2AL8AQMA340KTRoom Unit with 2.4GHz Thread

Room Unit, KNX IoT/Thread QMA340KT Room Unit, KNX IoT/Thread ● Wireless communication KNX IoT via Thread ● Measurement accuracy: Up to ±0.5 °C and ±2.5 % r.h. ● LED display resolution × pixels ● Integrated temperature sensor ● Easy mounting (wall, flush and tape mounting) ● COV functionality ● Up to10 years battery lifetime ● Dimensions: 88 × 120.8 × 16 mm A6V15019166_en--_aSmart Infrastructure 2025-10-24 2 SiemensA6V15019166_en--_a Smart Infrastructure2025-10-24 Use The Wireless Room Unit QMA340KT measures the following values in buildings: ● Temperature ● Relative humidity The Wireless Room Unit is commonly used in various application types, including: ● Office buildings ● Educational buildings ● Public buildings The room unit exchanges data with controllers, room devices and tools via wireless communication KNX IoT over Thread. Functions Temperature measurement The room unit measures temperature using a digital temperature and humidity sensor. Relative humidity measurement The room unit measures relative humidity using a digital temperature and humidity sensor. Indoor air quality indication The room unit indicates CO 2 levels using a traffic light LED: Green (ok), orange (fair), red (bad). Low-power operation With advanced algorithms and parameters, the room unit reduces measurement and communication frequency, achieving long sleep cycles and a battery life of upto 10 years. Firmware update The device supports over-the-air (OTA) firmware update. The device can be updated to the latest firmware version during commissioning. Smart linking The device supports smart linking, which allows for the automatic linking of group objects through a simple drag-and-drop action on smart linking channels. Cybersecurity Implements end-to-end encryption and authentication for all KNX IoT communications. All telegrams are digitally signed and encrypted, ensuring data integrity and confidentiality. Security mechanisms apply to both ETS-based commissioning and runtime communication between devices and visualizations. Mechanical design The Wireless Room Unit is designed for wall, flush, and tape mounting. It is compatible with most standard recessed conduit boxes available on the market. The device consists of two parts: ● Front part including electronics ● Mounting plate 3 SiemensA6V15019166_en--_a Smart Infrastructure2025-10-24 Type summary Product No.Stock No. Temperature measuring range Humidity measuring range BatteriesOutput signal QMA340KT S55627-H101 0...50 °C 5...95 %4 × 1.5 V AAA alkaline KNX IoT via Thread Delivery When ordering, specify name and product number, e.g.: Wireless Room Unit QMA340KT. Packaging content NameQuantity Wireless Room Unit1 Mounting plate1 Mounting instructions1 Mounting tape1 Set of screws and dowels1 Batteries4 x 1.5 V AAA alkaline batteries Equipment combinations Device typeProduct No.Stock No. KNX IoT RouterOCT200.KNRS55812-Y107 Thread Border RouterOCT110.BRS55812-Y103 Wireless Room SensorQAA2890/WI QFA2890/WI QPA2892/WI S55720-S550 S55720-S551 S55720-S552 Product documentation TitleDocument ID Basic documentationA6V15045993 Mounting instructionsA6V14784215 Planning and installation guideA6V14476178 System limitsA6V14455022 Environmental product declarationA5W0xxA 4 SiemensA6V15019166_en--_a Smart Infrastructure2025-10-24 TitleDocument ID CE declaration of conformityA5W0xxA UKCA declaration of conformityA5W0xxA RCM declaration of conformityA5W0xxA Related documents such as the environmental declarations, declarations of conformity, etc., can be downloaded from the following Internet address: www.siemens.com/bt/download Notes Safety CAUTION National safety regulations Failure to comply with national safety regulations may result in personal injury and property damage. ● Observe national regulations and comply with the appropriate safety regulations. WARNING Explosion due to fire or short circuits, even with discharged batteries Risk of injury due to flying parts ● Prevent the batteries from coming in contact with water. ● Do not recharge batteries. ● Do not damage or disassemble batteries. ● Do not heat batteries over 85 °C. ● Do not make batteries short-circuit. WARNING Risk of explosion Personal injury and property damage ● Install the battery at the correct polarity (+/-) using the illustration in the battery compartment. ● Install only the correct battery types according to the indication in the battery compartment. ● In case of a leakage, avoid contact with skin, eyes and mucous membranes. ● Remove leaking batteries from the battery compartment with a cloth. Observe the following: ● The batteries must be new and undamaged. ● Do not mix new and used batteries. ● Store, transport and dispose of the batteries in compliance with local requirements, regulations and laws and observe the instructions of the battery manufacturer. 5 SiemensA6V15019166_en--_a Smart Infrastructure2025-10-24 NOTICE Radio frequency energy Interference to radio communications ● Install and use equipment in accordance with the installation guide. ● Read all regulatory compliance information. Mounting Location ● The device is designed for wall mounting, flush mounting and tape mounting. ● Install in indoor environments (device is not suitable for outdoor use); do not install in recesses, behind curtains, above or close to heat sources or shelves and not on walls where a chimney is located. Do not expose the unit to spotlights or direct sunlight. ● Do not install the device in a cabinet or metal container. ● Install the sensor in the occupied space about 1.5 m above the floor, at least 20 cm from the next wall. ● Seal the end of the conduit at the sensor to prevent false measurements caused by draughts through the conduit. NOTICE See Mounting instructions (A6V14784215) for detailed instructions on how to mount the device. The humidity sensor is a sensitive measuring device and must be handled with care. Chemical vapors at high concentrations in combination with long exposure times may distort the s…

Text truncated - open the document above for the full version.

Siemens Smart Infrastructure A5W02969041A_AA A6V14784215_----_a 2025-09-22 1/3 Masse in mm Dimensions in mm Dimensions en mm Mått i mm Afmetingen in mm Dimensioni in mm Mitat mm Dimensiones en mm Mål I mm mm cinsinden ölçüler Wall mounting de Montageanleitung it Istruzioni di montaggio All documentation QMA340KT en Mounting instructions fi Asennusohje fr Instructions de montage es Instrucciones de montaje sv Monteringsinstruktion da Monteringsvejledning nl Montage-aanwijzing tr Montaj talimatları A5W02969041A 2/3 2025-09-22 A6V14784215_----_a A5W02969041A_AA Siemens Smart Infrastructure Flush mounting Tape mounting de Auf einer sauberen, trockenen, flachen und glatten Oberfläche montieren en Mount on clean, dry, flat and smooth surface fr A monter sur une surface propre, sèche, plane et lisse sv Monteras på en ren, torr, plan och slät yta nl Op een schoon, droog, vlak en glad oppervlak installeren it Montare su una superficie pulita, asciutta, piana e liscia fi Asenna puhtaalle, kuivalle, tasaiselle ja sileälle pinnalle es Montar en superficie limpia, seca, plana y lisa da Monteres på en ren, tør, flad og glat overflade tr ? OSS Software Declaration Embedded in this product are free software files that you may copy, distribute and/or modify under the terms of their respective licenses, such as the GNU General Public License, the GNU Lesser General Public License. In the event of conflicts between Siemens license conditions and the Open Source Software license conditions, the Open Source Software conditions shall prevail with respect to the Open Source Software portions of the software. On written request within three years from the date of product purchase and against payment of our expenses we will supply source code in line with the terms of the applicable license. For this, please contact us at: Siemens AG, Otto-Hahn-Ring 6, 81739 Muenchen, Germany Keyword: Open Source Request Generally, these embedded free software files are distributed in the hope that they will be useful, but WITHOUT ANY WARRANTY, without even implied warranty such as for MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE, and without liability for any Siemens entity other than as explicitly documented in your purchase contract. All open source software components used within the product (including their copyright holders and the license conditions) are contained on the web server, path ➞ [https://www.siemens.com/download?A6V14815466]. Issued by Siemens Switzerland Ltd Smart Infrastructure Global Headquarters Theilerstrasse 1a CH-6300 Zug Tel. +41 58 724 2424 www.siemens.com/buildingtechnologies © Siemens 2025 Technical specifications and availability subject to change without notice. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Siemens Switzerland Ltd. declares that the radio equipment type QMA340KT is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at https://www.siemens.com/download?A6V14801213. Siemens Smart Infrastructure A5W02969041A_AA A6V14784215_----_a 2025-09-22 3/3

Beijing Siemens Cerberus Electronics Ltd No.1 Fengzhi Donglu, Xibeiwang Haidian District, 100094 Beijing, P.R. China To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 11-04-2025 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2AL8AQMA340KT Beijing Siemens Cerberus Electronics Ltd certifies that, as of the date of the filing of the application, Siemens industry lnc. is our designated U.S. agent for service of process for the above referenced FCC ID. Beijing Siemens Cerberus Electronics Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Siemens industry lnc. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: FRN: 0037591351 Name: Siemens industry lnc Address: 1000 Deerfield Parkway Bufflao Grove, IL 60089 United States Contact Person: John Currie Tel.: 847-848-6027 Email: [email protected] Sincerely, [Insert U.S. agent company name] Siemens industry lnc (U.S. agent company name printed name) John Currie (U.S. agent company name signature) [Insert applicant name] Beijing Sicmens Cerberus Electronics Ltd. (Applicant printed name) Yanming Li (Applicant signature)

Beijing Siemens Cerberus Electronics Ltd No.1 Fengzhi Donglu, Xibeiwang Haidian District, 100094 Beijing, P.R. China Date: 11-14-2025 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: 2AL8AQMA340KT Dear Sir or Madam, Beijing Siemens Cerberus Electronics Ltd.certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, Beijing Siemens Cerberus Electronics Ltd.certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List ( as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment . If you have any questions, please contact us. Sincerely, Contact name: Yanming Li Company name: Beijing Sicmens Cerberus Electronics Ltd. Address: No.1 Fengzhi Donglu, Xibeiwang Haidian District, 100094 Beijing, P.R. China E-mail: [email protected] Tel: 8613810094145

Beijing Siemens Cerberus Electronics Ltd No.1 Fengzhi Donglu, Xibeiwang Haidian District, 100094 Beijing, P.R. China Declaration letter Data: 2025-11-14 Subject: Statement of disabled RF chip EFR32MG24 function by software FCC ID: 2AL8AQMA340KT IC: 22795-QMA340KT We Beijing Siemens Cerberus Electronics Ltd (Address: No.1 Fengzhi Donglu, Xibeiwang Haidian District, 100094 Beijing, P.R. China) hereby declare that although the RF chip EFR32MG24 can support different Modulation (GFSK:BLE and O-QPSK:Thread), Our product is only locked to operate at a frequency and Modulation of 2450MHz~2480MHz/ O-QPSK by software. This setting is not accessible and can’t active by the user or any other third-party. If you have any questions, please contact us. Sincerely, Contact name: Yanming Li Company name: Beijing Sicmens Cerberus Electronics Ltd. Address: No.1 Fengzhi Donglu, Xibeiwang Haidian District, 100094 Beijing, P.R. China E-mail: [email protected] Tel: 8613810094145

External Photos Documentation Applicant: Beijing Siemens Cerberus Electronics Ltd Page 1 of 3 Product: Room Unit FCC ID: 2AL8AQMA340KT IC: 22795-QMA340KT External Photos Documentation Applicant: Beijing Siemens Cerberus Electronics Ltd Page 2 of 3 Product: Room Unit FCC ID: 2AL8AQMA340KT IC: 22795-QMA340KT External Photos Documentation Applicant: Beijing Siemens Cerberus Electronics Ltd Page 3 of 3 Product: Room Unit FCC ID: 2AL8AQMA340KT IC: 22795-QMA340KT

1 c b a 1234 2 b a c Descri p tion Revisio n DIN A3 Document type Create d b y Approved by Date Template 8000051553-AE-006 Document number Revision state Revision Release status Page AA 001 01 WORKING Li.Linna 001 2025..10 10 Notes: 1. Font requirement: SIEMENS Logo: 11pt, reference height=2.7mm QMA340KT, S55627-H101: Siemens Sans black 7pt, reference height=1.7mm Others texts: Siemens Sans 6pt, reference height=1.5mm 2. YYYYMMDD S YYYY: Year, 4 digits; MM: Month, 2 digits; DD: Day, 2 digits; S: Product version(Mass product version refer to product survey Doc. ; Z for 0-series build; MS1, MS2... for MS build; ES 1,ES2... for ES build ) : SSN+ASN+S+YYYYMMDD3. DMC1(5X5mm) content1P31P2PFS16D 4. DMC2 (13x13mm) content: ASN+00FDXXXXXXXX+EUI:XXXXXXXXXXXXXXXX.P:XXXXXXXXXXXXXXXX.PA:XXXXXXXXXXXXXXXX31P41S3Z 1)41S00FDXXXXXXXX: S/N, 12-character hexadecimal KNX serial number. 2)3ZEUI:XXXXXXXXXXXXXXXX.P:XXXXXXXXXXXXXXXX.PA XXXXXXXXXXXXXXXX: EUI-64: IPv6 Network Identifier; joining device credential; P: PA: initial application password. EUI, P and PA field 16 characters. P and PA are composition of both: only capital letters and numbers (0-9 and A-Y) can be used, for the sake of readability, the letters I,O,Q,Z are not allowed to be used. 3)S/N, EUI, P and PA are read from software. r9C5. Color: PANTONE C G oolay 6. Laser marking must be clearly Laser marking content: QMA340KT Rear Cover Label A5W02936372A Initial release © Siemens Switzerland Ltd SI BP BSCE R&D MDI organization Laser marking content: s QAKTM 340 S55627-H101 T50 IP30 Country of Origin: China Siemens Switzerland Ltd, DC6.0V 40mA 4xLR03(AAA) YYYYMMDD S 30 S IoT2 CAN ICE-3(B)/NMB-3(B) FCC ID: 2AL8AQMA340KT + - + + + - - - CH-6300 Zug DMC1 DMC2 IC: 22795-QMA340KT Indoor use only s QAKTM 340 S55627-H101 T50 IP30 Country of Origin: China Siemens Switzerland Ltd, DC6.0V 40mA 4xLR03(AAA) YYYYMMDD S 30 S IoT2 CAN ICE-3(B)/NMB-3(B) FCC ID: 2AL8AQMA340KT + - + + + - - - CH-6300 Zug IC: 22795-QMA340KT Indoor use only

Prepared by: Wei Fangying Approved by: Xu Kai Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 MPE TEST REPORT Applicant Beijing Siemens Cerberus Electronics Ltd. FCC ID 2AL8AQMA340KT Product Room Unit Brand SIEMENS Model QMA340KT Report No. EFTA25090293-IE-03-M1 Issue Date December 8, 2025 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC 47 CFR Part 1 §1.1310, §2.1091. The test results show that the equipment tested can demonstrate the compliance with the requirements as documented in this report. MPE Test Report Report No.: EFTA25090293-IE-03-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 2 of 8 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. Table of Contents 1 Test Laboratory ................................................................................................................................. 3 1.1 Notes of the Test Report ............................................................................................................ 3 1.2 Test Facility ................................................................................................................................ 3 1.3 Testing Location......................................................................................................................... 3 1.4 Laboratory Environment ............................................................................................................ 3 2 Description of Equipment Under Test ............................................................................................... 4 3 Maximum Tune up and Antenna Gain .............................................................................................. 5 4 MPE Limit .......................................................................................................................................... 6 5 RF Exposure Evaluation Result ........................................................................................................ 7 ANNEX A: The EUT Appearance ............................................................................................................. 8 MPE Test Report Report No.: EFTA25090293-IE-03-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 3 of 8 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 1 Test Laboratory 1.1 Notes of the Test Report This report shall not be reproduced in full or partial, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. Measurement Uncertainties were not taken into account and are published for informational purposes only. This report is written to support regulatory compliance of the applicable standards stated above. 1.2 Test Facility FCC (Designation number: CN1179, Test Firm Registration Number: 446626) Eurofins TA Technology (Shanghai) Co., Ltd. has been listed on the US Federal Communications Commission list of test facilities recognized to perform measurements. 1.3 Testing Location Company: Eurofins TA Technology (Shanghai) Co., Ltd. Address: Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China City: Shanghai Post code: 201201 Country: P. R. China Contact: Xu Kai Telephone: +86-021-50791141/2/3 Fax: +86-021-50791141/2/3-8000 Website: https://www.eurofins.com/electrical-and-electronics E-mail: [email protected] 1.4 Laboratory Environment Temperature Min. = 18C, Max. = 25C Relative humidity Min. = 20%, Max. = 80% Ground system resistance < 0.5  Ambient noise is checked and found very low and in compliance with requirement of standards. Reflection of surrounding objects is minimized and in compliance with requirement of standards. MPE Test Report Report No.: EFTA25090293-IE-03-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 4 of 8 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 2 Description of Equipment Under Test Client Information Applicant Beijing Siemens Cerberus Electronics Ltd. Applicant address No.1 Fengzhi Donglu, Xibeiwang, Haidian District, 100094 Beijing, P. R. China Manufacturer Siemens Switzerland Ltd. Manufacturer address Theilerstrasse 1a, CH-6300 Zug, Switzerland General Technologies EUT Description Model QMA340KT Lab Internal SN EFTA25090293-IE-03/S01 Hardware Version A5W02932402-AB Software Version V00.00.04 Frequency Band TX (MHz) RX (MHz) 2.4G 2405 ~ 2480 2405 ~ 2480 Date of Testing September 23, 2025 ~ October 10, 2025 Date of Sample Received September 23, 2025 Note: 1. The EUT is sent from the applicant to Eurofins TA and the information of the EUT is declared by the applicant. 2. All indications of Pass/Fail in this report are opinions expressed by Eurofins TA Technology (Shanghai) Co., Ltd. based on interpretations and/or observations of test results. Measurement Uncertainties were not taken into account and are published for informational purposes only. MPE Test Report Report No.: EFTA25090293-IE-03-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 5 of 8 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. 3 Maximum Tune up and Antenna Gain The numeric gain (G) of the antenna with a gain specified in dB is determined by Numeric gain (G)=10^(antenna gain/10) Band Maximum Tune up Tolerance Antenna Gain (dBi) Numeric Gain (dBm) (mW) 2.4G 8.00 6.31 2.60 1.82 MPE Test Report Report No.: EFTA25090293-IE-03-M1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-01-014S Page 6 of 8 This report shall not be …

Text truncated - open the document above for the full version.

Siemens QMA340KT PCB Antenna Measurement September 24 th , 2025 Project Information Customer: Siemens Project Name: QMA340KT Application: Temperature and humidity room unit Antenna Size:19.1*4.9(mm) 2.4GHz PCB antenna PCB Size:76.6*109.4(mm) Report date: 2025/09/24 Version: 1 PCB Measurement Data Sample measuring data AntennaQMA340KT PCB Antenna Frequency(MHz)240024452480 R.L. (dB)-19.293-21.693-17.643 Max. Gain (dBi)2.55962.59162.2881 Efficiency79.76%76.79%71.63% Measurement Configuration Radiation Pattern 2400- 2500MHz Frequency (MHz)240024012402240324042405240624082410241224142416241824202422242424262428243024322434243624382440244224442446244824502452245424562458246024622464246624682470247224742476247824802482248424862488249024922494249624982500 Ant. Port Input Pwr. (dBm)000000000000000000000000000000000000000000000000000000 Tot. Rad. Pwr. (dBm) - 0.98233 - 0.97682 - 0.98107 - 0.97934 - 0.96197 - 0.94593 - 0.93624 - 0.92989 - 0.97078-0.9819 - 1.03683 - 0.97452 - 1.08809 - 1.12967 - 1.06626 - 1.15301 - 1.19781 - 1.18865 - 1.23145-1.3161 - 1.29418 - 1.28097 - 1.17958 - 1.25675 - 1.27959 - 1.14677 - 1.15123 - 1.10899 - 1.12197 - 1.11129 - 1.15303 - 1.13404 - 1.10933 - 1.09331 - 1.18876 - 1.30462-1.2243 - 1.25656 - 1.28005 - 1.36099 - 1.44167 - 1.45016 - 1.44523 - 1.44904-1.4655 - 1.52547 - 1.53912 - 1.42877 - 1.42028-1.4041 - 1.43541 - 1.45366 - 1.40316 - 1.36523 Peak EIRP (dBm)2.559622.582552.59742.575992.537972.527292.515052.504142.452042.486892.512132.476322.359582.334492.463562.423942.339062.343682.353112.321482.44012.497622.438362.431042.488182.591632.572062.51842.571612.598972.582062.593682.59442.544312.514972.48532.514472.44842.371832.351712.354522.340612.319132.288052.265372.247772.265232.303512.285162.287862.305392.366522.399672.41088 Directivity (dBi)3.541943.559373.578473.555333.499943.473233.451283.434033.422813.468783.548953.450843.447673.464163.529833.576963.536873.532333.584563.637573.734283.778583.617943.687793.767763.738413.723293.627393.693583.710253.735093.727723.703733.637623.703743.789923.738773.704973.651883.71273.796193.790773.764363.737093.730873.773233.804363.732283.705443.691953.74083.820183.802833.77611 Efficiency (dB) - 0.98233 - 0.97682 - 0.98107 - 0.97934 - 0.96197 - 0.94593 - 0.93624 - 0.92989 - 0.97078-0.9819 - 1.03683 - 0.97452 - 1.08809 - 1.12967 - 1.06626 - 1.15301 - 1.19781 - 1.18865 - 1.23145-1.3161 - 1.29418 - 1.28097 - 1.17958 - 1.25675 - 1.27959 - 1.14677 - 1.15123 - 1.10899 - 1.12197 - 1.11129 - 1.15303 - 1.13404 - 1.10933 - 1.09331 - 1.18876 - 1.30462-1.2243 - 1.25656 - 1.28005 - 1.36099 - 1.44167 - 1.45016 - 1.44523 - 1.44904-1.4655 - 1.52547 - 1.53912 - 1.42877 - 1.42028-1.4041 - 1.43541 - 1.45366 - 1.40316 - 1.36523 Efficiency (%)79.756779.85879.779879.811780.131480.427980.607680.725579.969179.764678.762179.900377.837977.096378.2376.682975.89676.056275.310473.856874.230474.456676.215374.872974.480376.793276.714577.464277.232977.423276.682677.018777.458177.744476.054374.052275.434674.876274.472473.097271.751871.611771.69371.630271.359370.380770.159771.965272.106172.375371.855471.554172.390973.0259 Gain (dBi)2.559622.582552.59742.575992.537972.527292.515052.504142.452042.486892.512132.476322.359582.334492.463562.423942.339062.343682.353112.321482.44012.497622.438362.431042.488182.591632.572062.51842.571612.598972.582062.593682.59442.544312.514972.48532.514472.44842.371832.351712.354522.340612.319132.288052.265372.247772.265232.303512.285162.287862.305392.366522.399672.41088 Total Po wer (d Bm ) -25 5 -20 -15 -10 -5 0 Y X Z Azim uth = 0.9 Elevation = 5.0 Roll = 0.8 Total Po wer (d Bm ) -25 5 -20 -15 -10 -5 0 Z Y X Azim uth = 0.0 Elevation = 0.0 Roll = -90.0 Total Po wer (d Bm ) -25 5 -20 -15 -10 -5 0 X Z Y Azim uth = -90.0 Elevation = -90.0 Roll = 90.0 Max Gain: 2.59897dBi @ 2452MHz

Prepared by: Xu Ying Approved by: Xu Kai Eurofins TA Technology (Shanghai) Co., Ltd. Building 3, No.145, Jintang Rd, Pudong Shanghai, P.R.China TEL: +86-021-50791141/2/3 FAX: +86-021-50791141/2/3-8000 RF TEST REPORT Applicant Beijing Siemens Cerberus Electronics Ltd. FCC ID 2AL8AQMA340KT Product Room Unit Brand SIEMENS Model QMA340KT Report No. EFTA25090293-IE-02-R1V1 Issue Date December 9, 2025 Eurofins TA Technology (Shanghai) Co., Ltd. tested the above equipment in accordance with the requirements in FCC CFR47 Part 15C (2025). The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. RF Test Report Report No.: EFTA25090293-IE-02-R1V1 Eurofins TA Technology (Shanghai) Co., Ltd. TA-MB-04-005R Page 2 of 43 This report shall not be reproduced except in full, without the written approval of Eurofins TA Technology (Shanghai) Co., Ltd. TABLE OF CONTENT 1. Test Laboratory ............................................................................................................................... 5 1.1. Notes of the Test Report ......................................................................................................... 5 1.2. Test Facility ............................................................................................................................. 5 1.3. Testing Location ...................................................................................................................... 5 2. General Description of Equipment Under Test ............................................................................... 6 2.1. Applicant and Manufacturer Information ................................................................................ 6 2.2. General Information ................................................................................................................ 6 3. Applied Standards ........................................................................................................................... 7 4. Test Configuration ........................................................................................................................... 8 5. Test Case ........................................................................................................................................ 9 5.1. Maximum output power .......................................................................................................... 9 5.2. 99% Bandwidth and 6dB Bandwidth .................................................................................... 10 5.3. Band Edge ............................................................................................................................ 11 5.4. Power Spectral Density ........................................................................................................ 12 5.5. Spurious RF Conducted Emissions ...................................................................................... 14 5.6. Unwanted Emission .............................................................................................................. 16 5.7. Conducted Emission ............................................................................................................. 23 6. Test Results .................................................................................................................................. 24 6.1. Maximum output power ........................................................................................................ 24 6.2. 99% Bandwidth and 6dB Bandwidth .................................................................................... 26 6.3. Band Edge ............................................................................................................................ 31 6.4. Power Spectral Density ........................................................................................................ 33 6.5. Spurious RF Conducted Emissions ...................................................................................... 36 6.6. Unwanted Emission .............................................................................................................. 39 6.7. Conducted Emission ............................................................................................................. 40 7. Main Test Instruments................................................................................................................... 41 8. The EUT Appearance ................................................................................................................... 42 9. Test Setup Photos ......................................................................................................................... 43 RF Tes…

Text truncated - open the document above for the full version.
