2AN96PO26802PoC Radio

THANK YOU! Thanks for your favor in our products, this manual is helpful for you to quickly know how to use, we believe this easy-to-use PoC Radio will provide dependable and reliable communication to your operating at peak efficiency. Please refer to the corresponding feature book for detailed features and operations. UNPACKING AND CHECKING EQUIPMENT Please unpack the radio and check the items listed below are received. If any item is missing or damaged, please contact your dealer at once. Packing List DESCRIPTION QUANTITY Radio 1 Li-ion Battery Pack 1 Desktop Charger 1 Adapter 1 USB Cable 1 Belt Clip 1 User Manual 1 Hand Strap 1 PREPARATION Charging the Battery Pack 1.Using the Battery Pack The battery pack is not charged at the factory, please charge it before use. To extend the battery pack lifetime, please power off the transceiver and remove the battery pack when not in use and do not leave the battery in hot or cold place. 2.Battery Pack Characteristics The battery will slowly wear out even not in use. After charging and recharging, it's normal that the talk and standby times are noticeably shorter than normal times. If leaving the battery in very hot place or conditions, it will reduce the capacity and lifetime of the battery. Overcharging may also shorten its lifetime. 3.Charging the Battery Pack Please charge your battery only with our approved charger. Initially charging the battery pack after purchase or extended storage (greater than 2 months) will not bring the battery pack to its normal operating capacity. After repeating the charge/discharge cycle two or three times, the operating capacity will increase to normal level. Please charge the battery pack as follows: 1.Insert the adapter and make sure the contacts are in contact with the socket. 2.Plug the USB cable into the desktop charger at the back. Then slide the battery pack into the desktop charger. 3.The charging LED lights red and charging begins. 4.After charging when the light turns to green, it means the battery pack is fully charged. Then you can take off the battery pack or radio with the battery pack and use it. Caution: •Make sure the radio is powered off before charging and do not use the radio during charging. •Read the safety Information booklet in advance to get necessary safety information. GETTING ACQUAINTED Orientation 1 Antenna 12 Speaker 2 Power On-Off/Volume Control Knob 13 Microphone 3 LED Indicator (TX: red, RX: green) 14 PTT Switch (PTT) 4 Accessory Jack 15 Backlight Switch 5 LCD Display 16 Quick Call Key 6 UP Key (UP) 17 Hand Strap Hook 7 Down Key (DN) 18 Battery Latch 8 Menu Key 19 SIM Card Slot 9 Back Key/Press Long Key For Lock and Unlock Key pad 20 Type-C USB 10 Programmable key 1 21 Battery Pack 11 Programmable key 2 MENU No. Main Menu Function Description 1 Group Sel. Can Select Enter Group, Monitor, Quick Call 2 Member Sel. Select Group MBB or Friend MBB to Mark Selcall or Quick Call 3 Dispatcher SMS List Use With Software PC Delete All 4 Settings Backlight Can Select Continue,5, 10, Backlight 15,20,25,30 Second Call Backlight Can Select ON/OFF Wallpaper Can Select Item 1,2,3,4,5 Wallpaper Beep Switch Can Select ON/OFF Profiles Outdoor Standard Indoor Earphone Mic Mode Low Middle High Time Zone Can Select World Time Zone (Factory Default is UTC+7) Power Saving Conf. Power Saving Level Can Select Level 1,2,3, Automatic Sleep Switch Can Select ON/OFF SIM Card SIM Card 1 SIM Card 2 SIM Switch Auto Can Select ON/OFF PTT Tone Can Select ON/OFF Sound Quality Standard High Definition Headphone Recognition Automatic Manual Bluetooth settings (optional) Can Adjust: Switch, Bluetooth Scan, Connect Bracelet PTT, Disconnect, Bluetooth Connection Time 5 Device Info. Account Info. Check Current Account App Ver Check Current Platform Version Module Ver Check Current Device Module Model Number IMEI Check Current IMEI Number ICCID Check Current ICCID Number POC Ver Check the POC Version FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF Exposure Statement SAR tests are conducted using standard operating positions according standards with the device transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. This model product has been tested and meets the RF exposure guidelines with the test distance 25mm for face and 0mm for body worn. The highest SAR1g value is 0.190W/Kg for face and 0.750 W/Kg for…
