2AMD8EM-001Bluetooth Sleeping Mask Headphone

BT SPEAKER MASK (SLEEP SOUNDS) PACKING LIST * BT SPEAKER MASK*1 * User manual*1 * USB charging cable*1 * Carry bag*1 PRODUCT SPECIFICATION Bluetooth version: V5.2 Function: Bluetooth, Sleep sounds, Hands-free Rated Voltage: 5V/100mA Rated Power: 70mW Speaker: 30mm SNR: ≥96dB Working Distance：10 Meters Battery：3.7V/200mAh Lithium battery Charging time: about 2.5 Hrs Play Bluetooth music time: 6-8Hrs Play sleep sounds time:more than 10 Hours Product size:450*110(MM) Frequency response: 20Hz-20kHz White noise source: 10 types CHARGING FUNCTION Use a USB cable to connect the headphone to USB charger or your computer USB port (Micro USB to USB Cable included). There is a notification LED light in our device, RED light shows that device is charging, Red light change into blue light mean fully charged. ( Note: There is a hidden charging port in the sleeping headphone that you can use it conveniently ) HOW TO CONNECT BLUETOOTH 1.Turn Bluetooth off when you're not using it. 2.Long press the “”button to turn on, the red light & blue light flash. 3.Double press “”to change mode, the blue light will flash. 4.Turn on Bluetooth with your phone, find device name“IAHB33”then connect. 5.You can enjoy music after Bluetooth connection. Note: Bluetooth devices can only be paired on a one-to-one basis, you can disconnect the Bluetooth on smart phone, or Triple press “”to disconnect the Bluetooth with the previous device when connect a new device, HOW TO FIT ON YOUR FACE 1. Gently place mask over face. 2. Adjust velcro length for optimal fit and comfort. 3. Gently adjust nose wing for optimal light blocking. INSIDE EARPLUG INSTRUCTION 1. Roll and compress earplug. 2. Reach over head and pull top of ear upward. Insert tapered end quickly into ear canal. Hold plug in until fully expanded. 3. Keep away from infants. OPERATING INSTRUCTION 1. Press once PLAY / STOP button to start playing, press once again to stop playing. 2. Long press Vol- for previous song. 3. Long press Vol+ for next song. 4. Press Vol - will constantly reduce volume to the minimum. 5. Press Vol+ will constantly increase volume to the max. 6. Double press will choose “white noise mode” / “bluetooth mode”. 7. Triple press will disconnect the Bluetooth on smart phone. TIMER & AUTOMATIC TURN OFF Remark: This is avaivable in both white noise mode and bluetooth mode. 1. Double press the Vol+ button for the first time with one “beep”, the product enters the automatically turn off mode in one hour. Then after one hour work, the device will turn off automatically. 2. Double press the Vol+ button for the second time with dual “beep”, the device will play normally and the will not turn off automatically. 3. Every time the device turns on, it will play normally without timing. When last scheduled timing not finished, it will turn off automatically based on the latest scheduled timing. BLUETOOTH HANDS-FREE CALLING For incoming call, you can press PLAY / STOP button to answer the phone. Tips!!! 1. Make sure the Bluetooth is opening in your phone and find device name“IAHB33”and connect. 2. Please take out the Bluetooth headphone before you wash it. 3. Bluetooth speakers could be adjustable for all head size. 4. Please check USB cable if the headphone can't be charge. 5. Please adjust the volume from your mobile or long press Vol+ if you can't hear any sound. 6. The sound may have a bit noise if there's environmental interference. WASHING INSTRUCTIONS The whole product is not waterproof, just the outside sleep mask can be washable. 1. Get the hidden headphone taken out from the inside holes of the sleep mask. Be caution of the cables inside of the unit, and get them out by gentle power, just in case a strong power to break it. 2. Hand wash only. 3. Water under 40°C ( 104°F ) 4. Don't tumble dry 5. Do not bleach HEADPHONE ASSEMBLY INSTRUCTIONS When assembling the headphones, please pay attention to the direction of the earphones. The mark "L" is the left side, and the mark "R" is the right side; the ones with letters (L, R) face front, and the ones without letters face rear. Installing it in the wrong direction will cause the volume to sound low. FCC Statement: This devicecomplieswithPart 15 of the FCC Rules.Operationis subjectto the followingtwo conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B Digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

Shenzhen Ground Enterprises Co.,Ltd Declaration on model difference We the undersigned hereby confirm that these models are identical, and all models have the same RF module and antenna, PCB layout , schematics and component. the difference is the model Numbers. Production name FCC ID Model no. Bluetooth Sleeping Mask Headphone 2AMD8EM-001 EM-001, IAHB33G Sincerely, James Cao Shenzhen Ground Enterprises Co.,Ltd Room607, Building F, MingYueHuaDu, Gonghe industrial Rd., XiXiang, Bao An District, Shenzhen, China

Shenzhen Ground Enterprises Co.,Ltd 2022-12-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (EUT Name: Bluetooth Sleeping Mask Headphone /Model: EM-001, IAHB33G) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Block Diagram ,Operational Description,Schematics) required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Sincerely, James Cao Shenzhen Ground Enterprises Co.,Ltd Room607, Building F, MingYueHuaDu, Gonghe industrial Rd., XiXiang, Bao An District, Shenzhen, China

Shenzhen Ground Enterprises Co.,Ltd 2022-12-15 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize DongGuan Anci Electronic Technology Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Sincerely, James Cao Shenzhen Ground Enterprises Co.,Ltd Room607, Building F, MingYueHuaDu, Gonghe industrial Rd., XiXiang, Bao An District, Shenzhen, China

ANT

RF EXPOSURE EVALUATION EUT Specification EUT Bluetooth Sleeping Mask Headphone Model Number EM-001, IAHB33G FCC ID 2AMD8EM-001 Antenna gain (Max) -0.58dBi Operation Frequency BT: 2402-2480MHz Input Rating DC 5V from adapter and DC 3.7V from battery Classification Per Stipulated Test Standard §15.247(i), §2.1093 Modulation GFSK, π/4-DQPSK， 8DPSK Max. output power 2.02dBm(0.001589W) Test Requirement: According to §15.247(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters with output power greater than the applicable low threshold require SAR evaluation to quality for TCB approval. One antenna is available for the EUT. The minimum separation distance is 5mm. BT DSS: According to KDB 447498, no stand-alone required for BT antenna, and no simultaneous SAR measurement is required. Signature: Tiger Xu Date: 2022-12-15 Transmit Frequency (MHz) Mode Measure d Power (dBm) Tune up Power (dBm) Max tune up power(dBm) Calculation Result 1-g SAR 2402 GFSK -2.31 -2±1 -1 0.442895 3 2441 GFSK -3.09 -3±1 -2 0.447766 3 2480 GFSK -3.73 -4±1 -3 0.155294 3 2402 Π/4-DQPSK 1.39 1±1 2 0.442895 3 2441 Π/4-DQPSK 0.27 0±1 1 0.447766 3 2480 Π/4-DQPSK -0.65 -2±1 0 0.452622 3 2402 8DPSK 2.02 2±1 3 0.442895 3 2441 8DPSK 0.96 1±1 2 0.447766 3 2480 8DPSK -0.08 0±1 1 0.452622 3

TRF No.: 01-R001-3A-BT TRF Originator: GTG TRF Date: 2022-06-29 Web: www.gtggroup.com E-mail: [email protected] Tel.: 86-400 755 8988 ELECTROMAGNETIC EMISSIONS COMPLIANCE REPORT INTENTIONAL RADIATOR CERTIFICATION TO FCC PART 15 SUBPART C REQUIREMENT OF Bluetooth Sleeping Mask Headphone Model No.: EM-001, IAHB33G Trademark: N/A FCC ID: 2AMD8EM-001 Report No.: E01A22110801F00101 Issue Date: December 15, 2022 Prepared for Shenzhen Ground Enterprises Co.,Ltd Room607, Building F, MingYueHuaDu, Gonghe industrial Rd., XiXiang, Bao An District, Shenzhen, China Prepared by Dong Guan Anci Electronic Technology Co., Ltd. 1-2 Floor, Building A, No.11, Headquarters 2 Road, Songshan, Lake Hi-tech Industrial Development Zone, Dongguan City, Guangdong Pr., China. This report shall not be reproduced, except in full, without the written approval of Dong Guan Anci Electronic Technology Co., Ltd. Page 2 of 97 Report No.: E01A22110801F00101 TRF No.: 01-R001-3A-BT Global Testing , Great Quality. VERIFICATION OF COMPLIANCE Applicant: Shenzhen Ground Enterprises Co.,Ltd Room607, Building F, MingYueHuaDu, Gonghe industrial Rd., XiXiang, Bao An District, Shenzhen, China Manufacturer: Shenzhen Ground Enterprises Co.,Ltd Room607, Building F, MingYueHuaDu, Gonghe industrial Rd., XiXiang, Bao An District, Shenzhen, China Product Description: Bluetooth Sleeping Mask Headphone Trade Mark: N/A Model Number: EM-001, IAHB33G We hereby certify that: The above equipment was tested by Dong Guan Anci Electronic Technology Co., Ltd.The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10-2013 and the energy emitted by the sample EUT tested as described in this report is in compliance with conducted and radiated emission limits of FCC Rules Part 15.247(2021). Date of Test : November 30, 2022 to December 02, 2022 Prepared by : Duke Liu/Editor Reviewer & Authorized Signer : Tiger Xu/ Supervisor Page 3 of 97 Report No.: E01A22110801F00101 TRF No.: 01-R001-3A-BT Global Testing , Great Quality. Modified Information Version Summary Revision Date Report No. Ver.1.0 Original Report / E01A22110801F00101 Page 4 of 97 Report No.: E01A22110801F00101 TRF No.: 01-R001-3A-BT Global Testing , Great Quality. Table of Contents 1. GENERAL INFORMATION .................................................................................................. 6 1.1 PRODUCT DESCRIPTION .................................................................................................................. 6 1.2 TEST METHODOLOGY ...................................................................................................................... 6 1.3 TEST FACILITY .................................................................................................................................. 7 2. SYSTEM TEST CONFIGURATION ..................................................................................... 8 2.1 EUT CONFIGURATION ..................................................................................................................... 8 2.2 EUT EXERCISE ................................................................................................................................ 8 2.3 TEST PROCEDURE ........................................................................................................................... 8 2.4 CONFIGURATION OF TESTED SYSTEM ............................................................................................ 9 3. SUMMARY OF TEST RESULTS ....................................................................................... 10 4. DESCRIPTION OF TEST MODES .................................................................................... 11 5. TEST SYSTEM UNCERTAINTY ........................................................................................ 12 6. CONDUCTED EMISSIONS TEST ..................................................................................... 13 6.1 MEASUREMENT PROCEDURE: ....................................................................................................... 13 6.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................. 13 6.3 MEASUREMENT EQUIPMENT USED: .............................................................................................. 13 6.4 MEASUREMENT RESULT: ................................................................................................................... 14 6.5 CO NDUCTED MEASUREMENT PHOTOS: ............................................................................................ 16 7. RADIATED EMISSION TEST ............................................................................................. 17 7.1 MEASUREMENT PROCEDURE ........................................................................................................ 17 7.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .............................................................. 19 7.3 MEASUREMENT EQUIPMENT USED: .................................................................................................. 20 7..4 RADIATED EMISSION LIMIT................................................................................................................ 21 7.5 MEASUREMENT RESULT .................................................................................................................. 22 7.5 RADIAT ED MEASUREMENT PHOTOS: ............................................................................................ 28 8. CHANNEL SEPARATION TEST ....................................................................................... 29 8.1 MEASUREMENT PROCEDURE ........................................................................................................ 29 8.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .............................................................. 29 8.3 MEASUREMENT EQUIPMENT USE…

Text truncated - open the document above for the full version.

Inverted F Antenna Specification Summary ITEMANT SPEC Model Name 2.4G ANT HorizontalVertical 2400MHz 2400MHz2500MHz2400MHz2400MHz 2500MHz Center Frequency -1.26-0.76-0.58-5.25-2.46-1.86 MAX. Gain -0.58dBi PolarizationHorizontal and Vertical Azimuth Beam Pattern Omni-directional Impedance50 Ohm Antenna Length 38.20mm Manufacture ZHUHAI JIELI TECHNOLOGY CO.,LTD Antenna Photo & Length (mm) Horizontal: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -40 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -1.26174 -30.0801 -7.18716 2450 -0.765802 -36.5604 -7.48023 2500 -0.585582 -22.0315 -6.59127 Vertical: 2400 MHz 2450 MHz 2500 MHz Power (dBm) Max: 0 Min: -30 Scale: 5/div Gain(dB) Frequency (MHz) Max Min Avg 2400 -5.2537 -22.1424 -12.4294 2450 -2.4652 -24.5837 -10.4702 2500 -1.86120 -29.5214 -9.20432 ANT Test Labs：Attestation of Global Compliance Co., Ltd.
