2ALUW-FNR3005G CPE

General SIM Card Micro SIM Card Nano SIM Card + Card Set Nano SIM Card Nano SIM Four-Faith 5G CPE F-NR300 User Manual 1. 5G CPE Interfaces 2. Indicator Description 4.Button Description Description of 5G CPE Ports and Indicators Wired Boardband Network Step 1： Network cables can only be connected to LAN2/WAN network ports. EthernetEthernetEthernet NetworkNetworkNetwork Step 2： Connect the power supply, the device will turn on automatically. On wall Ethernet port Optical/broadband /modem provided by broadband operator IndicatorInterfaces Button NameName Cellular Network Indicator Phone Port PHONE (Optional) LAN2/WAN LAN1 SIM Card Type C WPS RESET Ethernet Port Power Nano-SIM Card Slot Type-C Port 5G Indicator 4G Indicator WIFI Indicator Power Indicator 1）Blue，signal value RSRP≥ -95dBm 2）Yellow，signal value RSRP < -95dBm Phone RJ11 port, can directly connect the phone to make calls 1) Indicator is green and steady on, it is connected 2) Indicator is yellow and blinking, data is transmitt or receive Insert the Nano-SIM card DC 12V/3A The type-c interface is used only R&D personnel testing 1）On，Connect to 5G network 2）Off，Disconnect with 5G network 3）Blink，dialing, blink frequency 500ms/time 1）On，Connect to 4G network 2）Off，Disconnect with 4G network 3）Blink，dialing, blink frequency 500ms/time 1）On，WIFI on 2）Blink：After press the WPS button，500ms/time， continue 2 minutes 3）Off，WIFI off 1）On，Power on 2）Off, Power off DescriptionDescription 1) After the button is pressed, the WiFi indicator light will blink 500ms/time for 2 minutes. 2) The user terminal can quickly establish a secure WIFI connection without manually entering a password Press and hold the button for more than 10 seconds to reset to the factory setting. 5G 4G 1 1 8 9 10 12 11 13 7 14 6 7 9 11 121314 8 10 3 5 2 2 3 4 5 4 6 - + SIM Card Set up SIM Card or Wired Broadband Internet Access Step 1： Insert SIM card direction shown as below (Chip face down, notch face in). Can choose SIM card or wired broadband connect to network Description 1) After the button is pressed, the WiFi indicator light will blink 500ms/time for 2 minutes. 2) After Devices Shutdown: Plug and unplug the power supply, it will automically turn on. 3) After Shutdown: Long press the power button for 3s, turn on the device. 3.Interfaces Description Four-Faith 5G CPE F-NR300 User Manual Four-Faith 5G CPE F-NR300 User ManualFour-Faith 5G CPE F-NR300 User Manual Ethernet Port 1) Indicator is green and steady on, it is connected 2) Indicator is yellow and blinking, data is transmitt or receive User Manual Four-Faith CPE F-NR300 Bring Intelligent Across All Beings Step 4: Open the browser, and the page is automatically displayed. ( If no, manually enter 192.168.1.1 ) Default Account： admin Default Password： admin Step 5: Setting the user name and password for the WLAN Step 6: Set the password for logging in to the host After the application setting is complete, the login page will be displayed. Enter the password of the new account and click login. 2.4GHz 5GHz Step 3：Connect to network devices The desktop computer is connected to the LAN port of Four-Faith 5G CPE through a network cable. Mobile phones, tablets and other devices are connected to Four-Faith 5G CPE wireless networks. Default Password：12345678 Four-Faith 5G CPE F-NR300 User Manual Four-Faith 5G CPE F-NR300 User Manual Four-Faith 5G CPE F-NR300 User Manual FC C Regulations F-NR3 00 complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, under Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used by the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To comply with FCC RF exposure compliance requirements, this grant applies to only Mobile Configurations. The antennas used for the transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. We remind users here that changes or modifications not explicitly approv ed by the responsible party may cause users to lose the authority to operate the equipment.

Rev 11/20/07 Xiamen Four-Faith Communication Technology Co., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ALUW-FNR300 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (1. Block Diagram.pdf; 2.SCH.pdf; 3. Operation Description.pdf; 4.BOM.pdf; 5. Tune up.pdf;) (Block Diagram, SCH, Operation Description, BOM, Tune Up Procedure) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. We are requesting the commission to grant short-term confidentiality request on the following attachment(s) for 45 days after the grant as outlined in Public Notice DA 04-1705. Exhibit Type File Name (External Photos, Internal Photos, Test Setup Photos, Manual) (Appendix A.4-External Photos.pdf; Appendix A.5-Internal Photos.pdf; Appendix A.2 - DSS_DTS_NII Setup Photos; Appendix A.3 - PCB Setup Photos; Manual;) Sincerely, Name: Harven.Chen Title: Certification Manager

RF_160, Issue 04 Xiamen Four-Faith Communication Technology Co., Ltd. Declaration of Authorization We Name: Xiamen Four-Faith Communication Technology Co., Ltd. Address: 11th Floor, A-06 Area, No.370, Chengyi Street, Jimei, Xiamen, Fujian, China. City: Xiamen Country: China Declare that: Name Representative of agent: Well Wei Agent Company name: SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd Address: South of No. 6 Plant, No. 1, Runsheng Road, Suzhou Industrial Park, Suzhou Area, China (Jiangsu) Pilot Free Trade Zone City: Suzhou Country China is authorized to apply for Certification of the following product(s): Product description: 5G CPE Type designation: F-NR300 Trademark: Four-Faith on our behalf. Date: 2022/12/23.. City:  XiaMen .. Name:  Harven.Chen .. (2) Email: [email protected]....... Signature:  . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Xiamen Four-Faith Communication Technology Co., Ltd. 11th Floor,A-06 Area,No.370,Chengyi Street,Jimei, Xiamen,Fujian,China Statement and explanations 5G CPE is an 5G Indoor Commerical CPE product with WLAN function and WWAN certification module (module FG360-NA (Module FCC ID:ZMOFG360NA,Date of Grant:12/13/2021)). The 5G Module is installed in the host, which has no impact on the RF performance. Considering that the antenna is designed for the host, when the module is integrated into the host, we conducted an EMC test on the host, and retested RSE in RF. Standard Test Plan Module Reference Report Part 15C Full test NA Part 15E Full test NA Part 22/24/27/90/96 Only retest RSE and check power SAR20214000901 SAR20214000902 SUZR20217002001 SRTC2021-9004(F)-21082802(N) Part 2.1901 Reassessment NA The specific specifications are as follows: WLAN 2.4G/5G WCDMA:B2/B4/B5 LTE :B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B30/B41/B66/B71/B48 SA:N2/N5/N7/N12/N14/N25/N30/N41/N66/N71/N77/N78/N48/N70 Should you have any question or comment regarding this matter , Please have my best attention. Sincerely yours Name: Harven.Chen Title: Certification Manager

SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Power of Attorney we, Company Information：SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Name of authorized person：Well Wei Complete Address：South of No. 6 Plant, No. 1, Runsheng Road, Suzhou Industrial Park, Suzhou Area, China (Jiangsu) Pilot Free Trade Zone authorize Timco Engineering ,Inc. 849 NW State Road 45 Newberry,FL 32669, to the following person: Timco Engineering ,Inc. 849 NW State Road 45 Newberry,FL 32669 Emily Liang is authorized to apply for Certification of the following product(s): Product description: 5G CPE Type designation: F-NR300 Trademark: Four-Faith FCC ID: 2ALUW-FNR300 Sincerely, _________________________ _2023/01/04_____________ Signature of authorized person Date

FEDERAL COMMUNICATIONS COMMISSION Supplier’s Declaration of Conformity (SDoC) Equipment: 5G CPE Trademark(s) and Model(s): Four-Faith / F-NR300 Manufacturer: Xiamen Four-Faith Communication Technology Co., Ltd. FCC ID in case other parts of this equipment are subject to certification: 2ALUW-FNR300 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The following test reports are subject to this declaration: Test report number: Issue date: SEWM2209000178RG06 The following manufacturer/importer/entity (located in the USA) is responsible for this declaration: Date: 2022/12/23.. City:  XiaMen .. Name: Harven.Chen .. Email: [email protected]....... Signature:  . FCC

Page 1 of 3 1 Photographs - EUT Constructional Details F-NR300 Page 2 of 3 Page 3 of 3

Label Location of F-NR300 5G CPE Label Location: Label:

Page 1 of 7 2 Photographs - EUT Constructional Details Model No.: F-NR300 Page 2 of 7 WCDMA:B2/B4/B5 TRX LTE:B2/B4/B5/B7/B12/B13/B14/B17/B25/ B26/B30/B66/B71 TRX NR:N2/N5/N7/N12/N14/N25/N30/N66/N71/ N41(MIMO) TRX LTE:B41 TRX NR:N41(MIMO) TRX LTE:B48 TRX NR:N77/N78(MIMO) TRX WIFI WIFI Page 3 of 7 NR:N77/N78(MIMO) TRX Page 4 of 7 Page 5 of 7 Page 6 of 7 Page 7 of 7

` SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SAR/2021/4000901 Page: 1 of 53 Authorized Signature： Derek Yang Wireless Laboratory Manager FCC TEST REPORT Application No.: AR/2021/40009 Applicant: Fibocom Wireless Inc. Address of Applicant 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China Manufacturer: Fibocom Wireless Inc. Address of Manufacturer 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China EUT Description: 5G module Model No.: FG360-NA Trade Mark: Fibocom FCC ID: ZMOFG360NA Standards: 47 CFR Part 2 47 CFR Part 22 subpart H 47 CFR Part 24 subpart E 47 CFR Part 27 subpart C 47 CFR Part 90 subpart R 47 CFR Part 90 subpart S 47 CFR Part 96 subpart E Date of Receipt: 2021/5/7 Date of Test: 2021/5/7 to 2021/6/14 Date of Issue: 2021/6/14 Test Result : PASS * * In the configuration tested, the EUT detailed in this report complied with the standards specified above. ` SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SAR/2021/4000901 Page: 2 of 53 1 Version Revision Record Version Chapter Date Modifier Remark 01 2021-06-14 Original Authorized for issue by: Prepared By (Dee Zheng) / Engineer Checked By (Jim Huang) / Reviewer ` SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SAR/2021/4000901 Page: 3 of 53 Contents 1 Version .......................................................................................................................... 2 2 Test Summary ............................................................................................................... 5 2.1 GSM850/UMTS Band 5 & LTE Band 5 / 26(824~849 MHz) ............................. 5 2.2 GSM 1900/UMTS Band 2 /LTE Band 2 /25 ....................................................... 5 2.3 UMTS Band 4 /LTE Band 4 /66 ......................................................................... 6 2.4 LTE Band 7/41/ CA_41C ................................................................................... 6 2.5 LTE Band 12/17 ................................................................................................ 7 2.6 LTE Band 13 ..................................................................................................... 8 2.7 LTE Band 14 ................................................................................................... 10 2.8 LTE Band 26(814~824 MHz) .......................................................................... 12 2.9 LTE Band 30 ................................................................................................... 13 2.10 LTE Band 48 ................................................................................................... 15 2.11 LTE Band 71 ................................................................................................... 17 3 General Information ..................................................................................................... 18 3.1 Details of Client ............................................................................................... 18 3.2 Test Location .................................................................................................. 18 3.3 Test Facility ..................................................................................................... 19 3.4 General Description of EUT ............................................................................ 20 3.5 Test Mode ....................................................................................................... 20 3.6 Test Environment ............................................................................................ 21 3.7 Technical Specification ................................................................................... 21 3.8 Test Frequencies ............................................................................................ 25 4 Description of Tests ..................................................................................................... 35 4.1 Conducted Output Power ................................................................................ 35 4.2 Effective (Isotropic) Radiated Power of Transmitter ........................................ 36 4.3 EIRP Power Density ........................................................................................ 37 4.4 Occupied Bandwidth ....................................................................................... 38 4.5 Band Edge at Antenna Terminals ................................................................... 39 4.6 Spurious And Harmonic Emissions at Antenna Terminal ................................ 40 4.7 Peak-Average Ratio ........................................................................................ 41 4.8 Field Strength of Spurious Radiation............................................................... 42 ` SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SAR/2021/4000901 Page: 4 of 53 4.9 Frequency Stability / Temperature Variation ................................................... 44 4.10 Test Setups ..................................................................................................... 45 4.10.1 Test Setup 1 ....................................................................................... 45 4.10.2 Test Setup 2 ....................................................................................... 45 4.10.3 Test Setup 3 ....................................................................................... 46 4.11 Test Conditions ............................................................................................... 47 5 Main Test Instruments ................................................................................................. 50 6 Measurement Uncertainty....................................................................................…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SAR/2021/4000902 Page: 1 of 38 Authorized Signature: Derek Yang Wireless Laboratory Manager FCC TEST REPORT Application No: AR/2021/40009 Applicant: Fibocom Wireless Inc. Address of Applicant 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China Manufacturer: Fibocom Wireless Inc. Address of Manufacturer: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China EUT Description: 5G module Model No.: FG360-NA Trade Mark: Fibocom FCC ID: ZMOFG360NA Standards: 47 CFR Part 2 47 CFR Part 24 47 CFR Part 27 Test Method: FCC KDB 971168 D01 Power Meas License Digital Systems V03r01 C63.26 (2015) Date of Receipt: 2021/5/7 Date of Test: 2021/5/7 to 2021/6/14 Date of Issue: 2021/6/14 Test Result: PASS * * In the configuration tested, the EUT detailed in this report complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd.Shenzhen Branch Report No.: SAR/2021/4000902 Page: 2 of 38 1 Version Revision Record Version Chapter Date Modifier Remark 01 2021/6/14 Original Authorized for issue by: Prepared By (Dee Zheng) / Engineer Checked By (Jim Huang) / Reviewer SGS-CSTC Standards Technical Services Co., Ltd.Shenzhen Branch Report No.: SAR/2021/4000902 Page: 3 of 38 Content 1 VERSION ......................................................................................................................................................... 2 2 TEST SUMMARY ............................................................................................................................................ 5 2.1 NR BAND N41(ENDC DC_66A-N41A/DC_41A-N41A/DC_2A-N41A)/CA_N25A-N41A/ CA_N41A- N66A/ CA_N41A-N71A .............................................................................................................................................. 5 2.2 ENDC DC_12A-N2A ..................................................................................................................................... 6 2.3 NR BAND N66(ENDC DC_12A-N66A)/CA_N41A-N66A/CA_N66A-N71A ............................................ 7 2.4 NR BAND N25(ENDC DC_12A-N25A)/CA_N25A-N71A/CA_N25A-N41A ............................................ 7 2.5 NR BAND N71(ENDC DC_2A-N71A/DC_66A-N71A)/CA_N41A-N71A/CA_N25A-N71A/CA_N66A- N71A) 8 3 GENERAL INFORMATION ............................................................................................................................ 9 3.1 CLIENT INFORMATION ...................................................................................................................................... 9 3.2 TEST LOCATION ............................................................................................................................................... 9 3.3 TEST FACILITY ............................................................................................................................................... 10 3.4 GENERAL DESCRIPTION OF EUT .................................................................................................................. 11 3.5 TEST MODE ................................................................................................................................................... 11 3.6 TEST ENVIRONMENT...................................................................................................................................... 11 3.7 TECHNICAL SPECIFICATION ........................................................................................................................... 12 3.8 TEST FREQUENCIES ...................................................................................................................................... 14 3.8.1 Reference test frequencies for NR operating band n2 ..................................................................... 14 3.8.2 Reference test frequencies for NR operating band n25 ................................................................... 16 3.8.3 Reference test frequencies for NR operating band n41 ................................................................... 18 3.8.4 Reference test frequencies for NR operating band n66 ................................................................... 20 3.8.5 Reference test frequencies for NR operating band n71 ................................................................... 22 4 DESCRIPTION OF TESTS............................................................................................................................24 4.1 CONDUCTED OUTPUT POWER ...................................................................................................................... 24 4.2 EFFECTIVE (ISOTROPIC) RADIATED POWER OF TRANSMITTER .................................................................... 24 4.3 OCCUPIED BANDWIDTH ................................................................................................................................. 24 4.4 BAND EDGE AT ANTENNA TERMINALS .......................................................................................................... 25 4.5 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL ................................................................. 26 4.6 PEAK-AVERAGE RATIO .................................................................................................................................. 27 SGS-CSTC Standards Technical Services Co., Ltd.Shenzhen Branch Report No.: SAR/2021/4000902 Page: 4 of 38 4.7 FIELD STRENGTH OF SPURIOUS RADIATION ................................................................................................. 28 4.8 FREQUENCY STABILITY / TEMPERATURE VARIATION ................................................................................... 30 4.9 TEST SETUPS ...........................................................................................................…

Text truncated - open the document above for the full version.

Certificate Number: 5055.02 MPE REPORT Report No.: SRTC2021-9004(F)-21082802(I) Product Name: 5G module Product Model: FG360-NA Applicant: Fibocom Wireless Inc. Manufacturer: Fibocom Wireless Inc. Specification: FCC Part §2.1091, §2.1093, §1.1307(b), §1.1310 FCC ID: ZMOFG360NA The State Radio_monitoring_center Testing Center (SRTC) No.80 Beilishi Road Xicheng District Beijing, China Tel: 86-10-57996181 Fax: 86-10-57996288 No.: SRTC2021-9004(F)- 21082802(I) FCC ID: ZMOFG360NA The State Radio_monitoring_center Testing Center (SRTC) Page number: 3 of 14 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 CONTENTS 1 GENERAL INFORMATION ................................................................................................4 1.1 Notes of the test report .................................................................................................4 1.2 Information about the testing laboratory .......................................................................4 1.3 Applicant’s details .........................................................................................................4 1.4 Manufacturer’s details ..................................................................................................4 2 DESCRIPTION OF THE DEVICE UNDER TEST ...............................................................5 2.1 Final Equipment Build Status........................................................................................5 3 REFERENCE SPECIFICATION .........................................................................................6 4 RESULT SUMMARY ..........................................................................................................7 5 TEST RESULTS .................................................................................................................8 5.1 Average Power Output .................................................................................................8 5.2 Calculation result ..........................................................................................................2 No.: SRTC2021-9004(F)- 21082802(I) FCC ID: ZMOFG360NA The State Radio_monitoring_center Testing Center (SRTC) Page number: 4 of 14 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 1 GENERAL INFORMATION 1.1 Notes of the test report The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written permission of The State Radio_monitoring_center Testing Center (SRTC). The test results relate only to individual items of the samples which have been tested. 1.2 Information about the testing laboratory Company: The State Radio_monitoring_center Testing Center (SRTC) Address: No.80 Beilishi Road, Xicheng District City: Beijing Country or Region: P.R.China Contacted person: Liujia Tel: +86 10 5799 6181 Fax: +86 10 5799 6288 Email: [email protected] 1.3 Applicant’s details Company: Fibocom Wireless Inc. Address: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China Contacted person: shelly.xu Tel: 13823645040 Email: [email protected] 1.4 Manufacturer’s details Company: Fibocom Wireless Inc. Address: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China No.: SRTC2021-9004(F)- 21082802(I) FCC ID: ZMOFG360NA The State Radio_monitoring_center Testing Center (SRTC) Page number: 5 of 14 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 2 DESCRIPTION OF THE DEVICE UNDER TEST 2.1 Final Equipment Build Status Frequency Range: NR Band N5: Tx:824~849 MHz Rx:869 ~894MHz NR Band N7: Tx:2500~2570MHz Rx:2620~2690MHz NR Band N12: Tx:699~716 MHz Rx:729~746MHz NR Band N14: Tx:788~798 MHz Rx:758~768MHz NR Band N30: Tx:2305~2315MHz Rx:2350~2360MHz NR Band N77: Tx:3450~3550MHz;3700~3980MHz Rx: 3450~3550MHz;3700~3980MHz NR Band N78: Tx: 3450~3550MHz;3700~3800MHz Rx: 3450~3550MHz;3700~3800MHz Modulation Type: DFT-QPSK/DFT-16QAM/ DFT-64QAM/ DFT-256QAM/ CP-QPSK/CP-16QAM/CP-64QAM/CP-256QAM Antenna Type: External Antenna Gain: N5: 1.61dBi N7: 1.07dBi N12: 1.58dBi N14: 2.19dBi N30: 0.22dBi N77/N78: -2.09dBi Power Supply: Battery/Charger Hardware Version: V1.0 Software Version: 81103.7000.30.02.01.09 IMEI: 861139050018252 No.: SRTC2021-9004(F)- 21082802(I) FCC ID: ZMOFG360NA The State Radio_monitoring_center Testing Center (SRTC) Page number: 6 of 14 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 3 REFERENCE SPECIFICATION Specification Version Title 2.1091 Sept. 20, 2017 Radiofrequency radiation exposure evaluation: mobile devices. 2.1093 Sept. 20, 2017 Radiofrequency radiation exposure evaluation: portable devices. 1.1307(b) Apr. 22, 1986 Actions that may have a significant environmental effect, for which Environmental Assessments (EAs) must be prepared. 1.1310 June 4, 2013 Radiofrequency radiation exposure limits. KDB447498 October 23, 2015 RF exposure procedures and equipment authorization policies for mobile and portable devices No.: SRTC2021-9004(F)- 21082802(I) FCC ID: ZMOFG360NA The State Radio_monitoring_center Testing Center (SRTC) Page number: 7 of 14 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 4 RESULT SUMMARY No. Test case FCC reference 1 MPE Calculation FCC Part §2.1091, FCC Part §2.1093, FCC Part §1.1307(b) FCC Part §1.1310 KDB 447498 This Test Report Is Issued by: Mr. Peng Zhen Checked by: Ms. Liu Jia Tested by: Mr. Li Bin Issued date: 20210923 No.: SRTC2021-9004(F)- 21082802(I) FCC ID: ZMOFG360NA The State Radio_monitoring_center Testing Center (SRTC) Page number: 8 of 14 Tel: 86-10-57996183 Fax: 86-10-57996388 V3.0.0 5 TEST RESULTS 5.1 Average Power Output 5.1.1 Ambient condition Temperature Relative humidity Pressure 22°C 40% 101.5kPa 5.1.2 Test Description A transmitter antenna terminal of EUT is connected to the power meter. Measurement is made using a broadband power meter capable of making peak and average measurements while the EUT is operating at its maximum duty cycle (…

Text truncated - open the document above for the full version.

` SGS-CSTC Standards Technical Services (Suzhou) Co., Ltd. Report No.: SUZR/2021/7002002 Rev.： 01 Page: 1 of 8 Authorized Signature: Panta Sun Wireless Laboratory Manager Cover PRF Exposure Evaluation Report Application No.: ZR/2021/70020 Applicant: Fibocom Wireless Inc. Address of Applicant: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China Manufacturer: Fibocom Wireless Inc. Address of Manufacturer: 1101,Tower A, Building 6, Shenzhen International Innovation Valley, Dashi 1st Rd, Nanshan,Shenzhen, China EUT Description: 5G module Model No.: FG360-NA Trade Mark: Fibocom FCC ID: ZMOFG360NA Standards: 47 CFR Part 2.1091 FCC KDB 447498 D01 v06 Date of Receipt: 2021/10/1 Date of Test: 2021/10/22 to 2021/10/27 Date of Issue: 2021…
