2ALP8AP1Battery Pack

1 www.stihl.com © ANDREAS STIHL AG & Co. KG, 2020 AP 500 S EA01 400 XXXX ANDREAS STIHL AG & Co. KG, 71336 Waiblingen / GERMANY Get the STIHL connected App 2 41 3 REGISTER SIGN IN UG SAVE THESE INSTRUCTIONS! WARNING ￭ Use for any purpose other than powering compatible STIHL power tools could result in personal injury or property damage. – Use STIHL AP series batteries only to power compatible STIHL power tools. ￭ Use of unauthorized chargers can damage the battery and result in fire, explosion and personal injury and property damage. – Use only genuine STIHL AL series chargers to charge STIHL AP series batteries. ￭ The battery contains safety features and devices which, if damaged, may allow the battery to generate heat, rupture, leak, ignite or explode. – Never use or charge a malfunctioning, damaged, cracked, leaking or deformed battery. – Never open, disassemble, crush, drop, subject to heavy impact or otherwise damage the battery. – Never expose the battery to microwaves or high pressures. – Never insert objects into the battery's cooling slots. ￭ High temperatures may cause the battery to generate heat, rupture, leak, ignite or explode, resulting in severe or fatal personal injury and property damage. Exposure to temperatures outside the recommended temperature range may also reduce battery life and performance. ￭ To reduce the risk of personal injury and property damage in the event the battery emits smoke, an unusual smell or feels unusually hot while using, charging or storing: – Immediately discontinue using or charging the battery. Prepare to contact the authorities in the event of fire or explosion. ￭ To reduce the risk of a short circuit, which could lead to electric shock, fire and explosion: – Never bridge the battery terminals with wires or other metallic objects. – Keep a battery that is not in use away from metal objects (e.g., paper clips, nails, coins, keys). – Never transport or store the battery in a metal container. – Store the battery indoors in a dry room. – Never store the battery in damp or corrosive environments or in conditions that could lead to corrosion of its metal components. – Protect the battery from exposure to corrosive agents such as garden chemicals and de-icing salts. – Never store the battery in the power tool or charger. – Do not attempt to repair, open or disassemble the battery. There are no user-serviceable parts inside. ￭ Leaking battery fluid can cause skin and eye irritation or chemical burns. – Avoid contact with skin and eyes. – Use an inert absorbent such as sand on spilled liquids. – In the event of accidental contact, immediately rinse the contact area thoroughly with mild soap and water. – If fluid gets into your eye(s): Do not rub. Rinse water over the open eye(s) for at least 15 minutes and seek medical attention. ￭ A battery fire can be dangerous. To reduce the risk of severe personal injury and property damage in the event of fire: – Evacuate the area. Fire can spread rapidly. Stay clear of any vapors generated and maintain a safe distance. – Contact the fire department. – Although water can be used to put out a battery fire, use of a multi- purpose dry chemical fire extinguisher is preferable. – Consult the fire department regarding proper disposal of the burned battery. ￭ Dropping the battery could result in personal injury or property damage. To prevent the battery from falling during removal: – Place the power tool on a level surface and use care when ejecting the battery. Four LEDs show the status of the battery. These LEDs can glow or flash green or red. The green lights indicate the status of the charge, with four continuously glowing green lights indicating a full charge. If one green LED is flashing, less than 20% of the battery's charge remains. Operate the charger only indoors, in dry rooms and within an ambient temperature range of 41 °F to 104 °F (5 °C to 40 °C). For AL 301-4 charger only: You may install and operate the STIHL AL 301-4 charger in an enclosed, dry vehicle. Always read and follow the instructions and safety information for your charger. Store the battery out of reach of children in a cool, locked and dry area away from direct sunlight and excess heat or cold (14 °F to 122 °F (- 10 °C to 50 °C)). For maximum battery life, store the battery at an ambient temperature between 50 °F and 68 °F (10 °C and 20 °C) with a charge between 40 % (2 green LEDs) and 80 % (3 green LEDs). Do not leave spare batteries unused. Use them in rotation. A battery with this symbol is equipped with Bluetooth ® and can be used with the STIHL connected App. Turning On/Off: Press and hold the button on the battery for about 3 seconds. If the Bluetooth ® LED next to the connected symbol glows blue for about 3 seconds, the battery's Bluetooth ® interface is on. If the Bluetooth ® LED flashes blue six times, the Bluetooth ® interface is off. Connecting to the STIHL connected App: ► Turn on your mobile device's Bluetooth ® interface. ► Turn on the battery's Bluetooth ® interface. ► Download the STIHL connected App from Google Play or the App Store (Illustration 1). ► Follow in- app instructions for creating a new user account (Illustration 2 and 3). Returning users should log in using their existing account information. ► Follow the step-by-step instructions for adding the battery to your equipment list (Illustration 4). If the battery cannot be found with the STIHL connected App: ► Activate the Bluetooth ® interface on your battery and mobile device. ► Reduce the distance between the battery and your mobile device. If the battery still cannot be found with the STIHL connected App, contact a STIHL servicing dealer for assistance. Bluetooth ® Specifications: Data transmission protocol Bluetooth ® 5.1. Mobile receiving devices must be compatible with Bluetooth ® Low Energy 5.0 and support the Generic Access Profile (GAP). Frequency band: ISM band 2.4 GHz Radiated maximum transmission power: 1 mW; Bluetooth ® signal range: maximum 33 ft. (1…

Text truncated - open the document above for the full version.

Your Reference Dated Our Reference Phone Telefax E-Mail Date D2/EPG +4971 51261 451 [email protected] 2020-08-03 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2ALP8AP1 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Yours sincerely ANDREAS STIHL AG & Co. KG i. A. Andrea Griesheimer Senior Approval Engineer Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 USA

Your Reference Dated Our Reference Phone Telefax E-Mail Date D2/EPG +4971 51261 451 [email protected] 2020-08-03 Request for Permanent Confidentiality Company name: ANDREAS STIHL AG & Co. KG FCC ID: 2ALP8AP1 FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.457 and CFR 47 § 0.459 ANDREAS STIHL AG & Co. KG hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists. These documents contain detailed system and equipment description and related information about the product which ANDREAS STIHL AG & Co. KG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, ANDREAS STIHL AG & Co. KG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Yours sincerely ANDREAS STIHL AG & Co. KG i. A. Andrea Griesheimer Senior Approval Engineer Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 USA

FCC ID: 2ALP8AP1 IC: 23431-AP1 HVIN: AP 500 S G0M‐2006‐9064 FCC ID: 2ALP8AP1 IC: 23431-AP1 HVIN: AP 500 S G0M‐2006‐9064 FCC ID: 2ALP8AP1 IC: 23431-AP1 HVIN: AP 500 S G0M‐2006‐9064 FCC ID: 2ALP8AP1 IC: 23431-AP1 HVIN: AP 500 S G0M‐2006‐9064

FCC ID: 2ALP8AP1 IC: 23431-AP1 HVIN: AP 500 S G0M‐2006‐9064 FCC ID: 2ALP8AP1 IC: 23431-AP1 HVIN: AP 500 S G0M‐2006‐9064 FCC ID: 2ALP8AP1 IC: 23431-AP1 HVIN: AP 500 S G0M‐2006‐9064

Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 15 RF-EXPOSURE REPORT FCC 47 CFR 2.1093 ISED RSS-102 RF-Exposure evaluation of portable equipment Report Reference No G0M-2006-9064-TFC093PE-V03 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation DAkkS - Registration number : D-PL-12092-01-03 (ISED) ISED Testing Laboratory site: 3470A-2 DAkkS - Registration number : D-PL-12092-01-04 (FCC) FCC Filed Test Laboratory, Reg.-No.: 96970 Applicant Andreas Stihl AG & Co. KG Address Badstraße 115 71336 Waiblingen Germany Test Specification According to FCC/ISED rules Standard FCC 47 CFR 2.1093 ISED RSS-102 Issue 5 Non-Standard Test Method None Equipment under Test (EUT): Product Description battery pack with Bluetooth-Modul Model(s) AP 500 S Additional Model(s) None Brand Name(s) STIHL Hardware Version(s) 03.0 Software Version(s) 00.70 FCC-ID 2ALP8AP1 IC 23431-AP1 Test Result PASSED Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 15 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2020-08-12 Initial Release Abdullah Al Jamal 02 2020-11-05 Replaced document G0M-2006-9064-TFC093PE-V01 Replaced by G0M-2006-9064-TFC093PE-V02 Reason PMN and HVIN changed. New version of reference test report. Abdullah Al Jamal 03 2020-11-23 Replaced document G0M-2006-9064-TFC093PE-V02 Replaced by G0M-2006-9064-TFC093PE-V03 Reason New version of reference test report. Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 15 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power ERP Effective Radiated Power EUT Equipment Under Test LPE Low Power Exclusion N/A Not applicable Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 15 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Reference Documents ................................................................................................................................... 7 1.2 Standalone radiation sources ........................................................................................................................ 8 1.3 Concurrent Sources ...................................................................................................................................... 8 2 Result Summary ................................................................................................................................. 9 3 RF-Exposure classification ............................................................................................................ 10 4 RF-Exposure limits and exclusion thresholds ............................................................................ 11 4.1 SAR limits .................................................................................................................................................... 11 4.2 SAR standalone test exclusion threshold .................................................................................................... 11 4.3 SAR concurrent test exclusion threshold ..................................................................................................... 12 5 RF-Exposure Evaluation ................................................................................................................. 13 6 Single Source Evaluation Results - FCC ...................................................................................... 14 7 Single Source Evaluation Results - ISED ..................................................................................... 15 Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 15 1 Equipment (Test Item) Under Test Description battery pack with Bluetooth-Modul Model AP 500 S Additional Model(s) None Brand Name(s) STIHL Serial Number(s) Not specified. Test Sample ID 29658 Hardware Version(s) 03.0 Software Version(s) 00.70 PMN AP 500 S HVIN AP 500 S FVIN n/a HMN n/a FCC-ID 2ALP8AP1 IC 23431-AP1 Equipment type End Product Environment General public Use case Body worn Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 15 1.1 Reference Documents Document Type Document No. Issued by Date Test Report (FCC/ISED) – FCC 47 CFR 15.27 + ISED RSS-247 Issue 2 (February 2017) – Bluetooth Low Energy 5.1 G0M-2006-9064- TFC247BL-V02 Eurofins Product Servcei GmbH 2020-11-05 Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 15 1.2 Standalone radiation sources Standalone radiation sources Mode Operating Frequency [MHz] Maximum conducted power [dBm] Maximum radiated power [dBm EIRP] Maximum duty cycle [%] Antenna distance to body [mm] Bluetooth Low Energy 5.1 (LE 1M PHY) 2402 0.4 3.4 63 5.0 Comment: None. 1.3 Concurrent Sources No concurrent radiation sources. Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 15 2 Result Summary Standalone sources - FCC KDB 447498 Product Standard Reference Requirement Reference Method Mode Verdict KDB 447498 SAR Test Exclusion KDB 447498 4.3.1 Bluetooth Low Energy 5.1 (LE 1M PHY) PASS Comment: None. Standalone sources - ISED RSS-102 Product Standard Reference Requirement Reference Method Mode Verdict ISED RSS-102 SAR Test Exclusion ISED RSS-102 2.5.1 Bluetooth Low Energy 5.1 (LE 1M PHY) PASS Comment: None. Test Report No.: G0M-2006-9064-TFC093PE-V03 Eurofin…
