2ALYUHDR-AC74K OPTICAL VIDEO CAMERA

User manual 4K OPTICAL VIDEO CAMERA Overview Thankyouforpurchasingthisportabledigitalvideocamera, thiscamerafeaturesvideorecordingat4K.Withresolutionof 2880*2160,itadoptedSony1/3-inchimagesensor,H.264 videoencodingformat,thevideofilestorageusageissmall whileithashighimagequality! YoucanconnectyourcameraviaWi-Fiusingyoursmart Phoneremotely,toviewthecameralivescreenanduseyour phonetorecordorshooting. SafetyInstructions  Donotdrop,impactorpuncturethecamera  Donotexposethecameratohigh/lowtemperature, excessivedust,humidityorstrongvibration,otherwise theproductmaybedamaged.  Donotusecorrosivechemicalsorsolventstocleanthe product  Donotdisassemblethiscameraorattempttorepairor modifyitinanymanner,ifthereisanydamagetothe camera,stopusingthecameraandreturnthisproductto thestorewhereyouhavepurchaseditfrom,theproduct willbesentbacktothecompanyandfix. Cautions  Keepchildrenawayfromtheproduct,accessoriesand itspackagingmaterials,itmaycausesuffocation.  Donotputtheproductinafire,otherwiseitmaycause anexplosion.  Removethebatteryifthecameraisnotgoingtobeused forlongperiods,andpleasefully-chargedthebattery beforeusingitagain. TableOfContents GettingtoKnowYourCamera.......................................................1 StandardAccessories...........................................................1 ChargingtheBattery.............................................................1 ComponentIntroduction.......................................................2 InsertinganSDCard............................................................4 LoadingBattery.....................................................................5 GettingStarted.................................................................................6 RecordingMode....................................................................6 PhotoMode............................................................................8 Playback...............................................................................11 SlideShow...........................................................................12 Setting...................................................................................13 ConnectingtotheComputer........................................................14 MSDCMode........................................................................14 PCCameraMode...............................................................15 ConnectingtoTV...........................................................................15 APPUsing......................................................................................16 APPDownloading.............................................................16 APPConnecting................................................................16 APPFunctions.....................................................................18 TechnicalParameters...................................................................22 Troubleshooting.............................................................................23 GettingtoKnowYourCamera StandardAccessories 4KUltraHDCameraInfraredremotecontrol BatteryHDMICable ChargerUserManual USBCableWarrantyCard DVPouch ChargingtheBattery Beforeusingthecamera,youmustloadandchargethe battery Note: Insertthebatteryintothechargertochargeit,the indicatorlightwillberedwhencharging;Theindicator lightwillturngreenwhenthechargingiscompleted. Connectto 100-220V socket ComponentIntroduction A. 000 Forthefunctiondescriptionoftherelatedpartsintheabove figure,pleaserefertothefollowingtable. No.NameFunctiondescription ①IPSPanel Screenpreviewandvideo/photo playback.Itsupports270°rotation. ② SpeakerBacksoundsandkeystrokes. ③PowerButtonPowerOn/Off. ⑩ ⑪ ⑨ ① ③ ⑦ ⑤ ⑥ ② ⑧ ⑫ ⑬ ④ ④ T/WZoom Button Invideo/PhotoMode,pullleft/ righttozoomin/out. Italsocanbe"Options"button whenchoosingfunctions. ⑤PhotoButton Inphotomode,presstotakephoto. Italsocanbe"OK"buttonwhen confirmingfunctions. ⑥ StatusLight Chargingindicatorandworking indicator. ⑦ Recording Button 1.Recording/stopvideo. 2.Stopplaybackwhenthevideois Playing. ⑧ I/OInterface MIC:Accesstoanexternal microphone; HDMI ： ExternalHDCableto connecttoTV; USBinterface ： AccesstheUSB Cabletocharge. ⑨ ModeButtonPresstoenterthemodemenu. ⑩DISPButton Pressoncetoclosethescreendata display; Presstwicetoclosethescreen preview. ⑪ ModeButtonPresstoenterthemodemenu. ⑫ LEDLight Switch Presstoturnon/offtheLEDlight. ⑬ Built-in microphone Recordingsound. B. Forthefunctiondescriptionoftherelatedpartsintheabove figure,pleaserefertothefollowingtable. No.NameFunctiondescription ①LEDlightLightingassist. ② LensFraming. ③ Infrared remote-control receiver Receivingremotecommand. InsertinganSDCard ① ② ③ 1.OpentheBatterycover. 2.Insertthememorycardinthedirectionshownuntilyou hear“Clicks”. 3.ClosetheBatterycover. ※OpentheBatterycoverandpressthememorycard. LoadingBattery 1.OpentheBatterycover. 2.insertsalithiumbattery. 3.Closethebatterycover. Note: 1.Whenusingforthefirsttime,formattheSDcard Onthisunit.TheSDcardneedstobeU1. 2.DonotforcefullyremovetheSDcardwhileworking, otherwiseitmaycauselossoffilesormachine damage. GettingStarted Toturnonthecamera,pressthepowerbuttonorturnonthe screen.Thecamerawillenterthemaininterface.Select “Mode”toenterthemaininterfaceofmodeoptions. RecordingMode Menu Wi-Fi SDcardinserted CurrentMode Videorecordingtimeremaining Remainingbatterycapacity Currentresolution NameFunctionDescription Resolution Choosetheresolutionaccordingtoyour needs. AWB Choosedifferentwhitebalancefunctions accordingtotheenvironment:Auto, Daylight,Cloudy,Florescent,Tungsten. Color Choosedifferentscenecoloraccordingto yourneeds:Standard,Sepia, Monochrome,Vivid. Exposure Adjusttheexposurevalueaccordingtothe environment ： +3 、 +2 、 +1 、 0 、 -1 、 -2 、 -3 。 Metering Choosedifferentmeteringmodes accordingtoyourneeds ： Multi 、 Center 、 Spot. Time-lapse Video Byselecting:off、1sec、3sec、5sec Byusingthisfunction,youcancompressa fewminutesandseveralhoursofvideo intoashortervideo. 1.Select“Video”inmodetoenterthepr…

Text truncated - open the document above for the full version.

Shenzhen Pa. Times Technology Co., Ltd Add: Room D-E, Floor 14, Block B, Xuesong Building, Tairan Road 6, Tairan Science & Technology Park, Futian District, Shenzhen, China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Dear Sir/Madam, We, Shenzhen Pa. Times Technology Co., Ltd Hereby declares the following statement for FCC, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product Name: 4K OPTICAL VIDEO CAMERA FCCID: 2ALYUHDR-AC7 Model Number(s): HDR-AC7, AC7x, A7, A70 Signature: Date: 2020-08-13 Name: Peter Yang Title: Manager Company: Shenzhen Pa. Times Technology Co., Ltd

Shenzhen Pa. Times Technology Co., Ltd Agent Authorization Company: Shenzhen Pa. Times Technology Co., Ltd Address: Room D-E, Floor 14, Block B, Xuesong Building, Tairan Road 6, Tairan Science & Technology Park, Futian District, Shenzhen, China Product Name: 4K OPTICAL VIDEO CAMERA Trade Mark: ORDRO Model Number(s): HDR-AC7, AC7x, A7, A70 FCC ID: 2ALYUHDR-AC7 We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-08-13 Name: Peter Yang Title: Manager Company: Shenzhen Pa. Times Technology Co., Ltd

Shenzhen Pa. Times Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-08-13 Subject; Request for Confidentiality FCC ID: 2ALYUHDR-AC7 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Peter Yang Title: Manager

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 4 External Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 4 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 4 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 4 of 4 Fig.7 Fig.8

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 1 LABEL AND LOCATION (Size: L3.0m x 2.0cm) Material: Tagboard Glue: adhesive sticker Font color: White Label color: Black Label Location 4K OPTICAL VIDEO CAMERA Model No.: HDR-AC7 FCC ID: 2ALYUHDR-AC7 Made In China

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 3 Internal Photos of the EUT Fig.1 Fig.2 WIFI Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 3 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 3 Fig.5

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 3 FCC RF Exposure Evaluation 1. Product Information FCC ID: 2ALYUHDR-AC7 Product name 4K OPTICAL VIDEO CAMERA Model number HDR-AC7, AC7x, A7, A70 Model declaration PCB board, structure and internal of these model(s) are the same,So no additional models were tested. Power supply Capacity: DC 3.7V, 1250mAh, 4.625Wh Input: 5V, 1A For Adapter Input: 100-240V~, 50/60Hz, 0.2A Output: 5V, 1000mA Operation frequency 2412MHz-2462MHz Modulation Type IEEE 802.11b: DSSS(CCK,DQPSK,DBPSK); IEEE 802.11g/n: OFDM(64QAM, 16QAM, QPSK, BPSK) Channel Number 11 channels for 20MHz bandwidth(2412MHz~2462MHz) 7 channels for 40MHz bandwidth(2422MHz~2452MHz) Channel Spacing 5MHz Antenna Type FPC Antenna Antenna Gain 2.0 dBi(Max.) Hardware version V1.0 Software version V1.0 Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Portable Device 2. Evaluation method and Limit According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 3 • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. 3. Refer evaluation method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz. FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1093: Radiofrequency radiation exposure evaluation: portable devices 4. Conducted Power Results [2.4G WIFI Max Conducted Power] Mode Channel Frequency(MHz) Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 9.20 6 2437 8.96 11 2462 9.39 IEEE 802.11g 1 2412 9.01 6 2437 9.09 11 2462 8.94 IEEE 802.11n HT20 1 2412 8.81 6 2437 9.00 11 2462 8.81 IEEE 802.11n HT40 3 2422 9.05 6 2437 8.60 9 2452 8.15 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD FCC ID: 2ALYUHDR-AC7 ________________________________________________________________________ ___ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 3 5. Manufacturing tolerance 2.4GWIFI IEEE 802.11b (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 8.5 8.0 8.5 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11g (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 8.5 8.5 8.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11n HT20 (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 8.0 8.5 8.0 Tolerance ±(dB) 1.0 1.0 1.0 IEEE 802.11n HT40 (Peak) Channel Channel 3 Channel 6 Channel 9 Target (dBm) 8.5 8.0 8.0 Tolerance ±(dB) 1.0 1.0 1.0 6. Evaluation Results 2.4GWIFI Band/Mode f (GHz) Antenna Distance (mm) RF output power SAR Test Exclusion Threshold SAR Test Exclusion dBm mW IEEE 802.11b 2.412 5 9.5 8.9125 2.77 < 3.0 Yes IEEE 802.11g 2.412 5 9.5 8.9125 2.77 < 3.0 Yes IEEE 802.11n HT20 2.412 5 9.5 8.9125 2.77 < 3.0 Yes IEEE 802.11n HT40 2.422 5 9.5 8.9125 2.77 < 3.0 Yes Remark: 1…
