2AM68E8-LEDEthereal-Infinite Series LED Lighting System

1 Dear Customer, Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. User Memo: Date of purchase: Dealer name: Dealer address: Dealer website: Dealer email: Dealer phone no.: Please visit us on Facebook, Twitter or Instagram! Facebook Twitter Instagram User Memo EN 2 Please check the content in the package. Package Content EN 3 1. Remove any plastic bags and packaging material protecting the fixture. 2. Never look directly at the LED bulbs when you switch on the system. Incorrect use of this apparatus will increase eye hazard. On Safety 1. Power Source – Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 2. Power Cord Protection – The power supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Never take hold of the plug or cord if your hand is wet, and always grasp the plug body when connecting or disconnecting it. 3. Installation – Install indoor only, and use the attachments, mounting frames, hanging kit and accessories provided and specified by the manufacturer. On Operation 1. Operation – Always follow the operation instructions set forth in this manual when using the Maxspect™ Ethereal Infinite LED Lighting System. 2. Heat – The apparatus should be situated away from heat sources such as radiators, and do not expose to excessive heat such as sunshine, fire or the like. 3. Moisture – To reduce the risk of fire or electric shock, do not expose this apparatus to rain, moisture, dripping or splashing. 4. Ventilation – The apparatus should be situated so that its location or position does not interfere with its proper ventilation. 5. Magnetism – The apparatus should be situated away from equipment or devices that generate strong magnetism. 6. Cleaning – Clean only with dry or damp cloth. Waste Disposal 1. Product: Electronic devices are recyclable waste and must not be disposed of in the household waste. At the end of its service life, dispose of the product according to the relevant statutory regulations. Remove any inserted (rechargeable) batteries and dispose of them separately from the product. 2. (Rechargeable) batteries: You as the end user are required by law (Battery Ordinance) to return all used batteries/rechargeable batteries. Disposing of them in the household waste is prohibited. Used (rechargeable) batteries can be returned to collection points in your municipality or wherever (rechargeable) batteries are sold. You thus fulfil your statutory obligations and contribute to the protection of the environment. 3. As a producer in terms of the German ElektroG we are registered with the German registration authority Stiftung Elektro-Altgeräte-Register (Nordostpark 72, 90411 Nürnberg), having been granted the following WEEE registration number: DE21010727. Precautions Before using the Maxspect™ Ethereal Infinite LED Lighting System, please read these operating instructions carefully. Take special care to follow the safety suggestions listed below. Afterwards keep this manual handy for future reference. EN 4 Mounting the LED Lighting System Before connecting the fixture to power, first mount the system by using the provided stand. Installation Scan QR code to check out the detailed installation video. 1 2 3 4 5 A total of four combinations of bracket installation. 6 EN 5 Hanging Kits Installation (sold separately) Installation Scan QR code to check out the detailed installation video. EN 6 SYNA-G CLOUD APP Maxspect™ Ethereal Infinite LED Lighting System is a cloud-based controlling system. To get full access to the fixture, please scan below QR-Code to install SYNA-G CLOUD APP on your mobile device. iOS Android Operation Fixture Different color of the Indicator represents different working mode of the device. Scan the above QR code to check out the detailed operation instructions on YouTube. Operating Instructions Off: No Wi-Fi connection On: Wi-Fi connected Flashes: Wi-Fi connecting Yellow: Manual Mode Blue: Auto Mode Left Button Right Button ON/OFF Button ⚫Default Factory Setting: Manual Working Mode, all channels 100% brightness, Flip Up Turn Off (OFF), Mood Light Auto Turn Off (OFF). ⚫Press and hold Button for about 5s can turn ON/OFF the device. ⚫Press and hold and buttons for about 3s to turn the device into Wi-Fi connection status. indicator starts to flash, the buzzer sounds 0.2s. After Wi-Fi is connected, the indicator is constant on and the buzzer sounds 0.4s. ⚫While in the Manual Mode, press button can switch between brightness and color temperature settings, then press and buttons can adjust the settings. ⚫While in the Auto Mode, press and buttons can adjust the brightness. ⚫In normal working status, press and hold button for about 5s until indicator quick flashes for 3 times and the buzzer sounds 0.4s, the lighting settings are being recovered to the default factory setting (WiFi connection remains valid). ⚫Scan the above QR code to check out the detailed operation videos. EN 7 Ways of Connection User only gets limited access to the device through the Direct Connection. To get full access to the device, please connect it to the Internet. Function Wi-Fi Connection (with Internet) Wi-Fi Connection (without Internet) Direct Connection Auto Working Mode √ √ √ Manual Working Mode √ √ √ Color Temperature Setting √ √ √ Ambient Light √ √ √ Acclimation Mode √ √ x Region Cloud Patterns √ √ x Energy Saving Mode √ √ x Multiple Fixtures Controlling √ √ x Fixture Grouping √ √ x Fixture Naming √ √ x Global Control √ √ x Illumination Setting Saving √ x x Illumination Setting Sharing √ x x Operating Instructions EN 8 Maintenance of the fix…

Text truncated - open the document above for the full version.

Guangzhou Maiguang Electronic Science Technology Co.,Ltd. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 8/14/2024 U.S. Agent Designation Guangzhou Maiguang Electronic Science Technology Co.,Ltd. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AM68E8-LED): Name and company of U.S. agent: FCC US Agent, LLC Physical U.S. address of agent: 3722 Illinois Avenue, Saint Charles, IL, 60174, USA FRN of U.S. agent: 0033402884 Email address of U.S. agent: [email protected] FCC US Agent, LLC acknowledges their obligation to accept service of process on behalf of Guangzhou Maiguang Electronic Science Technology Co.,Ltd.. Guangzhou Maiguang Electronic Science Technology Co.,Ltd. with the FRN 0026722082 accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. S incerely, Signature Weixin Liang Technical Director Guangzhou Maiguang Electronic Science Technology Co.,Ltd. Signature Tim Payne Manager FCC US Agent, LLC 48_[model] US_Agent_2.911(d)(7)-U, V05

Covered Equipment Attestation Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Section 2.911(d)(5)(i)-(ii) of the Commission’s Rules (47 C.F.R.) we attest as follows for the product listed below: FCC ID Model name 2AM68E8-LED E8-230, E8-150 We, applicant Company Name: Guangzhou Maiguang Electronic Science Technology Co., Ltd. Address: Building 1, Shenlan Electrical and Mechanical Park, Shibei Gongye Road, Panyu District, Guangzhou 511430, China Phone: +86-13826214123 certify that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-12 Signature Date Name / Title: Weixin Liang / Technical Director Company: Guangzhou Maiguang Electronic Science Technology Co., Ltd. Address: Building 1, Shenlan Electrical and Mechanical Park, Shibei Gongye Road, Panyu District, Guangzhou 511430, China Phone: +86-13826214123 Fax: +86-20-34273934 E-Mail: [email protected]

Confidentiality Request Letter For Certification Service in the USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21048 To whom it may concern Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we request confidentiality for the documentation of the following products: FCC ID Model name 2AM68E8-LED E8-230, E8-150 For the products listed above, we request permanent confidentiality for all applicable exhibits as there are: • the Operational Description • the Block Diagram • the Schematics • the Part List • the Tune up Information The above listed exhibits contain trade secrets and proprietary information that could be of benefit to our competitors. If you have any questions, please feel free to contact us at the address shown below. Sincerely, 2024-08-12 Signature Date Name / Title: Weixin Liang / Technical Director Company: Guangzhou Maiguang Electronic Science Technology Co., Ltd. Address: Building 1, Shenlan Electrical and Mechanical Park, Shibei Gongye Road, Panyu District, Guangzhou 511430, China Phone: +86-13826214123 Fax: +86-20-34273934 E-Mail: [email protected]

Guangzhou Maiguang Electronic Science Technology Co., Ltd. Building 1, Shenlan Electrical and Mechanical Park, Shibei Gongye Road, Panyu District, Guangzhou 511430, China Date: August 12, 2024 FCC ID: 2AM68E8-LED Model Number: E8-230, E8-150 To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Guangzhou Maiguang Electronic Science Technology Co., Ltd. hereby declare that our product (Ethereal-Infinite Series LED Lighting System) Model Number: E8-230, E8-150 board, Schematic, Hardware version, Software version, structure and internal photos are same, named and appearance differently due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Weixin Liang / Technical Director Company: Guangzhou Maiguang Electronic Science Technology Co., Ltd. Address: Building 1, Shenlan Electrical and Mechanical Park, Shibei Gongye Road, Panyu District, Guangzhou 511430, China Phone: +86-13826214123 Fax: +86-20-34273934 E-Mail: [email protected]

Page 1 of 1 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity LABEL AND LOCATION (Size: L 4.5cm x W 2.5cm) Ethereal-Infinite Series LED Lighting System Test Model: E8-230 FCC ID: 2AM68E8-LED W L Label Location

Page 1 of 7 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Internal Photos of the EUT Fig. 1 Fig. 2 BLE/2.4GWIFI Antenna Page 2 of 7 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 3 Fig. 4 Page 3 of 7 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 5 Fig. 6 Page 4 of 7 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 7 Fig. 8 Page 5 of 7 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 9 Fig. 10 Page 6 of 7 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 11 Fig. 12 Page 7 of 7 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Fig. 13

Page 1 of 5 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Maximum Permissible Exposure Report 1. Product Information FCC ID : 2AM68E8-LED EUT : Ethereal-Infinite Series LED Lighting System Test Model : E8-230 Additional Model No. : E8-150 Model Declaration : PCB board, structure and internal of these model(s) are the same, So no additional models were tested Power Supply : Input: 24V10A For Adapter Input: 100-240V~ 50/60Hz 3.5A For Adapter Output: 24.0V10.0A; 240.0W Hardware Version : 0ESP32C3 Software Version : 0403000L Bluetooth : Frequency Range : 2402MHz~2480MHz Channel Number : 40 channels for Bluetooth V5.0 (DTS) Channel Spacing : 2MHz for Bluetooth V5.0 (DTS) Modulation Type : GFSK for Bluetooth V5.0 (DTS) Bluetooth Version : V5.0 Antenna Description : Internal Antenna, 2.0dBi(Max.) WIFI(2.4G Band) : Frequency Range : 2412MHz-2462MHz Channel Spacing : 5MHz Channel Number : 11 Channels for 20MHz bandwidth (2412~2462MHz) 7 Channels for 40MHz bandwidth (2422~2452MHz) Modulation Type : IEEE 802.11b: DSSS (CCK, DQPSK, DBPSK) IEEE 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) IEEE 802.11n: OFDM (64QAM, 16QAM, QPSK, BPSK) Antenna Description : Internal Antenna, 2.0dBi(Max.) Exposure category : General population/uncontrolled environment EUT Type : Production Unit Device Type : Mobile Device 2. Evaluation Method Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power Page 2 of 5 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–2019: IEEE Standard for Safety Levels with Respect to Human Exposure to Electric, Magnetic, and Electromagnetic Fields, 0 Hz to 300 GHz FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices. 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Uncontrolled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information EUT can only use antennas certificated as follows provided by manufacturer; Internal/External Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Notes Antenna Internal Antenna 2400-2500 MHz 2.0dBi BT/ WIFI Antenna Page 3 of 5 FCC ID: 2AM68E8-LED Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity 6. Conducted Power [BT LE] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 0.15 19 2440 0.53 39 2480 0.63 [2.4G WLAN] Mode Channel Frequency (MHz) Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 15.42 6 2437 15.38 11 2462 15.71 IEEE 802.11g 1 2412 14.88 6 2437 14.51…

Text truncated - open the document above for the full version.

1 Productspecificationsheet Product Description: 2.4GHz FPC Antenna Release date: August 27, 2023 Guang Zhou Jie Quan Electronic Co.,Ltd Y501, Building 7, No. 18, Dalingshan Road, Tianhe District, Guangzhou 2 1.Catalog Cover············································································1 1.Catalog·······································································2 2.SampleImage·······························································3 3.Product·······································································3-4 3.1Imagefileproduct······················································································3 4.Performanceparametertable·············································4 5.ElectricalPerformanceTestReport······································5-7 5.1Sparameter····························································································5 5.2Efficiency································································································6 5.3Antennapattern·························································································7 6.ReliabilityTestReport····················································8 6.1Constanttemperatureandhumiditytest·····························································5 6.2Saltspraytest··························································································6 3 2.Sampleimage 3.Product 3.1Imagebasedproducts 4 4.Performanceparametertable Electricalparameters frequencyrange 2400-2500MHz Inputimpedance 50Ω StandingPoppy ≤2.5 gain2.0dBi Powercapacity2W Voltagewithstand test 1KV On-offtest access Polarizationmode vertical Radiationdirection omnidirectional Transfermodel/ Mechanicalparameters ExternaldimensionsRefertotheproductinthe picturefile Maintainingpower / Insertionand extractionforce / Coaxialcableblack Environmentalparameters working temperature -30°C~65°C Storagetemperature -30°C~75°C 5 5.ElectricalPerformanceTestReport 5.1Sparameter 5.2 Efficiency 6 Efficiency Frequency(MHz) Standard 5.3 Antenna pattern 7

Page 1 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix A RF Test Data for BT LE (Conducted Measurement) Product Name: Ethereal-Infinite Series LED Lighting System Test Model: E8-230 Environmental Conditions Temperature: 23.8C Relative Humidity: 52.1% ATM Pressure: 100.0 kPa Test Engineer: Paddi Chen Supervised by: Nick Peng Page 2 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT BLE 1M 2402 Ant1 0.661 >=0.5 Pass NVNT BLE 1M 2440 Ant1 0.653 >=0.5 Pass NVNT BLE 1M 2480 Ant1 0.655 >=0.5 Pass Page 3 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs -6dB Bandwidth NVNT BLE 1M 2402MHz Ant1 -6dB Bandwidth NVNT BLE 1M 2440MHz Ant1 Page 4 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity -6dB Bandwidth NVNT BLE 1M 2480MHz Ant1 Page 5 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.2 Maximum Peak Conducted Output Power Condition Mode Frequency (MHz) Antenna Conducted Power (dBm) Limit (dBm) Verdict NVNT BLE 1M 2402 Ant1 0.15 30 Pass NVNT BLE 1M 2440 Ant1 0.53 30 Pass NVNT BLE 1M 2480 Ant1 0.63 30 Pass Page 6 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs Power NVNT BLE 1M 2402MHz Ant1 Power NVNT BLE 1M 2440MHz Ant1 Page 7 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Power NVNT BLE 1M 2480MHz Ant1 Page 8 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.3 Maximum Power Spectral Density Level Condition Mode Frequency (MHz) Antenna Conducted PSD (dBm/3kHz) Limit (dBm/3kHz) Verdict NVNT BLE 1M 2402 Ant1 -16.51 8 Pass NVNT BLE 1M 2440 Ant1 -16.29 8 Pass NVNT BLE 1M 2480 Ant1 -16.38 8 Pass Page 9 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs PSD NVNT BLE 1M 2402MHz Ant1 PSD NVNT BLE 1M 2440MHz Ant1 Page 10 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity PSD NVNT BLE 1M 2480MHz Ant1 Page 11 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity A.4 Band Edge Condition Mode Frequency (MHz) Antenna Max Value (dBc) Limit (dBc) Verdict NVNT BLE 1M 2402 Ant1 -55.68 -20 Pass NVNT BLE 1M 2480 Ant1 -56.8 -20 Pass Page 12 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Test Graphs Band Edge NVNT BLE 1M 2402MHz Ant1 Ref Band Edge NVNT BLE 1M 2402MHz Ant1 Emission Page 13 of 23 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EA Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 5…

Text truncated - open the document above for the full version.

Page 1 of 55 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity Appendix B RF Test Data for 2.4GWIFI (Conducted Measurement) Product Name: Ethereal-Infinite Series LED Lighting System Test Model: E8-230 Environmental Conditions Temperature: 23.8C Relative Humidity: 52.1% ATM Pressure: 100.0 kPa Test Engineer: Paddi Chen Supervised by: Nick Peng Page 2 of 55 FCC ID: 2AM68E8-LED Report No.: LCSA06174253EB Shenzhen LCS Compliance Testing Laboratory Ltd. Add: 101, 201 Bldg A & 301 Bldg C, Juji Industrial Park Yabianxueziwei, Shajing Street, Baoan District, Shenzhen, 518000, China Tel: +(86) 0755-82591330 | E-mail: [email protected] | Web: www.lcs-cert.com Scan code to check authenticity B.1 -6dB Bandwidth Condition Mode Frequency (MHz) Antenna -6 dB Bandwidth (MHz) Limit -6 dB Bandwidth (MHz) Verdict NVNT b 2412 Ant1 9.077 >=0.5 Pass NVNT b 2437 Ant1 8.52 >=0.5 Pass NVNT b 2462 Ant1 8.069 >=0.5 Pass NVNT g 2412 Ant1 16.073 >=0.5 Pass NVNT g 2437 Ant1 16.309 >=0.5 Pass NVNT g 2462 Ant1 16.31 >=0.5 Pass NVNT n20 2412 Ant1 16.849 >=0.5 Pass NVNT n20 2437 Ant1 17.37 >=0.5 Pass NVNT n20 2462 Ant1 16.944 >=0.5 Pass NVNT n40 2422 Ant1 34.757 >=0.5 Pass NVNT n40 2437 Ant1 34.26 >=0.5 …
