Guardian UWB RADAR SERIES OPERATION DESCRYPTION This detector is Impulse Radar based on the Ultra Wide Band technology at hi-band (7GHz-9GHz) with advanced digital signal processing, used for remote detection presence of peoples or/and animals inside of covering area. Detector are designed to ensure reliable catch performance of vital signs of human presence and false alarm immunity in commercial application. For this purpose, sensor contain two fields in detection solution: Doppler detector and Vital Sign detector. Doppler detector allows to detect movements of peoples inside of area, Vital Sign catch signals when body is unmoved (sleeping, reading book or watch tv etc.). This device complies with Part 15.517 of the FCC Rules. This equipment may only be operated indoors. Operation outdoors is in violation of 47 U.S.C. 301 and could subject the operator to serious penalties. The Guardian A1(M1) is largely composed of two blocks as shown in the above block diagram, and one is divided into an Rf Radar sensor (sky blue block) and a WiFi controller (orange block). In the case of an RF sensor, it is supposed to operate with a clock generated using an internal clock in the MCU, and the FPGA is also supposed to operate using a clock generated in the MCU. It operates by exchanging data through SPI internally, creates and exports a signal with DAC, and receives the reflected sensor value as an ADC value to measure the data change value. Using the detected value, the MCU transmits data to UART communication with the measured value. On the WiFi side, when there is no initial setting value, it operates in the BLE mode and operates in the setting mode. When you set up the WiFi environment with the setting app, you receive the data value through BLE, write it in the EEPROM, reset it, and re- operate, and if there is no abnormality in the setting value, WiFi is connected and the Internet is connected. When you access Cloud Platform with connected WiFi and send data, the value is stored in the internal database. If the program defaults to the saved database values with iOS or Android apps, it displays the current status values and operates to deliver alarms. The picture above is an RF sensor substrate that is largely composed of FPGA/MCU/RF/power, and the inner layer is ground-treated to block noise. In the case of the power supply unit, it does not operate alone, so it is operated by receiving 5V power. The above WiFi substrate inputs power inputs from 5V to 12V through USB-C, supplies 5V power to the RF sensor with the input power, and supplies power to operate internally by making 3.3V power again. The LED consists of two LEDs, and if the power is connected and the connection is normal, the orange LED flashes and turns on. If there is a problem with the WiFi connection, a green light will come on and make it known that it is all BLE. If the setting is normal, it is configured to be connected to the cloud, transmit data, and store it in the database.

MPE Calculation / RF Exposure Product: Guardian Applicant: Umain Inc. Model: UM80GA1 Address: 504, Fifth Floor, 59, Oncheon-ro, Yuseong-gu, Daejeon, Republic of Korea FCC ID: 2AN8QUM80GA1 This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC Rules and Regulations. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310 is listed in below table. According to FCC §1.1310: the criteria listed in the following tablesshall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Limits for General Population/Uncontrolled Exposure f = frequency in MHz * = Plane-wave equivalent power density Result Calculated Formulary: Predication of MPE limit at a given distance S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) MPE Prediction Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Classfication The antenna of this product is at least 20 cm away from the body of the user. So this product is classified as mobile device. - UWB Frequency (GHz) Tune up EIRP Evaluation Distance (cm) Power Density (mW/cm 2 ) MPE Limit (mW/cm 2 ) (dBm) (mW) 8.019 -2.19 0.604 20 0.000 12 1 Conclusion This confirms compliance to the required radio frequency radiation exposure limit of 1.0 mW/cm 2 at 20 cm operation. - Wi-Fi Max. tune-up power(dBm) 802.11b 802.11g 802.11n(HT20) 802.11n(HT40) 26.0 25.5 25.5 26.0 S = ERP/4 π R 2 In other words, R = √ERP/4π x S(Pd) Where S = Power density ERP = Effective Radiated Power R = distance to the centre of radiation of the antenna Values S = 1.0 mW/cm 2 for General population uncontrolled exposure (FCC Part 1.1310 Radiofrequency radiation exposure limits) S = 1.0 mW/cm 2 PT = 26.00 dBm (398.11 mW) : measured maximum output power G = Antenna gain = 3.40 dBi (2.188 in linear terms) EIRP = PT x G R = 20 cm Calculation EIRP = 398.11 x 2.188 = 870.96 mW S = 870.96/12.56 x (20) 2 = 870.96/5024 S = 0.173 mW/cm 2 Conclusion This confirms compliance to the required radio frequency radiation exposure limit of 1.0 mW/cm 2 at 20 cm operation. - BLE Max. tune-up power(dBm) BLE 8.0 S = ERP/4 π R 2 In other words, R = √ERP/4π x S(Pd) Where S = Power density ERP = Effective Radiated Power R = distance to the centre of radiation of the antenna Values S = 1.0 mW/cm 2 for General population uncontrolled exposure (FCC Part 1.1310 Radiofrequency radiation exposure limits) S = 1.0 mW/cm 2 PT = 8.00 dBm (6.31 mW) : measured maximum output power G = Antenna gain = 3.40 dBi (2.188 in linear terms) EIRP = PT x G R = 20 cm Calculation EIRP = 6.31 x 2.188 = 13.80 mW S = 13.80/12.56 x (20) 2 = 13.80/5024 S = 0.002 75 mW/cm 2 Conclusion This confirms compliance to the required radio frequency radiation exposure limit of 1.0 mW/cm 2 at 20 cm operation. ▣ Simultaneously MPE Simultaneously MPE = PSD1/Limit1 + PSD2/Limit2 + PSD2/Limit3 UWB+BLE+Wi-Fi Simultaneously MPE = (0.000 12 mW/cm 2 / 1) + (0.173 mW/cm 2 / 1) + (0.002 75 mW/cm 2 / 1) = 0.175 87 mW/cm 2 Results: Compliant This confirms compliance to the required radio frequency radiation exposure limit of 1.0 mW/cm 2 at 20 cm operation.
