2AMNB-CP8Compact 8

Optelec Nederland BV

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 05, 2023
Application Purpose: Original Equipment
Date of Application: Feb 09, 2023
Equipment Note: Compact 8
Frequency Range: 2412.00000000 - 2462.00000000
Company: Optelec Nederland BV
Country: Netherlands

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

UDC-000382 Rev. A, CP8-UMME, CP8-UMUK, CP8-UMCC, 2022-12 English Compact 8 Safety and Care © 2022 Optelec, The Netherlands. All Rights Reserved. Read these instructions carefully before setting up your device. Keep this document for future reference. Cleaning the LCD Screen Before cleaning the LCD screen, power off and unplug the device. Use a dry, clean microfiber cloth to gently wipe the cloth across the screen. Optionally, follow the directions of a cleaning liquid specifically for use on screens. Warning: Do not use a paper towel or press down hard on the screen. Cleaning the Compact 8 Body Unplug the device before cleaning the body. Use a lightly dampened, soft, clean cloth with water or mild detergent. Product Specifications Trade name Compact 8 Close magnification 1.8x to 30x Distance magnification 1.0x to 18x Color modes 25 color combinations, including true color, enhanced color, grayscale Focus range 20 cm to infinity Screen 8.0-in TFT, 400 cd/m2 Screen resolution 1280 x 720 Cameras 60 fps, 4208 x 3120 p Dimensions 205 x 139 x 25.4 mm 8.07 x 5.47 x 1 in Weight 0.776 kg / 1.71 lbs Battery Up to 3.2 hours of continuous use and up to 4 hours of charging time Li-ion battery Rechargeable, 3.7 V, 7600 mAh, 28.12 Wh Connections USB-C, 3.5mm audio (not used) Power supply Adapter Technology Co., LTD ATM012T-W052VU. Adapter input power rating 100-240 VAC, 50-60 Hz 2 Compact 8 Safety and Care Adapter output power rating Max load: 5.1 V 2.4 A WiFi WiFi 802.11b 2.4 GHz Miracast IPX rating IP21 Regular Maintenance and Service This device does not need regular service or maintenance during its expected service life. These tips, however, will help keep your product in good condition: • To keep your device clean and dry, transport it in its protective pouch. • Before storing the device for a long time, the battery charge should be 60% to 80%. • Inspect the device regularly and keep the battery charged at least 20%. It does not harm the device to leave it charging. • In case of defects or a decrease in performance, contact your local dealer or point of sale. Warnings and Precautions Do not remove any parts or disassemble your unit as it will void the warranty. For product support, contact an authorized service organization in your area. Note these warnings and precautions: • To avoid the risk of electric shock, devices powered using a grounded power connector must be connected to an electrical supply with a protective earth-ground connection. • Do not stare into LED lamps in operation as temporary discomfort and eye injury can result. • Critical diagnostic, medical or legal decisions should not be based on images displayed by this device. • Use only the original 5.1 V 2.4 A charger and cables provided with the device. Do not force the power connector into the power port of the device. • Do not spray any cleaning solutions directly on the LCD screen. • Do not use solvents, abrasives, aerosols, or any cleaner that contains acetone, ethyl alcohol, ethyl acid, ammonia, or methyl chloride. • Do not expose the device to excessive heat, direct sunlight, or extreme or rapid changes in temperature or humidity. Compact 8 Safety and Care 3 English • To avoid the risk of electrical damage, keep your device away from fluids and chemicals. • Handle the device with care. Rough handling will damage the internal components. • Do not use the device near inadequately shielded medical devices. Do not open a Miracast connection near devices like pacemakers or defibrillators. • Do not touch or look directly at the illumination lights. • Be careful that your fingers and clothing do not get stuck in moving parts (for example, the stand). • Common side effects of using an electronic display device for prolonged periods are eye fatigue and headaches. • Do not place the device on an unstable surface. It may fall, causing serious damage to the unit, or injury to the user. • To prevent condensation, do not use the device for one hour after transporting it from extreme cold to room temperature. • While charging the device, even while powered off, the ambient temperature must be between 0°C and 35°C or 32°F and 95°F. • Do not position the alternating-current (AC) power supply such that is difficult to access and disconnect. • Portions of the back housing may exceed 43°C, which may provide discomfort during continuous contact. If this occurs, adjust hand position to a cooler region. • No modification of this equipment is allowed. This product contains chemicals that are known to the State of California to cause cancer and birth defects or reproductive harm. For more information go to www.P65Warnings.ca.gov. Precautions for Battery Pack Do not charge if your device appears damaged, deformed, or defective. Contact your Optelec distributor or the nearest Optelec office for further instructions before use. 4 Compact 8 Safety and Care BATTERY MUST BE REPLACED BY CERTIFIED SERVICE PERSONNEL. RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO LOCAL REGULATIONS. Residual Risks Risks relating to the use of the device have been carefully evaluated and reduced to the lowest possible level. Residual risks have been found acceptable and the benefits of using the device outweigh these residual risks. Contacting Product Support For product support, contact your local dealer or point of sale. For incidents involving the device and someone’s health, contact [email protected]. Optelec Nederland B.V., Pesetastraat 5a, 2991 XT, Barendrecht, The Netherlands. www.in.optelec.com, [email protected]. Optelec / Optelec Limited, Unit C, Plot 5, Merlin Way Quarry Hill Ind. Estate Ilkeston, Derbyshire, DE7 4RA United Kingdom, www.lowvisionshop.co.uk Operating Conditions Storage and Transportation Conditions Temperature: +0°C to 35°C / 32°F to 95°F Relative humidity: less than 70%, no condensation Altitudes: up to 3,000 m (9,842 ft) Pressure: 700 – 1060 hPa Temperature: -10°C to 50°C / 14°F to 122°…

Text truncated - open the document above for the full version.

Attestation Statements

OptelecNederlandB.V. 2023.2.23 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 RE:AttestationStatementsPart2.911(d)(5)(i)requestfor(FCCID：2AMNB-CP8) [OptelecNederlandB.V.](“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Sincerely, (Applicantsignature) (Applicantprintedname)PatrickMurphy OptelecNederlandB.V. 2023.2.23 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 RE:AttestationStatementsPart2.911(d)(5)(ii)requestforFCCID：2AMNB-CP8 [ OptelecNederlandB.V. ](“theapplicant”)certifiesthat,asofthedateofthefilingof theapplication,theapplicantisnotidentifiedontheCoveredListasanentityproducing “covered”equipment. Sincerely, (Applicantsignature) (Applicantprintedname)PatrickMurphy

Attestation Statements

AttestationStatements 2023.2.23 TO:FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046,USA RE:AttestationStatementsPart2.911(d)(7)requestfor(FCCID： 2AMNB - CP8 ) ( OptelecNederlandB.V. ),theundersigned,herebyauthorize(FreedomScientificBLV Group)toactasourdesignatedU.S.agentforserviceofprocess, (OptelecNederlandB.V.)acceptstomaintainanagentfornolessthanoneyearafterthe granteehasterminatedallmarketingandimportationortheconclusionofany Commission-relatedproceedinginvolvingtheequipment. (FreedomScientificBLVGroup)acceptstheresponsibilitytoactasdesignatedU.S. agentforserviceofprocess. ApplicantInformation： Companyname:OptelecNederlandB.V. ContactName:PatrickMurphy Address:Pesetastraat5ª2991XTBarendrechtTheNetherlands TelephoneNo:+17278038000 Email:[email protected] Signature [name] U.S.AgentInformation: CompanyName:FreedomScientificBLVGroup Address:17757USHighway19NSuite560Clearwater,FL33764-1805UnitedStates FRN:0016491755 ContactName:PatrickMurphy TelephoneNo:(727)803-8000 Email:[email protected] Signature [name]

Cover Letter(s)

Optelec Nederland BV | Part of Vispero Pesetastraat 5a, 2991 XT Barendrecht, The Netherlands 12/20/2022 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 AUTHORITY TO ACT AS AGENT - FCC On our behalf, I appoint Shanghai ATBL Technology Co., Ltd./ 5-6/F., Unit 1, No 8, Free Trade One Life Science and Sci-Tech Industrial Park, No. 160 Basheng Road, Pudong, Shanghai, China/ Ada Wang , to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America Inc., still resides with us. Sincerely, Printed name: Patrick Murphy

Cover Letter(s)

Optelec Nederland BV | Part of Vispero Pesetastraat 5a, 2991 XT Barendrecht, The Netherlands 12/20/2022 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: 2AMNB-CP8 Click here to enter text. Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT LONG-TERM CONFIDENTIALITY: Schematics Bill of Materials/Parts List Bl ock Diagrams Theory of Operation When the device is marketed before the requested number of days listed above, the grantee will inform the TCB to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. The above information contains trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Sincerely, Signed : Printed name: Patrick Murphy Title:Director

Cover Letter(s)

OptelecNederlandBV 1/16/2023 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 DeclarationofDifferentModels We,OptelecNederlandBV,herebytodeclarethat4models CP8,CP8-UMME，CP8-UMCC，CP8-UMUKisonlyfordifferentmarkets,RFcircuitandwireless functionwillstayinsame. Sincerely, Printedname:PatrickMurphy

Cover Letter(s)

OptelecNederlandB.V. 1/16/2023 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 DeclarationofMultiHVIN We,OptelecNederlandB.V.,herebytodeclarethat4HVINs: CP8,CP8-UMME，CP8-UMCC，CP8-UMUKisonlyfordifferentmarkets,RFcircuitandwireless functionwillstayinsame. Sincerely, Printedname:PatrickMurphy

External Photos

Page 1 of 3 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. PHOTOGRAPHSOFTHEEUTEXTERNALCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 3 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Photo3 Photo4 Page 3 of 3 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Photo5 Photo6

External Photos

ID Label/Location Info

LABELLOCATION

ID Label/Location Info

LABELLOCATION -UMCC -UMME -UMUK

Internal Photos

Page 1 of 7 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. PHOTOGRAPHSOFTHEEUTINTERNALCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 7 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Photo3 Photo4 Page 3 of 7 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Photo5 Photo6 BT/WIFI ANT Page 4 of 7 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Photo7 Photo8 Page 5 of 7 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Photo9 Photo10 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Page 6 of 7 Photo11 Photo12 ReportNo.:SHATBL2210015 ShanghaiATBLTechnologyCo.,Ltd. Page 7 of 7 Photo 13 Photo 14

Internal Photos

Parts List/Tune Up Info

2AMNB-CP8_Tune Up Procedure Measurement Procedure: 1. Set the device to operational voltage and on a predefined channel in a special test mode. 2. The actual output power is measured at several power levels. 3. The gain factors of each individual device are adjusted until the target value is met. The appropriate gain control settings for each output power level are stored in each device individually (for each power level). The user has no possibility to change these settings later on. 4. The maximum gains of each individual device are adjusted and measured until the target value is met. The production target power with tolerance compiles with the maximum power in test report. Rated RF power output: Mode 2.4G WLAN(AVG) 802.11b 14±1dBm Mode BT(AVG) GFSK 8±1dBm π/4-DQPSK 6±1dBm 8DPSK 6±1dBm Mode BLE(AVG) GFSK(1Mbps) 2±1dBm Then these appropriate rated RF output power settings are stored in each device individually. The user has no possibility to change these settings later on, and during manufacturing each device will be individual calibrated. The measurement is done in fully calibrated setup, which is based on the base station simulator. Furthermore, the highest power level is verified afterwards in a call measurement on three channels(low, middle and high).

RF Exposure Info

2AMNB-CP8_SAR Setup photos Body Back side(separation distance is 0mm) Body Top side(separation distance is 0mm)

RF Exposure Info

Ref : ACR.262.10.20.MVGB.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F., BUILDING B, ZHUOKE SCIENCE PARK,No.190, CHONGQING ROAD,FUYONG STREET, BAO’ AN DISTRICT, SHENZHEN,GUANGDONG,CHINA MVG COMOSAR REFERENCE DIPOLE FREQUENCY: 2450 MHZ SERIAL NO.: SN 30/14 DIP2G450-335 SAR Reference Dipole Calibration Report 07/14/2020 Summary: This document presents the method and results from an accredited SAR reference dipole calibration performed in MVG. using the CALIPROBE test bench. for use with a MVG COMOSAR system only. The test results covered by accreditation are traceable to the International System of Units(SI). Calibrated at MVG Z.I. de la pointe du diable Technopôle Brest Iroise - 295 avenue Alexis de Rochon 29280 PLOUZANE - FRANCE Calibration date: 07/14/2020 Page: 1/11 SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262..20.MVGB.A Name Function Date Signature Prepared by : Jérôme LUC Technical Manager 7/28/2020 Checked by : Jérôme LUC Technical Manager 7/28/2020 Approved by : Yann Toutain Laboratory Director 7/28/2020 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 7/28/2020Initial release Name Jérôme LUC Page: 2/11 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. 0 1 SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262. TABLE OF CONTENTS 1 Introduction ................................................................................................................ 4 2 Device Under Test ..................................................................................................... 4 3 Product Description ................................................................................................... 4 3.1 General Information _______________________________________________________ 4 4 Measurement Method ................................................................................................ 5 4.1 Return Loss Requirements __________________________________________________ 5 4.2 Mechanical Requirements ___________________________________________________ 5 5 Measurement Uncertainty .......................................................................................... 5 5.1 Return Loss ______________________________________________________________ 5 5.2 Dimension Measurement ___________________________________________________ 5 5.3 Validation Measurement ____________________________________________________ 5 6 Calibration Measurement Results .............................................................................. 6 6.1 Return Loss and Impedance In Head Liquid ____________________________________ 6 6.2 Return Loss and Impedance In Body Liquid ____________________________________ 6 6.3 Mechanical Dimensions ____________________________________________________ 6 7 Validation measurement ............................................................................................ 7 7.1 Head Liquid Measurement __________________________________________________ 7 7.2 SAR Measurement Result With Head Liquid ____________________________________ 8 7.3 Body Liquid Measurement __________________________________________________ 9 7.4 SAR Measurement Result With Body Liquid __________________________________ 10 8 List of Equipment .................................................................................................... 11 Page: 3/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. .20.MVGB.A 0 1 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262. 1 INTRODUCTION This document contains a summary of the requirements set forth by the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards for reference dipoles used for SAR measurement system validations and the measurements that were performed to verify that the product complies with the fore mentioned standards. 2 DEVICE UNDER TEST Device Under Test Device Type COMOSAR 2450 MHz REFERENCE DIPOLE Manufacturer MVG Model SID2450 Serial Number SN 30/14 DIP2G450-335 Product Condition (new / used) Used A yearly calibration interval is recommended. 3 PRODUCT DESCRIPTION 3.1 GENERAL INFORMATION MVG’s COMOSAR Validation Dipoles are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. The product is designed for use with the COMOSAR test bench only. Figure 1 – MVG COMOSAR Validation Dipole Page: 4/11 This document shall not be reproduced, except in full or in part, without the written approval of MVG. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of MVG. .20.MVGB.A 0 1 Template_ACR.DDD.N.YY.MVGB.ISSUE_COMOSAR Dipole vH SAR REFERENCE DIPOLE CALIBRATION REPORT Ref: ACR.262. 4 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards provide requirements for reference dipoles used for system validation measurements. The following measurements were performed to verify that the product complies with the fore mentioned standards. 4.1 RETURN LOSS REQUIREMENTS The dipole used for SAR system validation measurements and checks must have a return loss of -20 dB or better. The return loss measurement shall be performed against a liquid filled flat phantom, with the phantom constucted as outlined in the fore mentioned standards. 4.2 MECHANICAL REQUIREMENTS The IEEE Std. 1528 and CEI/IEC 62209 standards specify the mechanical components and dimensions of the validation dipoles, with the dimensions…

Text truncated - open the document above for the full version.

RF Exposure Info

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. ShenZhen STS Test Services Co.,Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No.: STS2211324H02 Issued for Optelec Nederland B.V. Pesetastraat 5ª 2991 XT Barendrecht The Netherlands Product Name: Compact 8 Brand Name: Optelec Model Name: CP8 Series Model: CP8-xxyy FCC ID: 2AMNB-CP8 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. Report SAR (1g): Body: 0.202 W/kg S T L A B S Page 2 of 31 Report No.: STS2211324H02 Test Report Certification Applicant’s name ................. : Optelec Nederland B.V. Address ................................. : Pesetastraat 5ª 2991 XT Barendrecht The Netherlands Manufacturer's Name .......... : Optelec Nederland B.V. Address ................................. : Pesetastraat 5ª 2991 XT Barendrecht The Netherlands Product description Product name ........................ : Compact 8 Brand name ......................... : Optelec Model name ......................... : CP8 Series Model .......................... : CP8-xxyy Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ............................................ : 29 Nov. 2022 Date (s) of performance of tests ............. : 29 Nov. 2022 Date of Issue ........................................... : 30 Nov. 2022 Test Result ............................................... : Pass Testing Engineer : (Shifan. Long) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 31 Report No.: STS2211324H02 Table of Contents 1. General Information 5 1.1 EUT Description 5 1.2 Test Environment 6 1.3 Test Factory 6 2. Test Standards and Limits 7 3. SAR Measurement System 8 3.1 Definition of Specific Absorption Rate (SAR) 8 3.2 SAR System 8 4. Tissue Simulating Liquids 11 4.1 Simulating Liquids Parameter Check 11 5. SAR System Validation 13 5.1 Validation System 13 5.2 Validation Result 13 6. SAR Evaluation Procedures 14 7. EUT Antenna Location Sketch 15 7.1 SAR test exclusion consider table 16 8. EUT Test Position 18 8.1 Body-worn Position Conditions 18 9. Uncertainty 19 9.1 Measurement Uncertainty 19 10. Conducted Power Measurement 20 10.1 Test Result 20 11. EUT and Test Setup Photo 21 11.1 EUT Photo 21 11.2 Setup Photo 24 12. SAR Result Summary 25 12.1 Body-worn SAR 25 13. Equipment List 26 Appendix A. System Validation Plots 27 Appendix B. SAR Test Plots 29 Appendix C. Probe Calibration and Dipole Calibration Report 31 Page 4 of 31 Report No.: STS2211324H02 Revision History Rev. Issue Date Report No. Effect Page Contents 00 30 Nov. 2022 STS2211324H02 ALL Initial Issue Page 5 of 31 Report No.: STS2211324H02 1. General Information Environmental evaluation measurements of specific absorption rate (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 1.1 EUT Description Product Name Compact 8 Brand Name Optelec Model Name CP8 Series Model CP8-xxyy Model Difference CP8-UMME = EU Medical Device CP8-UMCC = Commercial Device CP8-UMUK = UK Medical Device Battery Rated Voltage:3.7V Charge Limit Voltage:4.2V Capacity: 7600mAh Device Category Portable Product stage Production unit RF Exposure Environment General Population / Uncontrolled Hardware Version A Software Version APK 2.4.18 BSP 20220726 Frequency Range WLAN802.11b: 2412 MHz ~ 2462 MHz Bluetooth: 2402 MHz to 2480 MHz Max. Reported SAR(1g): (Limit:1.6W/kg) Band Mode Body Worn (W/kg) DTS 2.4G WLAN 0.202 DSS BT 0.081 FCC Equipment Class Part 15 Spread Spectrum Transmitter(DSS) Digital Transmission System (DTS) Operating Mode: 2.4G WLAN : 802.11b(DSSS):CCK,DQPSK,DBPSK Bluetooth: GFSK +π/4DQPSK+8DPS…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Patrick Murphy(Director)

[email protected]+17278038000Fax: +17278038001

Test Firm

Shanghai ATBL Technology Co., Ltd.Haofei Huang

[email protected]13818033377

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	47.21 mW

Confidentiality

Long Term

Grant Notes

Output power is conducted. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. The highest reported SAR value is Body: 0.202 W/kg.
