2ALCFXY-OT038Wireless Charging Stand

FCCID：2ALCFXY-OT038 1 x Wireless Charging Stand 1 x integrated Type-C charging cable 1 x Instruction Manual 1. 2. 3. 4. 5. • • Mobile Phone Stand Board LED Indicator Integrated Cable with Type C tip Wireless Charging Surface Magnetic Surface (remove the film before use) What’s included: Features: 2 Type-C Input: DC 5V/2A; 9V/1.5A Wireless Output: 5W/7.5W/10W 1 5 4 3 Wireless Charging Mobile phones and other electronic devices: Connect the Type-C tip(3) of the charging pad to a power source. indicator will glow BLUE&RED for 4 seconds then turn RED to indicate the wireless charger is in standby mode and ready to begin charging. LED Place the wireless charging supported mobile device on the wireless charging surface(4), LED will glow BLUE when device is charging. Phone will begin to charge automatically. Once fully charged remove the device. Note: When wireless charging, if the Led indicator flash BLUE the device is either NOT a wireless charging device or there is an object between the the device and charging surface interfering with the charging process. 1. • • • • ** Wireless Charging with Magnetic Surface: If your wireless charging compatible device contains magnets, it will attach to the magnetic surface(5) of the stand for better alignment to secure wireless charging. This item is also compatible with other items, the magnetic function just won’t work. 2. • • Instructions: WARNING-When using this product, basic precautions should always be followed: Read all the instructions before use. Never store or use this product in temperatures below 32°F(0°C) or above 115°F(45°C). • 1. 2. SAFETY PRECAUTIONS: Do not overcharge your phone. The unit may become hot under excessive use. Remove your phone once it is fully 3. 3. Phone Holder Function: • If your device contains magnets, it will attach to the surface to hold your device vertically or horizontally. • If your device does not contain magnets, you will need to pull out the stand board(1) to hold it. Do not expose the device to moisture. Do not use the device in excess of its output rating. Overload outputs above the Do not use the device if damaged or Do not disassemble the device. For professional. incorrect reassembly may or temperatures above 104°F may cause explosion. use only identical replacement parts to ensure product safety. Attachments on the back of your phone can impede the effectiveness of the wireless charger, and lead to overheating. Please remove any attachments from the phone before charging on this device, attachments can interfer with wireless charging and lead to over heating. The strong magnetic fields of neodymium magnets can damage items such as television, computer monitors, credit cards, bank cards, computers, diskettes and other data carriers, video tapes, mechanical watches, hearing aids, loud speakers and 5. 6. 7. 8. 9. 10. 11. charged. Never charge your phone for more than 7 hours at a time. 4. To reduce the risk of injury, close supervision is required when the product is used near children. 12. VCRs. Pace-makers may be damaged or switch to "Test Mode" in the presence of a strongmagnetic force, if a pace-maker or other electrical body implant is in use, keep a minimum of 3 feet distance. FCC Warning This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interferenceto radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. During the operation of device a distance of 15 cm surrounding the device and 20 cm above the top surface of the device must be respected.

CONFIDENTIALITYREQUEST forCertificationServiceinUSA FederalCommunicationCommission EquipmentAuthorizationDivision,ApplicationProcessingBranch 7435OaklandMillsRoad Columbia,MD21046 Date:<2021-7-8> PursuanttoParagraphs§0.457and0.459oftheCommission’sRules(47C.F.R.)and Section§552(b)(4)oftheFreedomofInformationAct,werequestsconfidentialityfor thefollowingproducts: FCCIDModelname 2ALCFXY-OT038XY-OT038 Fortheproductstatedabove,werequestthatthefollowinginformationbeheld confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term ConfidentialityDays ExternalPhotos InternalPhotos BlockDiagram Schematics TestSetupPhotos User’sManual PartsList TuneUp OperationalDescriptions Thelong-termconfidentialityexhibitscontainourtradesecretsandproprietary informationthatcouldbeofbenefittoourcompetitors. Theshort-termconfidentialityonthebasisofensuringthatbusinesssensitive informationremainsconfidentialuntiltheactualmarketingofournewdevice. Ifyouhaveanyquestions,pleasefeelfreetocontactmeattheaddressshownbelow. Sincerely, Name/Title： Sunnyzhang/N/A Company: DongguanXingYueElectronicco.,Ltd Address: #98LiWuSwanIndustrialDistrict,QiaoTouTown,DongGuan, GuangDong,China Phone: 0769-81022708 Fax: 0769-83345348 E-Mail: [email protected]

DongguanXingYueElectronicco.,Ltd #98LiWuSwanIndustrialDistrict,QiaoTouTown,DongGuan,GuangDong,China FederalCommunicationsCommission AuthorizationandEvaluationDivision EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MD21046 2021-7-8 Towhomitmayconcern: We,DongguanXingYueElectronicco.,Ltdtheundersigned,herebyauthorizeEurofinsProduct ServiceGmbHtoactonourbehalfinallmattersrelatingtoapplicationsforequipment authorizationFCCID:2ALCFXY-OT038includingthesigningofalldocumentsrelatedtothese matters. AnyandallactscarriedoutbyEurofinsProductServiceGmbHonourbehalfshallhavethesame effectasactsofourown. Wealsoherebycertifythatnopartytothisapplicationissubjecttoadenialofbenefits,including FCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseActof1988,21U.S.C.862. Sincerely, Name/Title： Sunnyzhang/N/A Company: DongguanXingYueElectronicco.,Ltd Address: #98LiWuSwanIndustrialDistrict,QiaoTouTown,DongGuan, GuangDong,China Phone: 0769-81022708 Fax: 0769-83345348 E-Mail: [email protected]

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALCFXY-OT038 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 3 1. EXTERIOR PHOTOGRAPHS Fig. 1 Fig. 2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALCFXY-OT038 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 3 Fig. 3 Fig. 4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALCFXY-OT038 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 3 Fig. 5 Fig. 6

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALCFXY-OT038 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 Label and Location Size: L3.5cm*W2.5cm Material: Tagboard Glue: adhesive sticker Font color: White Label color: Black Label Location Wireless Charging Stand Test Model: XY-OT038 FCC ID: 2ALCFXY-OT038

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALCFXY-OT038 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 1 1. INTERIOR PHOTOGRAPHS Fig. 1 Fig. 2 Coil Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALCFXY-OT038 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 2 Fig. 3 Fig. 4

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ALCFXY-OT038 ___________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 11 RF Exposure Evaluation Report 1. Product Information FCC ID: 2ALCFXY‐OT038 Product Name Wireless Charging Stand Model Number XY‐OT038 Power Supply Type-C Input: DC 5V/2A; 9V/1.5A Wireless Output: 5W/7.5W/10W Modulation Type Continuous Wave Frequency Range 110.0~205.0KHz Operation Frequency 125.0 KHz Antenna Type Coil Antenna Hardware version LN9705B‐224K Software version A5011‐E6E1 Accessories Wireless charging load Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type MobileDevice Serial number 210607135A‐1(Engineer sample) 210607135A‐2(Normal sample) 2. Evaluation Method Per KDB 680106 D01 Section 3. RF Exposure Requirements; 1) Consumer wireless power transfer devices approved under Part 18 in some cases have to demonstrate compliance with RF exposure requirements. The potential for exposure must be assessed according to the operating configurations of the wireless system and the exposure conditions of users and bystanders. RF exposure must be evaluated with the client device(s) being charged by the primary at maximum output power. The RF exposure requirements must be determined in conjunction with the device operating characteristics, according to the mobile and portable exposure requirements in Section 2.1091 and Section 2.1093 of the rules. SAR and MPE limits do not cover the frequency range for wireless power transfer applications which operate below 100 kHz and 300 kHz respectively; therefore, RF exposure compliance needs to be determined with respect to 1.1307 (c) and (d) of the FCC rules. 2) Based on the design and implementation of the power transfer application, it must be clearly identified if mobile or portable RF exposure conditions apply. Devices that are installed to provide separation of at least 20 cm from users and bystanders may qualify for mobile exposure conditions. For some conditions where users and bystanders may be exposed at closer than 20 cm, section 2.1091(d) (4) of the rules may apply. 3) For devices designed for typical desktop applications, such a wireless charging pads, RF exposure evaluation should be conducted assuming a user separation distance of 15 cm. E and H field strength measurements or numerical modeling may be used to demonstrate compliance. Measurements should be made from all sides and the top of the primary/client pair, with the 15 cm measured from the center of the probe(s) to the edge of the device. Emissions between 100 kHz to 300 kHz should be assessed versus the limits at 300 kHz in Table 1 of Section 1.1310: 614 V/m and 1.63 A/m. A KDB inquiry is required to determine the applicable exposure limits below 100 kHz. 4) Portable exposure conditions from 100 kHz to 6 GHz are determined with respect to SAR requirements. SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ALCFXY-OT038 ___________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 11 Existing SAR systems and test procedures are generally intended for measurements above 100 MHz. While numerical modeling can be an alternative, the constraints of substantial computational resources at low frequencies could introduce further limitations. Under these circumstances, including operations below 100 kHz, the Commission may consider a combination of analytical analysis, field strength, radiated and conducted power measurements, in conjunction with some limited numerical modeling to assess compliance. 5) Depending on the operating frequency, existing SAR and MPE measurement procedures may be adapted to evaluate wireless power transfer devices for compliance with respect to mobile or portable exposure conditions. If the grantee or its test lab have any questions regarding RF exposure evaluation they should contact the FCC Laboratory with sufficient system operating configuration details to determine if RF exposure evaluation is necessary and, if required, how to apply specific test procedures. Below 100 MHz, when SAR testing is required and the device is operating at close proximity to persons, information on device design, implementation, operating configurations, exposure conditions of users and bystanders are needed to determine the evaluation and testing requirements. In addition, the influence of nearby objects may also need consideration according to the wireless power transfer system implementation; for example, the effects of placing the device, its coils or radiating elements on or near metallic surfaces 3. Evaluation Limit 3.1 Refer evaluation method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 680106 D01 RF Exposure Wireless Charging Apps v03: RF Exposure Considerations for Low Power Consumer Wireless Power Transfer Applications FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices FCC CFR 47 part 18.107:Indusial, Scientific, and Medical Equipment 3.2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3‐3.0 614 1.63 *100 6 3.0‐30 1842/f 4.89/f *900/f 2 6 30‐300 61.4 0.163 1.0 6 300‐1,500 / / f/300 6 1,500‐100,000 / / 5 6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID:2ALCFXY-OT038 ___________________________________________________________________________ This report shall not be repr…
