2AN4Y-WX113-in-1 Wireless Charger

User Manual 取扱説明書 In order to bring you a better experience, please read this user manual carefully before using this product and keep it properly for future reference. 0102 0304050607 0809101112 131415 Contents / 目次 Specifications Compatible Devices Overview Instructions Indicator Light Guide Important Safety Instructions 01 01 02 03 06 07 EN 製品仕様 対応機種 製品概要 使用方法 インジケーターランプについて 重要な安全上のご注意 09 09 10 11 14 15 JA 0102 0304050607 0809101112 131415 Specifications Compatible Devices Product Name Product Model Total Output Charge Sensing Distance Working Temperature 45W MAX ≈4mm 0°C~35°C/32°F~95°F Input Package Contents 3-in-1 Wireless Charger ×1, Charger (Optional) ×1, Charging Cable (Optional) ×1, User Manual ×1 The parameters above are derived from the laboratory of TORRAS. The image shown here is indicative only. Actual delivery is subject to customer purchase style. 9V⎓3A/12V⎓3A/15V⎓3A/ 20V⎓3.35A 3-in-1 Wireless Charger WX11 iPhone 12 and later models AirPods/AirPods Pro Series (with Wireless Charging Case) Apple Watch Series 6 and later models Apple Watch Ultra/SE Series Output Phone 1: 25W MAX; Phone 2/Earbuds: 15W MAX; Watch: 5W MAX EN 0102 0304050607 0809101112 131415 Overview Wireless Charging Area for iPhone Wireless Charging Area for Apple Watch Wireless Charging Area for AirPods Cooling Vent USB-C Port Function Button Stand Indicator Light 0102 0304050607 0809101112 131415 1. Connect the charger and charging cable to power on the device. The fan and semiconductor cooling function are off by default. 2. Button and Function Guide Note: Please use the charger (67W) included with this product. If using a third-party charger block, ensure it supports USB-C PD fast charging with an output power of at least 67W to ensure the best charging experience. Place your phone on the charging area (while powered on) Double-press the Function button Press and hold the Function button for 3 seconds Operation Turn off the indicator light. Turn the fan and semiconductor cooling function on or off. The fan and semiconductor cooling function turn on automatically. Function The indicator light turns off. The indicator light flashes 3 times, turns off, then returns to solid light after 1 second. The indicator light flashes 3 times, turns off, then returns to solid light after 1 second. Indicator Light Instructions 0102 0304050607 0809101112 131415 3. This product can wirelessly charge your iPhone, AirPods, and Apple Watch simultaneously. 4. This wireless charger features a foldable metal stand. Pull up the stand to unfold it, then adjust the viewing angle as needed. It supports both portrait and landscape charging, making it ideal for watching videos, working, and more. Warning: The following scenarios are not supported. Please remove any such items before charging. 0102 03 04050607 0809101112 131415 5. If your Apple Watch has a particularly thick metal band that prevents magnetic alignment, please remove the band and place the watch’s charging module onto the wireless charging area for Apple Watch. Ensure it aligns properly for charging. 6. If your AirPods are not charging, adjust the AirPods case position. Place it with the front facing up in the center of the wireless charging area for AirPods. (If your charging case has a protective cover, please remove it before charging.) 0102 0304 050607 0809101112 131415 7. Note the charging detection distance, and avoid using too thick phone cases. The vertical distance between the internal sensing coil of the phone and the wireless charger must be within about 4mm for charging to occur. For the best wireless charging experience, please avoid using phone cases thicker than 2mm or non-magnetic cases, as they may affect charging efficiency. The internal sensing coil of the cell phone The internal sensing coil of the wireless charger A thicker cell phone case ≈4mm Indicator Light Guide The indicator light stays on for 3 seconds, then turns off. Slow flashing Fast flashing Indicator Light - Incompatible charger detected. - Please use the charger (67W) included with this product. - Metal objects detected. - Remove any metal objects from the surface of the wireless charger to ensure proper operation. Power is connected. Status Description 0102 030405 0607 0809101112 131415 01. This product is designed for charging iPhone 12 and later models, Apple Watch, and AirPods only. It is not compatible with products from other brands. 02. Make sure your smartphone supports wireless charging. Otherwise, it cannot be charged. 03. Do not use a phone case thicker than 2 mm, as this may prevent wireless charging. 04. Do not place any foreign objects between your phone and the wireless charger, including metal plates for car mounts, credit cards, keys, coins, metal objects, or NFC cards. Doing so may prevent wireless charging or cause overheating. 05. Do not disassemble, strike, crush, or throw this product into fire. Improper reassembly may result in a risk of fire or personal injury. 06. Do not use this product in extremely hot, humid, or corrosive environments, as this may damage the circuitry and cause electrical leakage. 07. Do not spill water or other liquids on the wireless charger. If cleaning is necessary, make sure the power is disconnected first. 08. When charging, keep the wireless charger more than 30 cm away from implanted medical devices, such as pacemakers and cochlear implants, to avoid potential interference. 09. When using a charger for power supply, use a charger that is certified and complies with applicable safety standards. 10. Using power cables or chargers not recommended or sold by the manufacturer of this product may result in a risk of fire or personal injury. 11. This product requires a USB-C PD fast charger with an output of at least 67 W. 12. High temperatures can reduce charging speed and limit power output. This is a common characteristic of wireless charging. We recommend charging your device in an environment below 25 ° C/ 7 7 ° F. 13. Your phone case …
