2ANTH-FS2TS1Optical Time Domain Reflectometer

FlexScan ® FS200 OTDR With SmartAuto ® , FleXpress ™ and LinkMap ® User’s Guide www.AFLglobal.com or +1 (800) 235-3423 Test & Inspection 2 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Apple Inc . Legal Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Controls, Display, Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Front Panel Buttons and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Understanding Battery Charge Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Configuring FlexScan to Auto-Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 User Interface Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Home Screen Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Test Modes and Features Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Utility Modes and Features Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 General Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 SmartAuto ® OTDR with FleXpress ™ and LinkMap ® Display . . . . . . . . . . . . . . . . . .20 Using Touchscreen Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 SmartAuto Settings Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Configuring Pass/Fail Rule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Configuring Fiber Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Contents © 2022 AFL , all rights reserved . FS200-00-1000 Revision AD, 2022-11-01 3 Enabling Launch Quality Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Launch and Receive Cable Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Testing in SmartAuto ® OTDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 To Start SmartAuto Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Live Fiber Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Launch Quality Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Understanding LinkMap Display Features . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 Understanding Expert/Real-time OTDR Settings . . . . . . . . . . . . . . . . . . . . . . . . . .31 Expert OTDR Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 Real-Time OTDR Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Testing in Expert and Real-Time OTDR Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 To Test in Expert or Real-Time OTDR Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .34 Understanding Trace Display Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Light Source and Power Meter Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Light Source Settings and Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Power Meter Settings and Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38 Inspecting Fibers with FOCIS Flex and FlexScan . . . . . . . . . . . . . . . . . . . . . . . . . .39 FOCIS Flex Inspection Probe Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39 Pairing FlexScan with FOCIS Flex Inspection Probe . . . . . . . . . . . . . . . . . . . . .41 Contents 4 Enable Bluetooth on FlexScan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41 Enable Bluetooth on FOCIS Flex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42 Inspecting Optical Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43 Saving, Recalling and Uploading Test Results . . . . . . . . . . . . . . . . . . . . . . . . . . . .45 Saving to a Newly Created Folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Saving to the Current Folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47 Viewing Saved Test Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48 Deleting Jobs/Cables/Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49 Transferring Files to a PC via USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 Backing up Results to External USB Memory Stick . . . . . . . . . . . . . . . . . . . . . .51 Restoring Results from External USB Memory Stick . . . . . . . . . . . . . . . . . . . . .52 How to View Device Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 Warranty Terms and Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54 Repair Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55 Contents 5 Safety Information WARNING! Use of procedures or adjustments other than those specified herein may result in hazardous radiation exposure . 1550 nm OTDR/OLS port 1650 nm OTDR/OLS port 1310/1550 nm OTDR/OLS port 1310/1550/1650 nm OTDR/OLS port This is a CLASS I LASER output. VFL…

Text truncated - open the document above for the full version.

FlexScan ® TS100 Optical Troubleshooter User’s Guide Test & InspectionTest & Inspection www.AFLglobal.com | +1 (800) 235-3423 2 Table of Contents Safety Information .....................................3 Apple Inc. Legal Notice..................................4 Labeling and Hazard Warning............................5 Hardware Overview ....................................6 Controls, Display, Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Understanding Battery Charge Status . . . . . . . . . . . . . . . . . . . .7 Configuring FlexScan to Auto-Off . . . . . . . . . . . . . . . . . . . . . . .7 User Interface Overview .............................8 New Test - FlexScan’s Home Screen . . . . . . . . . . . . . . . . . . . . . .8 Test/Home Menu Screen Overview . . . . . . . . . . . . . . . . . . . . . .9 Fault Locate Setup Screen Overview . . . . . . . . . . . . . . . . . . . . .10 FleXpress ® Fault Locate Test Setup ........................11 Network Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Launch Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Pass/Fail Rule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Fiber Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Viewing and Configuring Fiber Type . . . . . . . . . . . . . . . . . . .13 General Settings .......................................14 Live Fiber Detection and Launch Quality Check..............16 Launch Quality Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Live PON Test..........................................16 Test Sequence in Live PON Test . . . . . . . . . . . . . . . . . . . . . . . . . .16 LinkMap Display and Navigation .........................17 Light Source and Power Meter Operation ..................18 Light Source Settings and Features . . . . . . . . . . . . . . . . . . . . . .18 Power Meter Settings and Features . . . . . . . . . . . . . . . . . . . . . .18 Inspecting Fibers with FOCIS Probe and FlexScan............19 FOCIS Flex Inspection Probe Overview . . . . . . . . . . . . . . . . . . . .19 Pairing FlexScan with FOCIS Flex Inspection Probe . . . . . . . . . .20 Configuring Auto-Send . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Inspecting Optical Connectors . . . . . . . . . . . . . . . . . . . . . . . . . .21 File Manager ..........................................22 Manually Saving Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Viewing Saved Test Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Deleting Projects/Jobs/Fibers . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Transferring Results to a PC via USB .......................25 Back Up Saved Results to USB Memory ....................25 How to View Device Information .........................26 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Warranty Terms and Conditions . . . . . . . . . . . . . . . . . . . . . . . . .26 Need Help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 © 2022 AFL, all rights reserved . TS100-00-1000 Revision AB, 2022-11-01 3 Safety Information WARNING! Use of procedures or adjustments other than those specified herein may result in hazardous radiation exposure . 1650 nm SM OTS/OLS/OPM portThis is a CLASS I LASER output. VFL port This is a CLASS Class 3A / Class 3R LASER output. Avoid exposure to the beam! NOTE! FlexScans equipped with Bluetooth (option W1) contain the following Bluetooth Transmitter Module: FCC ID: X3ZBTMOD8 IC: 8828A-MOD8 NOTE! FlexScans equipped with Wi-Fi contain the following Wi-Fi Transmitter: FCC ID: 2ANTH-FS2TS1 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation . Changes or modifications not expressly approved by AFL Test and Inspection could void the user's authority to operate the equipment . Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules . These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment . This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications . Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense . IC: 23261-FS2TS1 This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s license exempt (RSS(s) . Operation is subject to the following two conditions: 1 . This device may not cause interference . 2 . This device must accept any interference, including interference that may cause undesired operation of the device . L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence . L’exploitation est autorisée aux deux conditions suivantes : 1 . L’appareil ne doit pas produire de brouillage; 2 . L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement . WARNING! Use only the specified AC adapter . Use of another type of AC adapter can damage the instrument and create the danger of fire and electrical shock .…

Text truncated - open the document above for the full version.

1 October 2021 To Whom It May Concern: I hereby appoint Grant Burns to sign letters and applications for any filings with regulatory agencies on our behalf, and to receive and exchange data between our company, the agent’s company and the agency in connection with certification for any products that our company owns or manufactures. Sincerely, Dale Channing Eddy Engineering Technician III - Compliance AFL Test and Inspection (AFL Telecommunications LLC)

13 January 2022 To Whom It May Concern: I hereby appoint Michael Scholten to sign letters for any filings with regulatory agencies on our behalf, and to receive and exchange data between our company, the agent’s company and the agency in connection with certification for any products that our company owns or manufactures. Sincerely, Dale Channing Eddy Engineering Technician III - Compliance AFL Test and Inspection (AFL Telecommunications LLC)

September 1, 2021 To Whom It May Concern: We hereby delegate CKC Certification Services, LLC (CKC CS) power of attorney to act on our behalf in matters pertaining to certification of products pertaining to the FS200/TS100 product family. The actions of CKC CS shall be considered the same as our own. Sincerely, Grant Burns Executive Vice President and General Counsel

14 October 2022 To whom it may concern, The firmware for the FlexScan FS200 and TS100 written by AFL’s partner/contract manufacturer, Lifodas UAB, incorporates the Bluetooth driver/initialization software from the Bluetooth module manufacturer, Amp’ed RF. This software initializes the module and sets the RF output power parameters. When the proper RF output power level to meet SAR requirements was determined through testing by F2 Labs, Amp’ed included the power level setting in their software. The Amp’ed software is compiled into the FS200/TS100 firmware. This software cannot be modified by either AFL or Lifodas as it is proprietary to Amp’ed and neither AFL nor Lifodas have access to the source code. The Bluetooth module power settings cannot be changed either by FlexScan software updates or by the user as neither AFL nor the users have any access to the means of modifying output power settings. Regards, Dale Channing Eddy Engineering Technician III - Compliance AFL Test and Inspection (AFL Telecommunications LLC)

9/30/2021 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Permanent Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459 pertaining to confidential material, we hereby request to hold permanently confidential all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: 2ANTH-FS2TS1 1. Block Diagram 2. Operational Description The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. The public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, Dale Channing Eddy Engineering Technician III - Compliance AFL Test and Inspection

F2P25243C Page 1 of 17 2021-7-20 PHOTOGRAPHS: EXTERNAL AFL Test and Inspection - FCC ID: 2ANTH-FS2TS1 Model FS200-100A Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 2 of 17 2021-07-20 Model FS200-100A, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 3 of 17 2021-07-20 Model FS200-100A, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 4 of 17 2021-07-20 Model FS200-100A, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 5 of 17 2021-07-20 Model FS200-50B-U Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 6 of 17 2021-07-20 Model FS200-50B-U, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 7 of 17 2021-07-20 Model FS200-50B-U, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 8 of 17 2021-07-20 Model FS200-50B-U, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 9 of 17 2021-07-20 Model FS200-304C-U Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 10 of 17 2021-07-20 Model FS200-304C-U, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 11 of 17 2021-07-20 Model FS200-304C-U, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 12 of 17 2021-07-20 Model FS200-304C-U, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 13 of 17 2021-07-20 Model TS100-60B-A Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 14 of 17 2021-07-20 Model TS100-60B-A, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 15 of 17 2021-07-20 Model TS100-60B-A, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 16 of 17 2021-07-20 Model TS100-60B-A, cont’d Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 17 of 17 2021-07-20 Model TS100-60B-A, cont’d

1AFL FlexScan FS200 & TS100 Product Labels and Locations 04/04/2022 ~6.25" ~3.25" FLEXSCAN F C C ID : 2ANT H-FS2T S1 IC: 23 261-FS2T S1 C on t ai ns F C C ID : X3 ZB TMO D8 C ont ai ns IC : 88 28 A-MO D8 The above is an example drawing of FlexScan FS200. The TS100 is identical to the FS200 except for the boots on the end of case. ~6.25" ~3.25" AVOID EX POSURE – Laser radiat ion i s emit te d f rom t his apert ure LASER RADIATION DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT WAVELENGTH: 610 to 690nm MAX OUTPUT: 1.0 mW PULSE RATE: 2Hz, 50% DUTY IEC 60825-1:2007-03 CALIBR AT ION VOID IF SEAL IS BROKEN MODE L:FS 20 0-xxxb-c YYYY1310/1550 nm SERIAL:MYWWCC NNNNN AFL Test & Inspection www.AFLglobal.com Designed and Quality Assured in the USA This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, 6/24/07. Ba rc ode A ss em b l ed In Lithuania 5V 2.0A Pate nt Pe nding F C C ID : 2ANT H-FS2T S1 IC: 23 261-FS2T S1 C on t ai ns F C C ID : X3 ZB TMO D8 C ont ai ns IC : 88 28 A-MO D8 The above is an example drawing of FlexScan FS200. The TS100 is identical to the FS200 except for the boots on the end of case. Actual product labels: Standard FCC ID/IC label for FS200 & TS100 The above shows the location of the serial number/model type/CE/FDA certification label. This is the same location on both the FS200 and TS100. The labels shown below are for the individual FS200 and TS100 models. Some of the FS200 labels show older models that are still in service, have the Bluetooth module and CC3200-based WiFi transceiver, though the installed firmware does not support the WiFi function. Enabling WiFi would require a firmware update. MODE L:FS 20 0-xxxb-c YYYY1310/1550 nm SERIAL:MYWWCC NNNNN AFL Test & Inspection www.AFLglobal.com Designed and Quality Assured in the USA This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, 6/24/07. A ss em b l ed In Lithuania 5V 2.0A Pate nt Pe nding FS200 Serial Number Label MODE L:TS 10 0-xxxb-c YYYY1310/1550 nm SERIAL:MYWWCC NNNNN AFL Test & Inspection www.AFLglobal.com Designed and Quality Assured in the USA This product complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, 6/24/07. A ss em b l ed In Lithuania 5V 2.0A Pate nt Pe nding TS100 Serial Number Label FS200 Serial Number Label Key YYYY: Year of manufacture (e.g. ‘2017’) Configuration: Wavelengths: FS200-50 1550 nm FS200-60 1650 nm FS200-100 1310/1550 nm FS200-300 1310/1550 nm FS200-303 1310/1550/1625 nm FS200-304 1310/1550/1650 nm b = hardware version: absent = original hardware ‘B’ = Mar-2017 PCB ‘C’ = Jun-2019 PCB w/ improved APD protection c = ‘U’ (UPC OTDR/OLS connector) c = ‘A’ (APC OTDR/OLS connector) Serial Number: MYWWCCNNNNN where: M = Multiplier (2) Y = year character (A=2012, B=2013, etc.) WW = Week no. CC = Product code NNNNN = sequential quantity TS100 Serial Number Label Key YYYY: Year of manufacture (e.g. ‘2020’) Configuration: Wavelengths: TS100-60 1550 nm TS100-70 1650 nm TS100-100 1310/1550 nm b = hardware version: absent = original hardware B = Updated P2 filter c = ‘U’ (UPC OTDR/OLS connector) c = ‘A’ (APC OTDR/OLS connector) Serial Number: MYWWCCNNNNN where: M = Multiplier (2) Y = year character (A=2012, B=2013, etc.) WW = Week no. CC = Product code NNNNN = accumulating consecutive #

F2P25243C Page 1 of 4 2021-7-20 PHOTOGRAPHS: INTERNAL AFL Test and Inspection - FCC ID: 2ANTH-FS2TS1 Model FS200: Front Model FS200: Rear Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 2 of 4 2021-07-20 Model FS200: Bluetooth Model FS200: Wi-Fi Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 3 of 4 2021-07-20 Model TS100: Front Model TS100: Rear Order Number: F2P25243C Applicant: AFL Test and Inspection FCC ID: 2ANTH-FS2TS1 F2P25243C Page 4 of 4 2021-07-20 ModelTS100: Bluetooth Model TS100: Wi-Fi

042216 Report Number: F2P25243C-04E Page 1 of 8 Issue Date: 2022-10-05 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com SAR EXCLUSION REPORT Manufacturer: AFL Test and Inspection 16 Eastgate Park Road Belmont, New Hampshire 03220 USA Applicant: Same As Above Product Name: FlexScan Product Description: The FlexScan is an optical time domain reflectometer used on optical fiber networks. Model(s): FS200-304U* *Denotes actual model tested as representative of product family that includes models FS200-50/-60/-100/-300/-303/-304 and TS100-60/-70/-100. FCC ID: 2ANTH-FS2TS1 Testing Commenced: 2021-06-21 Testing Ended: 2022-08-31 Test Results: In Compliance The EUT complies with the EMC requirements when manufactured identically as the unit tested in this report, including any required modifications. Any changes to the design or build of this unit subsequent to this testing may deem it non-compliant. Standards: • KDB 447498 D04 v00 Interim guidance • FCC Rule Part 1.1307(b)(3)(i)(a) Order Number: F2P25243C Client: AFL Test and Inspection Model: FS200-304U 042216 Report Number: F2P25243C-04E Page 2 of 8 Issue Date: 2022-10-05 Evaluation Conducted by: Julius Chiller, EMC/Wireless Engineer Report Reviewed by: Ken Littell, Vice President of EMC F2 Labs F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road 8583 Zionsville Road Damascus, MD 20872 Middlefield, OH 44062 Indianapolis, IN 46268 Ph 301.253.4500 Ph 440.632.5541 Ph 317.610.0611 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order Number: F2P25243C Client: AFL Test and Inspection Model: FS200-304U 042216 Report Number: F2P25243C-04E Page 3 of 8 Issue Date: 2022-10-05 TABLE OF CONTENTS Section Title Page 1 ADMINISTRATIVE INFORMATION 4 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 5 3 ENGINEERING STATEMENT 6 4 EUT INFORMATION AND DATA 7 5 RF EXPOSURE FOR DEVICE <20cm FROM HUMAN 8 Order Number: F2P25243C Client: AFL Test and Inspection Model: FS200-304U 042216 Report Number: F2P25243C-04E Page 4 of 8 Issue Date: 2022-10-05 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to FCC rules and KDB558074. 1.4 Document History Document Number Description Issue Date Approved By F2P25243C-04E First Issue 2022- 10-05 K. Littell Order Number: F2P25243C Client: AFL Test and Inspection Model: FS200-304U 042216 Report Number: F2P25243C-04E Page 5 of 8 Issue Date: 2022-10-05 2 SUMMARY OF TEST RESULTS Test Name Standard(s) Results RF Exposure for Device <20cm from Human KDB 447498 D04 v00 Interim guidance FCC Rule Part 1.1307(b)(3)(i)(a) Complies Modifications Made to the Equipment None Order Number: F2P25243C Client: AFL Test and Inspection Model: FS200-304U 042216 Report Number: F2P25243C-04E Page 6 of 8 Issue Date: 2022-10-05 3 ENGINEERING STATEMENT This report has been prepared on behalf of AFL Test and Inspection to provide documentation for the testing described herein. This equipment has been tested and found to comply with the SAR Exclusion levels listed in FCC Rule Part 1.1307(b)(3)(i)(a) and KDB 447498 D04 v00 Interim guidance. Order Number: F2P25243C Client: AFL Test and Inspection Model: FS200-304U 042216 Report Number: F2P25243C-04E Page 7 of 8 Issue Date: 2022-10-05 4 EUT INFORMATION AND DATA 4.1 Equipment Under Test: Product: FlexScan Model: FS200-304U* Serial No.: 2E50WE1685 FCC ID: 2ANTH-FS2TS1 *Denotes actual model tested as representative of product family that includes models FS200-50/-60/-100/-300/-303/-304 and TS100-60/-70/-100. 4.2 Trade Name: FlexScan 4.3 Power Supply: Charger, AFL 4050-000031MR 4.4 Applicable Rules: KDB 447498 D04 v00 Interim guidance FCC Rule Part 1.1307(b)(3)(i)(a) 4.5 Equipment Category: Radio Transmitter-DTS 4.6 Antenna: Wi-Fi = Integral, 1.9dBi Chip Bluetooth = Integral 0.5dBi Chip 4.7 Accessories: N/A 4.8 Test Item Condition: The equipment to be tested was received in good condition. Order Number: F2P25243C Client: AFL Test and Inspection Model: FS200-304U 042216 Report Number: F2P25243C-04E Page 8 of 8 Issue Date: 2022-10-05 5 RF EXPOSURE FOR DEVICE <20cm FROM HUMAN 5.1 Requirements: Distance Used: 5mm Limit: 4.3mW Formula Used for Results: Results taken from the output power recorded in the Grant of Authorization for the Bluetooth Module, but reduced power, and new power measurements recorded with power settings reduced. Results taken from Test Report F2P25243C-01E for the Wi-Fi module. Transmitters cannot transmit simultaneously. Results: Highest Output Power: Mid-channel, 3.85dBm (2.43 mW) Max Antenna Gain: 1.9dBi E.I.R.P., Wi-Fi: 5.75dBm (3.758 mW) E.I.R.P., Bluetooth: 3.93 mW BLE EDR High Channel, which was the highest of all Bluetooth measurements from all modes. Maximum output power of the Bluetooth module was turned down to 5.441dBm. Max antenna gain was 0.5dBi. The max E.I.R.P. would be 5.941dBm or 3.93 mW.

Approved antennas list: Antenna Description Type Peak Gain (dBI) Ω ACX AT1608-A2R4NAA BT Chip 0.5 50 TY AH316M245001-T WiFi Chip 1.9 50

051816 Report Number: F2P25243C-01E Page 1 of 69 Issue Date: 2022-09-26 F2 Labs 16740 Peters Road Middlefield, Ohio 44062 United States of America www.f2labs.com CERTIFICATION TEST REPORT Manufacturer: AFL Test and Inspection 16 Eastgate Park Road Belmont, New Hampshire 03220 USA Applicant: Same As Above Product Name: FlexScan Product Description: The FlexScan is an optical time domain reflectometer used on optical fiber networks. Model(s): FS200-304U* *Denotes actual model tested as representative of product family that includes models FS200-50/-60/-100/-300/-303/-304 and TS100-60/-70/-100. FCC ID: 2ANTH-FS2TS1 Testing Commenced: 2021-06-21 Testing Ended: 2022- 08-31 Summary of Test Results: In Compliance The EUT complies with the EMC requirements when manufactured identically as the unit tested in this report, including any required modifications and/or manufacturer’s statement. Any changes to the design or build of this unit subsequent to this testing may deem it non-compliant. Standards: • FCC Part 15 Subpart C, Section 15.247 • FCC15.207 - Conducted Limits • FCC Part 15.31(e) • ANSI C63.10:2013 Order Number: F2P25243C Applicant: AFL Test and Inspection Model: FS200-304U 051816 Report Number: F2P25243C-01E Page 2 of 69 Issue Date: 2022-09-26 Evaluation Conducted by: Julius Chiller, EMC/Wireless Engineer Report Reviewed by: Ken Littell, Vice President of EMC F2 Labs F2 Labs F2 Labs 26501 Ridge Road 16740 Peters Road 8583 Zionsville Road Damascus, MD 20872 Middlefield, OH 44062 Indianapolis, IN 46268 Ph 301.253.4500 Ph 440.632.5541 Ph 317.610.0611 This test report may be reproduced in full; partial reproduction only may be made with the written consent of F2 Labs. The results in this report apply only to the equipment tested. Order Number: F2P25243C Applicant: AFL Test and Inspection Model: FS200-304U 051816 Report Number: F2P25243C-01E Page 3 of 69 Issue Date: 2022-09-26 TABLE OF CONTENTS Section Title Page 1 ADMINISTRATIVE INFORMATION 4 2 SUMMARY OF TEST RESULTS/MODIFICATIONS 5 3 TABLE OF MEASURED RESULTS 6 4 ENGINEERING STATEMENT 7 5 EUT INFORMATION AND DATA 8 6 LIST OF MEASUREMENT INSTRUMENTATION 9 7 OCCUPIED BANDWIDTH 10 8 CONDUCTED OUTPUT POWER 14 9 VOLTAGE VARIATIONS 18 10 CONDUCTED SPURIOUS EMISSIONS 25 11 RADIATED SPURIOUS EMISSIONS 44 12 PEAK POWER SPECTRAL DENSITY (PSD) 57 13 CONDUCTED EMISSIONS 61 14 TEST SETUP PHOTOGRAPHS 66 Order Number: F2P25243C Applicant: AFL Test and Inspection Model: FS200-304U 051816 Report Number: F2P25243C-01E Page 4 of 69 Issue Date: 2022-09-26 1 ADMINISTRATIVE INFORMATION 1.1 Measurement Location: F2 Labs in Middlefield, Ohio. Site description and attenuation data are on file with the FCC's Sampling and Measurement Branch at the FCC Laboratory in Columbia, MD. 1.2 Measurement Procedure: All measurements were performed according to the 2013 version of ANSI C63.10 and recommended FCC procedure of measurement of DTS operating under Section 15.247 and in KDB558074. A list of the measurement equipment can be found in Section 6. 1.3 Uncertainty Budget: The uncertainty in EMC measurements arises from several factors which affect the results, some ass…
