothdeviceinafewseconds,itwill automaticallyentertheCDmode,theCDmusicswillbetransmittedtothebluetoothdevice throughBluetooth,andthebluelightwillstayon. 4).UndertheBT2mode,youcanswitchtoCD/USB/SD/FM/AUX/BT2mode,thentheaudiowill betransmittedtothebluetoothdevicethroughBluetooth. 5).WhenswitchtoBT2mode,youcanswitchbacktoBT1modebypressBluetoothbuttonagainon theremoteorkeeppressthe“Play/Pause”key(onthedevice)about3s Note:Ifthebluetoothdeviceisoff,youwanttoconnecttootherbluetoothdevice,first youneedswitchbacktoBT1mode,thenswitchtoBT2modeagain,willautomaticallysearch otherBluetoothdevicestopair. FMModeInstructions 1.PressFM/SHbuttonontheremotetoswitchtoFMmodeorswitchthe“Mode"key(onthedevice) totheFMmode. 2.ThentheCDPlayerwillplaythepresetradiostation,the"FM"iconwillappearonthe screen. 3.PressFM/SHbuttonagainorKeepthe“Play/Pause”button(onthedevice)about3stosearch allradiostationsanditwillautomaticallystorethefirst40stationsifthereare suchenoughstationsaround;Aftercompletedthesearching,itwillplaythefirststation. 4.Press<Prev>or<Next>buttontogotopreviousstationpre-storedornextstationpre-stored;or pressdigitalkeystochangetoacertainstationpre-stored. USBModeInstructions 1.PluginaU-disktotheCDPlayerUSBport. 2.PressUSBbuttonontheremotetoswitchtoUSBmodeorswitchthe“Mode”key(onthedevice) totheUSBmode. 3.TheCDPlayerwillreadandplaythemusicintheU-disk,the"USB"iconwillappearonthe screen. MicroSDModeInstructions 1.InsertaMicroSDcardtotheMicroSDcardslot. 2.PressSDbuttonontheremotetoswitchtoMicroSDmodeorswitchthe“Mode”Key(onthe device)totheMicroSDmode. 3.TheCDPlayerwillreadandplaythemusicintheSDcard,the“SD”iconwillappearonthe screen. RepeatFunction Presstherepeatbuttonontheremotetocyclebetweenplaybackmodes,availableplaybackmodes are:"RepeatOne",“RepeatALL”or“Shuffleplay”,and”Normalplay”,willappear“ONE”, “ALL”,“SFL”and“OFF”onthescreen. . Diaphragm LEDDisplay Speaker PowerON/OFF Mode V o l — V o l + N e x t P r e v Play/Pause FMSearch BT1/BT2Switch USB2.0Port TYPE-C Charging Port AUXPort SDCardSlot Indicator A-B Repeat Function The A-B Repeat function enables playback to a specific section repeatedly by setting the start point(A) and end point(B) for the section. 1. Press A-B button on the remote to set the start point(A) while playing, and will appear the"A"on the screen. 2. Press A-B button on the remote to set the end point(B) while playing, and will appear the"B"on the screen. 3. Then the specified section from A to B will be played back repeatedly. 4. Press A-B button again to exit AB repeat, and will appear the “OFF”on the screen. 5. Note: A-B Repeat function only works on CD,USB and Micro SD mode AUX Mode 1. Connect the CD Player to other Audio player devices with the 3.5mmmale-to-male audio cable. 2. Press AUX button on the remote to switch to AUX IN mode or switch the“Mode”key(on the device) to the AUX IN mode, then the audio will be transmitted to the CD Player speaker, and will appe…

Text truncated - open the document above for the full version.

FocusIndustrial(HongKong)DevelopmentCO.,LIMITED Modeldifferences We: FocusIndustrial(HongKong)DevelopmentCO.,LIMITEDStatementthatAllthemodel “ FCD-W100, FCD-W200,FCD-W300,EA10,EA30,EA100,EA300,EANEWTRO,EA-RETRO,KC-808,KC-809, KC-606,KC-909 ” areidenticalexceptmodelname. AllabovemodelsareidenticalinthesamePCBlayout,interiorstructureandelectricalcircuits. Theonlydifferenceismodelnameforcommercialpurpose. CityandCountry:Date:Name: (thismustbeaperson) Function:Signature: (orofficialcompanystamp) HongKong2023.04.07TonyhuManager

1/1 USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:HiroInc. FRN:0024166175 ContactName:RichardChi Address:1361712thSt.UnitC,Chino,CA91710 Telephone:(909)902-1758 Email:[email protected] Applicant: Companyname:FocusIndustrial(HongKong)DevelopmentCO.,LIMITED ProductDescription:portablebluetoothCDplayer Granteecode:2AL7F FCCID:2AL7FFCD-W100 ContactName:Tonyhu Address:Room803,ChevalierHouse,45-51ChathamRoadSouth,TsimShaTsui,Kowloon, HongKong TelephoneNo:13923806817 Email:[email protected] Date:2023/04/1 [Focus Industrial (HongKong) Development CO.,LIMITED] certifies that, as of the date of this filing of the application with the TCB, [Hiro Inc.] is our designated US agent for service of process for the above referenced FCC ID. [Focus Industrial (HongKong) Development CO.,LIMITED] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [Hiro Inc.] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Processis aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. 1 Applicant’sName:FocusIndustrial (HongKong)DevelopmentCO.,LIMITED USAgent’sName:HiroInc. Title:ManagerTitle:CEO SignatureSignature

C5266091_X24_Ed.1 1/1 “AttestationStatements” TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 TheCommissionadoptedrulesthatprohibitequipmentauthorizationfor“covered” telecommunicationsequipmentandvideosurveillanceequipmentproducedbyentitiesidentified ontheCommission’sCoveredList 1 ,whichisperiodicallyupdated.SeetheCoveredListformore details.ThisAttestationStatementistoconfirmthatwefollowtheSection2.911(d)(5)(i)-(ii) Applicant Companyname:FocusIndustrial(HongKong)DevelopmentCO.,LIMITED Granteecode:2AL7F FCCID:2AL7FFCD-W100 ContactName:Tonyhu Address:Room803,ChevalierHouse,45-51ChathamRoadSouth,TsimShaTsui,Kowloon, HongKong TelephoneNo:13923806817 Email:[email protected] i.[FocusIndustrial(HongKong)DevelopmentCO.,LIMITED](“theapplicant”) certifiesthattheequipmentforwhichauthorizationissoughtisnot“covered” equipmentprohibitedfromreceivinganequipmentauthorizationpursuantto section2.903oftheFCCrules.Theapplicantmustsignthiscertification. ii.[FocusIndustrial(HongKong)DevelopmentCO.,LIMITED](“theapplicant”) certifiesthat,asofthedateofthefilingoftheapplication,theapplicant[is not]identifiedontheCoveredListasanentityproducing“covered” equipment.Theapplicantmustsignthiscertification. Date:2023/04/07 Applicant’sName:FocusIndustrial(HongKong)DevelopmentCO.,LIMITED Title:Manager Signature 1 TheCommission’sCoveredListispublishedbythePublicSafetyandHomelandSecurityBureauandpostedonthe Commission’swebsite.ThisCoveredList,whichisperiodicallyupdated,identifiesparticularequipment,producedby particularentities,thatconstitutes“covered”equipment.https://www.fcc.gov/supplychain/coveredlist

C5266091_X8_Ed.1 1/1 LetterofAuthorization <FocusIndustrial(HongKong)DevelopmentCO.,LIMITED> Company:FocusIndustrial(HongKong)DevelopmentCO.,LIMITED Address:Room803,ChevalierHouse,45-51ChathamRoadSouth, TsimShaTsui,Kowloon,HongKong ProductName:portablebluetoothCDplayer ModelNumber:FCD-W100,FCD-W200,FCD-W300,EA10,EA30, EA100,EA300,EANEWTRO,EA-RETRO,KC-808,KC-809,KC-606,KC- 909 FCCIdentifier:2AL7FFCD-W100 WeauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdelCarme,s/n, 08193Bellaterra,Spain,toactonourbehalfonallmattersconcerningthe abovenamedequipment. AnyindividualwithinLGAITechnologicalCenterS.A.isauthorizedtoactonour behalfandtakeactionontheapplication. WedeclarethatauthorizeLGAITechnologicalCenterS.A.,RondadelaFontdel Carme,s/n,08193Bellaterra,Spain,isallowedtoforwardallinformation relatedtotheapprovalprojecttotheFederalCommunicationCommissionand todiscussanyissuesconcerningtheapprovalapplication.Anyandallacts carriedoutbyLGAITechnologicalCenterS.A.onourbehalfshallhavethe sameeffectasactsofourown. Name:Tonyhu Date:2023-04-07 Title:manager Signatureofapplicant:

C5266091_X10_Ed.2 1/1 FocusIndustrial(HongKong)DevelopmentCO.,LIMITED OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 Date:2023-04-07 Subject:RequestforConfidentiality FCCID:2AL7FFCD-W100 ToWhomItMayConcern, PursuanttotheprovisionsofSections0.457and0.459ofCommission'srules (47CFR0.457,0.459),wearerequestingtheCommissiontowithholdthefollowing attachment(s)asconfidentialdocumentfrompublicdisclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality NOTE2 IDLabel/LocationNoNo AttestationStatementNoNo ExternalPhotosNo ☐ BlockDiagram ☒☐ Schematics ☒☐ TestReportNoNo TestSetupPhotosNo ☐ User’sManual ☐ NOTE 1 ☒ InternalPhotos ☐ NOTE 1 ☒ PartsList/TuneUp ☐☐ RFExposureInfoNoNo OperationalDescription ☒☐ CoverLetter(s)NoNo SDRSoftware/SecurityInfo ☐ No NOTE1:Long-TermConfidentialitymaybepermittedunderspecialconditions(SeeII.LONG-TERMCONFIDENTIALITY,Section3of KDB726920,uselastinforce) NOTE2:Short-TermConfidentialitycanberequestedforamaximumof180daysfromthedateofthegrant. Abovementioneddocumentcontainsdetailedsystemandequipmentdescriptionare consideredasproprietaryinformationinoperationoftheequipment.Thepublic disclosureofabovedocumentsmightbeharmfultoourcompanyandwouldgive competitoranunfairadvantageinthemarket. Incaseofshort-termConfidentiality,theapplicantrequeststheexhibitsselected abovearewithheldfrompublicviewforaperiodof____180__daysfromthedateof theGrantofEquipmentAuthorizationandpriortomarketing. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondentduringcertificationreviewprocesscannotbegrantedasconfidential documentsandthoseinformationwillbeavailableforpublicreviewoncethegrantof equipmentauthorizationisissued. Sincerely, Signature: Name:Tonyhu Title:Manager

FCCID:2AL7FFCD-W100

FCCIDLABELINGANDLOCATION FCCIDLabel FCCIDLabelLocation Thelabelshownshallbepermanentlyaffixedataconspicuouslocationonthedeviceandbe readilyvisibletotheuseratthetimepurchase(Labelingrequirementsper2.925) portablebluetoothCDplayer FCCID:2AL7FFCD-W100

FCCID:2AL7FFCD-W100 PCBAntenna

FCCID:2AL7FFCD-W100 RFExposureEvaluation Limits Thecriterialistedinthefollowingtableshallbeusedtoevaluatetheenvironmentimpactofhumanexposure toradiofrequency(RF)radiationasspecifiedin1.1307(b) LimitsforMaximumPermissibleExposure(MPE) Frequencyrange (MHz) Electricfield strength (V/m) Magneticfieldstrength (A/m) Powerdensity (mW/cm 2 ) Averagingtime (minutes) (A)LimitsforOccupational/ControlledExposures 0.3–3.06141.63*(100)6 3.0–301842/f4.89/f*(900/f 2 )6 30–30061.40.1631.06 300–1500f/3006 1500–100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure 0.3–1.346141.63*(100)30 1.34–30824/f2.19/f*(180/f 2 )30 30–30027.50.0730.230 300–1500f/150030 1500–100,0001.030 f=frequencyinMHz Friistransmissionformula:Pd=(Pout*G)/(4*pi*r 2 ) Where Pd=powerdensityinmW/cm 2 ,Pout=outputpowertoantennainmW; G=gainofantennainlinearscale,Pi=3.1416; R=distancebetweenobservationpointandcenteroftheradiatorincm PdidthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainoftheantennaandthetotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancerwheretheMPElimitisreached. TestProcedure SoftwareprovidedbyclientenabledtheEUTtotransmitandreceivedataatlowest,middleandhighest channelindividually. TestResultofRFExposureEvaluation BluetoothBR+EDR Channel Frequen cy (MHz) Outputpower toantenna (dBm) Outputpowerto antenna(mW) PowerDensityat R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 24020.1491.030.00021.0PASS 24410.6641.170.00021.0PASS 24800.9101.230.00021.0PASS Π/4DQPSK 24020.2081.050.00021.0PASS 24410.8151.210.00021.0PASS 24800.8801.220.00021.0PASS 8DPSK 24020.1951.050.00021.0PASS 24410.6611.160.00021.0PASS 24800.8451.210.00021.0PASS Remark:antennagain=-0.58dBi
