2ANBW-HY820High-Performance Handheld Terminal

1 UHF RFID User Manual 2020/12/22 2 LEGAL INFORMATION Copyright © 2020 Shenzhen Eastaeon Technology Co.,Ltd. All rights reserved. No part of this publication may be quoted, reproduced, translated or used in any form or by any means, electronic or mechanical, including photocopying and microfilm, without the prior written permission of Shenzhen Eastaeon Technology Co.,Ltd. Corporation. Shenzhen Eastaeon Technology Co.,Ltd. Corporation reserves the right to make modifications on print errors or update specifications in this guide without prior notice. Version No.: V1.0 Edition Time: 2020/12/22 3 Contents Getting Started ......................................................... 5 Overview ........................................................................ 5 Key Explainrd ................................................................. 6 Starting up ..................................................................... 6 Switching Your Terminal On/Off ..................................... 8 Getting Around Your Terminal ........................................ 9 RFID handle interaction ........................................ 10 Scene one RFID mode ................................................. 10 Scene two Scan code mode ......................................... 11 Touch Input Settings .................................................... 12 Browsing Options ......................................................... 12 Using Bookmarks ......................................................... 12 Making the Most of Multimedia ............................. 12 Camera ........................................................................ 12 Play Music ................................................................... 13 Photos ......................................................................... 13 Sorting out Your Terminal Settings ..................... 13 Applications ................................................................. 13 Display Settings ........................................................... 13 Sound Settings ............................................................. 14 Managing Your Device Memory ................................... 14 Special Settings ........................................................... 14 Scan Settings ............................................................... 14 Language Settings ....................................................... 15 4 Setting Date and Time ................................................. 15 Reset to Factory Settings ............................................ 15 Clock ........................................................................... 16 Calculator .................................................................... 16 For Your Safety ...................................................... 16 General Safety ............................................................ 16 Distraction ................................................................... 17 Product Handling ......................................................... 18 Electrical Safety ........................................................... 21 Interference ................................................................. 21 Explosive Environments .............................................. 23 System update ............................................................ 23 Common Fault Diagnosis ............................................ 24 5 Getting Started Overview 6 Key Explainrd Key Function Power Key  Hold to switch to power off, power on, restart.  Press to switch your terminal to Sleep mode.  Press to wake up your terminal. Home Key  Press to return to the Home Screen from any application or screen.  Hold to see recently used applications. Recent Key Press to recent APP.. Back Key Press to go to the previous screen. Volume Keys Press or hold to turn the volume up or down. Starting up Status and Notification lcons Your terminal will tell you exactly what’s going on by showing you simple icons. Here’s what they mean USB connected Battery charge Airplane mode Meeting mode Alarm set Silent mode 7 Installing the SD Switch off your terminal before installing or replacing the memory card. 1. Insert SD card into the tray and push it into the terminal. Charging the Battery When you first get your new terminal you’ll need to charge the battery. Connect the adapter to the charger jack. Ensure that the adapter is inserted with the correct orientation. Do not force the connector into the charger jack. Connect the charger to a standard AC wall outlet. Disconnect the charger when the battery is fully charged. 插入示意图 8 Switching Your Terminal On/Off Make sure the SD card is in your device and the battery is charged. 1. Hold Power Key to switch on your terminal. 2. To switch it off, hold Power Key to get the terminal options. Select Power off. Setting Up Your Terminal for the First Time When you first power on your terminal after you purchase it or reset it to factory settings (see chapter Sorting out Your Terminal Settings – System – Reset options Settings), you need to do some settings before using it. Switching to Sleep Mode To save battery power, Sleep Mode suspends your device to a low-power-consumption state while the display is off. Your device also goes into Sleep Mode by itself when the display is automatically turned off after a certain period of time. You can start sleep mode by the following method. Press Power Key to switch to Sleep Mode. Waking Up Your Terminal Press Power Key to activate your screen display. Tap the icon, drag to the up. NOTE: If you have set an unlock pattern, PIN or password for your terminal (see chapter Sorting out Your Terminal Settings – Security & location Settings) you’ll need to draw the pattern or enter the PIN/password to unlock your screen. 9 Getting Around Your Terminal Touch Control You can use finger gestures to control your terminal. The controls on your touch-screen change dynamically depen…

Text truncated - open the document above for the full version.

Rev 11/20/07 Shenzhen Hopeland Technologies CO., Ltd. Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ANBW-HY820 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit TypeFile Name Block Diagram, Schematics, Operational Description Block Diagram Operation Description schematic diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, xiaoxia xue/manager Shenzhen Hopeland Technologies CO., Ltd.

M:\Master Documents\TEMPLATES\POA_Letter.doc Shenzhen Hopeland Technologies CO., Ltd. Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: 2021-2-2 SUBJECT: FCC Application for FCC ID: 2ANBW-HY820 To Whom It May Concern: We, the undersigned, hereby authorize Lisa Wang at EMTEK (SHENZHEN) CO., LTD. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by EMTEK (SHENZHEN) CO., LTD. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, xiaoxia xue/manager Shenzhen Hopeland Technologies CO., Ltd.

EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 EUT View 3 EUT View 4 EUT View 5 EUT View 6 Adapter ----------------The end----------------

Label:

EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View 1: EUT Housing and Board View 2: RFID ANT EUT Housing and Board View 3: EUT Housing and Board View 4: EUT Housing and Board View 5: EUT Housing and Board View 6: EUT Housing and Board View 7: EUT Housing and Board View 8: EUT Housing and Board View 9: EUT Housing and Board View 10: External Ant. EUT Housing and Board View 11: EUT Housing and Board View 12: Battery top: Battery bottom: EUT Housing and Board View 13: EUT Housing and Board View 14: EUT Housing and Board View 14: EUT Housing and Board View 15: EUT Housing and Board View 16: EUT Housing and Board View 17: EUT Housing and Board View 18 ----------------The end----------------

Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2020/11/28 System Check_H900 DUT: Dipole 900 MHz;Type:D900V2; SN:1d121 Communication System: CW; Frequency: 900 MHz;Duty Cycle: 1:1 Medium: H900 Medium parameters used: f = 900 MHz; σ = 0.964 S/m; ε r = 41.988; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3970; ConvF(10 .24, 10.24, 10.24); Calibrated: 2020/2/8; - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1418; Calibrated: 2020/1/8 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=250mW/Area Scan (51x91x1): Interpolated grid: dx=2.000 mm, dy=2.000 mm Maximum value of SAR (interpolated) = 3.74 W/kg Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 63.504 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 4.36 W/kg SAR(1 g) = 2.71 W/kg; SAR(10 g) = 1.72 W/kg Maximum value of SAR (measured) = 3.85 W/kg

Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2020/11/28 915.25_FACE UP DUT: HY820 Communication System: RFID; Frequency: 915.25 MHz;Duty Cycle: 1:1 Medium: H900 Medium parameters used: f = 915 MHz; σ = 0.955 S/m; ε r = 40.869; ρ = 1000 kg/m 3 Ambient Temperature：22.5 °C; Liquid Temperature：21.6 °C DASY5 Configuration: - Probe: EX3DV4 - SN3970; ConvF(10.24, 10.24, 10.24); Calibrated: 2020/2/8; - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn1418; Calibrated: 2020/1/8 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Face up/Area Scan (121x141x1): Interpolated grid: dx=1.000 mm, dy=1.000 mm Maximum value of SAR (interpolated) = 0.463 W/kg Face up/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 20.237 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 0.822 W/kg SAR(1 g) = 0.367 W/kg; SAR(10 g) = 0.214 W/kg Maximum value of SAR (measured) = 0.402 W/kg

FCC SAR Test Report Report No. ES201127034WPage 1 of 31Ver.1.0 FCC SAR Test Report Report No.: ES201127034W Applicant: Shenzhen Hopeland Technologies CO., Ltd. Address: 17/F, Block A, Clou Bldg, Baoshen Road, Hitech Industrial Park North, Nanshan District, 518007, Shenzhen, China Product: High-Performance Handheld Terminal FCC ID: 2ANBW-HY820 Brand: Model No.: HY820 Standards: FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2013 KDB 865664 D01 v01r04 / KDB 865664 D02 v01r02 KDB 447498 D01 v06 Sample Received Date: Nov. 27, 2020 Date of Testing: Nov. 28, 2020 ~ Nov. 29, 2020 CERTIFICATION:The above equipment have been tested byEMTEK (SHENZHEN) CO., LTD. Bldg 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by A2LA or any government agencies. Prepared by : Lance Li/Editor Reviewer : Joe Xia/Supervisor Approve & Authorized Signer : Lisa Wang/Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. sororororoororrorororororororoorrorooorooorororrororoooororrrrororoooroororororororrrororrororoooooooorooororroor ger $Ḵ亜䞩$ FCC SAR Test Report Report No. ES201127034WPage 2 of 31Ver.1.0 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot.................................................................................................................................................................. 7 3.2.2 Probes................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms........................................................................................................................................................... 9 3.2.5 Device Holder................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 14 3.4 SAR Measurement Procedure ................................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 15 3.4.2 VolumeScan Procedure.................................................................................................................................... 15 3.4.3 Power Drift Monitoring...................................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation .......................................................................................…

Text truncated - open the document above for the full version.

Report No. ES201127034W01 Page 1 of 48 Ver.1.0 TEST REPORT Product Name : High-Performance Handheld Terminal Model Number : HY820 FCC ID : 2ANBW-HY820 Prepared for : Shenzhen Hopeland Technologies CO., Ltd. Address : 17/F, Block A, Clou Bldg, Baoshen Road, Hitech Industrial Park North, Nanshan District, 518007, Shenzhen, China Prepared by : EMTEK (SHENZHEN) CO., LTD. Address : Building 69, Majialong Industry Zone, Nanshan District, Shenzhen, Guangdong, China Tel: (0755) 26954280 Fax: (0755) 26954282 Report Number : ES201127034W01 Date(s) of Tests : Nov. 27, 2020 to Jan. 20, 2021 Date of issue : Jan. 25, 2021 Report No. ES201127034W01 Page 2 of 48 Ver.1.0 Table of Contents TEST REPORT ......................................................................................................................................................... 1 1 TEST RESULT CERTIFICATION ...................................................................................................................... 3 2 EUT TECHNICAL DESCRIPTION .................................................................................................................... 4 3 SUMMARY OF TEST RESULT ......................................................................................................................... 5 4 TEST METHODOLOGY.................................................................................................................................... 6 4.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................................... 6 4.2 MEASUREMENT EQUIPMENT USED .................................................................................................... 6 4.3 DESCRIPTION OF TEST MODES ........................................................................................................... 7 5 FACILITIES AND ACCREDITATIONS .............................................................................................................. 8 5.1 FACILITIES .............................................................................................................................................. 8 5.2 LABORATORY ACCREDITATIONS AND LISTINGS ............................................................................... 8 6 TEST SYSTEM UNCERTAINTY ....................................................................................................................... 9 7 SETUP OF EQUIPMENT UNDER TEST ........................................................................................................ 10 7.1 RADIO FREQUENCY TEST SETUP 1 ................................................................................................... 10 7.2 RADIO FREQUENCY TEST SETUP 2 ................................................................................................... 10 7.3 CONDUCTED EMISSION TEST SETUP ............................................................................................... 12 7.4 BLOCK DIAGRAM CONFIGURATION OF TEST SYSTEM ................................................................... 13 7.5 SUPPORT EQUIPMENT ....................................................................................................................... 13 8 TEST REQUIREMENTS ................................................................................................................................. 14 8.1 20DB BANDWIDTH ............................................................................................................................... 14 8.2 CARRIER FREQUENCY SEPARATION ................................................................................................ 17 8.3 NUMBER OF HOPPING FREQUENCIES ............................................................................................. 20 8.4 AVERAGE TIME OF OCCUPANCY (DWELL TIME) .............................................................................. 22 8.5 MAXIMUM PEAK CONDUCTED OUTPUT POWER ............................................................................. 24 8.6 CONDUCTED SUPRIOUS EMISSION .................................................................................................. 27 8.7 RADIATED SPURIOUS EMISSION ....................................................................................................... 34 8.8 CONDUCTED EMISSION TEST............................................................................................................ 44 8.9 ANTENNA APPLICATION ...................................................................................................................... 47 Report No. ES201127034W01 Page 3 of 48 Ver.1.0 1 TEST RESULT CERTIFICATION Applicant: Shenzhen Hopeland Technologies CO., Ltd. Address: 17/F, Block A, Clou Bldg, Baoshen Road, Hitech Industrial Park North, Nanshan District, 518007, Shenzhen, China Manufacturer: Shenzhen Hopeland Technologies CO., Ltd. Address: 17/F, Block A, Clou Bldg, Baoshen Road, Hitech Industrial Park North, Nanshan District, 518007, Shenzhen, China Product Description: High-Performance Handheld Terminal Model Number: HY820 Trademark: Measurement Procedure Used: APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 2, Subpart J FCC 47 CFR Part 15, Subpart C PASS The above equipment was tested by EMTEK(SHENZHEN) CO., LTD. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10 (2013) and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 2 and Part 15.247 The test results of this report relate only to the tested sample identified in this report Date of Test : Nov. 27, 2020 to Jan. 20, 2021 Prepared by : Tracy Hu /Editor Reviewer : Sewen Guo /Supervisor Approve & Authorized Signer : Lisa Wang/Manager Report No. ES201127034W01 Page 4 of 48 Ver.1.0 2 EUT TECHNICAL DESCRIPTION Characteristics Description Product : High-Perform…

Text truncated - open the document above for the full version.

FCC SAR Test Report Report No.ES201127037W Page 1 of 2 Ver.1.0 <Photographs of EUT> FCC SAR Test Report Report No.ES201127037W Page 2 of 2 Ver.1.0 <Photographs of SAR Setup> Face Up 0 cm Gap Rear Face 0 cm Gap Left Side 0 cm Gap Right Side 0 cm Gap Bottom Side 0 cm Gap

TEST SETUP PHOTOGRAPHS 1.1. Photos of Radiation Emission Measurement Spurious Emission Test Setup (Below 1GHz) Spurious Emission Test Setup (Above 1GHz) 1.2. Photos of Conducted Emission Measurement ----------------The end----------------
