150W Handheld Pocket Spotlight C150X User Manual Translated from Chinese (Simplified) to English - www.onlinedoctranslator.com Preface C150X LED photography light is a high brightness, portable fill light that supports brightness and color temperature adjustment. The power supply mode design can be fixed on the light stand or used by hand. It is easy to operate and can be used for landscape photography. Photography, video shooting, live broadcast, wedding photography, children's photography and other scenes. Main Features 1. Lightweight and portable, flexible for indoor and outdoor lighting. 2. Multiple scenario special effects modes provide more creative possibilities. 3. High brightness and uniform light output make the picture more textured. 4. Equipped with silent fan for heat dissipation, it ensures the stable operation of LED without generating excessive noise. 5. Multi-light joint control, support APP Bluetooth control. 6. Supports Boris mount adapter, universal mainstream accessories, more convenient light control 7. Support multiple power supply modes, not limited by power supply. Item List Standalone version: C150X ② ① ③ ④⑤⑥ ① Lamp body ⑥ AC power cord ② Reflector③ Pitch④ Tripod handle⑤ Adapter Package version: C150X COMBO ② ①③⑧ ⑨ ④⑤⑥⑦ ① Lamp body ⑥ AC power cord ⑦ V-mount battery mounting bracket ⑧ Baorong bayonet adapter ring ⑨ V-mount battery mounting kit ② Reflector③ Pitch④ Tripod handle⑤ Adapter Product Introduction Switch button heat sink Accessory mount SET key COB lamp beads DIM key Accessory unlock key Display Fan and protective cover Lanyard port 1/4 screw hole and positioning pin hole DC power supply interface Type C power supply interface Power Management This product does not contain batteries. To ensure the normal operation of the fill light, please use the following power supply methods: 1. DC power supply 1) Connect the DC power adapter to the DC power supply interface of the fill light and the AC power socket, and the fill light can be turned on. powered by. 100-240V Power Supply: 2) V-mount battery 12V-33.6V power supply, you need to use the V-mount battery holder to load the battery and then plug it into the DC port for power supply. 2. Type C power supply Powered by a charger/power bank that supports the PD fast charging protocol. It is recommended to use a charger/power bank that supports the PD fast charging protocol and has a power greater than or equal to 100W USB charger.When the input power is insufficient, the brightness of the fill light cannot be adjusted to 100%. Power Bank: Notice: ① When the input voltage is lower than 12V or higher than 34V, the light cannot be turned on. ② V-mount batteries need to be purchased separately. ③ PD fast charging charger/power bank needs to be purchased separately. 3. Power supply mode and brightness limit Different power supply modes have different powers and corresponding brightness. Please refer to the following for details: Power supply modeCurrent and voltagemodelFan H settingFan MFan OFF CCT100%50%10% adapter28V 6.4A FX100%50%10% CCT50%50%10% 12V-14V FX50%50%10% CCT64%50%10% 14V-16.8V FX64%50%10% CCT77%50%10% 16.8V-20.4V FX77%50%10% V-mount battery powered CCT100%50%10% 20.4V-24V FX100%50%10% CCT100%50%10% 24V-25V FX100%50%10% CCT100%50%10% 25V-33.6V FX100%50%10% CCT60%50%10% PD100W FX60%50%10% CCT38%38%10% PD Power Supply PD65W FX38%38%10% CCT18%18%10% PD30W FX18%18%10% CCT 60%50%10% PD100W Power Bank FX60%50%10% Instructions 1. Get started 1.1. Turn on and off the machine Press and hold the power button for 2s to turn the light on and off. 2. Mode selection Short press the SET button to switch between CCT color temperature and FX special effects mode 2.1 Color Temperature Mode Short press the SET button to switch to CCT color temperature mode Color temperature adjustment: Rotate the SET button to adjust the color temperature between 2700K-6500K. Brightness adjustment: Rotate the DIM button to adjust the brightness value from 0-100%. 2.2 Special Effects Mode Short press the SET button to switch to special effect mode Brightness adjustment: Rotate the DIM button to adjust the brightness from 0-100%. Special effect switching: Rotate the SET button to switch special effects, and short press the DIM button to switch frequency A/B/C. 3. Set up menu functions Long press the SET button to enter the settings menu page: 3.1 Bluetooth switch:Rotate the DIM button to select ON and OFF Bluetooth, and short press the SET button to confirm the setting. After exiting, the screen will show the Bluetooth status. OFF: Turn off Bluetooth and the Bluetooth status logo will disappear. ON: Turn on Bluetooth, and the Bluetooth status logo will appear. 3.2 Fan Mode:Rotate the SET button to select the fan gear mode H/M/OFF, short press the SET button to confirm the setting, and the screen The fan status will be displayed. H high speed gear: 100% high brightness and full power operation (laboratory test noise is about 26dB). M soft mode: maximum brightness 50%, reduces wind noise, and makes the light brightness softer (laboratory test noise 15dB). OFF Turn off the fan: Maximum brightness 10%, noise is almost zero. 4. Connect to mobile APP 4.1 Before using the APP, turn on the Bluetooth of the video light, press and hold the SET button to enter the menu page, and select Bluetooth switch. Turn on (ON). 4.2 Scan the QR code to download the "SIRUI Light" mobile APP. 4.3 Turn on Bluetooth on your phone, connect the corresponding light in the "SIRUI Light" APP and control it through the APP. For specific operations, please refer to the mobile APP instructions. 5. Installation and fixing The lamp body can be fixed on the quick-release plate through the 1/4 screw hole and positioning pin at the bottom of the lamp body. After installing the quick release plate,(1) Hold the light body with your right hand, press the unlock button of the tilt pan/tilt head with your left hand and move the handle backwards. It can be installed quickly.(2) Hold th…
