2ALIJ-M2SComputer

Shenzhen Benton Technology Co., LTD
Computer - FCC ID 2ALIJ-M2S - Shenzhen Benton Technology Co., LTD
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Feb 19, 2024
Application Purpose
Original Equipment
Date of Application
Feb 19, 2024
Equipment Note
Computer
Frequency Range
2412.00000000 - 2462.00000000
Company
Shenzhen Benton Technology Co., LTD
Country
China

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗
↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Thank you for purchasing this product. You can enjoy one-year free space parts and manual service assurance provided by our company. The following conditions lead to the need for our company to provide services, and the maintenance fees will be charged as appropriate: .Failure to perform proper operations according to the user manual or instructions. .Man-made damage, computer viruses, dampness, improper software installation or self-disassembly, etc. .Fire, flood, wind, earthquake and other irresistible forces. .Abrasive wear caused by accessories, consumables and natural use. .If we need to re-install software or adjust computer setting on our behalf, we will charge fees as appropriate. .Our company provides warranty for the damaged or dirty logo which may result in un-recognizability.Please backup your personal data before sending the product to repair. Mini PC User Manual 1,HD Port 5, Fan outlet 2,USB3.2 6,Earphone 3,LAN 7,Safe Lock 4, Power Input 8,Power Button 1.Connect the device with the display device (such as TV, screen, projector, etc.) via HD line, and select the"video input source" of the display device to the connected HD input channel. 2. DC power supply: Connect the DC interface of the power cord of the accessories to the device and insert 3. Use the device by connecting it with a wired or wireless keyboard and mouse via USB port. 4. Press the power button to start the system. 1. Computer Box *1 2. User Manual *1 3. Power Adapter *1 4. HDMI Wire*1 1. This Low-power RF motor is a certified and qualified product. Companies, businesses or individuals mayNotenot change the frequency, enhance the power or change the characteristics and functions of the original2. Low-frequency RF motors should not affect flight safety and interface with legitimate communicationdesign without permission.when they are used. When interference is found, they should be stopped using immediately and beimproved to no interference before they can continue to be used. Legitimate communication refers towireless communication in the work prescribed by law. Low-frequency RF motor must be able totolerate the interference of legitimate communication or electromagnetic radiation motor equipmentfor industrial, scientific and medical purposes3. This product contains miniature batteries for mainboard CMOS, which can't be replaced by consumersthemselves. lt may be dangerous if consumer replace incorrect types of batteries by themselves. Please properly handle the battery replacement. 1. This product is suitable for places below 3000 meters above sea level, this product is only suitable fornon-tropical areas. 2. After abnormal withdrawal or accidental power failure of the mini pc system, the hard disk scanningshould be carried out as soon as possible to repair the errors in time. 3. If you do not use the device for a long time, Please unplug the power adapter 4. The ideal working temperature of the device is 10-35 degrees, and the relative humidity is 30-80%5. The device should not be turn on or off frequently. 6. Don't get water, food and other fluids onto the device, and don't pull the data and power lines with force. 7. Avoid direct exposure of strong light to the device, and do not put it near the strong magnetic field FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. Made in China

Attestation Statements

ShenzhenBentonTechnologyCo.,LTD 2.911(d)(5)(i)EquipmentTypeAttestationv1.2 Section2.911(d)(5)(i)Certification–EquipmentType Companyname:ShenzhenBentonTechnologyCo.,LTD Address:No.4factorybuilding,No.1EastBlock,No.101-501,FuyeRoad,Zhangkengjing community,GuanhuStreet,LonghuaDistrict,ShenzhenCityChina ProductName:Computer FCCID:2ALIJ-M2S Model(s):M2S,M1,M1S,M2,M2PRO,M3,M3S,M3PRO,M4,M4S,M4PRO,M5,M5S,M5PRO, X13,X14,X15,X16,X17,D14,D15,D16,D17,D18,E10,E11,E12,E13,E14 2.911(d)(5)(i)EquipmentType We,ShenzhenBentonTechnologyCo.,LTD(“theapplicant”)certifythattheequipmentforwhich authorizationissoughtthroughcertificationisnot:  Prohibitedfromreceivinganequipmentauthorizationpursuantto§2.903;oftheFCCrules.  Identifiedasanequipmenttypeinthe“CoveredList” NOTE1 Yourssincerely, Name:JeanSongDate:2024.1.29 TitleandCompanyname:N/A/ShenzhenBentonTechnologyCo.,LTD NOTE1 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

ShenzhenBentonTechnologyCo.,LTD 2.911(d)(5)(ii)ApplicantAttestationv1.3 Section2.911(d)(5)(ii)Certification–Applicant(CoveredList) Companyname:ShenzhenBentonTechnologyCo.,LTD Address:No.4factorybuilding,No.1EastBlock,No.101-501,FuyeRoad,Zhangkengjing community,GuanhuStreet,LonghuaDistrict,ShenzhenCityChina ProductName:Computer FCCID:2ALIJ-M2S Model(s):M2S,M1,M1S,M2,M2PRO,M3,M3S,M3PRO,M4,M4S,M4PRO,M5,M5S,M5PRO, X13,X14,X15,X16,X17,D14,D15,D16,D17,D18,E10,E11,E12,E13,E14 2.911(d)(5)(ii)Applicantfiling We,ShenzhenBentonTechnologyCo.,LTD(“theapplicant”)certifythat,asofthedateofthefilingof theapplication,theapplicantisnotidentified NOTE1 onthe“CoveredList” NOTE2 ,established pursuantto§1.50002ofthischapter,asanentityproducingcoveredcommunicationsequipment. Yourssincerely, Name:JeanSongDate:2024.1.29 TitleandCompanyname:N/A/ShenzhenBentonTechnologyCo.,LTD NOTE1 Deleteoptionnotapplicabletothisapplication. NOTE2 “CoveredList”;istheListofEquipmentandServicesCoveredBySection2ofTheSecureNetworksAct,availableat https://www.fcc.gov/supplychain/coveredlist References; 1)986446D01CoveredEquipmentv01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2)FederalRegisterdocument2022-28263publishedon02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

Attestation Statements

Shenzhen Benton Technology Co., Ltd 2.911 (d)(7)USA Agent v1.5 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Benton Technology Co., LTD Address: No. 4 factory building, No. 1 East Block, No.101-501, Fuye Road, Zhangkengjing community,Guanhu Street, Longhua District, Shenzhen City China Product Name:Computer FCCID:2ALIJ-M2S Model(s):M2S, M1, M1S, M2, M2PRO, M3, M3S, M3PRO, M4, M4S, M4PRO, M5, M5S, M5PRO, X13, X14, X15, X16, X17, D14, D15, D16, D17, D18, E10, E11, E12, E13, E14 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Benton Technology Co., LTD] (“the applicant”) designate [Stone Trading Limited] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either we the grantee have permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or at the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Stone Trading Limited USA Address: 6547 N Academy Blvd #2266, Colorado Springs, CO 80918, United States FRN Number: 0033401936 Contact Name: Dongmei Fang Telephone No: +12134573118 Email: [email protected] Applicant Company name: Shenzhen Benton Technology Co., LTD Address: No. 4 factory building, No. 1 East Block, No.101-501, Fuye Road, Zhangkengjing community,Guanhu Street, Longhua District, Shenzhen City China Grantee FRN Number: 0026354191 FCC Grantee Code: 2ALIJ Contact Name: Jean Song Sig n Title Dat NO T of pr Refe https al-se S nature: e: Manager e: 2024-01 - TE 1: An app rocess. erence; Federa s://www.fede ecurity-threa Shenzhe -22 plicant locate al Register do eralregister.g ats-to-the-com en Bento d in the Unite ocument 2022- gov/documen mmunication on Tech T E S T D ed States ma -28263 publish nts/2023/02/0 s-supply-cha hnology Telephone N Email: jean@ Signature: Title: N/A Date: 2024- ay designate hed on 02/06/ 06/2022-282 ain-through-t y Co., Lt 2.911 ( No: 0755-2 @benton-cn -01-22 e itself as the /23 263/protecting the td (d)(7)USA Agen 8471613 n.com agent for se g-against-na nt v1.5 rvice ation

Cover Letter(s)

ShenzhenBentonTechnologyCo.,LTD AgentAuthorization Company:ShenzhenBentonTechnologyCo.,LTD Address:No.4factorybuilding,No.1EastBlock,No.101-501,FuyeRoad, Zhangkengjingcommunity,GuanhuStreet,LonghuaDistrict,ShenzhenCityChina ProductName:Computer ModelNumber(s):M2S,M1,M1S,M2,M2PRO,M3,M3S,M3PRO,M4,M4S,M4PRO, M5,M5S,M5PRO,X13,X14,X15,X16,X17,D14,D15,D16,D17,D18,E10,E11,E12, E13,E14 ProductDescription:Computer WeauthorizeMiCOMLabsInc.,575BoulderCourt,Pleasanton,California94566,USA, toactonourbehalfonallmattersconcerningthecertificationofabovenamed equipment. WedeclarethatMiCOMLabsInc.isallowedtoforwardallinformationrelatedtothe approvalandcertificationofequipmenttotheregulatoryagenciesasrequiredandto discussanyissuesconcerningtheapprovalapplication.Anyandallactscarriedoutby MiCOMLabsonourbehalfshallhavethesameeffectasactsofourown. Signature:Date:2024.1.29 Name:JeanSong Title:N/A Company:ShenzhenBentonTechnologyCo.,LTD

Cover Letter(s)

Shenzhen Benton Technology Co., Ltd Model Difference Product description: Computer Model name: M2S, M1, M1S, M2, M2PRO, M3, M3S, M3PRO, M4, M4S, M4PRO, M5, M5S, M5PRO, X13, X14, X15, X16, X17, D14, D15, D16, D17, D18, E10, E11, E12, E13, E14 Trade Name: N/A FCC ID:2ALIJ-M2S Only the model name is different. Regards Sincerely Client’s signature: Client’s name / title: Jean Song / Manager Contact information / address: No. 4 factory building, No. 1 East Block, No.101-501, Fuye Road, Zhangkengjing community,Guanhu Street, Longhua District, Shenzhen City, China

External Photos

EUT PHOTO(External Photos)

ID Label/Location Info

Label & label location 20mm*10mm FCC ID:2ALIJ-M2S Label location

Internal Photos

EUT PHOTO(Internal Photos) ※※※※※ END OF REPORT ※※※※※ ANT1 WIFI 2.4G/5G ANT2 BT

RF Exposure Info

FCC ID:2ALIJ-M2S RF Exposure Evaluation Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. Test Result of RF Exposure Evaluation BLE Mode Mode Frequency (MHz) Output power to antenna (dBm) Output power to antenna (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 2402 2.835 1.92 3.30 0.00082 1.0 PASS BT Mode Mode Frequency (MHz) Output power to antenna (dBm) Output power to antenna (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result GFSK 2402 2.876 1.94 3.30 0.00082 1.0 PASS π/4-DQPSK 2402 4.697 2.95 3.30 0.00125 1.0 PASS 8-DPSK 2402 5.124 3.25 3.30 0.00138 1.0 PASS 2.4G WI-FI Mode Mode Frequency (MHz) Output power to antenna (dBm) Output power to antenna (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11b 2412 14.064 25.49 2.74 0.00953 1.0 PASS 802.11g 2412 12.596 18.18 2.74 0.00680 1.0 PASS 802.11n20 2412 11.846 15.30 2.74 0.00572 1.0 PASS 802.11n40 2422 10.886 12.26 2.74 0.00458 1.0 PASS 5.2G WI-FI Mode Mode Frequency (MHz) Output power to antenna (dBm) Output power to antenna (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 5240 12.156 16.43 4.35 0.00890 1.0 PASS 802.11n20 5240 11.662 14.66 4.35 0.00794 1.0 PASS 802.11n40 5230 10.199 10.47 4.35 0.00567 1.0 PASS 802.11ac20 5240 10.708 11.77 4.35 0.00638 1.0 PASS 802.11ac40 5190 11.500 14.13 4.35 0.00765 1.0 PASS 802.11ac80 5210 11.527 14.21 4.35 0.00770 1.0 PASS 5.8G WI-FI Mode Mode Frequency (MHz) Output power to antenna (dBm) Output power to antenna (mW) Antenna Gain (dBi) Power Density at R=20cm (mW/cm 2 ) Limit (mW/cm 2 ) Result 802.11a 5785 13.438 22.07 4.43 0.01218 1.0 PASS 802.11n20 5785 12.431 17.50 4.43 0.00966 1.0 PASS 802.11n40 5795 12.958 19.76 4.43 0.01090 1.0 PASS 802.11ac20 5785 11.688 14.75 4.43 0.00814 1.0 PASS 802.11ac40 5755 12.455 17.60 4.43 0.00971 1.0 PASS 802.11ac80 5775 13.243 21.10 4.43 0.01164 1.0 PASS Remark: The same antenna cannot transmit at the same time, ANT1 & ANT2 can transmit atthe same time, So the worst simultaneous transmntting corsideration: The ratio = ANT1 MPE(MAX) / limit + ANT2 MPE(MAX) / limit = 0.00138 / 1.0 + 0.01218 / 1.0 = 0.01356 < 1.0.
