2AMHM-AD00A10055iTraMS Gen2A

CCU Gen2A | Operations Manual 1 | 20 Robert Bosch Engineering and Business Solutions Private Limited | September 19, 2020 CCU User Manual  Product Name: Connectivity Control Unit  Family Model Name: iTraMS CCU  Model Name: CU-303-0403 This preliminary document presents the status of the agreed specifications. It will be confirmed when all the validations has been completed with positive result CCU | User Manual 3 | 20 Robert Bosch Engineering and Business Solutions Private Limited | September 19, 2020 Table of Contents 1 Introduction .............................................................................................................................................................. 6 1.1 Objective ................................................................................................................................................................... 6 1.2 General ...................................................................................................................................................................... 6 1.3 Disclaimer ................................................................................................................................................................. 6 2 Copyright .................................................................................................................................................................. 6 3 Agreed Product Use ................................................................................................................................................. 7 3.1 Intended Use ............................................................................................................................................................. 7 4 Overview ................................................................................................................................................................... 8 5 Symbols Used........................................................................................................................................................... 8 6 Warranty and Service Clauses ................................................................................................................................ 8 7 Safety and Instructions ............................................................................................................................................ 8 7.1 Dos and Don’ts ......................................................................................................................................................... 8 7.2 Precautions for Installation ..................................................................................................................................... 9 8 Scope for Delivery .................................................................................................................................................... 9 9 Legal Requirements ................................................................................................................................................. 9 10 Device Description ................................................................................................................................................. 10 11 Installation .............................................................................................................................................................. 10 11.1 Installation of Cable Harness ................................................................................................................................ 10 12 Technical Specifications ........................................................................................................................................ 11 a. Digital Output.......................................................................................................................................................... 11 b. Bus (CAN0 and CAN1) ........................................................................................................................................... 11 c. Internal Memory ...................................................................................................................................................... 11 d. Power Requirements .............................................................................................................................................. 11 Annexure......................................................................................................................................................................... 12 1 Document Details .................................................................................................................................... 12 2 Document Revision History .................................................................................................................... 12 3 Abbreviations Used ................................................................................................................................. 12 4 EMC Recommendations .......................................................................................................................... 12 5 General Info .............................................................................................................................................. 13 6 Pin-Out details ......................................................................................................................................... 13 CCU | User Manual 4 | 20 Robert Bosch Engineering and Business Solutions Private Limited | September 19, 2020 6.1 Main Connector ......................................................................................................................................... 13 6.2 RF Connector .............................................................................................................…

Text truncated - open the document above for the full version.

FCC, Request for non-disclosure Date: 16-Mar-2020 RF_501, Issue 8 Page 1 of 1 Company Name: Robert Bosch Engineering & Business Solution Pvt. Ltd. Address: 123, Industrial Layout, Hosur Road, Koramangala, City: Bangalore - 560 095 Country: India To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2AMHM-AD00A10055 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: This document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor unfair advantage in the market. Date: March 16, 2020 Name and signature of applicant: Subbaramu G Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! The planned date should stated in the RF731 application form. 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Registered Office: Robert Bosch Engineering and Business Solutions Private Limited, 123, Industrial Layout, Hosur Road, Koramangala, Bengaluru - 560095, India Managing Director: Mr. Vijay Ratnaparkhe © Robert Bosch Engineering and Business Solutions Private Limited reserves all rights even in the event of industrial property rights. We reserve all rights of disposal such as copying and passing on to third parties. Robert Bosch Engineering and Business Solutions Private Limited (CIN: U72400KA1997PTC023164) 123, Industrial Layout, Hosur Road, Koramangala Bengaluru 560095 INDIA Tel +91 80 6657-5757 Fax +91 80 6657-1404 www.bosch-india-software.com To Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 13 March 2020 Subject: Authorized Individual Pursuant to the provisions of KDB 852134 D01 Authorized Policy Form 731, I, grantee contact, hereby authorize Subbaramu G to act on behalf of Robert Bosch Engineering and Business Solutions Private Limited for all matters relating to equipment authorization, including signing Form 731, attestations, and confidentiality request letters. This authorized individual may also assign another party to act as an authorized agent. This authorization is valid until further written notice from the grantee contact. Yours sincerely Pradeep TP Programme Manager Robert Bosch Engineering and Business Solutions Private Limited – (CIN: U72400KA1997PTC023164)

RF_160, Issue 04 Robert Bosch Engineering & Business Solution Pvt. Ltd. Declaration of Authorization We Name: Robert Bosch Engineering & Business Solution Pvt. Ltd. Address: 123, Industrial Layout, Hosur Road, Koramangala, City: Bangalore - 560 095 Country: India Declare that: Name Representative of agent: Ms. Melody Wu Agent Company name: BTL Inc. Address: 4F,No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist.114, City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: iTraMS Gen2A Type designation: CU-303-0403 Trademark: Bosch Validity/ expiry date: From October 5, 2020 to October 4, 2021 on our behalf. Date: October 6, 2020 City: Bangalore Name: Subbaramu G Function: Senior General Manager Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 1 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 2 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 3 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 4 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 5 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 6 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 7 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 8 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 9 of 21 External Antenna (Test Accessories) Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 10 of 21 External Antenna (Test Accessories) Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 11 of 21 Cable

,0 20 40 ,0 60 7U 80 IA\ BOSCH 0001 CCU JJ-MM-TT � AENSTAND10 076) 82 Made ifl rlndia FIELD318 PAMN HW 10 NOM A DOD A 10 055 5572156 F16 ■ �UL Logo ............ 20 FIELD198888888888888 FCC ID: 2AMHM-AD00A10055 30 FIELD1788888888 IC: 25763-AD00A10055 CU-303-0403 111111 11111 11111 1111 Label location

Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 12 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 13 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 14 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 15 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 16 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 17 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 18 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 19 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 20 of 21 Appendix No.: EP-1911T165-1 APPENDIX-EUT PHOTOS Project No.: 1911T165 Page 21 of 21

Report No.: BTL-FCCP-9-1911T165 Project No.: 1911T165 Page 1 of 6 Report Version: R02 FCC RF EXPOSURE REPORT FCC ID: 2AMHM-AD00A10055 Report No. : BTL-FCCP-9-1911T165 Equipment : iTraMS Gen2A Model Name : CU-303-0403 Brand Name : Bosch Applicant : Robert Bosch Engineering & Business Solution Pvt. Ltd. Address : 123, Industrial Layout, Hosur Road, Koramangala, Bengaluru, 560095 Bengaluru India Radio Function : Bluetooth EDR/ Bluetooth LE/WLAN 2.4G/RLAN 5G/WCDMA/LTE FCC Rule Part(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C Date of Receipt : 2019/11/27 Date of Test : 2019/11/27 ~ 2020/1/7 Issued Date : 2020/3/18 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Peter Chen, Engineer Approved by : Scott Hsu , Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-9-1911T165 Project No.: 1911T165 Page 2 of 6 Report Version: R02 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue 2020/3/9 R01 Revised report to address TCB’s comments. 2020/3/16 R02 Revised report to address TCB’s comments. 2020/3/18 Report No.: BTL-FCCP-9-1911T165 Project No.: 1911T165 Page 3 of 6 Report Version: R02 1. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna: For BT/LE/2.4GHz: Ant. Brand S/N Antenna Type Connector Gain (dBi) CH0 146153 Internal N/A 3.0 For 5GHz: Ant. Brand S/N Antenna Type Connector Gain (dBi) CH0 146153 Internal N/A 4.1 For WWAN: Ant. Brand Model Name Antenna Type Connector Gain (dBi) Note CH0 N/A PCB N/A 4 WCDMA Band II CH0 N/A PCB N/A 2.57 WCDMA Band V CH0 N/A PCB N/A 4 LTE Band 2 CH0 N/A PCB N/A 2.8 LTE Band 4 CH0 N/A PCB N/A 2.57 LTE Band 5 CH0 N/A PCB N/A 0 LTE Band 12 Ant. Brand Model Name Antenna Type Connector Gain (dBi) Note CH0 TAOGLAS MA250.A.LBI.001 Dipole N/A 3.37 WCDMA Band II CH0 TAOGLAS MA250.A.LBI.001 Dipole N/A 1.29 WCDMA Band V CH0 TAOGLAS MA250.A.LBI.001 Dipole N/A 3.37 LTE Band 2 CH0 TAOGLAS MA250.A.LBI.001 Dipole N/A 3.79 LTE Band 4 CH0 TAOGLAS MA250.A.LBI.001 Dipole N/A 1.29 LTE Band 5 CH0 TAOGLAS MA250.A.LBI.001 Dipole N/A 0.72 LTE Band 12 External Antenna (For evaluation only) Report No.: BTL-FCCP-9-1911T165 Project No.: 1911T165 Page 4 of 6 Report Version: R02 Band Max. gain for FCC MPE Limits Max. gain for Industry Canada MPE Limits Maximum gain to be compliant with all imits WCDMA Band II 12.5 9.1 9.1 WCDMA Band V 10.0 6.7 6.7 LTE Band 2 12.5 9.6 9.6 LTE Band 4 13.0 9.3 9.3 LTE Band 5 10.4 7.1 7.1 LTE Band 12 9.8 6.7 6.7 Output power including tune up tolerance Function Target power (dBm) Tolerance (dB) BT 1 ±1 BLE 7 ±1 WLAN 2.4G 18 ±1 RLAN 5GHz UNII-1 16 ±2 RLAN 5GHz UNII-2A 16 ±2 RLAN 5GHz UNII-2C 14 ±2 RLAN 5GHz UNII-3 13 ±2 WCDMA 23 ±1 LTE 24 ±1 Report No.: BTL-FCCP-9-1911T165 Project No.: 1911T165 Page 5 of 6 Report Version: R02 2. TEST RESULTS For BT: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Peak Output Power ( mW ) Power Density (mW/cm2) Limit of Power Density (mW/cm2) Test Result 3.00 1.9953 2 1.5849 0.00062943 1 Complies For LE: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Peak Output Power ( mW ) Power Density (mW/cm2) Limit of Power Density (mW/cm2) Test Result 3.00 1.9953 8 6.3096 0.00250582 1 Complies For 2.4GHz: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Peak Output Power ( mW ) Power Density (mW/cm2) Limit of Power Density (mW/cm2) Test Result 3.00 1.9953 19 79.4328 0.03154644 1 Complies For 5GHz UNII-1: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Peak Output Power ( mW ) Power Density (mW/cm2) Limit of Power Density (mW/cm2) Test Result 4.10 2.5704 18 63.0957 0.03228125 1 Complies For 5GHz UNII-2A: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Peak Output Power ( mW ) Power Density (mW/cm2) Limit of Power Density (mW/cm2) Test Result 4.10 2.5704 18 63.0957 0.03228125 1 Complies For 5GHz UNII-2C: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Peak Output Power ( mW ) Power Density (mW/cm2) Limit of Power Density (mW/cm2) Test Result 4.10 2.5704 16 39.8107 0.02036809 1 Complies For 5GHz UNII-3: Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Power (dBm) Peak Output Power ( mW ) Power Density (mW/cm2) Limit of Power Density (mW/cm2) Test Result 4.10 2.5704 15 31.6228 0.01617895 1 Complies Report No.: BTL-FCCP-9-1911T165 Project No.: 1911T165 Page 6 of 6 Report Version: R02 For WWAN: Mode Band Frequency (MHz) Antenna Gain (dBi) Max. Output Power (dBm) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) Test Result WCDMA Band II 1907.6 4 24 0.1255 1.0000 Complies WCDMA Band V 826.4 2.57 24 0.0903 0.5509 Complies LTE Band 2 1860.0 4 25 0.1580 1.0000 Complies LTE Band 4 1732.5 2.8 25 0.1199 1.0000 Complies LTE Band 5 836.5 2.57 25 0.1137 0.5577 Complies LTE Band 12 704.0 0 25 0.0629 0.4693 Complies For the max simultaneous transmission MPE: Maximum Bluetooth Power Density (mW/cm2) Maximum WLAN Power Density (mW/cm2) Maximum WWAN Power Density (mW/cm2) 0.0025 0.0323 0.1580 Simultaneous transmission of Bluetooth+WWAN 0.1605<1 Simultaneous transmission of WIFI+WWAN 0.1903<1 Note: (1) The calculated distance is 20 cm. End of Test Report

Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 1 of 97 Report Version: R01 FCC Radio Test Report FCC ID: 2AMHM-AD00A10055 Report No. : BTL-FCCP-5-1911T165 Equipment : iTraMS Gen2A Model Name : CU-303-0403 Brand Name : Bosch Applicant : Robert Bosch Engineering & Business Solution Pvt. Ltd. Address : 123, Industrial Layout, Hosur Road, Koramangala, Bengaluru, 560095 Bengaluru India Radio Function : WCDMA Band V, LTE Band 5 FCC Rule Part(s) : 47 CFR FCC Part 22 Subpart H 47 CFR FCC Part 2 ANSI/TIA/EIA-603-E-2016 FCC KDB 971168 D01 Power Meas License Digital Systems v03r01 Measurement Procedure(s) : ANSI C63.10-2013 Date of Receipt : 2019/11/27 Date of Test : 2019/11/27 ~ 2020/1/7 Issued Date : 2020/3/16 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Peter Chen, Engineer Approved by : Scott Hsu , Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 2 of 97 Report Version: R01 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 3 of 97 Report Version: R01 Table of Contents Page REPORT ISSUED HISTORY 5 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF EUT 8 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATIONOFSYSTEMTESTED 11 3.4 DESCRIPTION OF SUPPORT UNITS 11 3 . TEST RESULT 12 3.1 RADIATED POWER MEASUREMENT 12 3.1.1 LIMIT 12 3.1.2 TEST PROCEDURES 12 3.1.3 TEST SETUP LAYOUT 12 3.1.4 TEST DEVIATION 12 3.1.5 TEST RESULTS 12 3.2 OCCUPIED BANDWIDTH MEASUREMENT 13 3.2.1 TEST PROCEDURES 13 3.2.2 TEST SETUP LAYOUT 13 3.2.3 TEST DEVIATION 13 3.2.4 TEST RESULTS 13 3.3 CONDUCTED SPURIOUS EMISSIONS MEASUREMENT 14 3.3.1 LIMIT 14 3.3.2 TEST PROCEDURES 14 3.3.3 TEST SETUP LAYOUT 14 3.3.4 TEST DEVIATION 14 3.3.5 TEST RESULTS 14 3.4 RADIATED SPURIOUS EMISSIONS MEASUREMENT 15 3.4.1 LIMIT 15 3.4.2 TEST PROCEDURES 15 3.4.3 TEST SETUP LAYOUT 15 3.4.4 TEST DEVIATION 16 3.4.5 TEST RESULTS (30MHZ TO 1000MHZ) 16 3.4.6 TEST RESULTS (ABOVE 1000MHZ) 16 3.5 BAND EDGE MEASUREMENT 17 3.5.1 LIMIT 17 3.5.2 TEST PROCEDURES 17 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 4 of 97 Report Version: R01 Table of Contents Page 3.5.3 TEST SETUP LAYOUT 17 3.5.4 TEST DEVIATION 17 3.5.5 TEST RESULTS 17 3.6 PEAK TO AVERAGE RATIO MEASUREMENT 18 3.6.1 LIMIT 18 3.6.2 TEST PROCEDURES 18 3.6.3 TEST SETUP LAYOUT 18 3.6.4 TEST DEVIATION 18 3.6.5 TEST RESULTS 18 3.7 FREQUENCY STABILITY MEASUREMENT 19 3.7.1 LIMIT 19 3.7.2 TEST PROCEDURES 19 3.7.3 TEST SETUP LAYOUT 19 3.7.4 TEST DEVIATION 19 3.7.5 TEST RESULTS 19 4. LIST OF MEASUREMENT EQUIPMENTS 20 5. EUT TEST PHOTOS 21 6. EUT PHOTOS 21 APPENDIX A - RADIATED POWER 22 APPENDIX B - OCCUPIED BANDWIDTH 50 APPENDIX C - CONDUCTED SPURIOUS EMISSIONS 60 APPENDIX D - RADIATED SPURIOUS EMISSIONS (30MHZ TO 1000MHZ) 66 APPENDIX E - RADIATED SPURIOUS EMISSIONS (ABOVE 1000MHZ) 75 APPENDIX F - BAND EDGE 84 APPENDIX G - PEAK TO AVERAGE RATIO 90 APPENDIX H - FREQUENCY STABILITY 96 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 5 of 97 Report Version: R01 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. 2020/3/3 R01 Revised report to address TCB’s comments. 2020/3/16 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 6 of 97 Report Version: R01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part 22 Subpart H & Part 2 Standard(s) Section Test Item Judgment Remark 2.1046 22.913(a)(5) Effective Radiated Power PASS ------ 2.1049 Occupied Bandwidth PASS ------ 2.1051 22.917(a) Conducted Spurious Emissions PASS ------ 2.1053 22.917(a) Radiated Spurious Emissions PASS ------ 22.917(a) Band Edge Measurements PASS ------ - Peak To Average Ratio PASS Record Only 2.1055 22.355 Frequency Stability PASS ------ Note: (1) “N/A” deno…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 89 of 97 Report Version: R01 LTE Band 5_10M Spectrum Plot 1RB#0 1RB#49 Channel 20450 Channel 20600 50RB#0 Channel 20450 Channel 20600 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 90 of 97 Report Version: R01 APPENDIX G - PEAK TO AVERAGE RATIO Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 91 of 97 Report Version: R01 WCDMA Band V_WCDMA Spectrum Plot 4132 4182 4233 - Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 92 of 97 Report Version: R01 LTE Band 5_1.4M Spectrum Plot QPSK-20407 QPSK-20525 QPSK-20643 16QAM-20407 16QAM-20525 16QAM-20643 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 93 of 97 Report Version: R01 LTE Band 5_3M Spectrum Plot QPSK-20415 QPSK-20525 QPSK-20635 16QAM-20415 16QAM-20525 16QAM-20635 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 94 of 97 Report Version: R01 LTE Band 5_5M Spectrum Plot QPSK-20425 QPSK-20525 QPSK-20625 16QAM-20425 16QAM-20525 16QAM-20625 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 95 of 97 Report Version: R01 LTE Band 5_10M Spectrum Plot QPSK-20450 QPSK-20525 QPSK-20600 16QAM-20450 16QAM-20525 16QAM-20600 Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 96 of 97 Report Version: R01 APPENDIX H - FREQUENCY STABILITY Report No.: BTL-FCCP-5-1911T165 Project No.: 1911T165 Page 97 of 97 Report Version: R01 Test Mode WCDMA Band V_CH4182 & LTE Band 5_CH20525 Temperature vs. Frequency Stabiility 1.4MHz 3MHz 5MHz 10MHz -40 0.0025 0.0102 0.0107 0.0099 0.0094 2.5 -30 0.0024 0.0088 0.0092 0.0086 0.0083 2.5 -20 0.0029 0.0097 0.009 0.0067 0.0069 2.5 -10 0.0025 0.0081 0.0082 0.0076 0.0057 2.5 0 0.0028 0.0066 0.0059 0.005 0.0064 2.5 10 0.0028 0.0047 0.0051 0.0045 0.0049 2.5 20 0.0029 0.0028 0.0034 0.0029 0.0023 2.5 30 0.0026 0.0016 0.0018 0.0006 0.0013 2.5 40 0.0025 0.0009 -0.0002 -0.0009 -0.0003 2.5 50 0.0029 -0.0009 -0.0031 -0.0021 -0.0016 2.5 60 0.0024 -0.0017 -0.0026 -0.0034 -0.0029 2.5 70 0.0027 -0.0021 -0.0049 -0.0051 -0.0042 2.5 80 0.0025 -0.0037 -0.0059 -0.0044 -0.0038 2.5 90 0.0029 -0.0052 -0.0067 -0.0063 -0.0056 2.5 100 0.003 -0.0066 -0.0081 -0.0072 -0.0072 2.5 105 0.0027 -0.0079 -0.0087 -0.0089 -0.0079 2.5 Limit(ppm) Frequency Error(ppm) LTE Band5 WCDMA Temp Voltage vs. Frequency Stability 1.4MHz3MHz5MHz10MHz High Voltage0.0030.00280.00370.00330.00282.5 Normal Voltage0.00270.00260.00370.00310.00262.5 Low Voltage0.00260.00250.00350.00310.00252.5 LTE Band5 WCDMA Voltage Frequency Error(ppm) Limit(ppm) End of Test Report

Report No.: BTL-FCCP-6-1911T165 Project No.: 1911T165 Page 1 of 109 Report Version: R01 FCC Radio Test Report FCC ID: 2AMHM-AD00A10055 Report No. : BTL-FCCP-6-1911T165 Equipment : iTraMS Gen2A Model Name : CU-303-0403 Brand Name : Bosch Applicant : Robert Bosch Engineering & Business Solution Pvt. Ltd. Address : 123, Industrial Layout, Hosur Road, Koramangala, Bengaluru, 560095 Bengaluru India Radio Function : WCDMA Band II, LTE Band 2 FCC Rule Part(s) : 47 CFR FCC Part 24 Subpart E 47 CFR FCC Part 2 ANSI/TIA/EIA-603-E-2016 KDB 971168 D01 Power Meas License Digital Systems v03r01 Measurement Procedure(s) : ANSI C63.10-2013 Date of Receipt : 2019/11/27 Date of Test : 2019/11/27 ~ 2020/1/7 Issued Date : 2020/3/16 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Peter Chen, Engineer Approved by : Scott Hsu , Manager BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-6-1911T165 Project No.: 1911T165 Page 2 of 109 Report Version: R01 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. P…

Text truncated - open the document above for the full version.
