2AMBA-T25Car MP3 Player

Dongguan Pinmi Electronic Technology Co., Ltd. [2020-04-08] Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Dongguan Pinmi Electronic Technology Co., Ltd. FCC ID: 2AMBA-T25 To Whom It May Concern: We, Dongguan Pinmi Electronic Technology Co., Ltd. hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number (2AMBA-T25) under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is (2020-04-08). The Limited Agency Agreement expires until further notice, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, [Signature] Dongguan Pinmi Electronic Technology Co., Ltd. Contact person: Zhanyuan Du

Dongguan Pinmi Electronic Technology Co., Ltd. Apr. 13, 2020 Federal Communication Commission Authorization and Evaluation Division FCC ID: 2AMBA-T25 Re: Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1: Block Diagram 2: Schematics 3: Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rules 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Dongguan Pinmi Electronic Technology Co., Ltd. Contact person: Zhanyuan Du

External Photos TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

FCC ID Label Location 20mm*10mm FCC ID: 2AMBA-T25

Internal Photos OPEN VIEW OF EUT INTERNAL VIEW OF EUT-1 INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 BT Antenna INTERNAL VIEW OF EUT-4 FM Antenna

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description Car MP3 Player Model Name T25, T15, T16, T17, T18, T19, T20, T21, T22, T23, T24, T50 ,T51, T52, T53, T55, T56, T57, T58, T59, T60, T35Q, T25S, T25Q, T25C, T35, T35C, T29, T32, T45Q, T45C, T46Q, T46C, T47, T48Q, T48C, T49Q, T49C, CP24, CP89, CP89Q, CP93, CP94, CP123, CP98.NX10, NX11, HL-t25s, AMT22, AM6EB, AM6EW, CAD6005, X7, V8, BT02, BT03, BT04, BT05, SRXA-ABFM46, SRXA-ABFM60, SRXA-ABFM50, Peakage S6, IPH-1088N, 68491760054, PT-736, PT-737, PT-805, VO2101, 7946, TRACER T1, MY2119, MY2121, NOVELEKA-FM1, NOVELEKA-FM2, SWM 3535, SWM 4545, SWM 4848, SWM 5858, T71, T74, EBH05045GA01 FCC ID 2AMBA-T25 2. EVALUATION METHOD According to 447498 D01 General RF Exposure Guidance v05 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. Where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation 3. CALCULATION According to the follow transmitter output power（P t ）formula： P t =（E x d） 2 /（30 x g t ） P t =transmitter output power in watts g t =numeric gain of the transmitting antenna (unitess) E=electric field strength in V/m d=measurement distance in meters (m) BT Pt= 6.657dBm=4.63mW The result for RF exposure evaluation SAR=(4.63mW /5mm) .[√2.402(GHz)]= 1.44<3.0 for 1-g SAR FM Pt=0.0000098mW The result for RF exposure evaluation SAR=(0.0000098mW /5mm) .[√0.0881(GHz)]= 0.00000059<3.0 for 1-g SAR Simultaneous transmission between Bluetooth and FM transmitter [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)]·[√f(GHz)/x] W/kg, for test separation distances ≤ 50 mm; where x = 7.5 for 1-g SAR and x = 18.75 for 10-g SAR. SAR=(1.44+0.00000059)/7.5=0.192W/kg<1.6W/kg 4. CONCLUSION The SAR evaluation is not required.

Page 1 of 23 FCC Test Report Report No.: AGC00697200301FE06 FCC ID : 2AMBA-T25 APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Car MP3 Player BRAND NAME : N/A MODEL NAME : See page 4 APPLICANT : Dongguan Pinmi Electronic Technology Co., Ltd. DATE OF ISSUE : Apr. 09, 2020 STANDARD(S) : FCC Part 15.239 REPORT VERSION : V1.0 Attestation of Global Compliance(Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.: AGC00697200301FE06 Page 2 of 23 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Apr. 09, 2020 Valid Initial Release Report No.: AGC00697200301FE06 Page 3 of 23 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY .......................................................................................................... 4 2. GENERAL INFORMATION ...................................................................................................................... 5 2.1.PRODUCT DESCRIPTION .................................................................................................................. 5 3. MEASUREMENT UNCERTAINTY............................................................................................................ 5 4. DESCRIPTION OF TEST MODES............................................................................................................ 5 5. SYSTEM TEST CONFIGURATION .......................................................................................................... 6 5.1. EQUIPMENT USED IN EUT SYSTEM ................................................................................................ 6 5.2. SUMMARY OF TEST RESULTS ......................................................................................................... 6 6. TEST FACILITY ........................................................................................................................................ 7 7. RADIATED EMISSION ............................................................................................................................. 8 7.1. MEASUREMENT PROCEDURE ........................................................................................................ 8 7.2.TEST SETUP ..................................................................................................................................... 10 7.3. TEST RESULTFOR FIELD STRENGTH OF FUNDAMENTAL .......................................................... 11 7.4. TEST RESULT FOR FIELD STRENGTH OF BAND EDGE EMISSION ............................................. 11 7.5. TEST RESULT FOR SPURIOUS EMISSION .................................................................................... 12 8. BANDWIDTH .......................................................................................................................................... 14 8.1. MEASUREMENT PROCEDURE ...................................................................................................... 14 8.2. TEST SETUP .................................................................................................................................... 14 8.3. TEST RESULT .................................................................................................................................. 15 APPENDIX A: PHOTOGRAPHS OF TEST SETUP ................................................................................... 17 APPENDIX B:PHOTOGRAPHS OF EUT ................................................................................................... 18 Report No.: AGC00697200301FE06 Page 4 of 23 1. VERIFICATION OF CONFORMITY Applicant Dongguan Pinmi Electronic Technology Co., Ltd. Address 2F, E block, Hongda Industrial Park, Shima Community, Tangxia Town, Dongguan City, Guangdong, China Manufacturer Dongguan Pinmi Electronic Technology Co., Ltd. Address 2F, E block, Hongda Industrial Park, Shima Community, Tangxia Town, Dongguan City, Guangdong, China Factory Dongguan Pinmi Electronic Technology Co., Ltd. Address 2F, E block, Hongda Industrial Park, Shima Community, Tangxia Town, Dongguan City, Guangdong, China Product Designation Car MP3 Player Brand Name N/A Test Model T25 Series Model T15,T16,T17, T18, T19, T20, T21, T22, T23, T24, T50, T51, T52, T53, T55, T56, T57, T58, T59, T60, T35Q, T25S, T25Q, T25C, T35, T35C, T29, T32, T45Q, T45C,T46Q, T46C, T47, T48Q, T48C, T49Q, T49C, CP24, CP89, CP89Q, CP93, CP94, CP123, CP98.NX10, NX11, HL-t25s, AMT22, AM6EB, AM6EW, CAD6005, X7, V8, BT02, BT03, BT04, BT05, SRXA-ABFM46, SRXA-ABFM60, SRXA-ABFM50, Peakage S6, IPH-1088N, 68491760054, PT-736, PT-737, PT-805, VO2101, 7946, TRACER T1, MY2119, MY2121, NOVELEKA-FM1, NOVELEKA-FM2, SWM 3535, SWM 4545, SWM 4848, SWM 5858, T71, T74, EBH05045GA01 Difference Description All the same except for the model name Date of test Mar. 12, 2020 to Apr. 09, 2020 Deviation No any deviation from the test method Condition of Test Sample Normal Test Result Pass Report Template AGCRT-US-BR/RF (2013-03-01) We hereby certify that: The above equipment was tested by Attestation of Global Compliance (Shenzhen) Co., Ltd. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with radiated emission limits of FCC part 15.239. Prepared By NiNi Guo (Project Engineer) Apr. 09, 2020 Reviewed By Max Zhang (Reviewer) Apr. 09, 2020 Approved By Forrest Lei (Authorized Officer) Apr. 09, 2020 Report No.: AGC00697200301FE06 Page 5 of 23 2. GENERAL INFORMATION 2.1.PRODUCT DESCRIPTION A major technical description of EUT is described as following Operation Frequency 88.1MHz-107.9MHz Field Strength(3m) 45.12dBuV/m(Peak)@3m Modulation FM Number of channels 199(Channel spacing 100kHz) Hardwar…

Text truncated - open the document above for the full version.

Test Setup Photos RADIATED EMISSION TEST SETUP BELOW 1G RADIATED EMISSION TEST SETUP ABOVE 1G
