2AMLF-VL110LTE Vehicle Terminal

Rev6/28/2024 ShenzhenJimiIoTCo.,Ltd. 3-4/F,BlockA,Building#7,ShenzhenInternationalInnovationValley,Dashi1stRoad,NanshanDistrict, Shenzhen,Guangdong,China FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:November12,2024 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2AMLF-VL110 ShenzhenJimiIoTCo.,Ltd.certifiesthattheequipmentforwhichauthorizationissoughtisnot“covered” equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903oftheFCC rules. Sincerely, ContactPerson:YiXie E-mail:[email protected] Rev6/28/2024

Rev6/28/2024 ShenzhenJimiIoTCo.,Ltd. 3-4/F,BlockA,Building#7,ShenzhenInternationalInnovationValley,Dashi1stRoad,NanshanDistrict, Shenzhen,Guangdong,China FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:November12,2024 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2AMLF-VL110 ShenzhenJimiIoTCo.,Ltd..certifiesthat,asofthedateofthefilingoftheapplication,theapplicantis notidentifiedontheCoveredListasanentityproducing“covered”equipment. Sincerely, ContactPerson:YiXie E-mail:[email protected]

， 臣c5) JACS Solutions, Inc. Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 10-19-2024 Ref: Attestation Statements Part 2.911(d)(7) Filing FRN ：0026625269 （Shenzhen Jimi IoT Co., Ltd.） FCC ID: 2AMLF-VL110 Shenzhen Jimi loT Co., Ltd. certifies that, as of the date of the filing of the application,」ACS Solutions, Inc.. is our designated U.S. agent for service of process for the above referenced FCC ID. JACS Solutions, Inc. a ccepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. S henzhen」imi loT Co., Ltd. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for s ervice of process for the above referenced FCC ID. Designated U.S. Agent Information: Name:」ACS Solutions, Inc. Adaress: 809 Pinnacle Drive, Suite R, Linthicum Heights, MD 21090 FRN: · 0024561227 Contact Person: Candy Zhang Email: [email protected] S henzhen J imi IoT Co., Ltd. YI Xie [《；乒 JACS Solutions, Inc. Candy_ Zhang 」ACS Solutions, Inc. 809 Pinnacle Drive, STE R, Linthicum Heights, MD 21090

ShenzhenJimiIoTCo.,Ltd. Date:Nov.7,2024 To:FederalCommunicationsCommission, Authorization&EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD21046 ToWhomItMayConcern: ShenzhenJimiIoTCo.,Ltd.theundersigned,herebyauthorizesMr.WuXuewenfromShenzhen BALUNTechnologyCo.,Ltd.,toactonthebehalfoftheShenzhenJimiIoTCo.,Ltd.solelyin mattersrelatingtotheapplicationforanFCCequipmentauthorizationforFCCID:2AMLF- VL110includingthesigningofdocumentsinconnectionwiththisApplication.Necessaryacts carriedoutbyShenzhenBALUNTechnologyCo.,Ltd.inconnectionwiththeApplicationshall havethesameeffectasactsoftheShenzhenJimiIoTCo.,Ltd. ShenzhenJimiIoTCo.,Ltd.alsoherebycertifythatnopartytothisapplicationissubjecttoa denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.Section862. YoursSincerely, Printname:YiXie Title:manager ShenzhenJimiIoTCo.,Ltd.

Updatedon2005/1/5byElisNg DECLARATIONOFIDENTITY ShenzhenJimiIoTCo.,Ltd.: ModelNumber:VL110C SerialmodelNo VL110 、 C410 BrandName:JimiIoT ProductName:LTEVehicleTerminal There’snodifferencewiththePCBLayout,ElectricalPartsofthe originalproduct.Themajordifferenceis: 1 Onlythemodelnamesaredifferent. Remarks: Sincerelyyours, ContactPerson:Xieyi Company:ShenzhenJimiIoTCo.,Ltd. Email:[email protected] Date:2024.11.12

ShenzhenJimiIoTCo.,Ltd. 3-4/F,BlockA,Building#7,ShenzhenInternationalInnovationValley,Dashi1stRoad,NanshanDistrict,Shenzhen, Guangdong,China To:FederalCommunicationsCommission, Authorization&EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD21046 RE:ShenzhenJimiIoTCo.,Ltd. FCCID:2AMLF-VL110 FCCCertificationConfidentialityRequest Gentlemen: Thisletteristocomplywith47CFR0.457and0.459pertainingtoconfidentiality material.ShenzhenJimiIoTCo.,Ltd.requeststhatthefollowingdocumentsregardingthis submissionforFCCID:2AMLF-VL110bekeptLong-Termconfidential: ExhibitTypeFileName BlockDiagramBlockDiagram.pdf SchematicsSchematics.pdf OperationalDescriptionOperationalDescription.pdf PartlistBOM.pdf Tune-Up-ProcedureTuneupprocedure.pdf Andbelowexhibitkeptshort-termconfidential(180days): ExhibitTypeFileName ExternalPhotos ExternalPhotos.pdf InternalPhotos InternalPhotos.pdf TestSetupPhotos TestSetupPhotos.pdf UsersManuals UsersManual.pdf Thosedocumentscontaindetailedsystemandequipmentdescriptionandrelated informationabouttheproductwhichShenzhenJimiIoTCo.,Ltd.considerstobeconfidential proprietary,acustomdesignand,otherwise,notreleasabletothegeneralpublic.Sincethis designisabasisformwhichfuturetechnologicalproductswillevolve,ShenzhenJimiIoTCo., Ltd.considersthisinformationwouldbeofbenefittoitscompetitors,andthatthedisclosure oftheinformationinthesedocumentswouldgivecompetitorsanunfairadvantageinthe market. Thankyouforyourattentiontothismatter. YoursSincerely, NameoftheManager:YiXie E-mail:[email protected] Date:2024/11/12 Signature:

VL110C C_EM01 Operating Voltage LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 Cellular FCC ID:2AMLF-VL110 Contains FCC ID:2AMLFXQ600-LA IMEI:357301091884238(LA) VL110 C_EM01 Operating Voltage LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 Cellular FCC ID:2AMLF-VL110 Contains FCC ID:2AMLFXQ600-LA IMEI:357301091884238(LA) C410 C_EM01 Operating Voltage LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 Cellular FCC ID:2AMLF-VL110 Contains FCC ID:2AMLFXQ600-LA IMEI:357301091884238(LA)

Report No.: BL-SZ2490757-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 11 Web: www.titcgroup.com Template No.: TRP-FCC-Mobile (2023-10-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: Shenzhen Jimi IoT Co., Ltd. Address: 3-4/F, Block A, Building #7, Shenzhen International Innovation Valley, Dashi 1st Road, Nanshan District, Shenzhen, Guangdong, China Equipment Type: LTE Vehicle Terminal Model Name: VL110C (refer section 2.3) Brand Name: JimiIoT FCC ID: 2AMLF-VL110 Test Standard: 47 CFR Part 2.1091 KDB 447498 D04 v01 Sample Arrival Date: Sep. 18, 2024 Test Date: Sep. 18, 2024 - Oct. 15, 2024 Date of Issue: Nov. 08, 2024 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Xu Rui Checked by: Liyao Zong Approved by: Tolan Tu (Testing Director) _______________ _______________ _______________ Report No.: BL-SZ2490757-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 11 Web: www.titcgroup.com Template No.: TRP-FCC-Mobile (2023-10-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Content Rev. 01 Nov. 08, 2024 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ........................................................................................................ 3 1.1 Test Laboratory ............................................................................................................ 3 1.2 Test Location ................................................................................................................ 3 2 PRODUCT INFORMATION ....................................................................................................... 4 2.1 Applicant Information .................................................................................................... 4 2.2 Manufacturer Information .............................................................................................. 4 2.3 General Description for Equipment under Test (EUT) ................................................... 4 2.4 Technical Information ................................................................................................... 5 3 SUMMARY OF TEST RESULT ................................................................................................. 6 3.1 Test Standards ............................................................................................................. 6 3.2 Limit Standards ............................................................................................................. 6 4 DEVICE CATEGORY AND LEVELS LIMITS ............................................................................. 7 5 ASSESSMENT RESULT ........................................................................................................... 9 5.1 Output Power ............................................................................................................... 9 5.2 Tune-up power ........................................................................................................... 10 5.3 RF Exposure Evaluation Result .................................................................................. 10 5.4 Conclusion .................................................................................................................. 10 Report No.: BL-SZ2490757-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 11 Web: www.titcgroup.com Template No.: TRP-FCC-Mobile (2023-10-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1 GENERAL INFORMATION 1.1 Test Laboratory Name Shenzhen BALUN Technology Co., Ltd. Address Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Phone Number +86 755 6685 0100 1.2 Test Location Name Shenzhen BALUN Technology Co., Ltd. Location Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 1/F, Building B, Ganghongji High-tech Intelligent Industrial Park, No. 1008, Songbai Road, Yangguang Community, Xili Sub-district, Nanshan District, Shenzhen, Guangdong Province, P. R. China Accreditation Certificate The laboratory is a testing organization accredited by FCC as a accredited testing laboratory. The designation number is CN1196. Report No.: BL-SZ2490757-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 4 / 11 Web: www.titcgroup.com Template No.: TRP-FCC-Mobile (2023-10-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China 2 PRODUCT INFORMATION 2.1 Applicant Information Applicant Shenzhen Jimi IoT Co., Ltd. Address 3-4/F, Block A, Building #7, Shenzhen International Innovation Valley, Dashi 1st Road, Nanshan District, Shenzhen, Guangdong, China 2.2 Manufacturer Information Manufacturer Shenzhen Jimi IoT Co., Ltd. Address 3-4/F, Block A, Building #7, Shenzhen International Innovation Valley, Dashi 1st Road, Nanshan District, Shenzhen, Guangdong, China 2.3 General Description for Equipment under Test (EUT) EUT Name LTE Vehicle Terminal Model Name Under Test VL110C Series Model Name VL110, C410 Description of Model name differentiation All models are same with electrical parameters and internal circuit structure, but only differ in model name. (this information provided by the applicant) Hardware Version VL110_MB_V1.0 Software Version VL110_VL110C_WABI_LA_V1.3_CTA_240903.1635 Dimensions (Approx.) N/A Weight (Approx.) N/A Report No.: BL-SZ2490757-701 Tel: +86-755-66850100 E-mail: [email protected] Page No. 5 / 11 Web: www.titcgroup.com Template No.: TRP-FCC-Mobile (2023-10-07) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Sh…

Text truncated - open the document above for the full version.

Document No: BL-SZ2490757 Page 1 of 33 A.7 Field Strength of Spurious Radiation Document No: BL-SZ2490757 Page 2 of 33 BAND:GSM850,Channel:Low range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 824.236 -50.51 1.96 -13.0 37.51 142.00 Horizontal Horizontal N/A 869.244 -46.48 2.10 -13.0 33.48 214.00 Horizontal Horizontal N/A 1648.400 -54.60 -5.54 -13.0 41.60 190.00 Horizontal Horizontal Pass 3170.500 -49.08 5.50 -13.0 36.08 35.00 Horizontal Horizontal Pass 4860.000 -46.18 7.77 -13.0 33.18 142.00 Horizontal Horizontal Pass 7860.750 -37.93 16.68 -13.0 24.93 162.00 Horizontal Horizontal Pass Document No: BL-SZ2490757 Page 3 of 33 BAND:GSM850,Channel:Low range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 824.188 -61.08 1.96 -13.0 48.08 215.00 Vertical Horizontal N/A 869.147 -49.15 2.10 -13.0 36.15 260.00 Vertical Horizontal N/A 1359.800 -56.22 -4.37 -13.0 43.22 345.00 Vertical Horizontal Pass 3162.000 -49.15 5.29 -13.0 36.15 175.00 Vertical Horizontal Pass 5180.250 -45.94 8.35 -13.0 32.94 286.00 Vertical Horizontal Pass 7495.750 -37.93 16.70 -13.0 24.93 239.00 Vertical Horizontal Pass Document No: BL-SZ2490757 Page 4 of 33 BAND:GSM850,Channel:Mid range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 836.604 -36.04 2.21 -13.0 23.04 41.00 Horizontal Horizontal N/A 881.612 -45.84 2.45 -13.0 32.84 218.00 Horizontal Horizontal N/A 1673.500 -54.01 -5.08 -13.0 41.01 149.00 Horizontal Horizontal Pass 3124.750 -50.74 4.04 -13.0 37.74 54.00 Horizontal Horizontal Pass 4868.500 -45.74 7.77 -13.0 32.74 345.00 Horizontal Horizontal Pass 7856.250 -38.02 16.45 -13.0 25.02 54.00 Horizontal Horizontal Pass Document No: BL-SZ2490757 Page 5 of 33 BAND:GSM850,Channel:Mid range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 836.652 -41.71 2.21 -13.0 28.71 50.00 Vertical Horizontal N/A 881.514 -42.99 2.45 -13.0 29.99 208.00 Vertical Horizontal N/A 1743.400 -55.70 -5.01 -13.0 42.70 56.00 Vertical Horizontal Pass 2931.000 -50.37 2.80 -13.0 37.37 282.00 Vertical Horizontal Pass 5676.750 -45.62 8.15 -13.0 32.62 99.00 Vertical Horizontal Pass 7855.250 -38.07 16.37 -13.0 25.07 109.00 Vertical Horizontal Pass Document No: BL-SZ2490757 Page 6 of 33 BAND:GSM850,Channel:High range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 848.729 -48.47 2.40 -13.0 35.47 154.00 Horizontal Horizontal N/A 893.882 -44.23 2.32 -13.0 31.23 212.00 Horizontal Horizontal N/A 1697.800 -55.02 -5.37 -13.0 42.02 193.00 Horizontal Horizontal Pass 3201.250 -49.45 3.50 -13.0 36.45 133.00 Horizontal Horizontal Pass 4835.750 -46.33 7.61 -13.0 33.33 360.00 Horizontal Horizontal Pass 7871.250 -37.50 17.07 -13.0 24.50 220.00 Horizontal Horizontal Pass Document No: BL-SZ2490757 Page 7 of 33 BAND:GSM850,Channel:High range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 848.680 -55.81 2.40 -13.0 42.81 234.00 Vertical Horizontal N/A 893.833 -41.18 2.31 -13.0 28.18 208.00 Vertical Horizontal N/A 1345.800 -55.05 -4.51 -13.0 42.05 29.00 Vertical Horizontal Pass 2770.600 -52.36 0.50 -13.0 39.36 360.00 Vertical Horizontal Pass 4852.750 -46.24 7.69 -13.0 33.24 337.00 Vertical Horizontal Pass 7494.000 -38.10 16.75 -13.0 25.10 220.00 Vertical Horizontal Pass Document No: BL-SZ2490757 Page 8 of 33 BAND:GSM1900,Channel:Low range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 147.661 -67.38 -15.92 -13.0 54.38 81.00 Horizontal Horizontal Pass 1850.400 -29.13 -3.52 -13.0 16.13 158.00 Horizontal Horizontal N/A 1930.300 -37.55 -3.10 -13.0 24.55 271.00 Horizontal Horizontal N/A 5550.750 -39.28 7.29 -13.0 26.28 0.00 Horizontal Horizontal Pass 7860.000 -36.82 16.63 -13.0 23.82 129.00 Horizontal Horizontal Pass 17813.037 -30.38 26.31 -13.0 17.38 116.00 Horizontal Horizontal Pass Document No: BL-SZ2490757 Page 9 of 33 BAND:GSM1900,Channel:Low range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 31.261 -52.05 -20.95 -13.0 39.05 223.00 Vertical Horizontal Pass 1850.400 -44.79 -3.52 -13.0 31.79 223.00 Vertical Horizontal N/A 1930.400 -50.73 -3.14 -13.0 37.73 314.00 Vertical Horizontal N/A 5550.750 -37.77 7.29 -13.0 24.77 35.00 Vertical Horizontal Pass 12279.513 -34.88 20.65 -13.0 21.88 8.00 Vertical Horizontal Pass 17813.400 -31.09 26.31 -13.0 18.09 205.00 Vertical Horizontal Pass Document No: BL-SZ2490757 Page 10 of 33 BAND:GSM1900,Channel:Mid range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 150.911 -67.86 -16.05 -13.0 54.86 61.00 Horizontal Horizontal Pass 1879.700 -53.91 -3.01 -13.0 40.91 151.00 Horizontal Horizontal N/A 1960.300 -38.22 -4.44 -13.0 25.22 278.00 Horizontal Horizontal N/A 3950.000 -48.22 4.87 -13.0 35.22 45.00 Horizontal Horizontal Pass 5640.250 -39.66 8.17 -13.0 26.66 0.00 Horizontal Horizontal Pass 17636.137 -30.24 25.58 -13.0 17.24 328.00 Horizontal Horizontal Pass Document No: BL-SZ2490757 Page 11 of 33 BAND:GSM1900,Channel:Mid range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 31.407 -52.41 -20.85 -13.0 39.41 278.00 Vertical Horizontal Pass 899.799 -64.45 2.23 -13.0 51.45 208.00 Vertical Horizontal Pass 1960.200 -47.89 -4.45 -13.0 34.89 57.00 Vertical Horizontal N/A 5640.250 -40.60 8.17 -13.0 27.60 12.00 Vertical Horizontal Pass 7591.250 -38.16 16.20 -13.0 25.16 167.00 Vertical Horizontal Pass 17806.512 -31.30 26.39 -13.0 18.30 83.00 Vertical Horizontal Pass Document No: BL-SZ2490757 Page 12 of 33 BAND:GSM1900,Channel:High range Frequency (MHz) Result (dBm) Factor (dB) Limit (dBm) Margin (dB) Table (o) ANT EUT Verdict 147.322 -67.23 -15.88 -13.0 54.23 76.00 Horizontal Horizontal Pass 1990.000 -37.59 -4.40 -13.0 24.59 282.00 Horizontal Horizontal N/A 3915.750 -49.36 5.03 -13.0 36.36 82.00 Horizontal Horizontal Pass 5729.250 …

Text truncated - open the document above for the full version.

Report No.: BL-SZ2490757-501 Tel: +86-755-66850100 E-mail: [email protected] Page No. 1 / 66 Web: www.titcgroup.com Template No.: TRP-FCC (2024-06) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China TEST REPORT Applicant: Shenzhen Jimi IoT Co., Ltd. Address: 3-4/F, Block A, Building #7, Shenzhen International Innovation Valley, Dashi 1st Road, Nanshan District, Shenzhen, Guangdong, China Equipment Type: LTE Vehicle Terminal Model Name: VL110C (refer section 2.3) Brand Name: JimiIoT FCC ID: 2AMLF-VL110 Test Standard: 47 CFR Part 2 (Others refer to chapter 3.1) Sample Arrival Date: Sep. 18, 2024 Test Date Sep. 18, 2024 - Oct. 15, 2024 Date of Issue: Nov. 08, 2024 ISSUED BY: Shenzhen BALUN Technology Co., Ltd. Tested by: Guo Jianxin Checked by: Wu Huihui Approved by: Tolan Tu (Testing Director) _______________ _______________ _______________ Report No.: BL-SZ2490757-501 Tel: +86-755-66850100 E-mail: [email protected] Page No. 2 / 66 Web: www.titcgroup.com Template No.: TRP-FCC (2024-06) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China Revision History Version Issue Date Revisions Content Rev. 01 Nov. 08, 2024 Initial Issue TABLE OF CONTENTS 1 GENERAL INFORMATION ........................................................................................................ 4 1.1 Test Laboratory ................................................................................................................... 4 1.2 Test Location ....................................................................................................................... 4 2 PRODUCT INFORMATION ....................................................................................................... 5 2.1 Applicant Information ........................................................................................................... 5 2.2 Manufacturer Information .................................................................................................... 5 2.3 General Description for Equipment under Test (EUT) ......................................................... 5 2.4 Technical Information .......................................................................................................... 6 3 SUMMARY OF TEST RESULTS ............................................................................................... 7 3.1 Test Standards .................................................................................................................... 7 3.2 Test Verdict ......................................................................................................................... 8 3.3 Measurement Uncertainty ................................................................................................... 9 4 GENERAL TEST CONFIGURATIONS .................................................................................... 10 4.1 Test Environments ............................................................................................................ 10 4.2 Test Equipment List ........................................................................................................... 10 4.3 Test Configurations ........................................................................................................... 12 4.4 Test Setup ......................................................................................................................... 15 5 TEST ITEMS ........................................................................................................................... 17 5.1 Transmitter Radiated Power (EIRP/ERP) .......................................................................... 17 5.2 Peak to Average Ratio....................................................................................................... 20 5.3 Occupied Bandwidth ......................................................................................................... 22 5.4 Frequency Stability ............................................................................................................ 24 5.5 Spurious Emission at Antenna Terminals .......................................................................... 26 5.6 Band Edge ........................................................................................................................ 30 5.7 Field Strength of Spurious Radiation ................................................................................. 34 Report No.: BL-SZ2490757-501 Tel: +86-755-66850100 E-mail: [email protected] Page No. 3 / 66 Web: www.titcgroup.com Template No.: TRP-FCC (2024-06) Add: Block B, 1/F, Baisha Science and Technology Park, Shahe Xi Road, Nanshan District, Shenzhen, Guangdong Province, P. R. China ANNEX A TEST RESULTS ......................................................................................................... 38 A.1 Transmitter Radiated Power (EIRP/ERP) .......................................................................... 38 A.2 Peak to Average Ratio....................................................................................................... 63 A.3 Occupied Bandwidth ......................................................................................................... 63 A.4 Frequency Stability ............................................................................................................ 63 A.5 Spurious Emission at Antenna Terminals .......................................................................... 63 A.6 Band Edge ........................................................................................................................ 63 A.1 Field Strength of Spurious Radiation ................................................................................. 64 ANNEX B TEST SETUP PHOTOS ..........................................................…

Text truncated - open the document above for the full version.

Document No: BL-SZ2270935 Page 1 of 38 Annex A.2 Peak to Average Ratio Document No: BL-SZ2270935 Page 2 of 38 1. LTE_Band2 1.1. LTE Peak to Average Ratio(NTNV)(Subtest:1, Channel:18700, Bandwidth:20, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1860 0.1 4.97 13 Pass Document No: BL-SZ2270935 Page 3 of 38 1.2. LTE Peak to Average Ratio(NTNV)(Subtest:2, Channel:18700, Bandwidth:20, Modulation:QPSK, RB Number: 100, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1860 0.1 5.58 13 Pass Document No: BL-SZ2270935 Page 4 of 38 1.3. LTE Peak to Average Ratio(NTNV)(Subtest:3, Channel:18700, Bandwidth:20, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1860 0.1 5.67 13 Pass Document No: BL-SZ2270935 Page 5 of 38 1.4. LTE Peak to Average Ratio(NTNV)(Subtest:4, Channel:18900, Bandwidth:20, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1880 0.1 5.11 13 Pass Document No: BL-SZ2270935 Page 6 of 38 1.5. LTE Peak to Average Ratio(NTNV)(Subtest:5, Channel:18900, Bandwidth:20, Modulation:QPSK, RB Number: 100, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1880 0.1 5.48 13 Pass Document No: BL-SZ2270935 Page 7 of 38 1.6. LTE Peak to Average Ratio(NTNV)(Subtest:6, Channel:18900, Bandwidth:20, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1880 0.1 5.86 13 Pass Document No: BL-SZ2270935 Page 8 of 38 1.7. LTE Peak to Average Ratio(NTNV)(Subtest:7, Channel:19100, Bandwidth:20, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1900 0.1 5.11 13 Pass Document No: BL-SZ2270935 Page 9 of 38 1.8. LTE Peak to Average Ratio(NTNV)(Subtest:8, Channel:19100, Bandwidth:20, Modulation:QPSK, RB Number: 100, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1900 0.1 5.48 13 Pass Document No: BL-SZ2270935 Page 10 of 38 1.9. LTE Peak to Average Ratio(NTNV)(Subtest:9, Channel:19100, Bandwidth:20, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1900 0.1 5.72 13 Pass Document No: BL-SZ2270935 Page 11 of 38 2. LTE_Band4 2.1. LTE Peak to Average Ratio(NTNV)(Subtest:1, Channel:20050, Bandwidth:20, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1720 0.1 5.02 13 Pass Document No: BL-SZ2270935 Page 12 of 38 2.2. LTE Peak to Average Ratio(NTNV)(Subtest:2, Channel:20050, Bandwidth:20, Modulation:QPSK, RB Number: 100, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1720 0.1 5.58 13 Pass Document No: BL-SZ2270935 Page 13 of 38 2.3. LTE Peak to Average Ratio(NTNV)(Subtest:3, Channel:20050, Bandwidth:20, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1720 0.1 6.09 13 Pass Document No: BL-SZ2270935 Page 14 of 38 2.4. LTE Peak to Average Ratio(NTNV)(Subtest:4, Channel:20175, Bandwidth:20, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1732.5 0.1 4.45 13 Pass Document No: BL-SZ2270935 Page 15 of 38 2.5. LTE Peak to Average Ratio(NTNV)(Subtest:5, Channel:20175, Bandwidth:20, Modulation:QPSK, RB Number: 100, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1732.5 0.1 5.58 13 Pass Document No: BL-SZ2270935 Page 16 of 38 2.6. LTE Peak to Average Ratio(NTNV)(Subtest:6, Channel:20175, Bandwidth:20, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1732.5 0.1 5.2 13 Pass Document No: BL-SZ2270935 Page 17 of 38 2.7. LTE Peak to Average Ratio(NTNV)(Subtest:7, Channel:20300, Bandwidth:20, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1745 0.1 4.64 13 Pass Document No: BL-SZ2270935 Page 18 of 38 2.8. LTE Peak to Average Ratio(NTNV)(Subtest:8, Channel:20300, Bandwidth:20, Modulation:QPSK, RB Number: 100, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1745 0.1 5.67 13 Pass Document No: BL-SZ2270935 Page 19 of 38 2.9. LTE Peak to Average Ratio(NTNV)(Subtest:9, Channel:20300, Bandwidth:20, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 1745 0.1 5.67 13 Pass Document No: BL-SZ2270935 Page 20 of 38 3. LTE_Band5 3.1. LTE Peak to Average Ratio(NTNV)(Subtest:1, Channel:20450, Bandwidth:10, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 829 0.1 4.31 13 Pass Document No: BL-SZ2270935 Page 21 of 38 3.2. LTE Peak to Average Ratio(NTNV)(Subtest:2, Channel:20450, Bandwidth:10, Modulation:QPSK, RB Number: 50, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 829 0.1 5.3 13 Pass Document No: BL-SZ2270935 Page 22 of 38 3.3. LTE Peak to Average Ratio(NTNV)(Subtest:3, Channel:20450, Bandwidth:10, Modulation:Q16, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 829 0.1 5.3 13 Pass Document No: BL-SZ2270935 Page 23 of 38 3.4. LTE Peak to Average Ratio(NTNV)(Subtest:4, Channel:20525, Bandwidth:10, Modulation:QPSK, RB Number: 1, RB Position:LOW) Center Frequency(MHz) PAR Percent (%) PAR (dB) Upper Limit (dB) Verdict 836.5 0.1 4.08 13 Pass Document No: BL-SZ2270935 Page 24 of 38 3.5. LTE Peak to Average Ratio(NTNV)(Subtest:5, Channel:20525, Bandwidth:10, Modulation:QPSK, RB Number: 50, RB Position:LOW) Center Frequency(MHz) PAR P…

Text truncated - open the document above for the full version.

Document No: BL-SZ2270935 Page 1 of 104 Annex A.3 Occupied Bandwidth Document No: BL-SZ2270935 Page 2 of 104 1. GSM_GSM850 1.1. GSM Occupied Bandwidth(NTNV)(Channel:128) Center Frequency (MHz) OBW Power (%) XdB Down (dB) RBW (MHz) Detector OBW (MHz) XdB Bandwidth (MHz) Upper Limit (MHz) Verdict 824.2 99 26 0.004 Pea…
