2ALN6400NG hub

New Generation Hub User Manual Version 1.01 1. General description Phytech hub is part of an advanced AG IoT platform for optimized Irrigation management. Firstly, the device receives Phytech Plant sensor measurements. Then, the hub organizes the data and then sends it to a Phytech datalogger. Finally, the data is sent to the Phytech cloud for analysis and processing. The outcome is a simple color scheme that aids the grower to decide online when and how much to irrigate. 2. Installation and operation 2.1 Hub Installation 2.1.1 Up to 20 hubs can connect to a single logger. 2.1.2 The maximum distance between the hub and the logger is 300 meters. 2.1.3 After logger is setup, set the hub near the middle tree of the project in between the trees in the row. 2.1.4 Mound the hub on a tree or in soil (Figure B). 2.1.5 Turn the hub switch ON and take a few steps back. The led sequence should be as follows: ● Fast blinking LED – acquiring logger. ● Stable LED – connected to logger. ● Slow blinking LED – hub is in sensor acquiring mode. For the next 1 hour, sensors can be connected to the hub. 2.2 Sensor installation 2.2.1 Up to 40 sensors can connect to a single Hub. The maximum distance between the sensors and the Hub is 80 m. 2.2.2 Sensor must be installed after the hub was successfully installed and while in sensor acquiring mode. 2.2.3 Install the sensor: ● Dendrometer (Figure C1) ‐ Push the calibration spacer device to set the right distance between the dendrometer piston tip and the tree trunk. Once the tip has been pushed the sensor LED will stark blinking, searching for a hub. Wait for the blinking to stop and the LED to become steady, an indication that the sensor has connected to the hub and the installation is successful. ● Fruit sensor (Figure C2) ‐ open the sensor's “claws” and place them on the desired fruit. The LED on the sensor will immediately start blinking when opening the fruit sensor. Wait for the blinking to stop and the LED to become steady, an indication that the sensor has connected to the hub and the installation is successful. 3. Received data The data received from the sensors reaches the server where it is analyzed. The analyzed data provides users plant status and irrigation recommendations via web and mobile apps (Figure D). 4. Product features 4.1 Hub ● 40 sensors per hub. ● Easy installation. 4.2 Sensor ● Easy mount. ● High resolution trunk/fruit measurements. ● Event triggered radio transmission. D 5. Interfaces 5.1 Hub ● ON/OFF switch. ● 1 indication LED. 5.2 Sensor ● Indication LED. 6. Radio ● UHF 433.9 MHz. ● FM modulation. ● 2.4 kbps. ● Custom antenna (logger, hub and sensors) This device complies with FCC Rules Part 15. Operation is subject to two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may be received or that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ‐Reorient or relocate the receiving antenna. ‐Increase the separation between the equipment and receiver. ‐Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ‐Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance (Phytech Ltd.) could void the user’s authority to operate the equipment. Professional installation is required due to the intended application of the system is exclusively for the commercial/industry use. WARNING: It is the responsibility of the installer to ensure that when using the outdoor antenna kits in the United States (or where FCC rules apply), only those antennas certified with the product are used. The use of any antenna other than those certified with the product is expressly forbidden in accordance with FCC rules CFR47 part 15.204." 7. Electrical 7.1 Hub ● input voltage: 2.7‐3.2 Volts (2X type C alkaline battery). 7.2 Sensor ● input voltage: 2.7‐3.2 Volts (2X AAA alkaline battery).

RF_160, Issue 04 Declaration of Authorization We Name: Phytech Ltd. Address: 23 Hamelacha street, Park Afek, Rosh Haayin 4809173 Country: Israel Declare that: Name Representative of agent: Mr. Michael Nikishin............. (1) Agent Company name: Hermon Laboratories Ltd. Address: Harakevet Industrial Zone City: Binyamina 30500 Country Israel is authorized to apply for Certification of the following product(s): Product description:  NG Hub Type designation:  NGH001 Trademark:  Phytech Ltd. Validity/ expiry date: March 7, 2023 on our behalf. Date: March 7, 2022 City: Rosh Haayin Name: Eitan Peleg (2) Function: CTO Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Phytech Ltd. FCC ID:2ALN6400 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Phytech Ltd. FCC ID:2ALN6400 Page 2 of 3 Photograph No.1 Hub front view Phytech Ltd. FCC ID:2ALN6400 Page 3 of 3 Photograph No.2 Hub rear side view

Phytech Ltd. FCC ID:2ALN6400 Page 1 of 2 Label Phytech Ltd. FCC ID:2ALN6400 Page 2 of 2 Label location Label with FCC ID:2ALN6400 is located at the front side of the logger..

Phytech Ltd. FCC ID:2ALN6400 Page 1 of 7 INTERNAL PHOTOGRAPHS This document contains 6 photographs Phytech Ltd. FCC ID:2ALN6400 Page 2 of 7 Photograph No.1 Hub internal view Phytech Ltd. FCC ID:2ALN6400 Page 3 of 7 Photograph No.2 Hub internal view with batteries removed Phytech Ltd. FCC ID:2ALN6400 Page 4 of 7 Photograph No.3 Hub PCB second side view Phytech Ltd. FCC ID:2ALN6400 Page 5 of 7 Photograph No.4 Hub PCB front side close view Phytech Ltd. FCC ID:2ALN6400 Page 6 of 7 Photograph No.5 Hub PCB second side close view Phytech Ltd. FCC ID:2ALN6400 Page 7 of 7 Photograph No.6 Antenna view Antenna

FCC ID:2ALN6400 New generation hub operational description General description Phytech hub is part of an advanced AG IoT platform for optimized Irrigation management. Firstly, the device receives Phytech Plant sensor measurements. Then, the hub organizes the data and then sends it to a Phytech datalogger. Finally, the data is sent to the Phytech cloud for analysis and processing. The outcome is a simple color scheme that aids the grower to decide online when and how much to irrigate. Received data The data received from the sensors reaches the server where it is analyzed. The analyzed data provides users plant status and irrigation recommendations via web and mobile apps Functional specification: Parameter Description Min Typ max Unit Power Power source 2xC Alkaline Bat Battery capacity 4000 mAH Discharge in one year storage 70 mAH Number of working months (after one year of storage) 40.1 months Operating voltage 2.6 3 3.2 volt GPS UBLOX IC GPS receiver MAX‐ M8C ‐0‐ 10 Antenna Gain ‐3 dBi Antenna Type CERAMIC PATCH ANTENNA AMOTEC Communication Rf range 400600 1000 m frequency 433.82 MHz Number of sensors per Hub 48 Memory historical data 300 hours Environment Enclosure ratings IP65 standard Ambient min/max temperature ‐40 85 C° FOTA FW over the air supports remote FW update Electrical specification: Parameter Symbol Description Min Typ max Unit Absolute Maximum Ratings Storage temperature range TSTG ‐55‐ 150 C° Main supply voltage VDDMAX ‐0.3‐ VDD+0V .3 General Operating Conditions Operating supply voltage VDDOP 1.8‐ 3.6 V Store current consumption 3.8 8.2 mA Nominal Supply Voltage VDD 2x Alkaline Battery AAA Size 2.63 3.2 V Power Supply Current IIdle Radio OFF 34 4.2 mA ISleep Sleep MCU&Radio 810 12.1 uA ITx Radio Tx 20dBm 6572 89.3 mA IRx Radio Rx 18.220.5 21 mA Isd Deep sleep 3.84.8 8.2 uA Radio specification: Type Direction Description Min Typ Max Unit UHF Tx freq 433.82 MHz Pout max 20 dBm Pout min 0 dBm power step 10 dB Freq Dev /+,‐ 2400 Hz Bit per sec 2400 Bit/Sec Rx BW (rx( 10000 Hz Nosie Floor ‐134 dBm NF 14 dB Receiver sensitivity ‐120 dBm Antenna Gain ‐3 dBi Antenna Type Omni PCB Data Transmission package length 118 64 Byte Package length 43.33100 253.33 ms

Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Tel. +972 4628 8001 Fax. +972 4628 8277 E-mail: [email protected] Page 1 of 41 Report ID: PHYRAD_FCC.43942.docx Date of Issue: 30-Mar-22 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC CFR 47 Part 15 subpart C, section 15.231 and subpart B; RSS-210 issue 10 Annex A, ICES-003 Issue 7:2020 FOR: Phytech Ltd. NG Hub Model: NGH001 FCC ID:2ALN6400 This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: PHYRAD_FCC.43942.docx Date of Issue: 30-Mar-22 Page 2 of 41 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 EUT test configuration ................................................................................................................................................... 5 6.3 Changes made in EUT .................................................................................................................................................. 5 6.4 Transmitter characteristics ............................................................................................................................................ 6 7 Transmitter tests according to 47CFR part 15 subpart C requirements ........................................................................ 7 7.1 Periodic operation requirements ................................................................................................................................... 7 7.2 Field strength of emissions .......................................................................................................................................... 11 7.3 Occupied bandwidth test ............................................................................................................................................. 22 7.4 Antenna requirements ................................................................................................................................................. 25 8 Emissions tests according to 47CFR part 15 subpart B and ICES-003 requirements ................................................. 26 8.1 Radiated emission measurements .............................................................................................................................. 26 9 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 32 10 APPENDIX B Measurement uncertainties ................................................................................................................... 33 11 APPENDIX C Test laboratory description ................................................................................................................... 34 12 APPENDIX D Specification references ....................................................................................................................... 34 13 APPENDIX E Test equipment correction factors ......................................................................................................... 35 14 APPENDIX F Abbreviations and acronyms ................................................................................................................. 41 Report ID: PHYRAD_FCC.43942.docx Date of Issue: 30-Mar-22 Page 3 of 41 1 Applicant information Client name: Phytech Ltd. Address: 23 HaMelacha street, Park Afek, Rosh Haayin 4809900, Israel Telephone: +972 3947 8050 Fax: +972 3947 8010 E-mail: [email protected] Contact name: Mr. Eitan Peleg 2 Equipment under test attributes Product name: NG Hub Product type: Transceiver Model(s): NGH001 Serial number: 101 Hardware version: WBRD400 Software release: H.3.22.3 Receipt date 17-Oct-21 3 Manufacturer information Manufacturer name: Phytech Ltd. Address: 23 HaMelacha street, Park Afek, Rosh Haayin 4809900, Israel Telephone: +972 3947 8050 Fax: +972 3947 8010 E-Mail: [email protected] Contact name: Mr. Eitan Peleg 4 Test details Project ID: 43942 Location: Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Test started: 17-Oct-21 Test completed: 18-Oct-21 Test specification(s): FCC 47CFR part 15, subpart C, §15.231 and subpart B RSS-210 Annex 1, ICES-003 Issue 7: 2020 Report ID: PHYRAD_FCC.43942.docx Date of Issue: 30-Mar-22 Page 4 of 41 5 Tests summary Test Status Transmitter characteristics FCC Part 15, Section 231(a) / RSS-210, Section A1.1, Periodic operation requirements Pass FCC Part 15, Section 231(a) / RSS-210, Section A1.2, Field strength of emi…
