3. TOUCH CONTROL1. QUICK PLAY A. Discovery Turn on Bluetooth on your device : Head to settings > Bluetooth and tap Bluetooth ON. B. Pairing Slide open the case with your earbuds inside. Press the button on the front of the case for 2 seconds until a blinking white light appears. 4. CUSTOMIZE YOUR EXPERIENCE Search for: "DEVIALET GEMINI" in your App store. Open the Bluetooth settings on your device and search for "DEVIALET Gemini". C. Connect To remove the eartips, simply pull them towards you. To attach new eartips, simply push them in until secured. You can choose between XS/S/M/L M size are mounted on Devialet Gemini by default. To charge your earbuds, simply place them inside the case. The LED will indicate the battery status of your earbuds. Devialet Gemini comes with a two-year warranty. You can extend your coverage with Devialet Care. 2. FIND YOUR FIT Earbuds Battery Case Battery Green: > 50%Orange: < 50%Red: Low Battery To charge your case, use the USB-C cable provided or place it on a wireless charging station. Press the button on the front of the case to check battery status. 5. BATTERY STATUS User manual 6. WARRANTY DEVIALET Gemini Press to Play or Pause. Double-press to switch between Active Noise Cancellation and Transparency modes. When on a phone call, double-press to Pick-up or Hang-up. Press and hold to activate Voice Assistant. To perform a Factory Reset, leave both earbuds inside the case, then open and close the slider while pressing the button on the front of the case. CE DEVIALET hereby declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU and all other applicable EU directive requirements. The complete declaration of conformity can be found at: devialet.com/compliance. Warning Replacement of a battery with an incorrect type that can defeat a safeguard (such as catching fire, explosion, leakage of corrosive electrolyte etc); Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion; Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; and A battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. IC This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage; (2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. Cet équipement est conforme aux limites d'exposition aux radiations IC CNR-102 établies pour un environnement non contrôlé. This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. End user must follow the specific operating instructions for satisfying RF exposure compliance. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The portable device is designed to meet the requirements for exposure to radio waves established by the ISED. These requirements set a SAR limit of 1.6 W/kg averaged over one gram of tissue. The highest SAR value reported under this standard during product certification for use when properly worn on the body. Cet équipement est conforme aux limites d’exposition aux rayonnements ISED établies pour un environnement non contrôlé. L’utilisateur final doit suivre les instructions spécifiques pour satisfaire les normes. Cet émetteur ne doit pas être co-implanté ou fonctionner en conjonction avec toute autre antenne ou transmetteur. Le dispositif portatif est conçu pour répondre aux exigences d’exposition aux ondes radio établie par le développement énergétique DURABLE. Ces exigences un SAR limite de 1,6 W/kg en moyenne pour un gramme de tissu. La valeur SAR la plus élevée signalée en vertu de cette norme lors de la certification de produit à utiliser lorsqu’il est correctement porté sur le corps. Safety Caution · Do not expose baeries or baery packs to excessive heat such as sunshine, fire or the like. · Replacement of a baery with an incorrect type that can defeat a safeguard (such as catching fire, explosion,leakage of corrosive electrolyte etc). · Disposal of a baery into fire or a hot oven, or mechanically crushing or cuing of a baery, that can result in an explosion. · Leaving a baery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas. · A baery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. · Risk of explosion if baery is replaced by an incorrect type. · Dispose of used baeries according to the instructions. · The product operation maximum ambient temperature is 45°C. · The speaker can be used in tropical climates. · No naked flame sources, such as lighted candles, should be placed on the apparatus. · Aention should be drawn to the environmental aspects of baery disposal. Caution Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to instructions old electrical appliance must not be disposed of together with the residual …

Text truncated - open the document above for the full version.

bottomfront Earbud Left: FCC ID: 2AN9V-TL101Earbud Right: FCC ID: 2AN9V-TR101This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmfulinterference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 6 External Photos for SZEM2007007362CR FCC ID: 2AN9V-TL101 2AN9V-TR101 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 6 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 6

Label placement To Federal Communication Commission Equipment Authorization Branch 7 435 Oakland Mills Road Columbia, MID 21046 For the following product, Model Name: GEMINI Model No.: TL101, TR101 FCC ID: 2AN9V-TL101(for Earbud Left) FCC ID: 2AN9V-TR101(for Earbud Right) The FCC ID is not affixed on the product itself , but described in the product user manual and the product package/case due to below reasons. Reasons： The product is too small to put the label on it. The Size is below: 26.7mm* 18.6mm*23.6mm Print Name: Thiago Barbosa Title: Product Compliance Signature: On behalf of Company: DEVIALET Telephone: +33637966065 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 1 of 14 Internal Photos for SZEM2007007362CR FCC ID: 2AN9V-TL101 2AN9V-TR101 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 2 of 14 1 EUT Constructional Details SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 3 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 4 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 5 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 6 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 7 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 8 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 9 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 10 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 11 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 12 of 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 13 of 14 Antenna: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Page: 14 of 14

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700736204 Page: 1 of 9 Keny Xu EMC Laboratory Manager 1 Cover page SAR Evaluation Report Application No.: SZEM2007007362CR Applicant: DEVIALET Address of Applicant: 10 Place Vendome 75001 Paris FRANCE Manufacturer: DEVIALET Address of Manufacturer: 10 Place Vendome 75001 Paris FRANCE Factory: Tiinlab Acoustic Technology Limited Address of Factory: Tianliao Building 1403, Zone A Tianliao Industrial Park, Taoyuan Str.,Nanshan Dist., Shenzhen, P.R. China Equipment Under Test (EUT): EUT Name: GEMINI Model No.: TX101, Earbud Right- TR101, Earbud Left- TL101, Charging case- TC101   Please refer to section 4.1 of this report which indicates which model was actually tested and which were electrically identical. Trade mark: DEVIALET FCC ID: 2AN9V-TL101 2AN9V-TR101 Standards: 47 CFR Part 1.1307 47 CFR Part 2.1093 KDB447498D01 General RF Exposure Guidance v06 Date of Receipt: 2020-08-04 Date of Test: 2020-08-29 to 2020-08-29 Date of Issue: 2020-08-29 Test Result : PASS* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700736204 Page: 2 of 9 2 Version Revision Record Version Chapter Date Modifier Remark 01 2020-08-29 Original Authorized for issue by: Bill/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700736204 Page: 3 of 9 3 Contents Page 1 COVER PAGE .............................................................................................................................................. 1 2 VERSION ...................................................................................................................................................... 2 3 CONTENTS .................................................................................................................................................. 3 4 GENERAL INFORMATION .......................................................................................................................... 4 4.1 GENERAL DESCRIPTION OF EUT ............................................................................................................. 4 4.2 TEST LOCATION ...................................................................................................................................... 5 4.3 TEST FACILITY ........................................................................................................................................ 5 4.4 DEVIATION FROM STANDARDS ................................................................................................................. 6 4.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................... 6 4.6 OTHER INFORMATION REQUESTED BY THE CUSTOMER ............................................................................. 6 5 SAR EVALUATION ...................................................................................................................................... 7 5.1 RF EXPOSURE COMPLIANCE REQUIREMENT ............................................................................................ 7 5.1.1 Standard Requirement ..................................................................................................................... 7 5.1.2 Limits ................................................................................................................................................ 7 5.1.3 EUT RF Exposure ......................................................................................................................... 7-9 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700736204 Page: 4 of 9 4 General Information 4.1 General Description of EUT Battery: Left earphone:Rechargeable battery DC (Charge by charging box) Right earphone:Rechargeable battery (Charge by charging box) Charging box:Rechargeable battery (Charge by Type C) For BT: Spectrum Spread Technology: Frequency Hopping Spread Spectrum(FHSS) Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.0 Modulation Type: GFSK, Pi/4DQPSK, 8DPSK Number of Channels: 79 Channel Spacing: 1MHz Antenna Gain: -3.6dBi For BLE: Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.0 Modulation Type: GFSK Number of Channels: 40 Channel Spacing: 2MHz Data rate: 1Mbit/s Antenna Type: LDS antenna Antenna Gain: -3.6dBi Declaration of EUT Family Grouping: Model No.: TX101, Earbud Right- TR101, Earbud Left- TL101, Charging case- TC101 Only the model TX101 was tested. According to the declaration from the applicant, the electrical circuit design, layout, components used, internal wiring and functions were identical for the above models, with only difference on TX101 contain 3 models which are TR101- Earbud Right, TL101- Earbud Left, TC101- Charging case. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch Report No.: SZEM200700736204 Page: 5 of 9 4.2 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch No. 1 Workshop, M-10, Middle section, Science & Technology Park, Shenzhen, Guangdong, China 518057 Telephone: +86 (0) 755 2601 2053 Fax: +86 (0) 755 2671 0594 No tests were sub-contracted. 4.3 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01. • VCCI The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz, Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have been re…
